Texas Instruments BOOST-DAC8730-HART User manual

1
SLAU699–May 2017
Submit Documentation Feedback Copyright © 2017, Texas Instruments Incorporated
BOOST-DAC8730-HART Evaluation Module
User's Guide
SLAU699–May 2017
BOOST-DAC8730-HART Evaluation Module
This user's guide describes the characteristics, operation, and use of the BOOST-DAC8730-HART
evaluation board. This user’s guide also discusses the proper setup and configuration of both software
and hardware, and reviews various aspects of program operation. A complete circuit description,
schematic diagram, and bill of materials (BOM) are also included in this document.
spacer
Contents
1 Overview...................................................................................................................... 2
1.1 BOOST-DAC8730-HART Kit Contents .......................................................................... 2
1.2 Related Documentation From Texas Instruments.............................................................. 2
2 BOOST-DAC8730-HART Hardware Setup............................................................................... 3
2.1 Theory of Operation for BOOST-DAC8730-HART Hardware................................................. 3
2.2 MSP430FR5969 LaunchPad™ Connections ................................................................... 4
3 BOOST-DAC8730-HART Software Setup................................................................................ 5
3.1 Operating Systems for BOOST-DAC8730-HART Software................................................... 5
3.2 BOOST-DAC8730-HART Software Installation................................................................. 5
3.3 Installing Drivers and MSP430FR5969 LaunchPad™ Firmware............................................. 6
4 BOOST-DAC8730-HART Hardware Overview .......................................................................... 7
4.1 Electrostatic Discharge Warning.................................................................................. 7
4.2 Connecting the BOOST-DAC8730-HART....................................................................... 7
4.3 BOOST-DAC8730-HART Power Configurations ............................................................... 8
4.4 SPI Communication Signals and Digital Inputs/Outputs....................................................... 8
5 BOOST-DAC8730-HART Software Overview ........................................................................... 9
5.1 Starting the BOOST-DAC8730-HART Software................................................................ 9
5.2 BOOST-DAC8730-HART Software Features ................................................................... 9
6 BOOST-DAC8730-HART Documentation............................................................................... 13
6.1 BOOST-DAC8730-HART Board Schematic................................................................... 13
6.2 BOOST-DAC8730-HART PCB Components Layout ......................................................... 14
6.3 BOOST-DAC8730-HART Test Board Bill of Materials ....................................................... 15
List of Figures
1 BOOST-DAC8730-HART Hardware Setup............................................................................... 3
2 BOOST-DAC8730-HART Test Board Block Diagram .................................................................. 3
3 MSP430FR5969 LaunchPad™ Header .................................................................................. 4
4 BOOST-DAC8730-HART Installer Directory............................................................................. 5
5 BOOST-DAC8730-HART Install Path..................................................................................... 5
6 Install MSP430 Drivers Button............................................................................................. 6
7 Typical Hardware Connections on the BOOST-DAC8730-HART..................................................... 7
8 BOOST-DAC8730-HART GUI Location .................................................................................. 9
9 BOOST-DAC8730-HART GUI – Power On ............................................................................. 9
10 Low Level Configuration Page............................................................................................ 10
11 Low Level Configuration Page Available Options...................................................................... 10
12 High Level Configuration Page........................................................................................... 11
13 BOOST-DAC8730-HART Board Schematic............................................................................ 13

Overview www.ti.com
2SLAU699–May 2017
Submit Documentation Feedback
Copyright © 2017, Texas Instruments Incorporated
BOOST-DAC8730-HART Evaluation Module
14 BOOST-DAC8730-HART PCB Components Layout .................................................................. 14
List of Tables
1 Contents of BOOST-DAC8730-HART Kit ................................................................................ 2
2 Related Documentation..................................................................................................... 2
3 MSP430FR5969 LaunchPad™ Header .................................................................................. 4
4 Default Jumper Settings .................................................................................................... 7
5 BOOST-DAC8730-HART Power Supply Configuration................................................................. 8
6 Digital Block Signal Definition.............................................................................................. 8
7 UART Command Byte..................................................................................................... 12
8 BOOST-DAC8730-HART Test Board Bill of Materials ................................................................ 15
Trademarks
LaunchPad is a trademark of Texas Instruments.
Microsoft, Windows are registered trademarks of Microsoft Corporation.
All other trademarks are the property of their respective owners.
1 Overview
The DAC8730 integrates several components in creating a smart-loop-powered sensor transmitter with
included Highway Addressable Remote Transducer (HART), FOUNDATION Fieldbus (FF), and Profibus
PA (PA) modems. The key components of the device include a 16-bit PWM DAC, loop-control operation
amplifier, HART or FF/PA modem, internal reference and power tree.
1.1 BOOST-DAC8730-HART Kit Contents
Table 1 details the contents of the kit. Contact the TI Product Information Center or visit the Texas
Instruments E2E Community (http://E2E.ti.com) if any component is missing.
Table 1. Contents of BOOST-DAC8730-HART Kit
Item Quantity
BOOST-DAC8730-HART PCB evaluation board 1
1.2 Related Documentation From Texas Instruments
The following document provides information regarding Texas Instruments integrated circuits used in the
assembly of the BOOST-DAC8730-HART. This user's guide is available from the TI web site under
literature number SLAU699. Any letter appended to the literature number corresponds to the document
revision that is current at the time of the writing of this document. Newer revisions may be available from
the TI web site at http://www.ti.com/, or call the Texas Instruments Literature Response Center at (800)
477-8924 or the Product Information Center at [phone]. When ordering, identify the document by
both title and literature number.
Table 2. Related Documentation
Document Literature Number
BOOST-DAC8730-HART Product Data Sheet SLASEH8

DAC8730
Ext Power
External Passive/
Active
Conditioning
Block
MSP430 LaunchPadŒConnector
+
±
250 
J5
Terminal
Block
LOOP+
LOOP-
J1 Digital Header
MSP430FR5969
LP
Power
COM
Copyright © 2017, Texas Instruments Incorporated
BOOST-
DAC8730-HART
USB Bus
from
Computer
External Power
Source
LaunchPad
Connector
MSP430FR5969
LP
Personal
Computer
(PC)
Copyright © 2017, Texas Instruments Incorporated
www.ti.com BOOST-DAC8730-HART Hardware Setup
3
SLAU699–May 2017
Submit Documentation Feedback Copyright © 2017, Texas Instruments Incorporated
BOOST-DAC8730-HART Evaluation Module
2 BOOST-DAC8730-HART Hardware Setup
This section provides the overall system setup for the BOOST-DAC8730-HART Booster Pack. The
Booster Pack can be evaluated standalone – with any SPI- or UART-capable microcontroller – or with the
MSP430FR5969 LaunchPad™. The software provides installation steps to install the necessary
LaunchPad drivers, and MSP430FR5969 firmware. Additionally, the Graphical User Interface (GUI)
provides an interactive interface that syncs communication between the MSP430FR5969 LaunchPad and
DAC8730 device. The hardware (BOOST-DAC8730-HART and MSP430FR5969LP) is powered externally
via the loop connections of the BOOST-DAC8730-HART J2 terminal block. Figure 1 displays the system
setup for the BOOST-DAC8730-HART.
Figure 1. BOOST-DAC8730-HART Hardware Setup
2.1 Theory of Operation for BOOST-DAC8730-HART Hardware
A block diagram of the BOOST-DAC8730-HART board is displayed in Figure 2. The board provides an
external terminal block (J2) for the supplies, and a digital header connection (J1) that enables connection
to the DAC8730 digital pins. Once powered, the DAC8730 outputs a voltage that powers the
MSP430FR5969 LaunchPad. The BOOST-DAC8730-HART includes a diode bridge and protection circuit
that is tied to the J2 terminal block. This protection allows any polarity of power into the J2 terminal block.
Figure 2. BOOST-DAC8730-HART Test Board Block Diagram

