Texas Instruments TPS7A14EVM User manual

User's Guide
TPS7A14EVM Evaluation Module
ABSTRACT
Figure 1-1. TPS7A14EVM-058 Evaluation Module
Figure 1-2. TPS7A14EVM-095 Evaluation Module
www.ti.com
SBVU073A – NOVEMBER 2021 – REVISED JUNE 2023
Submit Document Feedback
TPS7A14EVM Evaluation Module 1
Copyright © 2023 Texas Instruments Incorporated

Table of Contents
1 Introduction.............................................................................................................................................................................3
2 Setup........................................................................................................................................................................................3
2.1 LDO Input/Output Connector Descriptions.........................................................................................................................3
2.2 Optional Load Transient Input/Output Connector Descriptions..........................................................................................3
2.3 TPS7A14 LDO Operation...................................................................................................................................................4
2.4 Optional Load Transient Circuit Operation......................................................................................................................... 6
3 Board Layout...........................................................................................................................................................................8
4 TPS7A14EVM Schematic......................................................................................................................................................11
5 Bill of Materials..................................................................................................................................................................... 13
6 Revision History................................................................................................................................................................... 17
List of Figures
Figure 1-1. TPS7A14EVM-058 Evaluation Module..................................................................................................................... 1
Figure 1-2. TPS7A14EVM-095 Evaluation Module..................................................................................................................... 1
Figure 2-1. TPS7A14EVM-058 Turn On...................................................................................................................................... 4
Figure 2-2. TPS7A14EVM-058 With Current Probes Attached................................................................................................... 5
Figure 2-3. TPS7A14EVM-058 Load Transient Results: 1-mA to 950-mA Load Step.................................................................7
Figure 2-4. TPS7A14EVM-058 Load Transient Results: 950-mA to 1-mA Load Step.................................................................7
Figure 3-1. TPS7A14EVM-058 Top Assembly Layer and Silk Screen........................................................................................ 8
Figure 3-2. TPS7A14EVM-058 Top Layer Routing......................................................................................................................8
Figure 3-3. TPS7A14EVM-058 Layer 2....................................................................................................................................... 8
Figure 3-4. TPS7A14EVM-058 Layer 3....................................................................................................................................... 8
Figure 3-5. TPS7A14EVM-058 Bottom Layer Routing................................................................................................................ 9
Figure 3-6. TPS7A14EVM-058 Bottom Assembly Layer and Silk Screen...................................................................................9
Figure 3-7. TPS7A14EVM-095 Top Assembly Layer and Silk Screen........................................................................................ 9
Figure 3-8. TPS7A14EVM-095 Top Layer Routing......................................................................................................................9
Figure 3-9. TPS7A14EVM-095 Layer 2..................................................................................................................................... 10
Figure 3-10. TPS7A14EVM-095 Layer 3................................................................................................................................... 10
Figure 3-11. TPS7A14EVM-095 Bottom Layer Routing.............................................................................................................10
Figure 3-12. TPS7A14EVM-095 Bottom Assembly Layer and Silk Screen...............................................................................10
Figure 4-1. TPS7A14EVM-058 Schematic.................................................................................................................................11
Figure 4-2. TPS7A14EVM-095 Schematic................................................................................................................................ 12
Trademarks
LeCroy™ is a trademark of Teledyne LeCroy.
Kapton® is a registered trademark of DuPont.
All trademarks are the property of their respective owners.
Table of Contents www.ti.com
2TPS7A14EVM Evaluation Module SBVU073A – NOVEMBER 2021 – REVISED JUNE 2023
Submit Document Feedback
Copyright © 2023 Texas Instruments Incorporated

