Texas Instruments TPS54291EVM-431 User manual

User's Guide
SLVU356–January 2010
Using the TPS54291EVM-431 A 12V Input, 3.3V 1.5A and
1.2V 2.5A Synchronous Buck Converter
Contents
1 Introduction .................................................................................................................. 2
1.1 Description .......................................................................................................... 2
1.2 Applications ......................................................................................................... 2
1.3 Features ............................................................................................................. 2
2 TPS54291EVM-431 Electrical Performance Specifications ........................................................... 3
3 Schematic .................................................................................................................... 4
3.1 Enable Jumpers (JP1 and JP2) .................................................................................. 5
3.2 Error Amplifier Outputs ............................................................................................ 5
3.3 Test Point Descriptions ............................................................................................ 5
4 Test Set UP .................................................................................................................. 6
4.1 Equipment ........................................................................................................... 6
4.2 Equipment Setup ................................................................................................... 7
4.3 Start Up / Shut Down Procedure ................................................................................. 9
4.4 Output Ripple Voltage Measurement Procedure ............................................................. 10
4.5 Control Loop Gain and Phase Measurement Procedure .................................................... 10
4.6 Equipment Shutdown ............................................................................................ 10
5 TPS54291EVM-431 Typical Performance Data and Characteristic Curves ....................................... 10
5.1 Efficiency .......................................................................................................... 11
5.2 Line and Load Regulation ....................................................................................... 11
5.3 Switch Node and Output Ripple Voltage ...................................................................... 12
6 EVM Assembly Drawings and Layout .................................................................................. 12
7 List of Materials ............................................................................................................ 16
List of Figures
1 TPS54291EVM-431 Schematic (For Reference Only, See Table 4: Bill of Materials for Specific Values) ..... 4
2 TPS54291EVM-431 Recommended Test Set-Up ...................................................................... 8
3 Output Ripple Measurement – Tip and Barrel using TP3 and TP4 or TP18 and TP19 ........................... 9
4 Control Loop Measurement Setup........................................................................................ 9
5 TPS54291EVM-431 Efficiency vs Load Current ...................................................................... 11
6 TPS54291EVM-431 Output Voltage vs Load Current................................................................ 11
7 TPS54291EVM-431 Output Voltage Ripple ........................................................................... 12
8 TPS54291EVM-431 Component Placement (Viewed from Top).................................................... 12
9 TPS54291EVM-431 Silkscreen (Viewed from Top)................................................................... 13
10 TPS54291EVM-431 Top Copper (Viewed from Top)................................................................. 13
11 TPS54291EVM-431 Bottom Copper (X-Ray View from Top)........................................................ 14
12 TPS54291EVM-431 Internal 1 (X-Ray View from Top) .............................................................. 14
13 TPS54291EVM-431 Internal 2 (X-Ray View from Top) .............................................................. 15
List of Tables
1 TPS54291EVM-431 Electrical and Performance Specifications...................................................... 3
1
SLVU356–January 2010 Using the TPS54291EVM-431 A 12V Input, 3.3V 1.5A and 1.2V 2.5A
Synchronous Buck Converter
Submit Documentation Feedback Copyright © 2010, Texas Instruments Incorporated

Introduction www.ti.com
2 Test Point Descriptions..................................................................................................... 5
3 TPS54291EVM-431 Bill of Materials.................................................................................... 16
1 Introduction
The TPS54291EVM-431 evaluation module (EVM) is a dual synchronous buck converter providing fixed
3.3V and 1.2V outputs at up to 1.5A and 2.5A respectively from a 12V bus. The EVM is designed to
start-up from a single supply, so no additional bias voltages are require for start-up. The module uses the
TPS54291 600kHz Dual Synchronous Buck Converter with integral MOSETs.
1.1 Description
TPS54291EVM-431 is designed to use a regulated 12V (+10% /–20%) bus to produce two regulated
power rails, 3.3V at 1.5A and 1.2V at 2.5A. TPS54291EVM-431 is designed to demonstrate the TPS54291
in a typical 12-V bus system while providing a number of test points to evaluate the performance of the
TPS54291 in a given application. The EVM can be modified to other output voltages by changing some of
the components.
1.2 Applications
• Non-Isolated Point of Load and Voltage bus converters.
• Consumer Electronics
• LCD TV
• Computer Peripherals
• Digital Set Top Box
1.3 Features
• 12 V +10% /–20% input range
• 5.0 V and 3.3 V fixed output voltage, adjustable with resistor change
• 1.5A (3.3V) and 2.5A (1.2V) Steady State Current
• 600kHz switching frequency (Fixed by TPS54291)
• Internal switching MOSFET and external Rectifier Diode.
• Double Sided 2 Active Layer PCB with all components on top side (Test Point signals routed on
internal layers)
• Active Converter area of 1.1 square inches (0.86" × 1.28")
• Convenient test points for probing switching waveforms and non-invasive loop response testing
2Using the TPS54291EVM-431 A 12V Input, 3.3V 1.5A and 1.2V 2.5A SLVU356–January 2010
Synchronous Buck Converter Submit Documentation Feedback
Copyright © 2010, Texas Instruments Incorporated