BOOST-DAC8730-HART Hardware Setup www.ti.com
4SLAU699–May 2017
Submit Documentation Feedback
Copyright © 2017, Texas Instruments Incorporated
BOOST-DAC8730-HART Evaluation Module
2.2 MSP430FR5969 LaunchPad™ Connections
Before connecting the LaunchPad to the BOOST-DAC8730-HART board, the following MSP430FR5969
LaunchPad (J13) jumpers must be set to the configuration shown in Table 3.
WARNING
If the jumper connections are not configured as in Table 3, the
BOOST-DAC8730-HART and MSP430FR5969 will receive damage
from the USB supply connection.
Table 3. MSP430FR5969 LaunchPad™ Header
PIN on J13 Signal Shunt position
20 GND Connected
18 5 V Open
16 V+ Open
14 RTS Open
12 CTS Open
10 RXD Connected
8 TXD Connected
6 RST Connected
4 TST Connected
Figure 3. MSP430FR5969 LaunchPad™ Header

www.ti.com BOOST-DAC8730-HART Software Setup
5
SLAU699–May 2017
Submit Documentation Feedback Copyright © 2017, Texas Instruments Incorporated
BOOST-DAC8730-HART Evaluation Module
3 BOOST-DAC8730-HART Software Setup
This section provides the procedures for software installation.
3.1 Operating Systems for BOOST-DAC8730-HART Software
The software has been tested on the Microsoft®Windows®XP and Windows 7 operating systems with the
United States and European regional settings. The software should also be compatible with other
Windows operating systems.
3.2 BOOST-DAC8730-HART Software Installation
The software is available through the product folder on the TI website. Once the software is downloaded
onto the PC, navigate to the BOOST-DAC8730-HART folder, and run the Setup.exe file, as shown in
Figure 4. When the software is launched, an installation dialog will open, and prompt the user to select an
installation directory. If left unchanged, the software location defaults to C:\Program Files (x86)\Texas
Instruments\BOOST-DAC8730-HART, as shown in Figure 5.
Figure 4. BOOST-DAC8730-HART Installer Directory
Figure 5. BOOST-DAC8730-HART Install Path

BOOST-DAC8730-HART Software Setup www.ti.com
6SLAU699–May 2017
Submit Documentation Feedback
Copyright © 2017, Texas Instruments Incorporated
BOOST-DAC8730-HART Evaluation Module
3.3 Installing Drivers and MSP430FR5969 LaunchPad™ Firmware
Before connecting the BOOST-DAC8730-HART board to the MSP430FR5969 LaunchPad, the user must
ensure that the MSP430 device drivers are installed on the PC, and that the firmware is flashed on the
MSP430FR5969 LaunchPad.
Driver installation is accomplished by invoking the GUI before any hardware is connected to the PC. In
this step, ensure that no hardware is connected to the PC. To invoke the GUI, click the “BOOST-
DAC8730-HART” icon found in the programs or apps section of the start menu. The GUI will display a
splash screen and a pop-up displaying “No MSP LaunchPad Found”. Press the OK button, and the GUI
will start in DEMO mode. Navigate to the DAC8730 page by pressing the “DAC8730” tab under the Pages
field and press the Install MSP430 Drivers button, as shown in Figure 6.
Figure 6. Install MSP430 Drivers Button
Once pressed, a batch file will execute from the software and install the necessary files. Several prompts
may appear that query the user to accept software changes made by the application. Press the Continue
button to proceed with the installation. The next step is to connect the MSP430FR5969 LaunchPad to the
PC (without BOOST-DAC8730-HART) via the micro USB cable. Now press the Install MSP430 Firmware
button of the GUI to flash custom firmware to the MSP430FR5969 LaunchPad. The LEDs of the
LaunchPad will begin to flash, and a black window may appear during the firmware installation.
Additionally, the text field next to the Install MSP430 Firmware should read as “UPLOADING”. When
flashing is complete, the cmd prompt will exit, and the text field will update to display “COMPLETE”. The
MSP430FR5969 LaunchPad has now been successfully flashed.
Now close the GUI by pressing the exit Xbutton located on the top right of the GUI page, and disconnect
the LaunchPad USB cable from the PC.

www.ti.com BOOST-DAC8730-HART Hardware Overview
7
SLAU699–May 2017
Submit Documentation Feedback Copyright © 2017, Texas Instruments Incorporated
BOOST-DAC8730-HART Evaluation Module
4 BOOST-DAC8730-HART Hardware Overview
The subsequent sections provide detailed information on the hardware, and jumper configuration settings.
Table 4 displays the default configurations of all jumper connections on the BOOST-DAC8730-HART.
Table 4. Default Jumper Settings
Jumper Default Position Description
JP1 Shunt on 1-2 Configures the VCCIO output voltage 00 = 1.8 V, 01 = 2.5 V, 10 = 3.0
V, 11 = 3.15 V (Default setting: 3.15 V)
JP2 Shunt on 1-2
JP3 Shunt on 2-3 Connect to GND for operation with crystal, connect to VINL for
operation with resonator (Default setting: GND)
4.1 Electrostatic Discharge Warning
Many of the components on the BOOST-DAC8730-HART are susceptible to damage by electrostatic
discharge (ESD). Customers are advised to observe proper ESD handling precautions when unpacking
and handling the board, including the use of a grounded wrist strap at an approved ESD workstation.
4.2 Connecting the BOOST-DAC8730-HART
To connect the BOOST-DAC8730-HART to the MSP430FR5969 LaunchPad, align and firmly connect the
LaunchPad connectors to the BOOST-DAC8730-HART J3 and J4 female headers. The booster pack
connects to the pins on the outermost column of the MSP430FR5969 LaunchPad connectors, and care
must be taken to align J3 and J4 of the DAC8730 board to the MSP430FR5969 LaunchPad. The
alignment of the connection is shown in Figure 7, with green boxes surrounding the electrical points of
contact.
Figure 7. Typical Hardware Connections on the BOOST-DAC8730-HART