1 Introduction
The Texas Instruments TPS7A14EVM-058 and TPS7A14EVM-095 evaluation module (EVM) helps designers
evaluate the operation and performance of the TPS7A14 LDO voltage regulator. As shown in Table 1-1,
the TPS7A14EVM-058 contains one TPS7A14 LDO voltage regulator in the DSBGA package and the
TPS7A14EVM-095 contains one TPS7A14 LDO voltage regulator in WSON package . An optional load transient
circuit is also included to assist the user with high-speed load transient testing. An input current loop is included
that allows fast measurements of the input current.
Table 1-1. Device Information
EVM ORDERABLE NUMBER VOUT PART NAME PACKAGE
TPS7A14EVM-058 0.8 V TPS7A1408PYBKR 6-pin DSBGA
TPS7A14EVM-095 1.8 V TPS7A1418PDRVR 6-pin WSON
2 Setup
This section describes the jumpers and connectors on the EVM, and how to properly connect, set up, and
use the TPS7A14EVM-058 and TPS7A14EVM-096. Section 2.1 and Section 2.3 describe the test setup and
operation for the TPS7A14 LDO. Section 2.2 and Section 2.4 describe the test setup and operation of the
optional load transient circuit.
2.1 LDO Input/Output Connector Descriptions
2.1.1 VIN and GND
VIN and GND are the connection terminals for the input supply. The VIN terminal is the positive connection, and
the GND terminal is the negative (that is, ground) connection.
2.1.2 BIAS and GND
BIAS and GND are the connection terminals for the bias supply. The BIAS terminal is the positive connection,
and the GND terminal is the negative (that is, ground) connection.
2.1.3 VOUT and GND
VOUT and GND are the connection terminals for the output load. The VOUT terminal is the positive connection,
and the GND terminal is the negative (that is, ground) connection.
2.1.4 EN
EN is a 3-pin header used to enable or disable the TPS7A14.
The center pin of the 3-pin header is tied to the TPS7A14 EN input. When the 2-pin shunt is placed across the
top two pins of the header, VIN is shorted to EN, and the TPS7A14 is enabled. When the 2-pin shunt is placed
across the bottom two pins of the header, GND is shorted to EN, and the TPS7A14 is disabled.
When driving the EN terminal with an off-board supply or signal generator, the applied voltage must be kept
between 0 V and 5.5 V.
2.2 Optional Load Transient Input/Output Connector Descriptions
2.2.1 VDD and GND
VDD and GND are the connection terminals for the input supply of the load transient circuit. The VDD terminal is
the positive connection, and the GND terminal is the negative (that is, ground) connection.
2.2.2 J13
J13 is an optional connection for the user to make measurements or apply loads to the output of the LDO.
2.2.3 J15
J15 is an optional connection to insert a damping circuit across the load transient MOSFET drain to source
voltage.
www.ti.com Introduction
SBVU073A – NOVEMBER 2021 – REVISED JUNE 2023
Submit Document Feedback
TPS7A14EVM Evaluation Module 3
Copyright © 2023 Texas Instruments Incorporated

2.2.4 J16
J16 is an optional connection to insert capacitance or additional load across the drain to source of the load
transient MOSFET.
2.2.5 J18
J18 is the connection for the function generator to drive the gate driver device. J18 is terminated by the 50-Ω
resistor, R13.
2.2.6 J19
J19 is a high-frequency kelvin connection that allows accurate measurements of the load transient MOSFET
drain to source voltage.
2.2.7 J22
J22 is a high-frequency kelvin connection that allows accurate measurements of the load transient MOSFET
gate to source voltage.
2.2.8 TP2, TP3, and TP4
TP2, TP3, and TP4 allow the user to measure the gate drive resistances R8 and R9 when power is turned off to
the EVM.
2.2.9 TP5
TP5 is the enable pin to enable the gate driver device. Tie this pin to GND to enable the gate driver.
2.3 TPS7A14 LDO Operation
The TPS7A14EVM-058 and TPS7A14EVM-095 evaluation module contains the TPS7A14 LDO with input,
bias, and output capacitors installed. These four components provide the minimum required solution size, as
illustrated by the white boxes in Figure 1-1 and Figure 1-2. Additional pads are available to test the LDO with
additional input, bias, and output capacitors beyond what is already installed on the EVM. The TPS7A14 LDO
can be enabled or disabled by using the J7 3-pin header.
1. Place a 2-pin shunt across the header to tie VIN to EN to enable the device.
2. Place a 2-pin shunt across the header to tie GND to EN to disable the device.
Alternatively, by connecting an external function generator to TP1 (EN) and a nearby GND post (J11), the
user can enable or disable the TPS7A14 LDO after VIN is applied. Figure 2-1 shows the result of the
TPS7A14EVM-058 during turn on. The blue trace is the enable voltage, and the red trace is the output voltage.
Figure 2-1. TPS7A14EVM-058 Turn On
Setup www.ti.com
4TPS7A14EVM Evaluation Module SBVU073A – NOVEMBER 2021 – REVISED JUNE 2023
Submit Document Feedback
Copyright © 2023 Texas Instruments Incorporated

