Texecom Prestige External Series User manual

Prestige External Series
Installation Manual
Issue 2

1 INS352-2
1 2
3
Remove the top cap and loosen screw
(screw retained in wall plate).
Push up head unit and remove.
Use a flat head screwdriver to lever out both
sides of the terminal cover as shown.
1. Accessing the Unit

INS352-2 2
2. Choosing a Location
Parallel
✓
1.0 - 1.4m
•Mounting height 1.0 - 1.4m (nominal 1.2m), measured to middle of unit.
•Mount perpendicular to ground.
•Try to avoid direct sunlight.
•Avoid pointing at swaying bushes/trees and
swaying clothes on a clothes line. ✗
✗
•Try to install the detector so its detection area is
terminated by building/fences etc. This will reduce
the effect of range variation caused by environmental
changes.
•In the detection area try to avoid reflective surfaces
such as standing water, swimming pools or polished
floors as this can cause the detectors range or coverage
to vary as reflected signals may be seen.
✗

3 INS352-2
3. Mounting the Unit
WALL MOUNTING
For wall mounting, the
cable should be brought
through the wall into the
cable entry hole.
Cable Entry
Cable Entry
Conduit Entry
Cable
Channels
SURFACE WIRING
For surface wiring, use the appropriate knockout in the
top or bottom of the unit. If wiring from the top, use the
knockouts in the top cap and run the cable down the
cable channels and into the unit as shown.
REAR TAMPER
To enable the rear tamper, the breakaway keyhole
section must be securely fixed to the mounting surface.
Front View
Rear View
Cable Entry
Knockout in Top Cap
POLE MOUNTING
Using the pole mount kit (available separately) the unit
can be mounted on poles with an outside diameter of
39 - 43mm. Assemble the kit around the pole as shown
and tighten the 4 bolts. Hook the detector wall plate
onto the kit and secure the remaining 2 bolts through
the lower mounting holes.
Diameter
Ø 39 - 43mm
1.
2.
4.3.

JP1: Pulse Count
4. Wiring the Unit
INS352-2 4
0.3 - 3.0m/s
3
2
4
JP2: Sensitivity
MEDIUMHIGH LOW
JP3: Alarm
NO: alarm relay normally open.NC: alarm relay normally closed.
TERMINAL BLOCK
12V & 0V: 9-16 VDC.
ALARM:NO/NC (selectable) relay output.
18 Ω, 50VDC, 100mA Max.
TAMPER:NC Relay output.
18 Ω, 50VDC, 100mA Max.
RLED:0V: LED off.
12V or No Connection: LED on.
AUX:NC relay input.
NC = Normally Closed, NO = Normally Open

5 INS352-2
JP4: LED
JP5: MODE
JP6 & JP7: END OF LINE JUMPERS
JP7
Selects the End-of-Line
resistance. Equivalent
to wiring a resistor of
the selected value as
shown.
JP6
Selects the resistance across the alarm
relay. Equivalent to wiring a resistor of the
selected value as shown.
TAMPER - JP6ALARM - JP7
Night Mode
Detector only operates at night.
Day/Night Mode
Detector is always operating.
JP8 & JP9: see Auxiliary section (page 9)

INS352-2 6
5. Range Adjustment - Microwave (only on Prestige External DT)
VR1
MIN
MID
MAX
2m
6'6"
12m
39'4"
VR1
MIN
MID
MAX
VR1
MIN
MID
MAX
Ensure microwave range is set correctly to avoid detection of objects beyond the
desired area of protection.

7 INS352-2
6. Range Adjustment - PIR
1.2m
2m 4m 6m 8m 10m 12m
0m
0m
1.2m
2m 4m 6m 8m 10m 12m
0m
0m
1.2m
2m 4m 6m 8m 10m 12m
0m
0m
1.2m
2m 4m 6m 8m 10m 12m
0m
0m
Position - 12m Coverage
Position - 8m Coverage
Position - 5m Coverage
Position - 2m Coverage
Selected Range Side View
Bottom of head unit
To adjust the range of the detector, rotate the
circular section shown until the desired range is
shown in the window.
Note: Range can vary due to environmental
conditions. To reduce the risk of false alarms
always select the lowest range possible for the
installation.
Specified ranges are valid for nominal 1.2m
mounting height.

2m 4m 6m 8m 10m 12m
0m
12m
10m
8m
6m
4m
2m
0m
12m 10m 8m 6m 4m 2m
Active
detection
coverage
INS352-2 8
7. Coverage Area
2m 4m 6m 8m 10m 12m
0m
12m
10m
8m
6m
4m
2m
0m
12m 10m 8m 6m 4m 2m
Active
detection
coverage
90˚
90˚
90˚
45˚
45˚
Bottom of head unit Bottom of head unit
Top View Top View
Walk-testing
With the range, sensitivity, coverage and pulse count set as desired, enable the LEDs and walk-through
the area of protection. Confirm the LEDs light and alarm relay activates.

9 INS352-2
8. Auxiliary Input
With the Auxiliary input enabled (JP8), a second detector with a normally
closed relay output can be connected to the Prestige External detector to give
directional detection. The order of activation required to give an alarm signal is
set by the direction jumper (JP9).
When this is set to ‘1st’ the auxiliary detector must be activated first followed by
the Prestige External detector within 1 minute to give a valid alarm signal.
With the jumper set to 2nd, the Prestige External detector must be activated
followed by the auxiliary detector within 1 minute.
If directional detection is not required, disable the auxiliary input using JP8.
AUX Prestige External PIR
AUX Prestige External PIR
JP8
ON
JP9
ALARM
NO
ALARM
1st
2nd
NO
ALARM
NO
ALARM
JP9
ALARM
NO
ALARM
1st
2nd
OFF
The Prestige External unit is designed to detect the movement of
an intruder and activate an alarm control panel. As the Prestige
External unit is not a complete alarm system, but only a part
thereof, Texecom cannot accept responsibility or liability for any
damages whatsoever based on a claim that the Prestige External
unit failed to function correctly.
Due to our policy of continuous improvement Texecom reserves
the right to change specification without prior notice. All
specifications are measured at 20ºC (68ºF).
Certificate Number: FM 35285 MADE IN ENGLAND
Quality Assurance
Warranty - 2 year replacement warranty.
The Prestige External detector is protected
by UK & International Designs.
Prestige is a Trademark of Texecom Ltd.

9. Specifications
INS352-2 10
10. Physical Specifications
Mounting Height: 1.0 - 1.4m, 1.2m nominal
Supply Voltage: 9-16 VDC
Current Drain (typical):
Prestige External TD 28mA
Prestige External DT 32mA
Detection Method:
Prestige External TD Dual, non-overlapping, digital PIR
Prestige External DT Dual, non-overlapping, digital PIR / Microwave
Range: 12m max. Adjustable to 8m, 5m and 2m
Alarm Output: NC/NO selectable relay. Rated 50VDC, 100mA, 18Ω
Tamper Detection: Wall and case. Sealed non-mechanical switch.
Tamper Output: NC relay. Rated 50VDC, 100mA, 18Ω
LED Indication:
Prestige External TD Red alarm indication
Prestige External DT Red alarm, yellow microwave, green PIR indication
Environmental Protection: IP65
Waterproof Coating: Conformal
EMC: EN 50130-4: 1996, A1 1998, A2 2002. EN 55022: Class B
89mm 86.5mm
250mm
550g (20oz)
approx.
-35°C (-31°F) to
+60°C (+140°F)
-35°C (-31°F) to
+55°C (+131°F)