BOOST-DAC8730-HART Hardware Overview www.ti.com
8SLAU699–May 2017
Submit Documentation Feedback
Copyright © 2017, Texas Instruments Incorporated
BOOST-DAC8730-HART Evaluation Module
4.3 BOOST-DAC8730-HART Power Configurations
The BOOST-DAC8730-HART provides a terminal block (J2) to connect to the external loop-supply. A
typical two-wire connection has a sense resistor tied to either the negative or positive node of the external
supply. A minimum loop resistance value of 250 ohms is commonly required for HART communication.
The minimum voltage for DAC8730 device operation and other parameter requirements are listed in the
DAC8730 data sheet (SLASEH8). For correct loop operation, please be aware that the loop-supply
voltage must exceed the sum of both the minimum voltage requirement of the DAC8730 device, and the
IR drop across the sense resistor.
Table 5. BOOST-DAC8730-HART Power Supply Configuration
Connector Connection Type Description
J2 Terminal block External loop-supply connection
A loop-supply voltage of 24 V is the nominal supply voltage for most 4- to 20-mA two-wire transmitters.
4.4 SPI Communication Signals and Digital Inputs/Outputs
The SPI signals are located on the J2 header and are described in Table 6, along with the digital input
signals of the BOOST-DAC8730-HART device.
Table 6. Digital Block Signal Definition
Name Connector Description
GND J2-1 Local GND
DS1 J2-2 Power transformer driver (driven from the REG_IN pins)
DS2 J2-3
VCCIO J2-4 External supply output
CLKOUT J2-5 Clock output
RESET J2-6 Hardware reset
CS J2-7 SPI chip select
MOSI J2-8 SPI data input
MISO J2-9 SPI data output
SCLK J2-10 SPI clock input
RX J2-11 UART RX input
TX J2-12 UART TX output
IRQ J2-13 Interrupt request output (active low)
GND J2-14 Local GND
VSHUNT J2-15 Internal DC/DC voltage FB_SUPPLY
VINL J2-16 Synchronous DAC load control input

www.ti.com BOOST-DAC8730-HART Software Overview
9
SLAU699–May 2017
Submit Documentation Feedback Copyright © 2017, Texas Instruments Incorporated
BOOST-DAC8730-HART Evaluation Module
5 BOOST-DAC8730-HART Software Overview
This section discusses how to use the BOOST-DAC8730-HART software.
5.1 Starting the BOOST-DAC8730-HART Software
Once the hardware connections are established and jumper settings configured, power on the BOOST-
DAC8730-HART with the loop-supply voltage. Next, launch the software located in the Texas Instruments
folder of the Start All Programs menu, and select the BOOST-DAC8730-HART icon.
Figure 8. BOOST-DAC8730-HART GUI Location
If the LaunchPad is properly connected to the BOOST-DAC8730-HART, the GUI should automatically
display "HARDWARE CONNECTED" on the lower left of the GUI, as seen in Figure 9.
Figure 9. BOOST-DAC8730-HART GUI – Power On
If the LaunchPad has a faulty connection, or is not connected at all, the GUI will launch in DEMO mode. If
this text appears while the LaunchPad device is connected, then power off the loop-supply voltage, unplug
the LaunchPad, and close the GUI. Reconnect the LaunchPad and ensure that the connectors are
correctly aligned. After this, verify the USB extender cable is properly connected to both the LaunchPad
and PC. Reapply the loop-supply voltage and re-launch the GUI. This issue can also occur if the MSP430
driver is installed incorrectly, and so the BOOST-DAC8730-HART software may need to be reinstalled.
5.2 BOOST-DAC8730-HART Software Features
The following subsections describe the functionality of each page of the BOOST-DAC8730-HART GUI.
5.2.1 BOOST-DAC8730-HART Low Level Configuration Page
The BOOST-DAC8730-HART features a Register Map page that allows access to low-level
communication by directly writing to and reading from the registers of the BOOST-DAC8730-HART.
Selecting a register on the Register Map list will present a description of the values in that register, and
also display register information such as the address, default value, size, and current value. The register
values can be modified by either writing directly to the value column or selecting the bit individually. This is
shown in Figure 10.

BOOST-DAC8730-HART Software Overview www.ti.com
10 SLAU699–May 2017
Submit Documentation Feedback
Copyright © 2017, Texas Instruments Incorporated
BOOST-DAC8730-HART Evaluation Module
Figure 10. Low Level Configuration Page
The values of the register map can also be saved by pressing the Save Configuration button under the
File menu option. Additionally, the configuration files can be accessed through the Load Configuration
button.
Other options selectable by the user are the Update Mode,Write Selected (red box), Read Selected
(orange box), Write Modified (gray box) and Read All (yellow box) icons. All icons are displayed in
Figure 11.
Figure 11. Low Level Configuration Page Available Options
If Update Mode is selected to “Immediate”, all changes to register values will update immediately, while
“Deferred” allows the user to modify the value of a register without taking effect until the Write Selected, or
Write Modified icon is pressed.
The Read Selected icon allows individual register reads, while the Read All icon reads the status of all
registers located in the register map.

www.ti.com BOOST-DAC8730-HART Software Overview
11
SLAU699–May 2017
Submit Documentation Feedback Copyright © 2017, Texas Instruments Incorporated
BOOST-DAC8730-HART Evaluation Module
5.2.2 BOOST-DAC8730-HART High Level Configuration Page
The High Level Configuration page provides an interface to observe and control the different data
registers, modes, and configurations available for the BOOST-DAC8730-HART device. This page is
displayed in Figure 12.
Figure 12. High Level Configuration Page
The main page primarily has 3 functions – the PWM Exerciser, the HART Exerciser (transmit and read),
and the Device Status button.
The 16-bit PWM DAC can be exercised by writing to the MSL and LSB fields and pressing the OK button
for Set PWM – the appropriate code range is 0x1000 - 0xEFFF.
The HART interface is controlled via UART, which is controlled in the firmware of the MSP430FR5969
device. To create a transmit packet type the data, in hexadecimal format, to the HART DATA array and
press the OK button located under Start HART Transmission. The resulting HART waveform can be
captured by monitoring the differential voltage across the loop-supply pins or the shunt resistor. To clear
this array, press the OK button located under Clear HART DATA Buffer.
NOTE: The DAC8730 device creates a local ground from the loop-supply voltage. In the case that a
desktop machine is used, the USB connection will share an earth ground connection with the
local ground that is generated from the DAC8730 device. Therefore, to avoid any potential
shorting between earth ground and probed nets, the user will require a differential probe
when inspecting the HART waveform.

