Texas Instruments PGA281EVM User manual

User's Guide
dit.SBOU130–May 2013
PGA281EVM
This user's guide describes the characteristics, operation, and use of the evaluation module (EVM) for the
PGA281. This document also includes the schematic, printed circuit board (PCB) layout, and a bill of
materials (BOM). Throughout this document the terms evaluation board,evaluation module, and EVM are
synonymous with the PGA281EVM.
Contents
1 Introduction .................................................................................................................. 2
2 PGA281EVM Hardware .................................................................................................... 3
3 Bill of Materials ............................................................................................................. 12
4 Related Documentation from Texas Instruments ..................................................................... 13
List of Figures
1 PGA281EVM ................................................................................................................ 2
2 PGA281EVM Schematic................................................................................................... 3
3 PGA281EVM Default Jumper Settings................................................................................... 4
4 Top Layer (Signal and Ground)........................................................................................... 8
5 Layer 2 (Power) ............................................................................................................. 9
6 Layer 3 (Power)............................................................................................................ 10
7 Bottom Layer (Power and Ground) ..................................................................................... 11
1
dit.SBOU130–May 2013 PGA281EVM
Submit Documentation Feedback Copyright © 2013, Texas Instruments Incorporated

Introduction www.ti.com
1 Introduction
1.1 PGA281
The PGA281 is a high-precision instrumentation amplifier with pin-programmable gain, attenuation, and
error detection. The PGA281 offers low offset voltage, near zero drift, and very low 1/f noise for high-
resolution, precision measurement. The high supply voltage and excellent common-mode rejection comply
with the requirements for universal industrial signal front-ends.
1.2 PGA281EVM
The PGA281EVM provides basic functional evaluation of the PGA281, along with the following features:
• Onboard power management circuitry generates all required power-supply rails from one split-supply
input
• DIP switch allows easy setting of pin-programmable gain
• Error flag LED provides visual feedback of any detected error condition
• Easy access to pertinent nodes with test points, BNC connectors, and banana jacks
• Component footprints allow multiple filtering configurations
A picture of the PGA281EVM is shown in Figure 1.
Figure 1. PGA281EVM
2PGA281EVM dit.SBOU130–May 2013
Submit Documentation Feedback
Copyright © 2013, Texas Instruments Incorporated

J5
J9
GND
J6
J7
VSN
VSP
VSON
VSOP_EXT
1.3k
R12
1.3k
R16
100p
C7
C9
10p
C5
10p
GND
GND
GND
GND
TP2
TP5
VDD VSN
VSP
VSON
VSOP
VOCM
TP10 TP11 TP13TP12
GNDGNDGND
TP6 TP7 TP9
0
R11
0
R15
DNP
C6
C8
DNP
C4
DNP
GND
GND
TP1
TP4
1
2 3 4
J1
1
2 3 4
J3
1
2 3 4
J2
1
2 3 4
J4
GND
GND
TP15
VDD
VSOP
VSOP
VSOP_EXT
VSOP_INT
VSP
GND
10k
R21
GND
C14
10u
VSOP_INT
C12
10n
GND
33.2k
R20
GND
GND
/EF
221
R17
TP3
Test Points
VSOP Source Jumper VDD Source Jumper
EF Status LED
LDOExternal Power Connections
Input Connections Output ConnectionsPGA281
VSOP
VOCM
100k
R3
100k
R4
GND
VOCM Divider
GND
C10
10n
VSN
GND
C1
10n
GND
VSP
C2
10n
VSOP
GND
GND
G4
G3
G2
G1
G0
C11
10n
VOCM
GND
C13
10u
C15
10u
C16
10u
/EF
J8
C17
10u
VDD_EXT
GND
VDD_EXT
C3
10n
INN1
15
INP1
14
VOP 9
VON 8
G4
3
G3
4
G2
5
G1
6
G0
7
VSOP 11
VSP 13
VDD 1
VSN
16
VSON
12
VOCM
10
EF 2
U1
PGA281
VDD
22
R18
22
R23
22
R19
22
R22
External VSOP
1
2
3
JMP1
1
2
3
JMP2
LDO VSOP
VDD = VSOP
External VDD
Gain Select
1
2
D2
1
2
D1
100k
R2
100k
R6
100k
R8
100k
R10
100k
R14
1
2
3
4
5
10
9
8
7
6
S1
G4
G3
G2
G1
G0
1
2
D3
VDD
1k
R1
1k
R5
1k
R7
1k
R9
1k
R13
GND
OPEN - G = 0
CLOSED - G = 1
0000
0001
0010
0011
0100
0101
0110
0111
1000
1001
1010
1011*
1100*
1101*
1110*
1111*
0.125 0.172
0.25
0.5
1
2
4
8
16
32
64
128
0.125
0.125
0.125
0.125
0.344
0.688
1.375
2.75
5.5
11
22
44
88
176
0.172
0.172
0.172
0.172
G3:G0 G4=0 G4=1
* Reserved
Gain Table
LTST-C190CKT
LED1
0.125 0.172
J10
13
D4
1
2
D5
N
N
TP14
OUT
1
FB
2
NC
3
GND
4EN 5
NC 6
NC 7
IN 8
U2
TPS7A4101
www.ti.com PGA281EVM Hardware
2 PGA281EVM Hardware
This section discusses the PGA281EVM hardware schematics and PCB layout.
2.1 Schematic
The schematic of the PGA281EVM is shown in Figure 2.
Figure 2. PGA281EVM Schematic
3
dit.SBOU130–May 2013 PGA281EVM
Submit Documentation Feedback Copyright © 2013, Texas Instruments Incorporated

