Textron Jacobsen RENOVAIRE 744317 User manual

WARNING: If incorrectly used this machine can cause severe injury. Those who
use and maintain this machine should be trained in its proper use, warned of its
dangers and should read the entire manual before attempting to set up, operate,
adjust or service the machine.
TECHNICAL MANUAL
Safety, Operation, Parts & Service
4130421 REV A
Model:
744317 RENOVAIRE

CALIFORNIA
Proposition 65 Warning
Diesel engine exhaust and some of
its constituents are known to the State
of California to cause cancer, birth
defects and other reproductive harm.
Californie Proposition 65
Avertissement
Les échappements des moteurs diesel
et certains de leurs composés sont
reconnus par l’Etat de Californie pour
être cancérigènes, provoquer des
défauts congénitaux et d’autres dangers
en matière de reproduction.
ADVERTENCIA
AVERTISSEMENT
WARNING
The engine exhaust from this product
contains chemicals known to the State
of California to cause cancer, birth
defects or other reproductive harm.
California Advertencia
de la Proposicion 65
El estado de California hace saber que
los gases de escape de los motores
diesel y algunos de sus componentes
producen cáncer, defectos de
nacimiento y otros daños en el
proceso de reproducción humana.
L’ é mission du moteur de ce mat é riel
contient des produits chimiques que
l’Etat de Californie consid è re ê tre
canc é rig è nes, provoquer des d é fauts
cong é nitaux et d’autres dangers en
mati è re de reproduction.
El estado de California hace saber
que los gases de escape de este
producto contienen productos
quÍmicos que producen cáncer,
defectos de nacimiento y otros daños
en el proceso de reproducción
humana.
© 2003, TEXTRON INC

1
RENOVAIRE
7-2003
IMPORTANT MESSAGE
Thank you for purchasing this Jacobsen product. You have purchased a world class product, one of the best
designed and built anywhere.
This machine comes with a Technical Manual containing safety, operation, parts and service information. The
useful life and good service you receive from this machine depends to a large extent on how well you read and
understand this manual. Treat your machine properly, lubricate and adjust it as instructed, and it will give you
many years of reliable service.
Your safe use of this Jacobsen product is one of our prime design objectives. Many safety features are built in,
but we also rely on your good sense and care to achieve accident-free operation. For best protection, study the
manual thoroughly. Learn the proper operation of all controls. Observe all safety precautions. Follow all
instructions and warnings completely. Do not remove or defeat any safety features. Make sure those who
operate this machine are as well informed and careful in its use as you are.
See a Jacobsen dealer for any service or parts needed. Jacobsen service ensures that you continue to receive
the best results possible from Jacobsen’s products. You can trust Jacobsen replacement parts because they
are manufactured with the same high precision and quality as the original parts.
Jacobsen designs and builds its equipment to serve many years in a safe and productive manner. For longest
life, use this machine only as directed in the manual, keep it in good repair and follow safety warnings and
instructions. You'll always be glad you did.
Jacobsen, a Textron Company
One Bob Cat Lane
Johnson Creek, WI 53038-0469
TABLE OF CONTENTS FIGURES PAGE
SAFETY ......................................................................................................................................................... 2
SETUP ........................................................................................................................................................... 3
OPERATION / TRANSPORTING ................................................................................................................... 4
SERVICE / SPECIFICATIONS ....................................................................................................................... 5
AERATION TOOLS ........................................................................................................................................ 6
DRAGMAT ..................................................................................................................................................... 7
HYDRAULIC HAND PUMP ............................................................................................................................ 8
PARTS SECTION .......................................................................................................................................... 9
FRAME ASSEMBLY ........................................... FIGURE 1 ..................................................................10, 11
AERATING WHEEL ........................................... FIGURE 2 ................................................................. 12, 13