BOOST-DAC8730-HART Software Overview www.ti.com
12 SLAU699–May 2017
Submit Documentation Feedback
Copyright © 2017, Texas Instruments Incorporated
BOOST-DAC8730-HART Evaluation Module
The DAC8730 device notifies the microcontroller of a valid HART transaction, and will send this
information to the microcontroller, which in turn will store to a buffer. Pressing the OK button located under
READ HART reads the byte information from the buffer. This information is displayed in the Status String
indicator field in hexadecimal format.
Pressing the OK button located under Device Status will read the Status Nibble of the DAC8730 device,
which will notify of any errors or flags. This information is displayed in the Status String indicator field in
hexadecimal format and is detailed in Table 7.
Table 7. UART Command Byte
Code Nibble Status Nibble
DB7 DB6 DB5 DB4 DB3 DB2 DB1 DB0
See the following table ILOOP_LOW VSHUNT_LOW Don’t Care HL_PWM
Command Code Nibble Reply 2nd Byte Description
RESET 0000 PWM A 25-ms timeout has occurred and an updated DAC data is
required. After 10 consecutive RESET commands, a
resynchronization occurs.
IDLE 0010 PWM TX-HART
(optional) Request for DAC data, no transmitted or received HART data is required for the bus
START_RX 0100 - - A carrier has been detected, and there is activity on the
HART bus
RX 0101 PWM RX-HART Correct HART data has been received and will be transmitted
in the next byte
RX_PE 1101 PWM RX-HART A parity error has been detected in the HART data. The
received byte will still be transmitted in the next byte.
RX_FE 1110 PWM RX-HART A framing error has been detected in the HART data. The
received byte will still be transmitted in the next byte.
END_RX 0110 PWM - The received HART packet is complete and the bus is no
longer occupied
START_TX 1000 PWM TX-HART
(optional) HART transmission started and HART data is ready to be transmitted
TX 1001 PWM TX-HART
(optional) HART data is still available and the HART packet is still transmitting
END_TX 1010 PWM - No more HART data is available and the packet is terminated
EXCEPTION 1111 - - Internal state machine error

AGND
1.10k
R18
AGND
AGND
DNI
R13
AGND
BUS+
BUS-
BUS+
AGND
AGND
AGND
AGND
AGND
AGND
1
3 4
2
G
G
8 MHz
Y1
406I35D08M00000 AGND
AGND
TO/FROM Application
BUS +
BUS -
Receiver Filter
AGND
2.2µFC5
20.0k
R6
0
R8
4.02R16
8.25k
R15
0.22µF
C21
0.22µF
C22
DNI
R10
DNI
D1
J2
AGND
External CLK
AGND
1000pF
C3
0.1µF
C4
1000pF
C6
2200pF
C10
DNI
C12
220pF
C18
390pF
C16
470pF
C25 470pF
C24
33pF
C27
0.047µFC23
0.022µF
C26
1000pF
C29
1000pF
C30
150pF
C28
0.022µF
C32
332k
R27
DNI
C2
VCCIO
RESET
CLKOUT
IRQ
DS1
DS2
RESETCLKOUT
VCCIODS2
DS1
VinL
Q4
Q1
DNI
Q3
DNI
V_DIG 100k
R7
100k
R11
DNI
R1
0
R2
DAC8730_MOSI
DAC8730_CS
DAC8730_TX
DAC8730_RX
DAC8730_SCLK
DAC8730_SCLK
DAC8730_MISO
DAC8730_MISO
DAC8730_CS DAC8730_MOSI
DAC8730_RX DAC8730_TX
IRQ
V_DIG
TP3
TP5
TP1
AGND
TP2
TP4
~
3
+1
~4
-
2
D4
600 ohm
FB1
600 ohm
FB2
0.01µF
C31 BUS+
BUS-
TP6
VCCIO
0.47µF
C8
2.2µF
C1
2.2µF
C11
100k
R12
402k
R14
10µF
C13
10µF
C14
5.1k
R17
30k
R19
10.0
0.1%
R20
33.0k
0.1%
R21
33.0k
0.1%
R22
100k
0.1%
R23
100k
0.1%
R24
200k
R25
49.9k
R26
33k
R28
33k
R29
37.4k
R30
AGND
2.2µF
C15
VinL
AGND
0.1µF
C19
0.01µF
C20
100uH
L1
1
3
2
D2
BAT54A-7-F
DNI
R5
0
R3
0
R4
SCLK 29
OUT_OPA
1
SLEW2 56
UART_TX 27
CAP3
10
NC 13
BF_INP1
46
BF_OUT2
49
CAP5
52
SLEW1 55
GND 4
CAP1
7
VEE
16
VSHUNT_CFG
19
DCDC_FB 22
GND 25
CS 32
VCCIO 35
XTAL2 38
VCCIO_CFG1 41
CAP2
9
GND 12
REG_IN 45
BF_INN2
48
VPP
51
MOD_IN
54
+IN_OPA
3
VREF_OUT
6
MODE_SEL
15
VSHUNT
18
DCDC_SW 21
CAP4
24
SDI 31
CLK_OUT 34
VDIG
37
RES_EN 40
NC 8
GND 11
DRIVER1 44
BF_OUT1
47
BF_CMP_IN
50
MOD_OUT
53
-IN_OPA
2
PWM_OUT
5
NC 14
STARTUP
17
DCDC_IN
20
GND 23
SDO 30
RESET 33
REG_IN 36
XTAL1 39
GND 57
UART_RX 28
IRQ 26
VCCIO_CFG2 42
DRIVER2 43
U1
DAC8730RSHR
Q2
2
1
3
JP1
2
1
3
JP2
2
1
3
JP3
100pF
C17
36V
D3
CDSOD323-T36SC
DNI
R9
18pFC7
18pFC9
VinL
1 2
3 4
5 6
7 8
9 10
11 12
13 14
15 16
J1
TSM-108-01-L-DV
VSHUNT
VSHUNT
AGND
Copyright © 2017, Texas Instruments Incorporated
www.ti.com BOOST-DAC8730-HART Documentation
13
SLAU699–May 2017
Submit Documentation Feedback Copyright © 2017, Texas Instruments Incorporated
BOOST-DAC8730-HART Evaluation Module
6 BOOST-DAC8730-HART Documentation
This section contains the complete bill of materials and schematic diagram for the BOOST-DAC8730-HART. Documentation information for the
SDM-USB-DIG platform is found in the SDM-USB-DIG Platform User’s Guide (SBOU136), available from the TI web site at http://www.ti.com.
6.1 BOOST-DAC8730-HART Board Schematic
Figure 13 illustrates the BOOST-DAC8730-HART schematic.
Figure 13. BOOST-DAC8730-HART Board Schematic

