Texas Instruments LM5185-Q1 User manual

EVM User's Guide: LM5185EVM-SIO
LM5185-Q1 Single-Isolated-Output Evaluation Module
Description
The LM5185-Q1 controller uses an external power
MOSFET and has adjustable loop compensation and
current limit. All these features bring flexibility and
design optimization for power scaling, transformer
design, and BOM optimization, as well as
overall performance and solution cost. Other user
programmabilities are also supported including
the input UVLO with hysteresis, soft-start, and
temperature compensation.
Get Started
1. Order the EVM at ti.com.
2. Read this user's guide carefully.
3. Prepare the bench setup per instructions. Take
cautions to prevent damage by ESD when
handling the EVM.
4. Power up the EVM by following the recommended
steps.
5. Run tests and measurements. Take cautions of
high voltage and hot temperature produced by the
EVM during test.
Features
• Wide input voltage range (default 20V to 60V,
extendable 6V to 90V)
• Tight voltage regulation of the isolated output
without opto-coupler: 16.4V ±1.5%
• Removal of the opto-coupler and transformer aux
winding saves solution size and cost.
• Peak conversion efficiency > 90%
• Programmable loop compensation, current limit,
input UVLO, and thermal compensation allowing
for flexible and optimal designs.
Applications
•Traction inverters
•Onboard charger (OBC)
•HEV/EV HVAC and heater
•Micro inverters
•Motor drives
• Battery Management Systems (BMS)
• Generic IGBT, MOSFET, GaN and SiC gate drivers
• PoE PD dc-dc converters
• Generic isolated bias power rails for industrial and
telecom systems
www.ti.com Description
SNVU869 – AUGUST 2023
Submit Document Feedback
LM5185-Q1 Single-Isolated-Output Evaluation Module 1
Copyright © 2023 Texas Instruments Incorporated

1 Evaluation Module Overview
1.1 Introduction
The LM5185-Q1 single-isolated-output (SIO) evaluational module (EVM), otherwise known as LM5185EVM-SIO,
is designed to demonstrate the features and functionality of the LM5185-Q1 device. The device is a 100-VIN
Primary-Side-Regulated (PSR) flyback DC/DC controller based on sampling the primary winding voltage of the
transformer to achieve tight output regulation and high efficiency, without using the opto coupler nor tertiary bias
winding like in a conventional flyback converter.
This user's guide describes the characteristics and operation of the evaluataion module LM5185EVM-SIO.
This document provides examples and instructions on how to use the evaluation module, and presents typical
performance curves and key waveforms. Throughout this document, the terms of evaluation board, evaluation
module, and EVM are synonymous with the LM5185EVM-SIO. This document also includes a schematic,
reference printed circuit board (PCB) layout, and a complete bill of materials (BOM).
1.2 Kit Contents
Table 1-1 details the contents of the EVM kit. Contact the TI Product Information Center at [phone] if any
component is missing. Download the latest versions of the related software on the TI website, www.ti.com.
Table 1-1. EVM Kit Contents
ITEM QUANTITY
LM5185EVM-SIO 1
1.3 Specification
Figure 1-1 shows the simplified schematic of the LM5185EVM-SIO circuit board. Table 1-2 shows the
specifications of the EVM in the factory default settings.
VIN
FB
RSET
TC
SS
AGND
EN/UVLO
DFLY
COUT
RSNB CSNB
DZ
RDMY
GATE
CS
PGND
COMP
VCC
RCS
Q1
CVCC
RFB
DCLAMP
DF
CIN
CSS
RSET
RTC
RCOMP
CCOMP CHF
RUVH
RUVL
RFLT
CFLT
T1
Figure 1-1. LM5185 PSR Flyback Converter Simplified Schematic
Evaluation Module Overview www.ti.com
2LM5185-Q1 Single-Isolated-Output Evaluation Module SNVU869 – AUGUST 2023
Submit Document Feedback
Copyright © 2023 Texas Instruments Incorporated

