Introduction www.ti.com
1 Introduction
The Texas Instruments LM74610-SQ Evaluation Module helps designers evaluate the operation and
performance of the LM74610-Q1 Reverse Polarity Protection Smart Diode Controller. This evaluation
module demonstrates how an N-Channel power MOSFET can emulate a very low forward voltage diode
with zero Iq and low leakage current flowing through the IC. In this design scheme the LM74610-Q1 is
combined with a MOSFET and used in series with battery as a replacement for schottky diode and PFET
in reverse polarity protection circuitry as shown in Figure 1 . For more information on the LM74610
functional and electrical characteristics, see the LM74610-Q1 Reverse Polarity Protection Smart Diode
Controller Data Sheet (LM74610).
Table 1. Device and Package Configurations
CONVERTER IC PACKAGE
U1 LM74610-Q1 VSSOP-8
2 Setup
This section describes the jumpers and connectors on the EVM as well and how to properly connect, set
up and use the LM74610-SQEVM. Ensure the power supply is turned off while making connections on the
board.
2.1 Input/Output Connector Description
•VBAT_1: Power input connector to the positive rail of the input power supply.
•GND: Battery ground connector.
•VOUT: is the power output connector to the positive side of the load.
•TEST POINTS: are also available at VBAT_1,GND,VOUT,DRV_1 (MOSFET Gate Voltage), and
VCAP_1 (Charge pump capacitor).
Figure 1. LM74610-Q1 Typical Application Circuit
4List of Tables SNVU489–October 2015
Submit Documentation Feedback
Copyright © 2015, Texas Instruments Incorporated

www.ti.com Setup
2.2 Board Setup
Before applying power to the LM74610EVM, all external connections should be verified. External power
supplies should be turned off and connected with proper polarity to the VBAT_1 and GND connectors. An
electronic or resistive load must be connected at the output.. The LM74610-Q1 will not initiate the
charge pump operation if a closed loop system is in standby mode or the drain current is smaller than
1mA (typical). The tests outlined in this document 3A constant current as the load and 12V at the input
(VBAT_1). Make sure that the external power supply source for the input voltage is capable of providing
enough current to the output load so that the output voltage can be obtained.
Once all connections to the LM74610-SQEVM are verified, power can be applied to VBAT_1. The EVM
will then begin to operate.
Figure 2. LM74610-SQ EVM
5
SNVU489–October 2015 List of Tables
Submit Documentation Feedback Copyright © 2015, Texas Instruments Incorporated

Time (100 µs/DIV)
VOUT (10 V/DIV, 12 V to 0 V)
VIN (10 V/DIV, 12 V to -20 V)
Gate Drive (10 V/DIV)
Operation www.ti.com
3 Operation
3.1 Reverse Polarity Protection
A dynamic voltage pulse from +12V to -20V is applied at the VBAT_1 input of the LM74610-SQEVM.
Figure 3 shows when the input voltage (yellow) drops down to -20V, the output voltage (blue) does not go
negative, and therefore, the load is protected from dynamic reverse pulses at the input. The LM74610-Q1
reacts the negative voltage surge within 2μsec and shuts down the MOSFET by pulling the gate voltage to
zero (green). The output slowly decays due to the large output capacitors and increased time constant.
Figure 3. Response to Reverse Polarity 12V to -20V
6List of Tables SNVU489–October 2015
Submit Documentation Feedback
Copyright © 2015, Texas Instruments Incorporated

www.ti.com Operation
A -12V source is connected to the VBAT_1 input of the LM74610-SQEVM. Figure 4 shows that the Output
voltage will stay at a constant 0V in this situation. This test simulates the event of connecting a 12V
battery in the reverse direction, and therefore, protects the load from negative voltages.
Figure 4. Response to Start Up Reverse Polarity
Note: Please note that the leakage current is 60uA (typ). This means that if you apply a voltage on the
output you will see some voltage on input and this voltage will collapse if you draw more current than the
leakage current. The same applies for a reverse voltage applied on the input.
7
SNVU489–October 2015 List of Tables
Submit Documentation Feedback Copyright © 2015, Texas Instruments Incorporated

Operation www.ti.com
3.2 Output Voltage
When power is initially applied, the load current (ID) will flow through the body diode of the MOSFET. This
current will produce a forward voltage drop (Vf) across the MOSFET body diode. This voltage is used to
charge up the charge pump capacitor Vcap. This periodic voltage drop will be equal to the MOSFET body
diode forward voltage drop and occurs for about 25.6msec as shown in Figure 5.
Figure 5. Periodic body diode voltage drop at the output
During the rest of the period of conduction, the LM74610-Q1 will drive the gate of the MOSFET. When the
MOSFET is ON, it provides a low resistive path for the drain current to flow and minimizes the power
dissipation associated with forward conduction. The power losses during the MOSFET ON state depend
primarily on the RDSON of the selected MOSFET and load current. The LM74610-Q1 operation keeps the
MOSFET ON at approximately 98% as shown in Figure 6, leading to very little overall power dissipation
when compared to a typical diode.
8List of Tables SNVU489–October 2015
Submit Documentation Feedback
Copyright © 2015, Texas Instruments Incorporated

www.ti.com Operation
Figure 6. The LM74610-SQEVM Output voltage waveform
9
SNVU489–October 2015 List of Tables
Submit Documentation Feedback Copyright © 2015, Texas Instruments Incorporated

Board Layout www.ti.com
4 Board Layout
Figure 7. Top Assembly Layer
10 List of Tables SNVU489–October 2015
Submit Documentation Feedback
Copyright © 2015, Texas Instruments Incorporated