If desired, a current probe can be inserted in the EVM as shown in Figure 2-2 to measure the input and output
current. The slots were sized to fit most current probes, such as the LeCroy™ AP015 or CP031 current probes.
Figure 2-2. TPS7A14EVM-058 With Current Probes Attached
The user has two options for providing a DC load on the output of the TPS7A14. J10 can be used to place a
DC load that flows through the current sense path on the output of the LDO. Alternatively, the J4 (VOUT) and
J12 (GND) banana connectors can be used for external measurements and loading; however, the IOUT loop
does not sense current flowing through these connectors. In cases where very fast transient tests are performed,
ringing can be observed on VIN or VOUT as a result of the parasitic inductance within the PCB of the EVM. A
strip of wire placed on the exposed copper in the current path can reduce this ringing. Select the correct size of
additional wire to fill the volume of the current probe. For most current probes, a 10 AWG wire can be used.
WARNING
The sensors of some current probes are tied to GND and cannot come into contact with energized
conductors. See the user manual of your current probe for details. If your current probe has this
limitation, use a thin strip of electrical or Kapton® tape to isolate the current sense path from the
current probe.
Optional kelvin sense points are provided using the SMA connectors J1 (VIN) and J2 (VOUT).
www.ti.com Setup
SBVU073A – NOVEMBER 2021 – REVISED JUNE 2023
Submit Document Feedback
TPS7A14EVM Evaluation Module 5
Copyright © 2023 Texas Instruments Incorporated

2.4 Optional Load Transient Circuit Operation
The TPS7A14EVM-058 and TPS7A14EVM-095 evaluation modules contains an optional high-performance load
transient circuit to allow efficient testing of the TPS7A14 LDO load transient performance. To use the optional
load transient circuit, install the correct components in accordance with the application. Modify the input and
output capacitance connected to the TPS7A14 LDO to match the expected operating conditions. Determine the
desired peak current to test, and modify the parallel resistor combination of R2, R3, R4, R5, and R6 as shown:
OUT
Peak
2 3 4 5 6
V
I
R R R R R
(1)
The slew rate of the load step can be adjusted by C11, R7, R8, and R9. In this section, only R8 and R9 is
adjusted to set the slew rate. For a 0-mA to 1-A to 0-mA load step, use Table 2-1 to select a value of R8 and R9
that results in the desired rise or fall time.
Table 2-1. Suggested Ramp Rate Resistor Values
R8 R9 Rise/Fall Time
97.6 kΩ 86.6 kΩ 10 µs
52.3 kΩ 40.2 kΩ 5 µs
31.6 kΩ 20.5 kΩ 2.5 µs
12.4 kΩ 8.06 kΩ 1 µs
6.19 kΩ 4.02 kΩ 500 ns
3.74 kΩ 2.43 kΩ 300 ns
2.49 Ω 1.62 Ω 200 ns
806 Ω 806 Ω 100 ns
After the EVM is modified (if needed), connect a power supply to banana connectors J17 (VDD) and J21 (GND)
with a 5-V DC supply and a 1-A DC current limit. As illustrated in Figure 2-3 and Figure 2-4, the TPS7A14
transient response is very fast and the output voltage recovers in well under 1 ms after the initial load transient.
Therefore, use a load transient pulse duration limit of 1 ms to prevent excessive heating of the pulsed resistors
(R2, R3, R4, R5, and R6). Configure a function generator for the 50-Ω output, in a 0-V DC to 5-V DC square
pulse. If necessary, burst mode can be configured in the function generator for repetitive, low duty cycle, load
transient testing.
A 10.7-kΩ resistor is installed on the EVM at R8, and a 10-kΩ resistor is installed on the EVM at R9. These
resistors provide approximately 1 A/μs slew rate from 0 mA to 1 A. Figure 2-3 and Figure 2-4 provide example
test data with R8 = 10.7 kΩ and R9 = 10 kΩ. The red trace is the output voltage and the blue trace is the output
current. J10 provides 1 mA of DC load current and R2, R3, R4, R5, and R6 provide 949 mA of pulsed load. The
resulting test data shows a 1-mA to 950-mA load step on VOUT of the LDO, with only a 2.2-μF capacitor on the
output of the LDO.
Setup www.ti.com
6TPS7A14EVM Evaluation Module SBVU073A – NOVEMBER 2021 – REVISED JUNE 2023
Submit Document Feedback
Copyright © 2023 Texas Instruments Incorporated