www.ti.com TPS54291EVM-431 Electrical Performance Specifications
2 TPS54291EVM-431 Electrical Performance Specifications
Table 1. TPS54291EVM-431 Electrical and Performance Specifications
Parameter Notes and Conditions Min Nom Max Units
INPUT CHARACTERISTICS
VIN Input Voltage 9.6 12 13.2 V
IIN Input Current VIN = Nom, IOUT = Max – 2.4 2.6 A
No Load Input Current VIN = Nom, IOUT = 0 A – 12 20 mA
VIN_UVLO Input UVLO IOUT = Min to Max 4.0 4.2 4.4 V
OUTPUT CHARACTERISTICS
VOUT1 Output Voltage 1 VIN = Nom, IOUT = Nom 3.20 3.30 3.40 V
VOUT2 Output Voltage 2 VIN = Nom, IOUT = Nom 1.15 1.20 1.25 V
Line Regulation VIN = Min to Max – – 1%
Load Regulation IOUT = Min to Max – – 1%
VOUT_ripple Output Voltage Ripple VIN = Nom, IOUT = Max – – 50 mVpp
IOUT1 Output Current 1 VIN = Min to Max 0 2.5 A
IOUT2 Output Current 2 VIN = Min to Max 0 2.5 A
IOCP1 Output Over Current Channel 1 VIN = Nom, VOUT = VOUT1–5% 1.6 2.0 2.4 A
IOCP2 Output Over Current Channel 2 VIN = Nom, VOUT = VOUT2–5% 3.0 3.6 4.4 A
SYSTEMS CHARACTERISTICS
FSW Switching Frequency 520 600 720 kHz
ηpk Peak Efficiency VIN =Nom – 88% –
ηFull Load Efficiency VIN =Nom, IOUT1 = IOUT1 = Max – 85% –
Top Operating Temperature Range VIN= Min to Max, IOUT = Min to Max 0 25 60 °C
3
SLVU356–January 2010 Using the TPS54291EVM-431 A 12V Input, 3.3V 1.5A and 1.2V 2.5A
Synchronous Buck Converter
Submit Documentation Feedback Copyright © 2010, Texas Instruments Incorporated

+
Schematic www.ti.com
3 Schematic
Figure 1. TPS54291EVM-431 Schematic
(For Reference Only, See Table 4: Bill of Materials for Specific Values)
4Using the TPS54291EVM-431 A 12V Input, 3.3V 1.5A and 1.2V 2.5A SLVU356–January 2010
Synchronous Buck Converter Submit Documentation Feedback
Copyright © 2010, Texas Instruments Incorporated

