Texas Instruments TPS65980EVM User manual

TPS65980EVM
User's Guide
Literature Number: SLVUA50
April 2014

Contents
1 Introductions....................................................................................................................... 4
2 Setup.................................................................................................................................. 4
2.1 Power Supply Inputs..................................................................................................... 4
2.2 Jumper Settings .......................................................................................................... 5
2.3 Device Configurations ................................................................................................... 6
2.4 Test Points ................................................................................................................ 8
3 Board Assembly and Layout ................................................................................................. 9
4 Schematic ......................................................................................................................... 11
5 Bill of Materials .................................................................................................................. 12
2Table of Contents SLVUA50–April 2014
Submit Documentation Feedback
Copyright © 2014, Texas Instruments Incorporated

www.ti.com
List of Figures
1 Connection Points ........................................................................................................... 4
2 Low Voltage Input............................................................................................................ 6
3 High Voltage Input During Sleep .......................................................................................... 6
4 High Voltage Input With Lower CBL_OUT Current Limit............................................................... 7
5 High Voltage Input With Higher CBL_OUT Current Limit .............................................................. 7
6 Top Layer Assembly......................................................................................................... 9
7 Bottom Layer Assembly..................................................................................................... 9
8 Top Layer Routing ......................................................................................................... 10
9 Bottom Layer Routing...................................................................................................... 10
10 Schematic ................................................................................................................... 11
3
SLVUA50–April 2014 List of Figures
Submit Documentation Feedback Copyright © 2014, Texas Instruments Incorporated

TBT
IN
+
-
J1
DEV_EN
J5
OFF|ON
CBL_ILIM
J6
HI|LOW
+
-
J2
+
-
J3
+
-
J4
DEV
OUT
TBT
OUT
CBL
OUT
User's Guide
SLVUA50–April 2014
TPS65980EVM
1 Introductions
The Texas Instruments TPS65980EVM evaluation module (EVM) helps designers evaluate the operation
and performance of the TPS65980: a DC/DC switching regulator that receives power from a Thunderbolt
bus ranging from 2.5V to 15.75V on TBT_IN and generates three separate 3.3V supply outputs
TBT_OUT, CBL_OUT, and DEV_OUT.
The TBT_OUT supply provides power to the local peripheral Thunderbolt™ controller and support
circuitry. The CBL_OUT supply provides power back to the Thunderbolt™ cable and has adjustable
current limit. The DEV_OUT supply provides power to all other circuitry in the device to perform its
designed function.
The TPS65980 is available in a 24-pin 5mm x 4mm x 0.9mm QFN package.
Table 1. Device and Package Configurations
CONVERTER IC PACKAGE
U1 TPS65980RHF RHF
2 Setup
This section describes the jumpers and connectors on the EVM as well as how to properly connect, set
up, and use the TPS65980EVM.
2.1 Power Supply Inputs
Figure 1 shows the connection points needed to fully and correctly interface with the TPS65980EVM.
Figure 1. Connection Points
4TPS65980EVM SLVUA50–April 2014
Submit Documentation Feedback
Copyright © 2014, Texas Instruments Incorporated

www.ti.com Setup
The TPS65980 has three operating modes dictated by the voltage applied on TBT_IN. The total power
available at each of the outputs is determined by the operating mode. Table 2 summarizes the operating
modes in terms of input voltage range and output current ranges.
Input/Output Supply Ranges
Operating Mode TBT_IN Vrange TBT_OUT Irange(1) CBL_OUT DEV_OUT
Irange(1) Irange(1)
Low Voltage 2.5V – 3.4V 5mA – 50mA Output Disabled Output Disabled
High Voltage 10V – 15.75V 235mA – 1A 0 – 1.44A(1) 0 – 2.5A
High Voltage 5.2V – 15.75V 5mA – 31mA 0 – 235mA 0 – 700mA
(Sleep)
(1) Note: the total combined output current from TBT_OUT, CBL_OUT, and DEV_OUT should never
exceed 3.5A.
2.2 Jumper Settings
There are two digital input signals which can be set with jumpers as defined in Table 3. These signals
can be set to a logical value of “0” or “1” by moving the jumper between the 2 available positions (left and
right). See the TPS65980 data sheet for more information on the functionality of these signals.
Digital Signal Jumpers
Header Name Logic Jumper Position Effect
J5 DEV_EN 1 Left (TBT_OUT) DEV_OUT
Disabled
DEV_EN 0 Right (GND) DEV_OUT Enabled
J6 CBL_ILIM 1 Left (TBT_OUT) CBL_OUT using
higher current limit
CBL_ILIM 0 Right (GND) CBL_OUT using
lower current limit
5
SLVUA50–April 2014 TPS65980EVM
Submit Documentation Feedback Copyright © 2014, Texas Instruments Incorporated

