ALM2403-Q1 Evaluation Module
User's Guide
SBOU236–February 2020
ALM2403-Q1 Evaluation Module
This user's guide contains information and support documentation for the ALM2403-Q1 evaluation module
(EVM). Included are the circuit description, jumper settings, required connections, printed circuit board
(PCB) layout, schematic, and bill of materials of the ALM2403Q1EVM. Throughout this document, the
terms evaluation board, evaluation module, and EVM are synonymous with the ALM2403Q1EVM.