www.ti.com Schematic
3.1 Enable Jumpers (JP1 and JP2)
TPS54291EVM-431 provides separate 3 pin 100-mil headers and shunts for exercising the TPS54291
Enable functions. Place the JP1 shunt in the Left Position connects EN1 to ground and turns on Output 1
and placing the JP2 shunt in the Left Position connects EN2 to ground and turns on Output 2.
3.2 Error Amplifier Outputs
The output of the TPS54291 transconductance error amplifiers (COMP1 and COMP2) are sensitive to
capacitive loading, including the typical 8-15pF capacitance added by an oscilloscope probe. No direct
measurements of these signals should be attempted without using an external buffer to prevent loading of
the control voltage.
3.3 Test Point Descriptions
Table 2. Test Point Descriptions
Test Point Label Use Section
TP1 VIN Monitor Input Voltage 3.3.1
TP2 GND Ground for Input Voltage 3.3.1
TP3 VOUT1 Monitor VOUT1 Voltage 3.3.2
TP4 GND Ground for VOUT1 Voltage 3.3.2
TP5 GND Ground for VOUT1 Channel B Loop Monitoring 3.3.3
TP6 CHB VOUT1 Channel B for Loop Monitoring 3.3.3
TP7 GND Ground for VOUT1 Channel A Loop Monitoring 3.3.3
TP8 CHA VOUT1 Channel B for Loop Monitoring 3.3.3
TP9 SW1 Monitor Switching Node of Channel 1 3.3.4
TP10 GND Ground for Switch Node of Channel 1 3.3.4
TP11 IC_GND Monitor IC Ground 3.3.5
TP12 SW2 Monitor Switching Node of Channel 2 3.3.6
TP13 GND Ground for Switch Node of Channel 2 3.3.6
TP14 CHA VOUT2 Channel A for Loop Monitoring 3.3.7
TP15 GND Ground for VOUT2 Channel A Loop Monitoring 3.3.7
TP16 CHB VOUT2 Channel B for Loop Monitoring 3.3.7
TP17 GND Ground for VOUT2 Channel B Loop Monitoring 3.3.7
TP18 VOUT2 Monitor VOUT2 Voltage 3.3.8
TP19 GND Ground for VOUT2 Voltage 3.3.8
3.3.1 Input Voltage Monitoring (TP1 and TP2)
TPS54291EVM-431 provides two test points for measuring the voltage applied to the module. This allows
the user to measure the actual module voltage without losses from input cables and connectors. All input
voltage measurements should be made between TP1 and TP2. To use TP1 and TP2, connect a voltmeter
positive terminal to TP1 and negative terminal to TP2.
3.3.2 Channel 1 Output Voltage Monitoring (TP3 and TP4)
TPS54291EVM-431 provides two test points for measuring the voltage generated by the module. This
allows the user to measure the actual module output voltage without losses from output cables and
connectors. All output voltage measurements should be made between TP3 and TP4. To use TP3 and
TP4, connect a voltmeter positive terminal to TP3 and negative terminal to TP4. For Output ripple
measurements, TP3 and TP4 allow a user to limit the ground loop area by using the Tip and Barrel
measurement technique shown in Figure 3. All output ripple measurements should be made using the Tip
and Barrel measurement. . Even this Tip and Barrel measurement technique increases the measured
switch edge noise. For improved output ripple measurement, measure the output ripple at the output
capacitor (C5)
5
SLVU356–January 2010 Using the TPS54291EVM-431 A 12V Input, 3.3V 1.5A and 1.2V 2.5A
Synchronous Buck Converter
Submit Documentation Feedback Copyright © 2010, Texas Instruments Incorporated

Test Set UP www.ti.com
3.3.3 Channel 1 Loop Analysis (TP5, TP6, TP7 and TP8)
TPS54291EVM-431 contains a 51Ωseries resistor (R1) in the feedback loop to allow for matched
impedance signal injection into the feedback for loop response analysis. An isolation transformer should
be used to apply a small (30mV or less) signal across R1 through TP6 and TP8. By monitoring the AC
injection level at TP8 and the returned AC level at TP6, the power supply loop response can be
determined.
3.3.4 Channel 1 Switching Waveforms (TP9 and TP10)
TPS54291EVM-431 provides a surface test pad and a local ground connection (TP10) for the monitoring
of the channel 1 power stage switching waveform. Connect an Oscilloscope probe to TP9 to monitor the
Switch Node voltage for channel 1. Test pads are used on the switch nodes to minimize radiated noise
from the switch node.
3.3.5 TPS54291 IC Ground (TP11)
TPS54291EVM-431 provides a test point for the IC ground. To measure IC pin voltages, connect the
ground of the oscilloscope probe to TP11.
3.3.6 Channel 2 Switching Waveforms (TP12 and TP13)
TPS54291EVM-431 provides a surface test pad and a local ground connection (TP13) for the monitoring
of the channel 1 power stage switching waveform. Connect an Oscilloscope probe to TP12 to monitor the
Switch Node voltage for channel 1. Test pads are used on the switch nodes to minimize radiated noise
from the switch node.
3.3.7 Channel 2 Loop Analysis (TP14, TP15, TP16 and TP17)
TPS54291EVM-431 contains a 51 series resistor (R13) in the feedback loop to allow for matched
impedance signal injection into the feedback for loop response analysis. An isolation transformer should
be used to apply a small (30mV or less) signal across R13 through TP14 and TP16. By monitoring the AC
injection level at TP14 and the returned AC level at TP16, the power supply loop response can be
determined.
3.3.8 Output Voltage Monitoring (TP18 and TP19)
TPS54291EVM-431 provides two test points for measuring the voltage generated by the module. This
allows the user to measure the actual module output voltage without losses from output cables and
connector losses. All output voltage measurements should be made between TP18 and TP19. To use
TP18 and TP19, connect a voltmeter positive terminal to TP18 and negative terminal to TP19. For Output
ripple measurements, TP18 and TP19 allow a user to limit the ground loop area by using the Tip and
Barrel measurement technique shown in Figure 3 All output ripple measurements should be made using
the Tip and Barrel measurement. Even this Tip and Barrel measurement technique increases the
measured switch edge noise. For improved output ripple measurement, measure the output ripple at the
output capacitor (C17)
4 Test Set UP
4.1 Equipment
4.1.1 Voltage Source
VIN
The input voltage source (VIN) should be a 0-15V variable DC source capable of 2Adc. Connect VIN to J1
as shown in Figure 3.
4.1.2 Meters
A1: 0-2Adc, ammeter
6Using the TPS54291EVM-431 A 12V Input, 3.3V 1.5A and 1.2V 2.5A SLVU356–January 2010
Synchronous Buck Converter Submit Documentation Feedback
Copyright © 2010, Texas Instruments Incorporated