TBT
IN
+
-
J1
DEV_EN
J5
OFF|ON
CBL_ILIM
J6
HI|LOW
+
-
J2
+
-
J3
+
-
J4
DEV
OUT
TBT
OUT
CBL
OUT
3.0V – 3.319V
0mA – 700mA
3.221V – 3.319V
5mA – 31mA
3.171V – 3.319V
0mA – 235mA
5.2V – 15.75V
TBT
IN
+
-
J1
DEV_EN
J5
OFF|ON
CBL_ILIM
J6
HI|LOW
+
-
J2
+
-
J3
+
-
J4
DEV
OUT
TBT
OUT
CBL
OUT
OUTPUT
OFF
3.135V – 3.4V
5mA – 50mA
OUTPUT
OFF
2.5V – 3.4V
Setup www.ti.com
2.3 Device Configurations
Figure 2,Figure 3,Figure 4, and Figure 5illustrate the three operating modes discussed in section 2.1 as
well as the two programmable CBL_OUT current limits.
This is the average output voltage range for normal loads. During light load, the peak output voltage from TBT_OUT
may surpass 3.4V, but not exceeding 3.42V
Figure 2. Low Voltage Input
This is the average output voltage range for normal loads. During light load, the average output voltage from
CBL_OUT may reach 3.4 with peaks not exceeding 3.42V.
Figure 3. High Voltage Input During Sleep
6TPS65980EVM SLVUA50–April 2014
Submit Documentation Feedback
Copyright © 2014, Texas Instruments Incorporated

TBT
IN
+
-
J1
DEV_EN
J5
OFF|ON
CBL_ILIM
J6
HI|LOW
+
-
J2
+
-
J3
+
-
J4
DEV
OUT
TBT
OUT
CBL
OUT
3.0V – 3.319V
0mA – 2500mA
3.221V – 3.319V
235mA – 1000mA
3.12V – 3.319V
0mA – 1440mA
10V – 15.75V
TBT
IN
+
-
J1
DEV_EN
J5
OFF|ON
CBL_ILIM
J6
HI|LOW
+
-
J2
+
-
J3
+
-
J4
DEV
OUT
TBT
OUT
CBL
OUT
3.0V – 3.319V
0mA – 2500mA
3.221V – 3.319V
235mA – 1000mA
3.171V – 3.319V
0mA – 720mA
5.2V – 15.75V
www.ti.com Setup
A This is the average output voltage range for normal loads. During light load, the average output voltage from
TBT_OUT and CBL_OUT may reach 3.4 with peaks not exceeding 3.42V
B The total combined output current from TBT_OUT, CBL_OUT, and DEV_OUT should never exceed 3.5A.
Figure 4. High Voltage Input With Lower CBL_OUT Current Limit
A This is the average output voltage range for normal loads. During light load, the average output voltage from
TBT_OUT and CBL_OUT may reach 3.4 with peaks not exceeding 3.42V
B The total combined output current from TBT_OUT, CBL_OUT, and DEV_OUT should never exceed 3.5A.
Figure 5. High Voltage Input With Higher CBL_OUT Current Limit
7
SLVUA50–April 2014 TPS65980EVM
Submit Documentation Feedback Copyright © 2014, Texas Instruments Incorporated

Setup www.ti.com
2.4 Test Points
Several test points are provided solely for the purpose measuring certain signals. It is NOT recommended
to use the test points to supply power to TBT_IN or load TBT_OUT, CBL_OUT, or DEV_OUT.
Table 2. Test Point Descriptions
Test Point Signal Description
TP1 GND
TP2 DEV_OUT
TP3 Switching Node
TP4 BOOT
TP5 GND
TP6 TBT_IN
TP7 GND
TP8 TBT_OUT
TP9 Compensation Pin
TP10 GND
TP11 GND
TP12 Soft Start Pin
TP13 RESET_N Signal
TP14 HV_OK Signal
TP15 GND
TP16 CBL_OUT
8TPS65980EVM SLVUA50–April 2014
Submit Documentation Feedback
Copyright © 2014, Texas Instruments Incorporated

www.ti.com Board Assembly and Layout
3 Board Assembly and Layout
Figure 6 and Figure 7 show the top and bottom assembly for the TPS65980EVM.
Figure 6. Top Layer Assembly
Figure 7. Bottom Layer Assembly
9
SLVUA50–April 2014 TPS65980EVM
Submit Documentation Feedback Copyright © 2014, Texas Instruments Incorporated

Board Assembly and Layout www.ti.com
Figure 8 and Figure 9 show the top and bottom layout for the TPS65980EVM.
Figure 8. Top Layer Routing
Figure 9. Bottom Layer Routing