BOOST-DAC8730-HART Documentation www.ti.com
14 SLAU699–May 2017
Submit Documentation Feedback
Copyright © 2017, Texas Instruments Incorporated
BOOST-DAC8730-HART Evaluation Module
6.2 BOOST-DAC8730-HART PCB Components Layout
Figure 14 shows the layout of the components for the BOOST-DAC8730-HART board.
Figure 14. BOOST-DAC8730-HART PCB Components Layout

www.ti.com BOOST-DAC8730-HART Documentation
15
SLAU699–May 2017
Submit Documentation Feedback Copyright © 2017, Texas Instruments Incorporated
BOOST-DAC8730-HART Evaluation Module
6.3 BOOST-DAC8730-HART Test Board Bill of Materials
Table 8 lists the BOOST-DAC8730-HART test board BOM.
Table 8. BOOST-DAC8730-HART Test Board Bill of Materials
Item # Designator Qty Value Part Number Manufacturer Description Package
Reference
1 !PCB1 1 PA022 Any Printed Circuit Board
2 C1, C11 2 2.2uF GRM188Z71C225KE43 Murata CAP, CERM, 2.2 µF, 16 V, ±10%, X7R, 0603 0603
3 C2, D1, Q1, Q3,
R1, R5, R10,
R31
8 DNI DNI DNI DNI, Diode, Zener, 6.8 V, 500 mW, SOD-123, Transistor, NPN, 65
V, 0.1 A, SOT-23, Transistor, PNP, 60 V, 0.8 A, SOT-23, RES, 0,
5%, 0.063 W, 0402, DNI, RES, 1.10 k, 1%, 0.1 W, 0603, RES, 0,
5%, 0.063 W, 0402
DNI
4 C3, C6, C29,
C30 4 1000pF GRM1555C1H102JA01D Murata CAP, CERM, 1000 pF, 50 V, ±5%, C0G/NP0, 0402 0402
5 C4, C19 2 0.1uF GCM155R71H104KE02D Murata CAP, CERM, 0.1 µF, 50 V, ±10%, X7R, AEC-Q200 Grade 1, 0402 0402
6 C5, C15 2 2.2uF C0805C225K4RACTU Kemet CAP, CERM, 2.2 µF, 16 V, ±10%, X7R, 0805 0805
7 C7, C9 2 18pF GRM1555C1H180JA01D Murata CAP, CERM, 18 pF, 50 V, ±5%, C0G/NP0, 0402 0402
8 C8 1 0.47uF GRM188R71E474KA12D Murata CAP, CERM, 0.47 µF, 25 V, ±10%, X7R, 0603 0603
9 C10 1 2200pF GRM155R71H222KA01D Murata CAP, CERM, 2200 pF, 50 V, ±10%, X7R, 0402 0402
10 C12 1 1000pF DNI DNI DNI 0402
11 C13, C14 2 10uF GRM21BZ71E106KE15L Murata CAP, CERM, 10 µF, 25 V, ±10%, X7R, 0805 0805
12 C16 1 390pF GRM1555C1H391JA01D Murata CAP, CERM, 390 pF, 50 V, ±5%, C0G/NP0, 0402 0402
13 C17 1 100pF GRM1555C1H101JA01D Murata CAP, CERM, 100 pF, 50 V, ±5%, C0G/NP0, 0402 0402
14 C18 1 220pF GRM1555C1H221JA01D Murata CAP, CERM, 220 pF, 50 V, ±5%, C0G/NP0, 0402 0402
15 C20 1 0.01uF GCM155R71H103KA55D Murata CAP, CERM, 0.01 µF, 50 V, ±10%, C0G/NP0, 0402 0402
16 C21, C22 2 0.22uF 885012206048 Wurth Elektronik CAP, CERM, 0.22 µF, 16 V, ±10%, X7R, 0603 0603
17 C23 1 0.047uF C1005X7R1H473K050BB TDK CAP, CERM, 0.047 µF, 50 V, ±10%, X7R, 0402 0402
18 C24, C25 2 470pF GRM1555C1H471JA01D Murata CAP, CERM, 470 pF, 50 V, ±5%, C0G/NP0, 0402 0402
19 C26, C32 2 0.022uF GCM155R71H223KA55D Murata CAP, CERM, 0.022 µF, 50 V, ±10%, C0G/NP0, 0402 0402
20 C27 1 33pF GRM1555C1H330JA01D Murata CAP, CERM, 33 pF, 50 V, ±5%, C0G/NP0, 0402 0402
21 C28 1 150pF GRM1555C1H151JA01D Murata CAP, CERM, 150 pF, 50 V, ±5%, C0G/NP0, 0402 0402
22 C31 1 0.01uF C0603C103K5RACTU Kemet CAP, CERM, 0.01 µF, 50 V, ±10%, X7R, 0603 0603
23 C33 1 1uF GCM188R71E105KA64D Murata CAP, CERM, 1 µF, 25 V, ±10%, X7R, AEC-Q200 Grade 1, 0603 0603
24 D2 1 30V BAT54A-7-F Diodes Inc. Diode, Schottky, 30 V, 0.2 A, SOT-23 SOT-23
25 D3 1 36V CDSOD323-T36SC Bourns Diode, TVS, Bi, 36 V, SOD323, 2-Leads, Body 1.9x1.45mm, No
Polarity Mark SOD323, 2-Leads, Body 1.9x1.45mm,
No Polarity Mark
26 D4 1 1000V DSRHD10-13 Diodes Inc. Diode, Switching-Bridge, 1000V, 1A, 5.0x1.21x6.2mm 5.0x1.21x6.2mm
27 FB1, FB2 2 600 ohm FBMH3225HM601NT Taiyo Yuden Ferrite Bead, 600 ohm @ 100 MHz, 3 A, 1210 1210
28 FID1, FID2, FID3 3 N/A N/A Fiducial mark. There is nothing to buy or mount. Fiducial

