INSTRUCTION MANUAL
916
Cable Reel Transporter
99987511 © 2014 Greenlee Textron Inc. IM 1011 REV 5 6/14
Read and understand all of the instructions and
safety information in this manual before operating
or servicing this tool.
Register this product at www.greenlee.com

916 Cable Reel Transporter
Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070
2
Description
The Greenlee 916 Cable Reel Transporter is intended for
transporting and dispensing cable from cable spools.
For more information, refer to “Specications” on
page4.
Safety
Safety is essential in the use of Greenlee tools and
equipment. This instruction manual and any markings
on the tool provide information for avoiding hazards and
unsafe practices related to the use of this tool. Observe
all of the safety information provided.
Purpose of this Manual
This manual is intended to familiarize all personnel with
the safe operation for the Greenlee tool:
916 Cable Reel Transporter
Keep this manual available to all personnel.
Replacement manuals are available upon request at
no charge at www.greenlee.com.
All specications are nominal and may change as design
improvements occur. Greenlee Textron Inc. shall not be liable for
damages resulting from misapplication or misuse of its products.
KEEP THIS MANUAL
Table of Contents
Description .................................................................... 2
Safety ............................................................................ 2
Purpose of this Manual ................................................. 2
Important Safety Information ........................................ 3
Illustration and Parts List............................................... 4
Specications................................................................ 4
Operation ...................................................................... 4

916 Cable Reel Transporter
Greenlee / A Textron Company 4455 Boeing Dr. • Rockford, IL 61109-2988 USA • 815-397-7070
3
IMPORTANT SAFETY INFORMATION
SAFETY
ALERT
SYMBOL
This symbol is used to call your attention to hazards
or unsafe practices which could result in an injury or
property damage. The signal word, dened below,
indicates the severity of the hazard. The message
after the signal word provides information for pre-
venting or avoiding the hazard.
Immediate hazards which, if not avoided, WILL result
in severe injury or death.
Hazards which, if not avoided, COULD result in
severe injury or death.
Hazards or unsafe practices which, if not avoided,
MAY result in injury or property damage.
Read and understand all of the
instructions and safety information
in this manual before operating or
servicing this tool.
Failure to observe this precaution
may result in injury or property
damage.
Keep hands and feet clear when
loading and unloading cable spools.
Failure to observe this precau-
tion may result in injury or property
damage.
• Make sure bystanders are clear of the work area
when loading, unloading, or dispensing cable.
Nearby personnel can be injured if transporter
falls.
• Do not use this tool for cable with damaged
spools. Damaged spools may not turn freely and
may pull over the transporter.
• Use only on a hard, at, level surface.
• Do not exceed the rated capacity of this tool.
Failure to observe these precautions may result in
injury or property damage.
Use this tool for manufacturer’s use only. Use other
than that which is described in this manual may
result in injury or property damage.
Note: Keep all decals clean and legible, and replace
when necessary.

916 Cable Reel Transporter
Specifications
Capacity: Reels of cable or BX up to 25" (635 mm)
wide and 40" (1016 mm) in diameter. Maximum total
reel weight: 300 lb (136 kg).
Service Information for Earlier Models
Use wheel kit 90524667 for models prior to
August2012.
Operation
1. Position the spindle through the center of the spool.
2. Guide the transporter slots onto the spindle as
shown above.
3. Lift the spool and transport.
Note: Be sure to steady transporter with foot as
forks are lowered to release and lift loads.
4. To dispense cable, place the transporter in the
horizontal position as shown above.
Note: Handle may pivot and lock in vertical position.
Parts List
Key Part No. Description Qty
1 50330357 Spool spindle ........................................1
2 Wheel ....................................................2
3 Axle, ø 3/4 x 31.80................................1
4 Washer..................................................2
5 Rue ring, #34.........................................2
6 Plug, round ...........................................2
Kits
52064330 Wheel kit (includes items 2, 4, and 5)
52064331 Axle kit (includes items 3 and 5)
1
2
3
4
5
6
Transporter Slot
Handle Lock
Illustration