www.ti.com Test Set UP
V1: VIN, 0-15V voltmeter
V2: VOUT1 0-6V voltmeter
V3: VOUT2 0-4V voltmeter
4.1.3 Loads
LOAD1
The Output1 Load (LOAD1) should be an Electronic Constant Current Mode Load capable of 0-1.5Adc at
3.3V
LOAD2
The Output2 Load (LOAD2) should be an Electronic Constant Current Mode Load capable of 0-2.5Adc at
1.2V
4.1.4 Oscilloscope
OSCILLOSCOPE
A Digital or Analog Oscilloscope can be used to measure the ripple voltage on VOUT1 or VOUT2. The
Oscilloscope should be set for 1MΩimpedance, 20MHz Bandwidth, AC coupling, 1μs/division horizontal
resolution, 10mV/division vertical resolution for taking output ripple measurements. TP3 and TP4 or TP18
and TP19 can be used to measure the output ripple voltages by placing the oscilloscope probe tip through
TP3 or TP18 and holding the ground barrel to TP4 or TP19 as shown in Figure 3. For a hands free
approach, the loop in TP4 or TP19 can be cut and opened to cradle the probe barrel. Using a leaded
ground connection may induce additional noise due to the large ground loop area.
4.1.5 Recommended Wire Gauge
VIN to J1
The connection between the source voltage, VIN and J1 of HPA431 can carry as much as 5 Adc. The
minimum recommended wire size is AWG #16 with the total length of wire less than 4 feet (2 feet input, 2
feet return).
J2 to LOAD1
The power connection between J2 of HPA431 and LOAD1 can carry as much as 1.5Adc. The minimum
recommended wire size is AWG #18, with the total length of wire less than 2 feet (1 foot output, 1 foot
return).
J3 to LOAD2
The power connection between J3 of HPA431 and LOAD2 can carry as much as 2.5Adc. The minimum
recommended wire size is AWG #18, with the total length of wire less than 2 feet (1 foot output, 1 foot
return).
4.1.6 Other
FAN
This evaluation module includes components that can get hot to the touch, because this EVM is not
enclosed to allow probing of circuit nodes, a small fan capable of 200-400 lfm is recommended to reduce
component surface temperatures to prevent user injury. The EVM should not be left unattended while
powered. The EVM should not be probed while the fan is not running.
4.2 Equipment Setup
Shown in Figure 2 is the basic test set up recommended to evaluate the TPS54291EVM-431. Note that
although the return for J1, J2 and JP3 are the same system ground, the connections should remain
separate as shown in Figure 2.
4.2.1 Procedure
1. Working at an ESD workstation, make sure that any wrist straps, bootstraps or mats are connected
referencing the user to earth ground before power is applied to the EVM. Electrostatic smock and
safety glasses should also be worn.
2. Prior to connecting the DC input source, VIN, it is advisable to limit the source current from VIN to 2.0A
7
SLVU356–January 2010 Using the TPS54291EVM-431 A 12V Input, 3.3V 1.5A and 1.2V 2.5A
Synchronous Buck Converter
Submit Documentation Feedback Copyright © 2010, Texas Instruments Incorporated