Figure 2-3. TPS7A14EVM-058 Load Transient
Results: 1-mA to 950-mA Load Step
Figure 2-4. TPS7A14EVM-058 Load Transient
Results: 950-mA to 1-mA Load Step
www.ti.com Setup
SBVU073A – NOVEMBER 2021 – REVISED JUNE 2023
Submit Document Feedback
TPS7A14EVM Evaluation Module 7
Copyright © 2023 Texas Instruments Incorporated

3 Board Layout
Figure 3-1 through Figure 3-6 illustrate the board layout for the TPS7A14EVM-058 PCB.
Figure 3-7 through Figure 3-12 illustrate the board layout for the TPS7A14EVM-095 PCB
The TPS7A14EVM-058 and TPS7A14EVM-095 dissipate power, which can cause some components to
experience an increase in temperature. The TPS7A14 LDO, LMG1020YFFR gate driver, and pulsed resistors
R2, R3, R4, R5, and R6 are most at risk of raising to a high junction temperature during normal operation.
Figure 3-1. TPS7A14EVM-058 Top Assembly Layer
and Silk Screen
Figure 3-2. TPS7A14EVM-058 Top Layer Routing
Figure 3-3. TPS7A14EVM-058 Layer 2 Figure 3-4. TPS7A14EVM-058 Layer 3
Board Layout www.ti.com
8TPS7A14EVM Evaluation Module SBVU073A – NOVEMBER 2021 – REVISED JUNE 2023
Submit Document Feedback
Copyright © 2023 Texas Instruments Incorporated

Figure 3-5. TPS7A14EVM-058 Bottom Layer
Routing
Figure 3-6. TPS7A14EVM-058 Bottom Assembly
Layer and Silk Screen
Figure 3-7. TPS7A14EVM-095 Top Assembly Layer
and Silk Screen
Figure 3-8. TPS7A14EVM-095 Top Layer Routing
www.ti.com Board Layout
SBVU073A – NOVEMBER 2021 – REVISED JUNE 2023
Submit Document Feedback
TPS7A14EVM Evaluation Module 9
Copyright © 2023 Texas Instruments Incorporated

Figure 3-9. TPS7A14EVM-095 Layer 2 Figure 3-10. TPS7A14EVM-095 Layer 3
Figure 3-11. TPS7A14EVM-095 Bottom Layer
Routing
Figure 3-12. TPS7A14EVM-095 Bottom Assembly
Layer and Silk Screen
Board Layout www.ti.com
10 TPS7A14EVM Evaluation Module SBVU073A – NOVEMBER 2021 – REVISED JUNE 2023
Submit Document Feedback
Copyright © 2023 Texas Instruments Incorporated