BOOST-DAC8730-HART Documentation www.ti.com
16 SLAU699–May 2017
Submit Documentation Feedback
Copyright © 2017, Texas Instruments Incorporated
BOOST-DAC8730-HART Evaluation Module
Table 8. BOOST-DAC8730-HART Test Board Bill of Materials (continued)
Item # Designator Qty Value Part Number Manufacturer Description Package
Reference
29 J1 1 TSM-108-01-L-DV Samtec Header, 2.54mm, 8x2, Gold, SMT Header, 2.54mm,
8x2, SMT
30 J2 1 ED555/2DS On-Shore Technology Terminal Block, 6A, 3.5mm Pitch, 2-Pos, TH 7.0x8.2x6.5mm
31 J3, J4 2 SSW-110-22-F-D-VS-K Samtec Connector, Receptacle, 100mil, 10x2, Gold plated, SMD 10x2 Receptacle
32 JP1, JP2, JP3 3 TMM-103-01-G-S-SM Samtec Header, 2mm, 3x1, Gold, SMT Header, 2mm, 3x1,
SMT
33 L1 1 1mH 74476630 Wurth Elektronik Inductor, Wirewound, 1 mH, 0.03 A, 50 ohm, SMD 1812
34 Q2 1 60 V MMBT2907A Fairchild Semiconductor Transistor, PNP, 60 V, 0.8 A, SOT-23 SOT-23
35 Q4 1 65 V BC846BLT1G ON Semiconductor Transistor, NPN, 65 V, 0.1 A, SOT-23 SOT-23
36 R2, R3, R4, R32 4 0 RC0402JR-070RL Yageo America RES, 0, 5%, 0.063 W, 0402 0402
37 R6 1 20.0k RC0603FR-0720KL Yageo America RES, 20.0 k, 1%, 0.1 W, 0603 0603
38 R7, R11 2 100k RC0603FR-07100KL Yageo America RES, 100 k, 1%, 0.1 W, 0603 0603
39 R8 1 0 RC0603JR-070RL Yageo America RES, 0, 5%, 0.1 W, 0603 0603
40 R9, R13 2 DNI DNI DNI RES, 5.62 k, 1%, 0.1 W, 0603, RES, 1.10 k, 1%, 0.1 W, 0603 0603
41 R12 1 100k CRCW0603100KFKEA Vishay-Dale RES, 100 k, 1%, 0.1 W, 0603 0603
42 R14 1 402k CRCW0603402KFKEA Vishay-Dale RES, 402 k, 1%, 0.1 W, 0603 0603
43 R15 1 8.25k CRCW06038K25FKEA Vishay-Dale RES, 8.25 k, 1%, 0.1 W, 0603 0603
44 R16 1 4.02 CRCW06034R02FKEA Vishay-Dale RES, 4.02, 1%, 0.1 W, 0603 0603
45 R17 1 5.1k CRCW06035K10JNEA Vishay-Dale RES, 5.1 k, 5%, 0.1 W, 0603 0603
46 R18 1 1.10k CRCW06031K10FKEA Vishay-Dale RES, 1.10 k, 1%, 0.1 W, 0603 0603
47 R19 1 30k CRCW060330K0JNEA Vishay-Dale RES, 30 k, 5%, 0.1 W, 0603 0603
48 R20 1 10.0 RT0603BRD0710RL Yageo America RES, 10.0, 0.1%, 0.1 W, 0603 0603
49 R21, R22 2 33.0k RG1608P-333-B-T5 Susumu Co Ltd RES, 33.0 k, 0.1%, 0.1 W, 0603 0603
50 R23, R24 2 100k RT0603BRD07100KL Yageo America RES, 100 k, 0.1%, 0.1 W, 0603 0603
51 R25 1 200k CRCW0402200KFKED Vishay-Dale RES, 200 k, 1%, 0.063 W, 0402 0402
52 R26 1 49.9k CRCW040249K9FKED Vishay-Dale RES, 49.9 k, 1%, 0.063 W, 0402 0402
53 R27 1 332k CRCW0402332KFKED Vishay-Dale RES, 332 k, 1%, 0.063 W, 0402 0402
54 R28, R29 2 33k CRCW040233K0JNED Vishay-Dale RES, 33 k, 5%, 0.063 W, 0402 0402
55 R30 1 37.4k CRCW040237K4FKED Vishay-Dale RES, 37.4 k, 1%, 0.063 W, 0402 0402
56 SH-J1, SH-J2,
SH-J3 3 1x2 2SN-BK-G Samtec Shunt, 2mm, Gold plated, Black 2mm Shunt, Closed Top
57 TP1, TP2, TP3,
TP4, TP5, TP6 6 5019 Keystone Test Point, Miniature, SMT Test Point, Miniature, SMT
58 U1 1 DAC8730RSHR Texas Instruments Loop Powered DAC with HART / FOUNDATION Fieldbus / Profibus
PA Modems, RSH0056A (VQFN-56) RSH0056A
59 Y1 1 406I35D08M00000 CTS Electrocomponents Crystal, 8 MHz, 18 pF, SMD SMD, 4-Leads,
Body 6.2x3.7mm

STANDARD TERMS FOR EVALUATION MODULES
1. Delivery: TI delivers TI evaluation boards, kits, or modules, including any accompanying demonstration software, components, and/or
documentation which may be provided together or separately (collectively, an “EVM” or “EVMs”) to the User (“User”) in accordance
with the terms set forth herein. User's acceptance of the EVM is expressly subject to the following terms.
1.1 EVMs are intended solely for product or software developers for use in a research and development setting to facilitate feasibility
evaluation, experimentation, or scientific analysis of TI semiconductors products. EVMs have no direct function and are not
finished products. EVMs shall not be directly or indirectly assembled as a part or subassembly in any finished product. For
clarification, any software or software tools provided with the EVM (“Software”) shall not be subject to the terms and conditions
set forth herein but rather shall be subject to the applicable terms that accompany such Software
1.2 EVMs are not intended for consumer or household use. EVMs may not be sold, sublicensed, leased, rented, loaned, assigned,
or otherwise distributed for commercial purposes by Users, in whole or in part, or used in any finished product or production
system.
2Limited Warranty and Related Remedies/Disclaimers:
2.1 These terms do not apply to Software. The warranty, if any, for Software is covered in the applicable Software License
Agreement.
2.2 TI warrants that the TI EVM will conform to TI's published specifications for ninety (90) days after the date TI delivers such EVM
to User. Notwithstanding the foregoing, TI shall not be liable for a nonconforming EVM if (a) the nonconformity was caused by
neglect, misuse or mistreatment by an entity other than TI, including improper installation or testing, or for any EVMs that have
been altered or modified in any way by an entity other than TI, (b) the nonconformity resulted from User's design, specifications
or instructions for such EVMs or improper system design, or (c) User has not paid on time. Testing and other quality control
techniques are used to the extent TI deems necessary. TI does not test all parameters of each EVM.
User's claims against TI under this Section 2 are void if User fails to notify TI of any apparent defects in the EVMs within ten (10)
business days after delivery, or of any hidden defects with ten (10) business days after the defect has been detected.
2.3 TI's sole liability shall be at its option to repair or replace EVMs that fail to conform to the warranty set forth above, or credit
User's account for such EVM. TI's liability under this warranty shall be limited to EVMs that are returned during the warranty
period to the address designated by TI and that are determined by TI not to conform to such warranty. If TI elects to repair or
replace such EVM, TI shall have a reasonable time to repair such EVM or provide replacements. Repaired EVMs shall be
warranted for the remainder of the original warranty period. Replaced EVMs shall be warranted for a new full ninety (90) day
warranty period.
3Regulatory Notices:
3.1 United States
3.1.1 Notice applicable to EVMs not FCC-Approved:
FCC NOTICE: This kit is designed to allow product developers to evaluate electronic components, circuitry, or software
associated with the kit to determine whether to incorporate such items in a finished product and software developers to write
software applications for use with the end product. This kit is not a finished product and when assembled may not be resold or
otherwise marketed unless all required FCC equipment authorizations are first obtained. Operation is subject to the condition
that this product not cause harmful interference to licensed radio stations and that this product accept harmful interference.
Unless the assembled kit is designed to operate under part 15, part 18 or part 95 of this chapter, the operator of the kit must
operate under the authority of an FCC license holder or must secure an experimental authorization under part 5 of this chapter.
3.1.2 For EVMs annotated as FCC – FEDERAL COMMUNICATIONS COMMISSION Part 15 Compliant:
CAUTION
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to
operate the equipment.
FCC Interference Statement for Class A EVM devices
NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to
correct the interference at his own expense.