Table 1-2. Electrical Performance Characteristics
PARAMETER TEST CONDITION MIN TYP MAX UNIT
INPUT CHARACTERISTICS
Input voltage range, VIN 20 60 V
Input voltage turn on, VIN_ON Adjustable using EN/UVLO divider resistors 19
Input voltage turnoff, VIN_OFF 18
Input current, operating with no load, IIN_NL IOUT = 0 A VIN = 20 V 5.57 mA
VIN = 60 V 3.32
Input current, disabled, IIN_OFF, excluding the
external UVLO resistor leak current
VEN = 0 V, removing R6 VIN = 20 V 5.0 µA
VIN = 40 V 10.0
VIN = 60 V 20.0
OUTPUT CHACTERISTICS
Output voltage, VOUT 16.154 16.400 16.646 V
Max output current, IOUT VIN = 20 V 1.0 A
VIN = 40 V 1.5 A
VIN = 60 V 1.8 A
Soft-start time, tSS IOUT = 1 A 25 ms
SYSTEM CHARACTERISTICS
Switching Frequency VIN = 48 V, IOUT = 0.5 A 350 kHz
Half-load efficiency, ηHALF IOUT = 0.5A VIN = 20 V 90.2
VIN = 40 V 84.3
VIN = 60 V 82.0
Full load efficiency, ηFULL IOUT = 1.0A VIN = 20 V 90.5
VIN = 40 V 89.9
VIN = 60 V 86.9
Isolation rating(3) RMS voltage 1500 V
LM5180 junction temperature, TJ-40 150 °C
1.4 Device Information
The factory default settings of the EVM allow the operation with an input voltage range from 20 V to 60 V. The
device produces a single isolated output voltage of 16.4 V ±1% @ 1 A load, and achieves > 90% peak efficiency.
Fine-tuning of the output voltage can be realized by adjusting the external resistor values at the FB pin. In
addition, the users can modify the EVM to enable the operation under a VIN down to 6 V with derated output
current of 0.4A by changing the EN/UVLO set point. Further lower input voltage down to 4.5V is supported by
the LM5185-Q1 but the EVM requires a different transformer. However, the maximum VIN voltage of the EVM
can be increased to 90 V if the power MOSFET is changed to a 150 V or higher rated device, and if the input
bulk capacitor is replaced with at least a 100 V rated part. Multiple isolated output can also be supported by the
LM5185-Q1 but requires a different transformer. Please refer to the Quick Start Design Calculator to help design.
Refer to TI product data sheet SNVSBT4 for more detailed information of the LM5185-Q1 PSR flyback controller.
www.ti.com Evaluation Module Overview
SNVU869 – AUGUST 2023
Submit Document Feedback
LM5185-Q1 Single-Isolated-Output Evaluation Module 3
Copyright © 2023 Texas Instruments Incorporated

2 Hardware
2.1 Setup
Figure 2-1 shows the diagram of EVM bench test setup. Refer to Section 2.2 and Section 2.3 in this user's guide
for detailed information of headers, jumpers and test points. Refer to Section 2.4 for the setup assembly and test
procedure. Refer to Section 2.5 for the important notice on safety concerns when handling the EVM.
Power Supply
- +
Ammeter 1
ACOM
Voltmeter 1
VCOM
Load
-+
Ammeter 2
ACOM
Voltmeter 2
VCOM
Figure 2-1. EVM Test Setup
The test setup consists the following instruments in addition to the EVM board.
•Power Supply: The input dc voltage source capable of at least 0-80-V and 2 A.
•Load: The load must be electronic constant-resistance (CR) or constant-current (CC) mode load, capable of
0 Adc to 2 Adc up to 20 V. For a no-load input current measurement, disconnect the electronic load as the
load can draw a small residual current.
•Multimeters:
–Voltmeter 1: Input voltage at VIN+ to VIN–. Set voltmeter to an input impedance of 100 MΩ.
–Voltmeter 2: Output voltage at VOUT+ to VOUT-. Set voltmeter to an input impedance of 100 MΩ.
–Ammeter 1: Input current. Set ammeter to 1-second aperture time.
–Ammeter 2: Output current. Set ammeter to 1-second aperture time
•Oscilloscope: With the scope set to 20-MHz bandwidth and AC coupling, measure the output voltage ripple
directly across an output capacitor with a short ground lead normally provided with the scope probe. Place
the oscilloscope probe tip on the positive terminal of the output capacitor, holding the ground barrel of the
probe through the ground lead to the negative terminal of the capacitor. TI does not recommend using
a long-leaded ground connection because this can induce additional noise given a large ground loop. To
measure other waveforms, adjust the oscilloscope as needed.
2.2 Header Information
Table 2-1 lists the header information of the EVM.
Table 2-1. Header Information
HEADER SIGNAL DESCRIPTION
J1-1 VIN+ Voltage source input port.
J1-2 VIN- Voltage source input return.
J2 VOUT+ Output voltage port.
J3 VOUT- Output voltage return port, and also the isolated ground reference ISO-GND.
J4 PGND Primary side power ground reference.
J5-1 EN/UVLO Enable and UVLO control signal. Closing J5-1 and J5-2 disables the EVM.
J5-2 AGND Analog signal reference ground.
Hardware www.ti.com
4LM5185-Q1 Single-Isolated-Output Evaluation Module SNVU869 – AUGUST 2023
Submit Document Feedback
Copyright © 2023 Texas Instruments Incorporated