2
RENOVAIRE
SAFETY
NOTICE !!!
Unauthorized modifications may present extreme
safety hazards to operators and bystanders and
could also result in product damage.
Jacobsen, a Textron Company strongly warns
against, rejects and disclaims any modifications,
add-on accessories or product alterations that are
not designed, developed, tested and approved by
Jacobsen's Engineering Department. Any Jacobsen
product that is altered, modified or changed in any
manner not specifically authorized after original
manufacture–including the addition of “after-market”
accessories or component parts not specifically
approved by Jacobsen–will result in the Jacobsen
Warranty being voided.
Any and all liability for personal injury and/or property
damage caused by any unauthorized modifications,
add-on accessories or products not approved by
Jacobsen will be considered the responsibility of
the individual(s) or company designing and/or
making such changes. Jacobsen will vigorously
pursue full indemnification and costs from any party
responsible for such unauthorized post-manufacture
modifications and/or accessories should personal
injury and/or property damage result.
This symbol means:
ATTENTION!
BECOME ALERT!
Your safety and the safety of others is involved.
Signal word definitions:
The signal words below are used to identify levels
of hazard seriousness. These words appear in this
manual and on the safety labels attached to
Jacobsen machines. For your safety and the safety
of others, read and follow the information given with
these signal words and/or the symbol shown above.
DANGER indicates an imminently hazardous
situation which, if not avoided, WILL result in death
or serious injury.
WARNINGindicates a potentially hazardous situation
which, if not avoided, COULD result in death or
serious injury.
CAUTION indicates a potentially hazardous situation
which, if not avoided, MAY result in minor or moderate
injury. It may also be used to alert against unsafe
practices or property damage.
CAUTION used without the safety alert symbol
indicates a potentially hazardous situation which, if
not avoided, MAY result in property damage.

3
RENOVAIRE
SET-UP
GENERAL NOTE: FRONT, REAR, RIGHT HAND AND LEFT HAND REFERENCES BELOW
ARE WITH RESPECT TO AN OPERATOR AT THE CONTROLS.
SET-UP
1. Set Frame Assembly on blocks so that hitch end
of frame is approximately 18" above ground.
To prevent possible injury use an adequate
lifting device or a minimum of two (2) men
when placing main frame on blocks.
2. Attach transport tires to wheel yokes and inflate
tires to 55 p.s.i.
3. Attach cradle assembly to yokes on frame as
shown in frame assembly diagram.
4. Attach hydraulic cylinder to lugs on underside of
frame and cradle assembly. Make sure end of
cylinder with hose attachment points toward
hitch of machine.
5. Assemble aerating wheels as shown in
assembly diagram. Do not mount weight trays at
this time.
6. Attach aerating wheel to square bar on main
frame as shown in Figure 1.
NOTE: Attach outside aerating wheel sets as close
to clevis pin as possible and the middle sets as
close to center clevis pin as possible. Center
the middle set of each side.
7. Attach aerating tools on aerating wheels.
Tines and slicing knives are sharp. To
prevent possible injury use caution when
installing these items.
8. Attach weight trays as shown in assembly
diagram.
9. Remove blocks from beneath main frame.
10. Attach machine to tractor at draw bar and attach
hydraulic hose from tractor to cylinder.
11. Lubricate aerating wheels until grease can be
seen at wheel bushings.

4
RENOVAIRE
OPERATION / TRANSPORTING
OPERATION
NOTE: Failure to lubricate aerating wheels can
cause serious damage to aerating wheels,
bushings and axles.
To prevent possible injury do not operate
machine without weight trays in place. Do
not make any adjustments or perform any
maintenance while trator is running.
Before operating Renovaire, check all moving
parts and all fasteners, also check area and
remove any objects which may present a
safety hazard or damage the machine.
(Rocks, cans, etc.)
1. Position the tractor and machine where you wish
to begin aerating.
2. Lower aerating wheels and proceed to aerate.
NOTE: When aerating in soft ground and full
penetration is not desired, the depth may be
controlled with the hydraulic system.
Never cross hard objects or surfaces (sidewalks,
drives, stepping stones, etc.) with the tines
down.
The Renovaire is designed to be towed. Do not
back up when the tines are in the ground or
damage to the tines and clamps may result.
To prevent possible injury or damage to the
aerator, DO NOT leave tractor unattended
without lowering aerator to lowest position
and shutting off motor of tractor.
TRANSPORTING
1. Raise aerating wheels high enough to hook
latching rings over hook on sides of cradle
assembly.
2. Lower aerating wheels until latching rings on eye
bolt assembly hold the cradle assembly
To prevent possible injury or damage to the
aerator, DO NOT leave tractor unattended
without lowering aerator to lowest position
and shutting of motor of tractor.