FCC Interference Statement for Class B EVM devices
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more
of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
3.2 Canada
3.2.1 For EVMs issued with an Industry Canada Certificate of Conformance to RSS-210 or RSS-247
Concerning EVMs Including Radio Transmitters:
This device complies with Industry Canada license-exempt RSSs. Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2) this device must accept any interference, including interference that may
cause undesired operation of the device.
Concernant les EVMs avec appareils radio:
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation
est autorisée aux deux conditions suivantes: (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit
accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.
Concerning EVMs Including Detachable Antennas:
Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser)
gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the antenna type
and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for
successful communication. This radio transmitter has been approved by Industry Canada to operate with the antenna types
listed in the user guide with the maximum permissible gain and required antenna impedance for each antenna type indicated.
Antenna types not included in this list, having a gain greater than the maximum gain indicated for that type, are strictly prohibited
for use with this device.
Concernant les EVMs avec antennes détachables
Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peut fonctionner avec une antenne d'un type et
d'un gain maximal (ou inférieur) approuvé pour l'émetteur par Industrie Canada. Dans le but de réduire les risques de brouillage
radioélectrique à l'intention des autres utilisateurs, il faut choisir le type d'antenne et son gain de sorte que la puissance isotrope
rayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité nécessaire à l'établissement d'une communication satisfaisante. Le
présent émetteur radio a été approuvé par Industrie Canada pour fonctionner avec les types d'antenne énumérés dans le
manuel d’usage et ayant un gain admissible maximal et l'impédance requise pour chaque type d'antenne. Les types d'antenne
non inclus dans cette liste, ou dont le gain est supérieur au gain maximal indiqué, sont strictement interdits pour l'exploitation de
l'émetteur
3.3 Japan
3.3.1 Notice for EVMs delivered in Japan: Please see http://www.tij.co.jp/lsds/ti_ja/general/eStore/notice_01.page 日本国内に
輸入される評価用キット、ボードについては、次のところをご覧ください。
http://www.tij.co.jp/lsds/ti_ja/general/eStore/notice_01.page
3.3.2 Notice for Users of EVMs Considered “Radio Frequency Products” in Japan: EVMs entering Japan may not be certified
by TI as conforming to Technical Regulations of Radio Law of Japan.
If User uses EVMs in Japan, not certified to Technical Regulations of Radio Law of Japan, User is required to follow the
instructions set forth by Radio Law of Japan, which includes, but is not limited to, the instructions below with respect to EVMs
(which for the avoidance of doubt are stated strictly for convenience and should be verified by User):
1. Use EVMs in a shielded room or any other test facility as defined in the notification #173 issued by Ministry of Internal
Affairs and Communications on March 28, 2006, based on Sub-section 1.1 of Article 6 of the Ministry’s Rule for
Enforcement of Radio Law of Japan,
2. Use EVMs only after User obtains the license of Test Radio Station as provided in Radio Law of Japan with respect to
EVMs, or
3. Use of EVMs only after User obtains the Technical Regulations Conformity Certification as provided in Radio Law of Japan
with respect to EVMs. Also, do not transfer EVMs, unless User gives the same notice above to the transferee. Please note
that if User does not follow the instructions above, User will be subject to penalties of Radio Law of Japan.

【無線電波を送信する製品の開発キットをお使いになる際の注意事項】 開発キットの中には技術基準適合証明を受けて
いないものがあります。 技術適合証明を受けていないもののご使用に際しては、電波法遵守のため、以下のいずれかの
措置を取っていただく必要がありますのでご注意ください。
1. 電波法施行規則第6条第1項第1号に基づく平成18年3月28日総務省告示第173号で定められた電波暗室等の試験設備でご使用
いただく。
2. 実験局の免許を取得後ご使用いただく。
3. 技術基準適合証明を取得後ご使用いただく。
なお、本製品は、上記の「ご使用にあたっての注意」を譲渡先、移転先に通知しない限り、譲渡、移転できないものとします。
上記を遵守頂けない場合は、電波法の罰則が適用される可能性があることをご留意ください。 日本テキサス・イ
ンスツルメンツ株式会社
東京都新宿区西新宿６丁目２４番１号
西新宿三井ビル
3.3.3 Notice for EVMs for Power Line Communication: Please see http://www.tij.co.jp/lsds/ti_ja/general/eStore/notice_02.page
電力線搬送波通信についての開発キットをお使いになる際の注意事項については、次のところをご覧ください。http:/
/www.tij.co.jp/lsds/ti_ja/general/eStore/notice_02.page
3.4 European Union
3.4.1 For EVMs subject to EU Directive 2014/30/EU (Electromagnetic Compatibility Directive):
This is a class A product intended for use in environments other than domestic environments that are connected to a
low-voltage power-supply network that supplies buildings used for domestic purposes. In a domestic environment this
product may cause radio interference in which case the user may be required to take adequate measures.
4EVM Use Restrictions and Warnings:
4.1 EVMS ARE NOT FOR USE IN FUNCTIONAL SAFETY AND/OR SAFETY CRITICAL EVALUATIONS, INCLUDING BUT NOT
LIMITED TO EVALUATIONS OF LIFE SUPPORT APPLICATIONS.
4.2 User must read and apply the user guide and other available documentation provided by TI regarding the EVM prior to handling
or using the EVM, including without limitation any warning or restriction notices. The notices contain important safety information
related to, for example, temperatures and voltages.
4.3 Safety-Related Warnings and Restrictions:
4.3.1 User shall operate the EVM within TI’s recommended specifications and environmental considerations stated in the user
guide, other available documentation provided by TI, and any other applicable requirements and employ reasonable and
customary safeguards. Exceeding the specified performance ratings and specifications (including but not limited to input
and output voltage, current, power, and environmental ranges) for the EVM may cause personal injury or death, or
property damage. If there are questions concerning performance ratings and specifications, User should contact a TI
field representative prior to connecting interface electronics including input power and intended loads. Any loads applied
outside of the specified output range may also result in unintended and/or inaccurate operation and/or possible
permanent damage to the EVM and/or interface electronics. Please consult the EVM user guide prior to connecting any
load to the EVM output. If there is uncertainty as to the load specification, please contact a TI field representative.
During normal operation, even with the inputs and outputs kept within the specified allowable ranges, some circuit
components may have elevated case temperatures. These components include but are not limited to linear regulators,
switching transistors, pass transistors, current sense resistors, and heat sinks, which can be identified using the
information in the associated documentation. When working with the EVM, please be aware that the EVM may become
very warm.
4.3.2 EVMs are intended solely for use by technically qualified, professional electronics experts who are familiar with the
dangers and application risks associated with handling electrical mechanical components, systems, and subsystems.
User assumes all responsibility and liability for proper and safe handling and use of the EVM by User or its employees,
affiliates, contractors or designees. User assumes all responsibility and liability to ensure that any interfaces (electronic
and/or mechanical) between the EVM and any human body are designed with suitable isolation and means to safely
limit accessible leakage currents to minimize the risk of electrical shock hazard. User assumes all responsibility and
liability for any improper or unsafe handling or use of the EVM by User or its employees, affiliates, contractors or
designees.
4.4 User assumes all responsibility and liability to determine whether the EVM is subject to any applicable international, federal,
state, or local laws and regulations related to User’s handling and use of the EVM and, if applicable, User assumes all
responsibility and liability for compliance in all respects with such laws and regulations. User assumes all responsibility and
liability for proper disposal and recycling of the EVM consistent with all applicable international, federal, state, and local
requirements.
5. Accuracy of Information: To the extent TI provides information on the availability and function of EVMs, TI attempts to be as accurate
as possible. However, TI does not warrant the accuracy of EVM descriptions, EVM availability or other information on its websites as
accurate, complete, reliable, current, or error-free.