2.3 Test Points
The EVM has a variety of test points available for measuring and debugging purposes. Table 2-2 explains the
purpose of each test point.
Table 2-2. EVM Test Points
TEST POINT SIGNAL DESCRIPTION
TP1 VIN PSR Flyback dc-dc stage input voltage
TP2 PGND Primary side power ground reference
TP3 VOUT Isolated output voltage
TP4 COMP Compensation circuit node for the error amplifier
TP5 RSET Output voltage set pin
TP6 ISO-GND Isolated output ground reference
2.4 Assembly Instructions
Refer to Section 2.5 of this user's guide for the important notice on safety concerns when handling the EVM. The
following are the recommended instructions for the EVM test setup assembly.
Input Connections
• Prior to connecting the DC input source, set the current limit of the input supply to 100 mA maximum. Verify
the input source is initially set to 0 V and connected to the VIN+ and VIN– connection points, as shown in
Figure 2-1. An additional input bulk capacitor is recommended to provide damping if long input lines are used.
• Connect Voltmeter 1 at VIN+ and VIN– connection points to measure the input voltage.
• Connect Ammeter 1 to measure the input current and set to at least 1-second aperture time.
Output Connections
• Connect electronic load to VOUT+ and VOUT- connection points as shown in Figure 2-1. Set the load to
constant-resistance mode or constant-current mode at 0 A before applying input voltage.
• Connect Voltmeter 2 at VOUT+ and VOUT- connection points to measure the output voltage.
• Connect Ammeter 2 measure the output current.
Test Procedure
• Set up the EVM as described above.
• Set load to constant resistance or constant current mode and to sink 10 mA.
• Increase input source from 0 V to 20 V; use voltmeter 1 to measure the input voltage.
• Increase the current limit of the input supply to 1000 mA.
• Use voltmeter 2 to measure the output voltage, vary the load from 10 mA to 1000 mA DC; VOUT must
remain within the load regulation specification.
• Set the load current to 500 mA (50% rated load) and vary the input source voltage from 20 V to 60 V; VOUT
must remain within the line regulation specification.
• Use the oscilloscope to probe different signals of interest. Be careful of the probe ground reference.
• Decrease load to 10 mA. Decrease input source voltage to 0 V.
• Shut down both the input source and load, and then the voltmeters and ammeters.
2.5 Best Practices
Please take caution when handling the EVM. Operating the EVM board with up to 60 VIN can generate >75 V
voltage at certain circuit nodes as marked by the high voltage symbol on the PCB. Operating the EVM board
with the maximum load can generate hot spots in certain areas of the PCB as marked by the hot surface
symbols. Please read the following notices carefully.
WARNING
www.ti.com Hardware
SNVU869 – AUGUST 2023
Submit Document Feedback
LM5185-Q1 Single-Isolated-Output Evaluation Module 5
Copyright © 2023 Texas Instruments Incorporated