LOAD1
3.3V @
1.5A
-
+
FAN
V2
+-
See Tip and Barrel
Measurement for
Vout ripple
V1
+
-
A1
-
+
V
VIN
Oscilloscope
1MW, AC
20mV / div
20MHz
LOAD2
1.2V @
2.5A
+
-
V3
-+
Test Set UP www.ti.com
maximum. Make sure VIN is initially set to 0V and connected as shown in Figure 2.
3. Connect the ammeter A1 (0-5A range) between VIN and J1 as shown in Figure 2.
4. Connect voltmeter V1 to TP1 and TP2 as shown in Figure 2.
5. Connect LOAD1 to J2 as shown in Figure 2. Set LOAD1 to constant current mode to sink 0Adc before
VIN is applied.
6. Connect voltmeter, V2 across TP3 and TP4 as shown in Figure 2.
7. Connect LOAD2 to J3 as shown in Figure 2. Set LOAD2 to constant current mode to sink 0Adc before
VIN is applied.
8. Connect voltmeter, V3 across TP18 and TP19 as shown in Figure 2.
9. Place Fan as shown in Figure 3 and turn on, making sure air is flowing across the EVM.
4.2.2 Diagram
Figure 2. TPS54291EVM-431 Recommended Test Set-Up
8Using the TPS54291EVM-431 A 12V Input, 3.3V 1.5A and 1.2V 2.5A SLVU356–January 2010
Synchronous Buck Converter Submit Documentation Feedback
Copyright © 2010, Texas Instruments Incorporated

TP4 /
TP19
TP3 /
TP18
Metal Ground Barrel
Probe Tip
Tip and Barrel Vout ripple
measurement
Network
Analyzer
Isolation
Transformer
FAN
V1
+
-
A1
-
+
V
VIN LOAD1
3.3V @
1.5A
-
+
V2
+-
LOAD2
1.2V @
2.5A
+
-
V3
-+
www.ti.com Test Set UP
Figure 3. Output Ripple Measurement – Tip and Barrel using TP3 and TP4 or TP18 and TP19
Figure 4. Control Loop Measurement Setup
4.3 Start Up / Shut Down Procedure
1. Increase VIN from 0V to 12Vdc
9
SLVU356–January 2010 Using the TPS54291EVM-431 A 12V Input, 3.3V 1.5A and 1.2V 2.5A
Synchronous Buck Converter
Submit Documentation Feedback Copyright © 2010, Texas Instruments Incorporated

C hannelB
20 LOG
ChannelA
æ ö
´ç ÷
è ø
TPS54291EVM-431 Typical Performance Data and Characteristic Curves www.ti.com
2. Vary LOAD1 from 0 – 1.5Adc
3. Vary LOAD2 from 0 – 2.5Adc
4. Vary VIN from 9.6Vdc to 13.2Vdc
5. Decrease VIN to 0Vdc
6. Decrease LOAD1 to 0A
7. Decrease LOAD2 to 0A
4.4 Output Ripple Voltage Measurement Procedure
See Section 5.4 for more information on measuring output ripple.
1. Increase VIN from 0V to 12Vdc
2. Adjust LOAD1 to desired load between 0Adc and 1.5Adc
3. Adjust LOAD2 to desired load between 0Adc and 2.5Adc
4. Adjust VIN to desired load between 9.6Vdc and 13.2Vdc
5. Connect Oscilloscope Probe to TP3 and TP4 or TP18 and TP19 as shown in Figure 3
6. Measure Output Ripple
7. Decrease VIN to 0Vdc
8. Decrease LOAD1 to 0A
9. Decrease LOAD2 to 0A
4.5 Control Loop Gain and Phase Measurement Procedure
1. Connect 1kHz–1MHz Isolation Transformer to TP6 and TP8 as show in Figure 4
2. Connect Input Signal Amplitude Measurement Probe (Channel A) to TP8 as shown in Figure 4
3. Connect Output Signal Amplitude Measurement Probe (Channel B) to TP6 as shown in Figure 4
4. Connect Ground Lead of Channel A and Channel B to TP5 and TP7 as shown in Figure 4
5. Inject 30mV or less signal across R1 through Isolation Transformer
6. Sweep Frequency from 1kHz to 1MHz with 10Hz or lower post filter
7. Control Loop Gain can be measured by
8. Control Loop Phase is measured by the Phase difference between Channel A and Channel B
9. Control Loop for Channel 2 can be measured by making the following substitutions
(a) Change TP6 to TP16
(b) Change TP8 to TP14
(c) Change TP5 to TP17
(d) Change TP7 to TP15
10. Disconnect Isolation Transformer before making any other measurements (Signal Injection into
Feedback may interfere with accuracy of other measurements)
4.6 Equipment Shutdown
1. Shut Down Oscilloscope
2. Shut down VIN
3. Shut down LOAD1
4. Shut down LOAD2
5. Shut down FAN
5 TPS54291EVM-431 Typical Performance Data and Characteristic Curves
Figure 5 through Figure 7 present typical performance curves for the TPS54291EVM-431. Since actual
performance data can be affected by measurement techniques and environmental variables, these curves
are presented for reference and may differ from actual field measurements.
10 Using the TPS54291EVM-431 A 12V Input, 3.3V 1.5A and 1.2V 2.5A SLVU356–January 2010
Synchronous Buck Converter Submit Documentation Feedback
Copyright © 2010, Texas Instruments Incorporated