PGA281EVM Hardware www.ti.com
2.2 Jumper Settings
The PGA281EVM jumper settings are given in Table 1. The default settings are shown in Figure 3.
Figure 3. PGA281EVM Default Jumper Settings
Table 1. PGA281EVM Jumper Settings
Jumper Position Function
VSOP provided by onboard low dropout (LDO)
INT (default) regulator
JMP1 EXT VSOP provided externally at J6
VSOP (default) VDD connected to VSOP
JMP2 EXT VDD provided externally at J8
4PGA281EVM dit.SBOU130–May 2013
Submit Documentation Feedback
Copyright © 2013, Texas Instruments Incorporated

www.ti.com PGA281EVM Hardware
2.3 Power Supply Connections
Power is applied through banana connectors J5, J6, J7, J8, J9, and J10. The PGA281 requires three
supply voltages: the high-voltage analog input stage supply, the low-voltage analog output stage supply,
and the digital supply.
2.3.1 Analog Input Stage Power (VSP, VSN)
Power for the analog input stage is applied at J5 (VSP), J10 (GND), and J9 (VSN). The specified range for
these supplies is given in Table 2.
Table 2. Analog Input Stage Power
Name Minimum Maximum Description
VSP +5 V +18 V Positive supply for analog input stage
Ground reference voltage for analog
GND 0 V 0 V input stage
Negative supply voltage for analog input
VSN –5 V –18 V stage
2.3.2 Analog Output Stage Power (VSOP, VSON)
Power for the analog output stage is applied at J6 (VSOP) and J7 (VSON). The specified range for these
supplies is given in Table 3. On the PGA281EVM, VSON is always connected to GND.
Table 3. Analog Output Stage Power
NAME MINIMUM Maximum Description
VSOP +2.7 V +5.5 V Positive supply for analog output stage
Negative voltage/ground reference for
VSON 0 V 0 V analog output stage
2.3.3 Digital Logic Power (VDD)
Power for the digital core is applied at J8 (VDD). The specified range for VDD is the same as VSOP (+2.7
V to +5.5 V). VSON is used as the digital core ground reference.
2.3.4 Onboard LDO Regulator
The PGA281EVM contains an onboard LDO regulator (U2) that is used to generate VSOP and VDD from
VSP. This configuration greatly simplifies the power connections to the PGA281EVM, because then only
VSP, VSN, and GND must be provided. The LDO regulator output voltage can be adjusted by replacing
resistor R20. When using the LDO regulator in this manner, set jumpers JMP1 and JMP2 to INT and
VSOP, respectively.
Table 4. LDO Adjustable Output Voltages
R20 Resistance Output Voltage
33.2 kΩ5 V
18.2 kΩ3.3 V
5
dit.SBOU130–May 2013 PGA281EVM
Submit Documentation Feedback Copyright © 2013, Texas Instruments Incorporated

PGA281EVM Hardware www.ti.com
2.4 Input/Output Connections
The PGA281 is a differential input, differential output amplifier. The input signal is applied at BNC
connectors J1 (IN+) and J3 (IN–), while the output signal is measured at BNC connectors J2 (OUT+) and
J4 (OUT–).
2.5 VOCM
VOCM controls the output stage common-mode voltage. On the PGA281EVM, a resistive voltage divider
created by R3 and R4 sets VOCM equal to (VSOP/2).
2.6 Gain Select
Switch S1 controls the PGA281 gain. Each switch channel sets the logic level at the corresponding gain
set pin. When the switch channel is on (up position), GN= 1. When the switch channel is off (down
position), GN= 0. See Table 5 for all possible gain settings.
Table 5. PGA281 Gain Settings
G3:G0 G4 = 0 G4 = 1
0000 0.125 0.172
0001 0.25 0.344
0010 0.5 0.688
0011 1 1.375
0100 2 2.75
0101 4 5.5
0110 8 11
0111 16 22
1000 32 44
1001 64 88
1010 128 176
1011* 0.125 0.172
1100* 0.125 0.172
1101* 0.125 0.172
1110* 0.125 0.172
1111* 0.125 0.172
2.7 Error Flag
The PGA281 contains circuitry that monitors the integrity of the analog signal at several of the internal
nodes. When signal conditions are outside the linear range, the error flag pin goes active (sets to VDD). In
an error condition, LED1 on the PGA281EVM turns on.
Error conditions include:
• Input common-mode range exceeded
• Input clamp active
• Input stage at supply rail
• Input-stage current limit exceeded
• Output stage at supply rail
• Output-stage current limit exceeded
6PGA281EVM dit.SBOU130–May 2013
Submit Documentation Feedback
Copyright © 2013, Texas Instruments Incorporated

www.ti.com PGA281EVM Hardware
2.8 PGA281EVM PCB Layout
Figure 4,Figure 5,Figure 6, and Figure 7 depict the four layers of the PGA281EVM PCB layout.
NOTE: Board layouts are not to scale. These figures are intended to show how the board is laid out;
they are not intended to be used for manufacturing PGA281EVM PCBs.
7
dit.SBOU130–May 2013 PGA281EVM
Submit Documentation Feedback Copyright © 2013, Texas Instruments Incorporated

PGA281EVM Hardware www.ti.com
Figure 4. Top Layer (Signal and Ground)
8PGA281EVM dit.SBOU130–May 2013
Submit Documentation Feedback
Copyright © 2013, Texas Instruments Incorporated

www.ti.com PGA281EVM Hardware
Figure 5. Layer 2 (Power)
9
dit.SBOU130–May 2013 PGA281EVM
Submit Documentation Feedback Copyright © 2013, Texas Instruments Incorporated

PGA281EVM Hardware www.ti.com
Figure 6. Layer 3 (Power)