Always follow TI’s set-up and application instructions, including use of all interface components within their
recommended electrical rated voltage and power limits. Always use electrical safety precautions to help ensure
your personal safety and the safety of those working around you. Contact TI’s Product Information Center http://
support.ti.com for further information.
Save all warnings and instructions for future reference.
Failure to follow warnings and instructions can result in personal injury, property damage, or death due
to electrical shock and/or burn hazards.
The term TI HV EVM refers to an electronic device typically provided as an open framed, unenclosed printed-
circuit board assembly. It is intended strictly for use in development laboratory environments, solely for qualified
professional users having training, expertise, and knowledge of electrical safety risks in development and
application of high-voltage electrical circuits. Any other use and/or application are strictly prohibited by Texas
Instruments. If you are not suitably qualified, you should immediately stop from further use of the HV EVM.
•Work Area Safety:
– Maintain a clean and orderly work area.
– Qualified observers must be present anytime circuits are energized.
– Effective barriers and signage must be present in the area where the TI HV EVM and interface electronics
are energized, indicating operation of accessible high voltages can be present, for the purpose of
protecting inadvertent access.
– All interface circuits, power supplies, evaluation modules, instruments, meters, scopes, and other related
apparatus used in a development environment exceeding 50 VRMS/75 VDC must be electrically located
within a protected Emergency Power Off (EPO) protected power strip.
– Use a stable and non-conductive work surface.
– Use adequately insulated clamps and wires to attach measurement probes and instruments. No freehand
testing whenever possible.
•Electrical Safety:
As a precautionary measure, it is always a good engineering practice to assume that the entire EVM can
have fully accessible and active high voltages.
– De-energize the TI HV EVM and all inputs, outputs, and electrical loads before performing any electrical or
other diagnostic measurements. Confirm that TI HV EVM power has been safely de-energized.
– With the EVM confirmed de-energized, proceed with required electrical circuit configurations, wiring,
measurement equipment hook-ups, and other application needs, while still assuming the EVM circuit and
measuring instruments are electrically live.
– When EVM readiness is complete, energize the EVM as intended.
WARNING
WARNING: While the EVM is energized, never touch the EVM or its electrical circuits as
the EVM and circuits can be at high voltages capable of causing electrical shock hazard.
•Personal Safety:
– Wear personal protective equipment, for example, latex gloves and/or safety glasses with side shields or
protect EVM in an adequate lucent plastic box with interlocks from accidental touch.
•Limitation for Safe Use:
– EVMs are not to be used as all or part of a production unit.
Safety and Precautions
The EVM is designed for professionals who have received the appropriate technical training, and is designed
to operate from an AC power supply or a high-voltage DC supply. Please read this user guide and the safety-
related documents that come with the EVM package before operating this EVM.
Hardware www.ti.com
6LM5185-Q1 Single-Isolated-Output Evaluation Module SNVU869 – AUGUST 2023
Submit Document Feedback
Copyright © 2023 Texas Instruments Incorporated

CAUTION
!
Do not leave the EVM powered when unattended.
WARNING
Hot surface! Contact can cause burns. Do not touch!
WARNING
High Voltage! Electric shock is possible when connecting board to live wire. Board must be handled
with care by a professional.
For safety, use of isolated test equipment with overvoltage and overcurrent protection is highly
recommended.
www.ti.com Hardware
SNVU869 – AUGUST 2023
Submit Document Feedback
LM5185-Q1 Single-Isolated-Output Evaluation Module 7
Copyright © 2023 Texas Instruments Incorporated

3 Implementation Results
3.1 Performance Data and Results
Figure 3-1 through Figure 3-8 presents typical performance curves for the LM5185EVM-SIO. Because actual
performance data can be affected by measurement techniques and environmental variables, these curves are
presented for reference and the curves can differ from actual field measurements.
3.1.1 Conversion Efficiency
Load Current (A)
Efficiency (%)
0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1
0
10
20
30
40
50
60
70
80
90
100
VIN = 20 V
VIN = 30 V
VIN = 40 V
VIN = 50 V
VIN = 60 V
Figure 3-1. EVM Efficiency vs. Load and Input Voltage
3.1.2 Output Voltage Regulation
Load Current (A)
Output Voltage Deviation (%)
0 0.2 0.4 0.6 0.8 1 1.2 1.4
-1%
-0.8%
-0.6%
-0.4%
-0.2%
0
0.2%
0.4%
0.6%
0.8%
1%
VIN = 20 V
VIN = 40 V
VIN = 60 V
Figure 3-2. EVM Output Voltage Regulation vs Load and Input Voltage
Implementation Results www.ti.com
8LM5185-Q1 Single-Isolated-Output Evaluation Module SNVU869 – AUGUST 2023
Submit Document Feedback
Copyright © 2023 Texas Instruments Incorporated