6. Disclaimers:
6.1 EXCEPT AS SET FORTH ABOVE, EVMS AND ANY MATERIALS PROVIDED WITH THE EVM (INCLUDING, BUT NOT
LIMITED TO, REFERENCE DESIGNS AND THE DESIGN OF THE EVM ITSELF) ARE PROVIDED "AS IS" AND "WITH ALL
FAULTS." TI DISCLAIMS ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, REGARDING SUCH ITEMS, INCLUDING BUT
NOT LIMITED TO ANY EPIDEMIC FAILURE WARRANTY OR IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE OR NON-INFRINGEMENT OF ANY THIRD PARTY PATENTS, COPYRIGHTS, TRADE
SECRETS OR OTHER INTELLECTUAL PROPERTY RIGHTS.
6.2 EXCEPT FOR THE LIMITED RIGHT TO USE THE EVM SET FORTH HEREIN, NOTHING IN THESE TERMS SHALL BE
CONSTRUED AS GRANTING OR CONFERRING ANY RIGHTS BY LICENSE, PATENT, OR ANY OTHER INDUSTRIAL OR
INTELLECTUAL PROPERTY RIGHT OF TI, ITS SUPPLIERS/LICENSORS OR ANY OTHER THIRD PARTY, TO USE THE
EVM IN ANY FINISHED END-USER OR READY-TO-USE FINAL PRODUCT, OR FOR ANY INVENTION, DISCOVERY OR
IMPROVEMENT, REGARDLESS OF WHEN MADE, CONCEIVED OR ACQUIRED.
7. USER'S INDEMNITY OBLIGATIONS AND REPRESENTATIONS. USER WILL DEFEND, INDEMNIFY AND HOLD TI, ITS
LICENSORS AND THEIR REPRESENTATIVES HARMLESS FROM AND AGAINST ANY AND ALL CLAIMS, DAMAGES, LOSSES,
EXPENSES, COSTS AND LIABILITIES (COLLECTIVELY, "CLAIMS") ARISING OUT OF OR IN CONNECTION WITH ANY
HANDLING OR USE OF THE EVM THAT IS NOT IN ACCORDANCE WITH THESE TERMS. THIS OBLIGATION SHALL APPLY
WHETHER CLAIMS ARISE UNDER STATUTE, REGULATION, OR THE LAW OF TORT, CONTRACT OR ANY OTHER LEGAL
THEORY, AND EVEN IF THE EVM FAILS TO PERFORM AS DESCRIBED OR EXPECTED.
8. Limitations on Damages and Liability:
8.1 General Limitations. IN NO EVENT SHALL TI BE LIABLE FOR ANY SPECIAL, COLLATERAL, INDIRECT, PUNITIVE,
INCIDENTAL, CONSEQUENTIAL, OR EXEMPLARY DAMAGES IN CONNECTION WITH OR ARISING OUT OF THESE
TERMS OR THE USE OF THE EVMS , REGARDLESS OF WHETHER TI HAS BEEN ADVISED OF THE POSSIBILITY OF
SUCH DAMAGES. EXCLUDED DAMAGES INCLUDE, BUT ARE NOT LIMITED TO, COST OF REMOVAL OR
REINSTALLATION, ANCILLARY COSTS TO THE PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES, RETESTING,
OUTSIDE COMPUTER TIME, LABOR COSTS, LOSS OF GOODWILL, LOSS OF PROFITS, LOSS OF SAVINGS, LOSS OF
USE, LOSS OF DATA, OR BUSINESS INTERRUPTION. NO CLAIM, SUIT OR ACTION SHALL BE BROUGHT AGAINST TI
MORE THAN TWELVE (12) MONTHS AFTER THE EVENT THAT GAVE RISE TO THE CAUSE OF ACTION HAS
OCCURRED.
8.2 Specific Limitations. IN NO EVENT SHALL TI'S AGGREGATE LIABILITY FROM ANY USE OF AN EVM PROVIDED
HEREUNDER, INCLUDING FROM ANY WARRANTY, INDEMITY OR OTHER OBLIGATION ARISING OUT OF OR IN
CONNECTION WITH THESE TERMS, , EXCEED THE TOTAL AMOUNT PAID TO TI BY USER FOR THE PARTICULAR
EVM(S) AT ISSUE DURING THE PRIOR TWELVE (12) MONTHS WITH RESPECT TO WHICH LOSSES OR DAMAGES ARE
CLAIMED. THE EXISTENCE OF MORE THAN ONE CLAIM SHALL NOT ENLARGE OR EXTEND THIS LIMIT.
9. Return Policy. Except as otherwise provided, TI does not offer any refunds, returns, or exchanges. Furthermore, no return of EVM(s)
will be accepted if the package has been opened and no return of the EVM(s) will be accepted if they are damaged or otherwise not in
a resalable condition. If User feels it has been incorrectly charged for the EVM(s) it ordered or that delivery violates the applicable
order, User should contact TI. All refunds will be made in full within thirty (30) working days from the return of the components(s),
excluding any postage or packaging costs.
10. Governing Law: These terms and conditions shall be governed by and interpreted in accordance with the laws of the State of Texas,
without reference to conflict-of-laws principles. User agrees that non-exclusive jurisdiction for any dispute arising out of or relating to
these terms and conditions lies within courts located in the State of Texas and consents to venue in Dallas County, Texas.
Notwithstanding the foregoing, any judgment may be enforced in any United States or foreign court, and TI may seek injunctive relief
in any United States or foreign court.
Mailing Address: Texas Instruments, Post Office Box 655303, Dallas, Texas 75265
Copyright © 2017, Texas Instruments Incorporated
