texet TPB-2110 User manual
USER GUIDE
PowerPack
TPB-2110
POWER BANK
FOR SMARTPHONES AND TABLET PCs
USER GUIDE
PowerPack
TPB-2110
POWER BANK
FOR SMARTPHONES AND TABLET PCs
Manufactured for teXet Global SE, U Vodarny 3032/2a, 61600, Brno,
Czech Republic
Manufacturer: “Lincom Limited”, 4210, Ofce Tower,
Convention Plaza, 1 Harbour Road, Wanchai, Hong Kong
Made in China
« », 4210, ,
, 1, ,
« «»
:
: « », , 194406,
-, . , . 10, . , . 3
CN.88.29968
28.01.2013 27.01.2014
«»,
RU.0001.1188
Warranty for teXet® PowerPack TPB-2110: 24 months
Warranty for cable and connectors: 3 months
teXet® PowerPack TPB-2110: 24
( ): 3
www.texet.eu
Device and controls
1 — USB interface (Out 1 and Out 2) for plugging in a
mobile device’s charging cable
USB (Out 1 Out 2)
2 — micro USB interface for charging the PowerPack
micro USB PowerPack
3 — Multifunctional Button (MFB)
()
4 — 5-section PowerPack battery charge LED indicator
5-
PowerPack
3
4
2
1
Connecting a mobile device
mini USB
for/
teXet tablet PCs
micro USB
for/
iPhone 3, 4, 4S&
Samsung Galaxy Tab
for/
for iPhone 5, iPod touch 5,
nano 7, iPad 4, mini
You have purchased a teXet® brand
PowerPack series power bank for charging
mobile phones, smartphones, multimedia
players, e-readers and tablet PCs. This form
of backup power allows you to charge your
mobile devices at any time and in any place.
You do not need a power socket, or a car. The
PowerPack is indispensable and very useful
when travelling on trains, as well as useful
to those who actively speak, Google, play
games, listen to audio, and watch videos on a
mobile phone or smartphone.
When leaving the house, don’t forget to take
your PowerPack with you!
ENG
1
PowerPack technical specifications
Model: PowerPack TPB-2110
Capacity: 10000 mAh
Battery type: Li-Pol 10000 mAh, 3,7 V,
size 60*90*16 mm
Input: DC 5 V, 1 A
Output: DC 5 V, 2,1 A
for Out 1 and Out 2
Overall dimensions: 65*120*20 mm
Weight: 200 g
Ideally suited for charging mobile phones,
smartphones, multimedia players, e-readers,
tablet PCs and other mobile devices capable
of charging via a USB interface, with the
use of an included cable and a maximum
consumption current of 2,1 A
Checking the battery level of your
PowerPack
Press the MFB. The number of illuminated
sections indicates the battery level of the
2
PowerPack
1 section: 20%
2 sections: 40%
3 sections: 60%
4 sections: 80%
5 sections: 100%
Charging the PowerPack
In order to charge the PowerPack power
bank , use any household or automobile USB
teXet® charging device*with a maximum
output current of 1 A, 2,1 A or 3,1 A
Connect a micro USB connector to the cable
provided and place it in the corresponding
port on the case of the PowerPack, and then
connect the cable to the USB charger. The
PowerPack will begin charging automatically.
A flashing LED indicates the charging process,
*The charging device is not included and must be purchased
separately. It is recommended to use the teXet® series
PowerUno (output current 1A), PowerLot (output current
2,1A), or PowerMaster (output current 3,1A)
3
and the number of constantly illuminated
sections indicates the battery level.
A flashing 5th section indicates that the
PowerPack has finished charging.
Charging a mobile device with the
help of the PowerPack
You can connect and charge 2 mobile devices
simultaneously:
- A mobile phone and a smartphone
- 2 smartphones
- A smartphone and a tablet PC*
Link the connector for your mobile device to
the included cable, plug it into the mobile
device, and then connect the cable to the
USB interface on the PowerPack. For charging
you can also use the USB cable included with
your mobile device.
*In this case, the maximum output current will be shared
between the 2 USB interfaces in the following proportion:
0,6 for Out 1 and 1,5 A for Out 2, and the time required to
charge a mobile device will be increased.
4
Press and hold the MFB, the charging LED
indicator will light up for several seconds,
and the mobile device will begin charging
automatically.
When the mobile device is disconnected,
PowerPack will automatically turn off after
several seconds.
A fully charged 10000 mAh PowerPack
charges:
A mobile phone with a 1000 mAh battery: 8 times
A smartphone with a 1350-1500 mAh battery: 5,3 times
An iPhone with a 1830 mAh battery: 4,3 times
A Samsung Galaxy Tab with a 4000 mAh battery: 2 times
An iPad with a 6500 mAh battery: 1,2 times
5
Package contents
1. Power bank PowerPack TPB-2110
2. User Guide
3. USB cable
Connectors:
4. mini USB
5. micro USB
6. universal for iPhone
and Samsung Galaxy Tab
7. for iPhone 5, iPod touch 5,
nano 7, iPad 4, mini
8. for teXet tablet PCs
6
teXet® PowerPack -
, ,
,
. -
-
. -
, . PowerPack
, ,
,
, ,
, ,
.
PowerPack!
7
RUS
PowerPack
: PowerPack
TPB-2110
: 10000
: Li-Pol 10000 ,
3,7 ,
60*90*16
: DC 5 , 1 A
: DC 5 B, 2,1 A
Out 1 Out 2
: 65*120*20
: 200
-
, ,
,
,
,
USB , -
-
2,1 A
8
PowerPack
. -
PowerPack
1 : 20%
2 : 40%
3 : 60%
4 : 80%
5 : 100%
PowerPack
PowerPack
USB
teXet® * . 1 A, 2,1 A
3,1 A
*
.
teXet® PowerUno (. 1A), PowerLot (.
2,1A), PowerMaster (. 3,1A).
9
micro USB
, -
-
PowerPack, -
USB .
PowerPack . -
-
,
.
5- -
PowerPack.
PowerPack
2 -
:
-
- 2
- *
*
2- USB : 0,6 Out
1 1,5 A Out 2,
.
10
,
, -
USB
PowerPack.
USB -
.
,
-
, -
.
PowerPack -
.
PowerPack 10000
mAh :
1000 mAh: 8
1350-1500 mAh: 5,3
iPhone 1830 mAh: 4,3
Samsung Galaxy Tab 4000 mAh: 2
iPad 6500 mAh: 1,2
11
1. PowerPack TPB-2110
2.
3. USB
:
4. mini USB
5. micro USB
6. iPhone Samsung
Galaxy Tab
7. iPhone 5, iPod touch 5,
nano 7, iPad 4, mini
8. teXet tablet PCs
12