5
RENOVAIRE
SERVICE / SPECIFICATIONS
SERVICE
When replacing any bolt, screw or other
fastener, use only original equipment parts or
parts of equivalent strength and material to
prevent possible failure.
1. Thoroughly clean all tines inside and out when
aerating is completed. A light coat of oil will
prevent rust and insure proper coring and slicing
the next time unit is put into service.
LUBRICATION
1. Wipe off grease fittings before and after
greasing.
2. Grease aerating wheel bearings as required.
TRANSPORT WHEELS
1. Check daily
2. Repack with grease yearly.
3. Air pressure: MINIMUM 45 p.s.i.
MAXIMUM 65 p.s.i.
SPECIFICATIONS
Chassis:..................................... 2" extra strong pipe
Hitch:.....................Clevis type with 3/4" diameter pin
Axles:..................................Aerating: 1-1/4" diameter
Transporting: 3/4" diameter bolted to frame
Wheels:.....Aerating: 12 cast iron wheels w/bushings
Transporting: Pneumatic 4.80 x 4.00-8, 6
ply
w/roller bearings
Net Weight:......................... Approximately 1000 lbs.
Dimensions:
Width:........................................................................8'
Transport Height:...... ...........................................30"
Length:........................................................................9'
Operating Speed:.................................Up to 10 mph
Transport Speed:.................................Up to 10 mph
Aerating Width:.......................................................6'
Aerating Depth:............................................Up to 5"
Aerating Pattern:....................Approximately 6" x 6"
Hydraulic Lift:........Raise and lower aerating wheels
Hydraulic Cylinder:...........2-1/2" bore with 8" stroke
rated @ 3000 p.s.i.
Lubrication:..........................Pressure grease fittings

6
RENOVAIRE
AERATION TOOLS
545364 - 1/2" Coring Tine Kit
545365 - 3/4" Coring Tine Kit
Each kit consisting of 100 #515196 1/2" coring tines
or 100 #515197 3/4" coring tines is for thorough
aeration programs in the Spring and Fall. Soil cores
up to 4" (102mm) in length can be removed with
minimal surface disturbance letting in air, moisture
and fertilizer to the root zone. The cores on the
surface quickly disintegrate forming top dressing for
an excellent seed bed. Using this system, rain water
run-off is minimized and extra moisture is held down
in the root zone.
545363 - Deep Slicing Knife Kit
Consists of 100 #521155 slicing knives, this kit is for
aeration and renovation programs during all sea-
sons. Slicing knives control thatch by cutting
through grass runners and also have the advantage
of no surface clean up after aerating. Knives are
especially helpful in that they do not place buried
seeds of noxious weeds on the surface where they
can germinate.
Slicing knives are especially recommended for
athletic fields. Due to the "invisible" slices, moisture,
air and fertilizer can be trapped while not creating
hazardous playing conditions for athletes.
545366 - Aerating Tine Kit
Consists of 100 #520404 tinew, this kit is for turf
building and Fall renovation programs. These tines
will thoroughly open up the soil by penetrating deep
into the ground bringing up large amounts of soil,
which then becomes top dressing.

7
RENOVAIRE
DRAGMAT
544518 - DRAGMAT
When aerating a fairway, a DRAGMAT can be
attached directly behind the Renovaire to break up
the cores while aerating all in one quick easy opera-
tion.
Mat size: 12' wide x 10' long.

8
RENOVAIRE
HYDRAULIC HAND PUMP
546010 - Hydraulic Hand Pump
For use on Renovaire when hydraulic lifting system
on tractor is not used. There are three service kits
available for gasket and seal replacement on worn
pumps.
548812 - Seal and Gasket Kit
Includes one each of items 1, 4, 5 and 12; two each
of item 2; and three each of item 11. For use on
pumps: HP2503-51-00 P148, HP2503-51-00 P348
548831 - Release Valve Replacement Kit
Includes one each of items 6, 7, 8, 9 & 10; and three
each of item 11. For use on all units
548832 - Safety Valve Replacement Kit
Includes one each of item 4; and one assembled
safety valve subassembly (substitute for item 3).
Specify pressure setting required. For use on all
units