0 0.2 0.4 0.6 0.8 1 1.2 1.4 1.6
I - Load Current - A
LOAD
8 V 12 V
14 V
60
65
70
75
80
85
90
95
100
η - Efficiency - %
60
65
70
75
80
85
90
0 0.5 1 1.5 2 2.5 3
η - Efficiency - %
I - Load Current - A
LOAD
8 V
12 V
14 V
1.188
1.194
1.2
1.206
1.212
V - Output Voltage - V
O
3.25
3.27
3.29
3.31
3.33
3.35
V - Output Voltage - V
O
8 V
0 0.2 0.4 0.6 0.8 1 1.2 1.4 1.6
I - Load Current - A
LOAD
0 0.5 1 1.5 2 3
I - Load Current - A
LOAD
14 V
12 V
2.5
12 V
14 V
8 V
www.ti.com TPS54291EVM-431 Typical Performance Data and Characteristic Curves
5.1 Efficiency
VIN = 9.6-13.2V, VOUT1 = 3.3V IOUT1 = 0-1.5A, VOUT2 = 1.2V IOUT2 = 0-2.5A
Figure 5. TPS54291EVM-431 Efficiency vs Load Current
5.2 Line and Load Regulation
VIN = 9.6-13.2V, VOUT1 = 3.2V IOUT1 = 0-1.5A, VOUT2 = 1.2V IOUT2 = 0-2.5A
Figure 6. TPS54291EVM-431 Output Voltage vs Load Current
11
SLVU356–January 2010 Using the TPS54291EVM-431 A 12V Input, 3.3V 1.5A and 1.2V 2.5A
Synchronous Buck Converter
Submit Documentation Feedback Copyright © 2010, Texas Instruments Incorporated

EVM Assembly Drawings and Layout www.ti.com
5.3 Switch Node and Output Ripple Voltage
VIN = 13.2V, VOUT1 = 3.3A, IOUT2 = 1.2V IOUT2 = 2.5A
Ch1: TP3 (VOUT1), Ch2: TP18 (VOUT2) Ch3: TP9 (SW1), Ch4: TP12 (SW2)
Figure 7. TPS54291EVM-431 Output Voltage Ripple
6 EVM Assembly Drawings and Layout
Figure 8 through Figure 13 show the designs of the TPS54291EVM-431 printed circuit board. The EVM
has been designed using a 4-Layer, 2oz copper-clad circuit board 3.0” × 3.0” with all components in a
0.86" × 1.28" active area on the top side and all active traces to the top and bottom layers to allow the
user to easily view, probe and evaluate the TPS54291 control IC in a practical double-sided application.
Moving components to both sides of the PCB or using additional internal layers can offer additional size
reduction for space constrained systems
Figure 8. TPS54291EVM-431 Component Placement (Viewed from Top)
12 Using the TPS54291EVM-431 A 12V Input, 3.3V 1.5A and 1.2V 2.5A SLVU356–January 2010
Synchronous Buck Converter Submit Documentation Feedback
Copyright © 2010, Texas Instruments Incorporated

www.ti.com EVM Assembly Drawings and Layout
Figure 9. TPS54291EVM-431 Silkscreen (Viewed from Top)
Figure 10. TPS54291EVM-431 Top Copper (Viewed from Top)
13
SLVU356–January 2010 Using the TPS54291EVM-431 A 12V Input, 3.3V 1.5A and 1.2V 2.5A
Synchronous Buck Converter
Submit Documentation Feedback Copyright © 2010, Texas Instruments Incorporated

