The Oak Bed Store Guest Bed User manual

14
F
K
L
G
I
J
H
Bolt
M8 × 80mm × 4 pcs
M8 × 30 × 15 × 4 pcs
Half Moon Washer
M8 × 4 pcs
Flat Washer
M8 × 4 pcs
Hex Nut
14# × 1 pc
Spanner
Ø10 × 40mm × 24 pcs
Wooden Dowel
M8 × 55mm × 8 pcs
Bolt
A
B
D
C
E
M5 × 1 pc
Allen Key
M8 × 8 pcs
Barrel Nut
Fittings Checklist
38 pcs
Sprung Slats
76 pcs
Sprung Slat Caps
4 pcs
Castor Wheel
Page 2 of 6
Boxes
1 of 5 - Headboard
2 of 5 - Footboard,Fittings pack
3 of 5 - Main Bed Side Rails
4 of 5 - Trundle Bed Side Rails
5 of 5 - Slats, Cross Bar, End Panels
①
③
③
②
④
④
⑤
⑤
⑤
⑤

A
B
E
D
C
F
F
A
Step 1:
Attach the Side Rails to the Headboard using Bolt (A) and Wooden Dowel (F) as shown ensuring the
pre-drilled holes on the side rails are facing up.
Step 2:
Using the Half Moon Washer (B), Flat Washer (C), Hex Nut (D) and Spanner (E) please secure them
into place and tighten, but do not fully tighten.
Page 3 of 6
Main Bed Assembly Steps 1 - 4

Step 3:
Attach the Side Rails to the Footboard by repeating steps 1 and 2. Once the frame is secure, please
tighten all 4 ends fully using the Spanner (E).
Page 4 of 6
Step 4:
Fit the Slat Cap (K) onto the Sprung Slat (L) and insert into the pre-drilled holes on the Side Rails,
please note you may need to press firmly into place.
K
L
L
K
K

Page 5 of 6
H
H
Step 2:
Insert Wooden Dowel (F) and Barrel Nut (I) into the side rail and place the headboard into position
securing with Bolt (G) and Allen Key (H) and then repeat on footboard.
G
G
F
F
F
F
I
I
II
Trundle Bed Assembly Steps 1 - 3
Please do not place the trundle upon its side as it features a spring mechanism that
could cause injury.
Step1:
Cut the leg ties on the Trundle Side Rails, please note the legs may spring back. Attach the Cross Bar to
the Side Rails legs using Wooden Dowel (F), Barrel Nut (I), Bolt (G) and secure fully with Allen Key (H).
Please repeat this for the other leg.
G
G
G
F
F
H
H
I
N
I
G

Page 6 of 6
K
L
E
J
Step 3:
Fit the Slat Cap (K) onto the Sprung Slat (L) and attach to the predrilled holes into Side Rails, please
note you may need to press firmly into place. Screw the Castor Wheels (J) into the legs and then
tighten fully using Spanner (E).
K
J
J