9
RENOVAIRE
PARTS SECTION
PARTS
SECTION

8
RENOVAIRE
FIGURE 1
FRAME ASSEMBLY
16 1110
21
19
12 14 15 17 18
9853231
97642
10 11 20 24
22 13
25

9
ITEM PART NO. DESCRIPTION QTY ITEM PART NO. DESCRIPTION QTY
RENOVAIRE
FIGURE 1
FRAME ASSEMBLY
1-1 548008 SCREW, HEX HD 1/2-20X1 4
1-2 515183 NUT, 1/2-20 4
1-3 548265 SEAL, OIL 4
1-4 548124 BEARING, TAPERED 4
1-5 385174 BEARING, CUP 4
1-6 515182 AXLE 2
1-7 548494 TUBE 2
1-8 548590 TIRE 2
1-9 515181 HUB 2
*546009 TIRE AND WHEEL ASSY 2
(INCLUDES ITEMS 2-9)
1-10 120310 PIN, COTTER, 1/8" X 1-1/2" 3
1-11 548473 PIN, CRADLE 1
1-12 546017 CRADLE ASSEMBLY 1
1-13 546014 CYLINDER 1
1-14 548602 PIN, HAIR 4
1-15 548603 PIN, CLEVIS 2
1-16 548051 NUT, LOCK, 1/2-13 2
1-17 515235 WASHER 2
1-18 518495 SPRING 2
1-19 546018 EYE BOLT, ASSEMBLY 2
1-20 546016 FRAME ASSEMBLY 1
1-21 4130430 LABEL-RENOVAIRE 2
1-22 519842 DECAL, INSTRUCTION 1
1-23 548210 SET SCREW, 10-24 X 1/2 4
1-24 4124074 LABEL-JACOBSEN 2
1-25 835892 DECAL, DANGER 2
*NOT ILLUSTRATED

12
RENOVAIRE
FIGURE 2
AERATING WHEEL

13
ITEM PART NO. DESCRIPTION QTY ITEM PART NO. DESCRIPTION QTY
RENOVAIRE
FIGURE 2
AERATING WHEEL
2-1 306414 SCREW, HEX HD 3/8-16X1 24
2-2 306562 NUT, HEX, 3/8-16 72
2-3 120177 WASHER, LOCK, 3/8 72
2-4 515119 TRAY, WEIGHT 6
2-5 302600 SCREW, HEX 3/8-16X1-1/2 48
2-6 515118 SUPPORT, TRAY 6
2-7 515120 SUPPORT, TRAY 6
2-8 305134 NUT, HEX, JAM, 7/8-14 12
2-9 316954 WASHER, SHKPRF, 7/8 12
2-10 307665 NUT, HEX, JAM, 3/4-16 12
2-11 309799 WASHER, SHKPRF, 3/4 12
2-12 515204 RAIL, SIDE 12
2-13 548230 GREASE FITTING, 5/16 18
2-14 316912 SCREW, HEX 1/2-13X2-1/4 12
2-15 308332 NUT, HEX, 1/2-13 12
2-16 120166 WASHER, LOCK, 1/2 12
2-17 515109 CLAMP 6
2-18 515115 CAP 6
2-19 515103 SHAFT 6
2-20 306836 SCREW, HEX 3/8-16X2-1/2 192
2-21 548804 NUT, WHIZLOCK, 3/8-16 192
2-22 515198 CLAMP 96
2-23 521155 KNIFE, DEEP SLICING 96
2-24 520404 TINE, AERATING 96
2-25 515196 TINE, 1/2" CORING 96
2-26 515197 TINE, 3/4" CORING 96
(SEE PAGE 6 FOR AERATION TOOLS
AND SUGGESTED USES.)
2-27 546048 WHEEL 12
2-28 548256 SEAL, OIL 24
2-29 515184 BUSHING 24
2-30 515185 AXLE 6

BOB-CAT BROUWER BUNTON CUSHMAN RYAN STEINER
Equipment from Jacobsen, a Textron company,
is built to exacting standards ensured by
ISO 9001 and ISO 14001 registration at all our
manufacturing locations.
A worldwide dealer network and factory-trained
technicians backed by Textron Parts Xpress
provide reliable, high-quality product support.