3.1.3 Operating Waveforms
3.1.3.1 Start-up
C1=Vin; C2=Vout; C3=COMP; C4=SW
Figure 3-3. Start-up Under No Load: Vin=24V, Iout=0A
C1=Vin; C2=Vout; C3=COMP; C4=SW
Figure 3-4. Start-up Under Full Load: Vin=24V, Iout=1A
www.ti.com Implementation Results
SNVU869 – AUGUST 2023
Submit Document Feedback
LM5185-Q1 Single-Isolated-Output Evaluation Module 9
Copyright © 2023 Texas Instruments Incorporated

3.1.3.2 Load Transient Response
C1=Vin; C2=Vout (ac coupled); C3=Vcomp; C4=Iout
Figure 3-5. Load Transient Response: Vin=24V, 0.625A to 1.25A Load Transients
3.1.3.3 Switching
C1=SW; C2=Vsec; C4=Vcomp
Figure 3-6. FFM Operation: VIN=48 V, Iout= 0.1A
Implementation Results www.ti.com
10 LM5185-Q1 Single-Isolated-Output Evaluation Module SNVU869 – AUGUST 2023
Submit Document Feedback
Copyright © 2023 Texas Instruments Incorporated

C1=SW; C2=Vsec; C4=Vcomp
Figure 3-7. DCM Operation: Vin=48V, Iout=0.5A
Figure 3-8. BCM Operation: Vin=48V, Iout=1.0A
www.ti.com Implementation Results
SNVU869 – AUGUST 2023
Submit Document Feedback
LM5185-Q1 Single-Isolated-Output Evaluation Module 11
Copyright © 2023 Texas Instruments Incorporated

3.2 Thermal Performance
Figure 3-9. EVM Thermal Image. Vin=48V, Iout=1.0A
Implementation Results www.ti.com
12 LM5185-Q1 Single-Isolated-Output Evaluation Module SNVU869 – AUGUST 2023
Submit Document Feedback
Copyright © 2023 Texas Instruments Incorporated

4 Hardware Design Files
4.1 Schematic
Figure 4-1 shows the complete schematic of the EVM.
PGND
0.1uF
C24
294k
R15
PGND
PGND
10.0k
R18
4.7uF
C14
100pF
C20
12.1k
R17
0.022uF
C25
C10
1000pF
1
2
J1
AGND
47pF
C22
SW
0
R8
VIN_EMI
1). UVLO rising ~19V
2). UVLO falling ~18V
19-V to 60-V
200k
R6
PGND
NT1
Net-Tie
AGND
4.7uF
C6
4.7uF
C7
VIN
VIN
VIN VCC
ISO-GND
ISO-GND
VIN
PGND
VOUT
J2
J3
22uH
L1
100
R13
4.7uF
C4
3.01
R2
10
65
1
2
3NC
4 7
NC 8
9
T1
ZD2250-AE
1
3
2
100V
D2
22uF
C17
22uF
C18 C16
100uF
18V
D4
PGND
3.24k
R9
150pF
C11
100
R4
100nF
C15
100nF
C8
100nF
C3
100nF
C19
0
R12
150pF
C12
100
R7
0.02
R14
16.9k
R16
2 1
100V
D3
1000pF
C21
1.0k
R11
C1
1000pF
TP5
TP4
10.0
R5
10 VCC
14 VIN
7COMP
CS 9
1EN/UVLO
15
EP
13
FB
LO 11
4RSET
6SS/BIAS
3TC
NC 2
NC 12
5
AGND 8
PGND
LM5185-Q1
U1
D1
28V
1
J4
TP2
TP6
TP1
TP3
165k
R10
100pF
C13
1 2
34
L2
0.1uF
C2
0.1uF
C23
0
R1
0
R3
4.7uF
C5
+
47uF
C9
4
1 5-6
2 3
100V
Q1
2
1
J5
AGND
EN
Figure 4-1. LM5185EVM-SIO Schematic
www.ti.com Hardware Design Files
SNVU869 – AUGUST 2023
Submit Document Feedback
LM5185-Q1 Single-Isolated-Output Evaluation Module 13
Copyright © 2023 Texas Instruments Incorporated