EVM Assembly Drawings and Layout www.ti.com
Figure 11. TPS54291EVM-431 Bottom Copper (X-Ray View from Top)
Figure 12. TPS54291EVM-431 Internal 1 (X-Ray View from Top)
14 Using the TPS54291EVM-431 A 12V Input, 3.3V 1.5A and 1.2V 2.5A SLVU356–January 2010
Synchronous Buck Converter Submit Documentation Feedback
Copyright © 2010, Texas Instruments Incorporated

www.ti.com EVM Assembly Drawings and Layout
Figure 13. TPS54291EVM-431 Internal 2 (X-Ray View from Top)
15
SLVU356–January 2010 Using the TPS54291EVM-431 A 12V Input, 3.3V 1.5A and 1.2V 2.5A
Synchronous Buck Converter
Submit Documentation Feedback Copyright © 2010, Texas Instruments Incorporated

List of Materials www.ti.com
7 List of Materials
Table 3 lists the EVM components as configured according to the schematic shown in Figure 1.
Table 3. TPS54291EVM-431 Bill of Materials
QTY RefDes Value Description Size Part Number MFR
1 C1 100 μF Capacitor, Aluminum, 25V, ±20% 0.328 x 0.390 inch EEEFC1E101P Panasonic
1 C12 4.7 μF Capacitor, Ceramic, 10V, X5R, 20% 0805 Std Std
2 C2, C14 22 μF Capacitor, Ceramic, 6.3V, X5R, 20% 1206 C3216X5R0J226M TDK
2 C3, C13 470 pF Capacitor, Ceramic, 25V, X7R, 20% 0603 Std Std
2 C4, C11 0.047 μF Capacitor, Ceramic, 25V, X7R, 20% 0603 Std Std
2 C5, C10 10 μF Capacitor, Ceramic, 25V, X5R, 20% 1210 C3225X5R1E106M TDK
1 C6 1.8 nF Capacitor, Ceramic, 25V, X7R, 20% 0603 Std Std
1 C7 15 pF Capacitor, Ceramic, 25V, C0G, 20% 0603 Std Std
1 C8 47 pF Capacitor, Ceramic, 25V, C0G, 20% 0603 Std Std
1 C9 1.2 nF Capacitor, Ceramic, 25V, X7R, 20% 0603 Std Std
3 J1, J2, J3 ED1609-ND Terminal Block, 2-pin, 15-A, 5.1mm 0.40 x 0.35 inch ED120/2DS OST
2 JP1, JP2 PEC03SAAN Header, 3-pin, 100mil spacing 0.100 inch x 3 PEC03SAAN Sullins
1 L1 8.2 μH Inductor, SMT, 4.38A, 20 mΩ0.402 x 0.394 inch MSS1048-822L Coilcraft
1 L2 3.3 μH Inductor, SMT, 4.38A, 20 mΩ0.402 x 0.394 inch MSS1048-332L Coilcraft
2 R1, R8 51 Resistor, Chip, 1/16W, 5% 0603 Std Std
1 R10 40.2 k Resistor, Chip, 1/16W, 1% 0603 Std Std
2 R2, R11 10 Resistor, Chip, 1/16W, 5% 0603 Std Std
2 R3, R12 20.5 k Resistor, Chip, 1/16W, 1% 0603 Std Std
1 R4 6.49 k Resistor, Chip, 1/16W, 1% 0603 Std Std
2 R5, R9 0 Resistor, Chip, 1/16W, 5% 0603 Std Std
1 R6 53.6 k Resistor, Chip, 1/16W, 1% 0603 Std Std
1 R7 18.7 k Resistor, Chip, 1/16W, 1% 0603 Std Std
3 TP1, TP3, TP18 5010 Test Point, Red, Thru Hole 0.125 x 0.125 inch 5010 Keystone
TP2, TP4, TP5,
TP7, TP10, TP13,
TP15
9 TP17, TP19, TP6, 5011 Test Point, Black, Thru Hole 0.125 x 0.125 inch 5011 Keystone
TP8, TP11, TP14
5 TP16 5012 Test Point, White, Thru Hole 0.125 x 0.125 inch 5012 Keystone
0 TP9, TP12 None Test point, 40 mil SMT None None None
1 U1 TPS54291PWP IC, 2.5/1.5A, 600Hz, Dual Output Fully CSP TPS54291PWP TI
Synchronous Buck Converter W/Integrated
FET
2 – Shunt, 100-mil, Black 0.100 929950-00 3M
1 – PCB, 3 In × 3 In × 0.063 In HPA431 Any
16 Using the TPS54291EVM-431 A 12V Input, 3.3V 1.5A and 1.2V 2.5A SLVU356–January 2010
Synchronous Buck Converter Submit Documentation Feedback
Copyright © 2010, Texas Instruments Incorporated