4.2 PCB Layout
Figure 4-2 through Figure 4-7 show the printed circuit board layout of the EVM.
Figure 4-2. Top Layer Silkscreen (Top View)
Figure 4-3. Top Layer Layout (Top View)
Hardware Design Files www.ti.com
14 LM5185-Q1 Single-Isolated-Output Evaluation Module SNVU869 – AUGUST 2023
Submit Document Feedback
Copyright © 2023 Texas Instruments Incorporated

Figure 4-4. Mid Layer 1 Layout (Top View)
Figure 4-5. Mid Layer 2 Layout (Top View)
www.ti.com Hardware Design Files
SNVU869 – AUGUST 2023
Submit Document Feedback
LM5185-Q1 Single-Isolated-Output Evaluation Module 15
Copyright © 2023 Texas Instruments Incorporated

Figure 4-6. Bottom Layer Layout (Bottom View)
Figure 4-7. Bottom Layer Silkscreen (Bottom View)
Hardware Design Files www.ti.com
16 LM5185-Q1 Single-Isolated-Output Evaluation Module SNVU869 – AUGUST 2023
Submit Document Feedback
Copyright © 2023 Texas Instruments Incorporated

4.3 Bill of Materials (BOM)
Table 4-1 lists the LM5185EVM-SIO bill of materials (BOM).
Table 4-1. Bill of Materials
Designator Qty Description PartNumber Manufacturer
C1 1 CAP, CERM, 1000 pF, 2000 V, +/- 10%, X7R, 1206_190 202R18W102KV4E Johanson
Technology
C2 1 CAP, CERM, 0.1 uF, 100 V, +/- 10%, X7R, 1206 GRM319R72A104KA01D MuRata
C3, C8, C15,
C19
4 CAP, CERM, 0.1 uF, 100 V, +/- 10%, X7R, 0603 GRM188R72A104KA35D MuRata
C4, C5, C6,
C7
4 CAP, CERM, 4.7 uF, 100 V, +/- 10%, X7S, 1210 C3225X7S2A475K200AB TDK
C9 1 Aluminum Electrolytic Capacitor 47uF 20% 80 V
10.3x10.3x10.5mm SMT
865081757008 Wurth Electronics
C11, C12 2 0603 150 pF 100 V ±5 % Tolerance C0G/NP0 SMT
Multilayer Ceramic Capacitor
06031A151JAT2A KYOCERA AVX
C14 1 CAP, CERM, 4.7 uF, 16 V,+/- 10%, X7R, 0603 GRM188Z71C475KE21D MuRata
C16 1 CAP, AL, 100 uF, 25 V, +/- 20%, 0.34 ohm, AEC-Q200
Grade 2, SMD
EEE-FK1E101XP Panasonic
C17, C18 2 CAP, CERM, 22 uF, 25 V, +/- 10%, X7R, 1210 GRM32ER71E226KE15L MuRata
C20 1 CAP, CERM, 100 pF, 50 V, +/- 5%, C0G/NP0, 0603 GRM1885C1H101JA01D MuRata
C21 1 CAP, CERM, 1000 pF, 100 V, +/- 5%, C0G/NP0, AEC-
Q200 Grade 1, 0603
GCM1885C2A102JA16D MuRata
C22 1 CAP, CERM, 47 pF, 50 V,+/- 5%, C0G/NP0, AEC-Q200
Grade 0, 0603
CGA3E2NP01H470J080AA TDK
C24 1 CAP, CERM, 0.1 uF, 16 V, +/- 5%, X7R, 0603 C0603C104J4RACTU Kemet
C25 1 CAP, CERM, 0.022 uF, 25 V, +/- 10%, X7R, 0603 C0603C223K3RACTU Kemet
D1 1 Diode, Zener, 28 V, 5 W, SMB SMBJ5362B-TP Micro Commercial
Components
D2 1 Diode, Schottky, 100 V, 5 A, PowerDI5 SDT5H100LP5-7 Diodes Inc.
D3 1 Diode 100 V 1 A Surface Mount SOD-123H ACDBMT1100-HF Comchip
Technology
D4 1 Diode, Zener, 18 V, 1 W, AEC-Q101, SMA SMAZ18-13-F Diodes Inc.
L1 1 Inductor, Shielded, Composite, 22 uH, 3.4 A, 0.1 ohm,
SMD
XAL5050-223MEB Coilcraft
Q1 1 N-Channel 100 V 8.4A (Ta), 31 A (Tc) 3.6W (Ta), 49 W (Tc)
Surface Mount 5-DFN (5x6) (8-SOFL)
NVMFS021N10MCLT1G Onsemi
R1, R3 2 RES, 0, 5%, 0.25 W, AEC-Q200 Grade 0, 1206 ERJ-8GEY0R00V Panasonic
R2 1 RES, 3.01, 1%, 0.125 W, 0805 RC0805FR-073R01L Yageo America
R4, R7 2 RES, 100, 1%, 0.25 W, AEC-Q200 Grade 0, 1206 ERJ-8ENF1000V Panasonic
R5 1 RES, 10.0, 1%, 0.1 W, 0603 RC0603FR-0710RL Yageo
R6 1 RES, 200 k, 1%, 0.1 W, 0603 RC0603FR-07200KL Yageo
R8 1 RES, 0, 5%, 0.125 W, AEC-Q200 Grade 0, 0805 ERJ-6GEY0R00V Panasonic
R9 1 RES, 3.24 k, 1%, 0.25 W, AEC-Q200 Grade 0, 1206 ERJ-8ENF3241V Panasonic
R10 1 RES, 165 k, 1%, 0.1 W, AEC-Q200 Grade 0, 0603 CRCW0603165KFKEA Vishay-Dale
R11 1 RES, 1.0 k, 5%, 0.1 W, 0603 RC0603JR-071KL Yageo
R12 1 RES, 0, 5%, 0.1 W, 0603 RC0603JR-070RL Yageo
R13 1 RES, 100, 1%, 0.1 W, 0603 RC0603FR-07100RL Yageo
R14 1 RES, 0.02, 1%, 1 W, 0612 PRL1632-R020-F-T1 Susumu Co Ltd
R16 1 RES, 16.9 k, 1%, 0.1 W, 0603 RC0603FR-0716K9L Yageo
R17 1 RES, 12.1 k, 1%, 0.1 W, 0603 RC0603FR-0712K1L Yageo
R18 1 RES, 10.0 k, 1%, 0.1 W, 0603 RC0603FR-0710KL Yageo
www.ti.com Hardware Design Files
SNVU869 – AUGUST 2023
Submit Document Feedback
LM5185-Q1 Single-Isolated-Output Evaluation Module 17
Copyright © 2023 Texas Instruments Incorporated