IMPORTANT NOTICE
Texas Instruments Incorporated and its subsidiaries (TI) reserve the right to make corrections, modifications, enhancements, improvements,
and other changes to its products and services at any time and to discontinue any product or service without notice. Customers should
obtain the latest relevant information before placing orders and should verify that such information is current and complete. All products are
sold subject to TI’s terms and conditions of sale supplied at the time of order acknowledgment.
TI warrants performance of its hardware products to the specifications applicable at the time of sale in accordance with TI’s standard
warranty. Testing and other quality control techniques are used to the extent TI deems necessary to support this warranty. Except where
mandated by government requirements, testing of all parameters of each product is not necessarily performed.
TI assumes no liability for applications assistance or customer product design. Customers are responsible for their products and
applications using TI components. To minimize the risks associated with customer products and applications, customers should provide
adequate design and operating safeguards.
TI does not warrant or represent that any license, either express or implied, is granted under any TI patent right, copyright, mask work right,
or other TI intellectual property right relating to any combination, machine, or process in which TI products or services are used. Information
published by TI regarding third-party products or services does not constitute a license from TI to use such products or services or a
warranty or endorsement thereof. Use of such information may require a license from a third party under the patents or other intellectual
property of the third party, or a license from TI under the patents or other intellectual property of TI.
Reproduction of TI information in TI data books or data sheets is permissible only if reproduction is without alteration and is accompanied
by all associated warranties, conditions, limitations, and notices. Reproduction of this information with alteration is an unfair and deceptive
business practice. TI is not responsible or liable for such altered documentation. Information of third parties may be subject to additional
restrictions.
Resale of TI products or services with statements different from or beyond the parameters stated by TI for that product or service voids all
express and any implied warranties for the associated TI product or service and is an unfair and deceptive business practice. TI is not
responsible or liable for any such statements.
TI products are not authorized for use in safety-critical applications (such as life support) where a failure of the TI product would reasonably
be expected to cause severe personal injury or death, unless officers of the parties have executed an agreement specifically governing
such use. Buyers represent that they have all necessary expertise in the safety and regulatory ramifications of their applications, and
acknowledge and agree that they are solely responsible for all legal, regulatory and safety-related requirements concerning their products
and any use of TI products in such safety-critical applications, notwithstanding any applications-related information or support that may be
provided by TI. Further, Buyers must fully indemnify TI and its representatives against any damages arising out of the use of TI products in
such safety-critical applications.
TI products are neither designed nor intended for use in military/aerospace applications or environments unless the TI products are
specifically designated by TI as military-grade or "enhanced plastic." Only products designated by TI as military-grade meet military
specifications. Buyers acknowledge and agree that any such use of TI products which TI has not designated as military-grade is solely at
the Buyer's risk, and that they are solely responsible for compliance with all legal and regulatory requirements in connection with such use.
TI products are neither designed nor intended for use in automotive applications or environments unless the specific TI products are
designated by TI as compliant with ISO/TS 16949 requirements. Buyers acknowledge and agree that, if they use any non-designated
products in automotive applications, TI will not be responsible for any failure to meet such requirements.
Following are URLs where you can obtain information on other Texas Instruments products and application solutions:
Products Applications
Amplifiers amplifier.ti.com Audio www.ti.com/audio
Data Converters dataconverter.ti.com Automotive www.ti.com/automotive
DLP® Products www.dlp.com Communications and www.ti.com/communications
Telecom
DSP dsp.ti.com Computers and www.ti.com/computers
Peripherals
Clocks and Timers www.ti.com/clocks Consumer Electronics www.ti.com/consumer-apps
Interface interface.ti.com Energy www.ti.com/energy
Logic logic.ti.com Industrial www.ti.com/industrial
Power Mgmt power.ti.com Medical www.ti.com/medical
Microcontrollers microcontroller.ti.com Security www.ti.com/security
RFID www.ti-rfid.com Space, Avionics & www.ti.com/space-avionics-defense
Defense
RF/IF and ZigBee® Solutions www.ti.com/lprf Video and Imaging www.ti.com/video
Wireless www.ti.com/wireless-apps
Mailing Address: Texas Instruments, Post Office Box 655303, Dallas, Texas 75265
Copyright © 2010, Texas Instruments Incorporated

Mouser Electronics
Authorized Distributor
Click to View Pricing, Inventory, Delivery & Lifecycle Information:
Texas Instruments:
TPS54291EVM-431