Table 4-1. Bill of Materials (continued)
Designator Qty Description PartNumber Manufacturer
T1 1 Flyback Transformer, 12 µH, 4.1A Isat, 1 : 1 turns ratio,
EFD15 10PIN SMD
ZD2250-AE Coilcraft
U1 1 100-VIN PSR Flyback Automotive DC/DC Controller With
Low IQ and Low EMI, HTSSOP14
LM5185-Q1 Texas Instruments
5 Compliance Information
5.1 Compliance and Certifications
LM5185EVM-SIO EU Declaration of Conformity (DoC) for Restricting the Use of Hazardous Substances (RoHS)
(SSZQR78)
6 Additional Information
6.1 Trademarks
All trademarks are the property of their respective owners.
Compliance Information www.ti.com
18 LM5185-Q1 Single-Isolated-Output Evaluation Module SNVU869 – AUGUST 2023
Submit Document Feedback
Copyright © 2023 Texas Instruments Incorporated

STANDARD TERMS FOR EVALUATION MODULES
1. Delivery: TI delivers TI evaluation boards, kits, or modules, including any accompanying demonstration software, components, and/or
documentation which may be provided together or separately (collectively, an “EVM” or “EVMs”) to the User (“User”) in accordance
with the terms set forth herein. User's acceptance of the EVM is expressly subject to the following terms.
1.1 EVMs are intended solely for product or software developers for use in a research and development setting to facilitate feasibility
evaluation, experimentation, or scientific analysis of TI semiconductors products. EVMs have no direct function and are not
finished products. EVMs shall not be directly or indirectly assembled as a part or subassembly in any finished product. For
clarification, any software or software tools provided with the EVM (“Software”) shall not be subject to the terms and conditions
set forth herein but rather shall be subject to the applicable terms that accompany such Software
1.2 EVMs are not intended for consumer or household use. EVMs may not be sold, sublicensed, leased, rented, loaned, assigned,
or otherwise distributed for commercial purposes by Users, in whole or in part, or used in any finished product or production
system.
2Limited Warranty and Related Remedies/Disclaimers:
2.1 These terms do not apply to Software. The warranty, if any, for Software is covered in the applicable Software License
Agreement.
2.2 TI warrants that the TI EVM will conform to TI's published specifications for ninety (90) days after the date TI delivers such EVM
to User. Notwithstanding the foregoing, TI shall not be liable for a nonconforming EVM if (a) the nonconformity was caused by
neglect, misuse or mistreatment by an entity other than TI, including improper installation or testing, or for any EVMs that have
been altered or modified in any way by an entity other than TI, (b) the nonconformity resulted from User's design, specifications
or instructions for such EVMs or improper system design, or (c) User has not paid on time. Testing and other quality control
techniques are used to the extent TI deems necessary. TI does not test all parameters of each EVM.
User's claims against TI under this Section 2 are void if User fails to notify TI of any apparent defects in the EVMs within ten (10)
business days after delivery, or of any hidden defects with ten (10) business days after the defect has been detected.
2.3 TI's sole liability shall be at its option to repair or replace EVMs that fail to conform to the warranty set forth above, or credit
User's account for such EVM. TI's liability under this warranty shall be limited to EVMs that are returned during the warranty
period to the address designated by TI and that are determined by TI not to conform to such warranty. If TI elects to repair or
replace such EVM, TI shall have a reasonable time to repair such EVM or provide replacements. Repaired EVMs shall be
warranted for the remainder of the original warranty period. Replaced EVMs shall be warranted for a new full ninety (90) day
warranty period.
WARNING
Evaluation Kits are intended solely for use by technically qualified,
professional electronics experts who are familiar with the dangers
and application risks associated with handling electrical mechanical
components, systems, and subsystems.
User shall operate the Evaluation Kit within TI’s recommended
guidelines and any applicable legal or environmental requirements
as well as reasonable and customary safeguards. Failure to set up
and/or operate the Evaluation Kit within TI’s recommended
guidelines may result in personal injury or death or property
damage. Proper set up entails following TI’s instructions for
electrical ratings of interface circuits such as input, output and
electrical loads.
NOTE:
EXPOSURE TO ELECTROSTATIC DISCHARGE (ESD) MAY CAUSE DEGREDATION OR FAILURE OF THE EVALUATION
KIT; TI RECOMMENDS STORAGE OF THE EVALUATION KIT IN A PROTECTIVE ESD BAG.

www.ti.com
2
3Regulatory Notices:
3.1 United States
3.1.1 Notice applicable to EVMs not FCC-Approved:
FCC NOTICE: This kit is designed to allow product developers to evaluate electronic components, circuitry, or software
associated with the kit to determine whether to incorporate such items in a finished product and software developers to write
software applications for use with the end product. This kit is not a finished product and when assembled may not be resold or
otherwise marketed unless all required FCC equipment authorizations are first obtained. Operation is subject to the condition
that this product not cause harmful interference to licensed radio stations and that this product accept harmful interference.
Unless the assembled kit is designed to operate under part 15, part 18 or part 95 of this chapter, the operator of the kit must
operate under the authority of an FCC license holder or must secure an experimental authorization under part 5 of this chapter.
3.1.2 For EVMs annotated as FCC – FEDERAL COMMUNICATIONS COMMISSION Part 15 Compliant:
CAUTION
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to
operate the equipment.
FCC Interference Statement for Class A EVM devices
NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to
correct the interference at his own expense.
FCC Interference Statement for Class B EVM devices
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more
of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
3.2 Canada
3.2.1 For EVMs issued with an Industry Canada Certificate of Conformance to RSS-210 or RSS-247
Concerning EVMs Including Radio Transmitters:
This device complies with Industry Canada license-exempt RSSs. Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2) this device must accept any interference, including interference that may
cause undesired operation of the device.
Concernant les EVMs avec appareils radio:
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation
est autorisée aux deux conditions suivantes: (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit
accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.
Concerning EVMs Including Detachable Antennas:
Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser)
gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the antenna type
and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for
successful communication. This radio transmitter has been approved by Industry Canada to operate with the antenna types
listed in the user guide with the maximum permissible gain and required antenna impedance for each antenna type indicated.
Antenna types not included in this list, having a gain greater than the maximum gain indicated for that type, are strictly prohibited
for use with this device.
