Theben SELEKTA 171 top2 RC 24 V User manual

Installation and
Operating Manual
Digital astronomic time switch
SELEKTA
SELEKTA 171 top2 RC
SELEKTA 172 top2
1710100
1720100
309254 05
MENU OK
SELEKTA 171 top2 RC
LN
Ext
DATA
0 6 12 18 24
2,5mm2
0,5mm -
2
230-240V~
50-60Hz
R 10a -30T
16(10)A 250V~
123
8mm
+
MENU OK
12
0 6 12 18 24
SELEKTA 172 top2
L
N
Ext1 Ext2
2,5mm2
0,5mm -
2
230-240V~
50-60Hz
R 10a -30T
16(10)A 250V~
1
C1
C2
2
5
4
3
6
8mm
C1/C2
SELEKTA 171 top2 RC SELEKTA 172 top2
Correct connection required for smooth zero-cross switching operation
(see connection diagram)!
GB
DGB F
IE

2
Contents
Basic safety instructions 3
Display and keys/operating instructions 4
Overview of menu selection 5
Connection/installation 6
Initial start-up 7
Menu item ASTRO
Astro times, complete simulation, offset, astromode, location 8
Change position 9
Menu item PROGRAM
Program switching time in standard program 10
Extra program 11
Program switching time in extra program 1 13
Menu item MANUAL
Manual and permanent switching 14
Menu item OPTIONS
External input 15
PIN code, elapsed time counter 17
OBELISK top2 memory card 18
Reception with antenna top2 RC-DCF / antenna top2 RC-GPS 19
Technical data 20
Service address/Hotline 20

3
Basic safety instructions
• The device is designed for installation on DIN top hat rails (in accordance with EN 60715)
• Corresponds to type 1 BSTU in accordance with IEC/EN 60730-2-7
• Power reserve (10 years) is reduced if memory card is inserted (in battery operation).
• OBELISK top2 memory card: Avoid mechanical stress or contamination caused by other storage/
transport methods
Designated use
• The astronomic time switch is used for lighting equipment (roads), external staircases, shop win-
dows, entrances etc.
• For use only in closed, dry rooms
Disposal
Dispose of equipment in an environmentally-friendly manner
GB
Danger of death through electric shock or fire!
 Installation should only be carried out by a professional electrician!
WARNING

4
Screen display and keys Operating instructions
0 6 12 18 24
Time display
DCF antenna display
Sunrise/sunset display
Date display
Channel status
C1, C2
ON = On
OFF = Off
 MENU
– Activate screen
– Open menu
– Cancel menu
– ESC
(leave menu)
YES
Confirmation
OK
press
NO
Change/
select
 
press
 OK
– Confirm
selection
– Confirm
selection
  
Selection options
are displayed
Days of the week
from 1 to 7
Display of active keys with
relevant function
Programmed
ON times
bbbb
1. Read text lines
Flashing text/symbol
is a prompt
bbbb
2. Make a decision

5
GB
Overview of menu selection
ASTRO MANUALPROGRAM TIME/DATE OPTIONS END
CHANNEL C1
PERM ON
PERM OFF
OVERRIDE ON
TIMER
OPERATING HOUR
EXT INPUT
     
HOLIDAY
CHANNEL C1
STANDARD
EXTRA 1 ASTRO-
PROG
EXTRA 2 ON
EXTRA 3 OFF
TOTAL
SIMULATION
DELETE ALL
LCD-ILLUMINA-
TION
LANGUAGE
PIN
FACTORY
SETTING
INFO
END
ASTRO
TIMES
TOTAL
SIMULATION
OFFSET
ASTROMODE
TIME
SET DATE
SU--WI
WEEK DAY
FORM DATE
FORM TIME
EASTER
RULE
END
END
END
19 10 08
C1 OFF C2 OFF
9:4046
LOCATION
END

6
Connection/installation
Warning, danger of death through electric shock!
 Must be installed by a professional electrician!
 Disconnect power source!
 Cover or shield any adjacent live components.
 Ensure device cannot be switched on!
 Check power supply is disconnected!
 Earth and bypass!
45° cable
Spring
screwless
terminal
NC contact
Test tap
DuoFix® screw-
less terminal
WARNING
Connect cable
 Strip cable by 8 mm (max. 9).
 Insert 45° cable in the open DuoFix® screwless terminal
(2 cables per terminal position possible).
 To open the DuoFix® screwless terminal,
press screwdriver downwards.

GB
Initial start-up
Set language, country, town/city, date, time as well as summer/winter time (SO-WI)
Press required key and display follows on screen (see fig).
7
GERMAN
ENGLISH
SPANISH
...

ok RETAINS
PROGRAMS
DELETE
PROGRAMS
COUNTRY
COORDINATES
DEUTSCHLAND
SPAIN
ESTONIA
FRANCE
GREAT
BRITAIN
STUTTGART
BERLIN
BREMEN
DRESDEN
DUESSELDORF
FORM DATE
YEAR
MONTH
DAY
FORM TIME
HOUR
MINUTE
SU-WI EUROPE
...
...

ok

ok

ok 
ok
28 02 08
ON
9:4046

8
ASTRO menu
In the ASTRO menu astro times, complete
simulation, offset, astromode as well as posi-
tion (location) can be viewed or changed.
• Astro times
Display of the astro times (including the offsets)
for the current day.
• Total simulation
Display of the switching behaviour with a freely
selectable Start date (the holiday program is not
displayed).
• Offset
The offset (adjustment value) can be used to
shift calculated astro times +/– 2 h. This enables
the Astro switch-on and switch-off times to be
adapted to local circumstances (e.g. mountains,
high buildings etc.) or to personal requirements.
• Astro mode
– Evenings on, morningsoff
Switches on at sunset, switches off at sunset
(Example: street lighting).
– Evenings off, mornings on
Switches off at sunset,
switches on at sunrise (Example: terrarium).
– Astro inactive
The astro times are ineffective
(timer function only).
• Position
Location set by selecting a city or by coordinates
(latitude/longitude, time zone). The OBELISK top2
memory card allows up to 10 further cities
(= favourites) to be entered.

GB
9
Change position
E.g. enter different country, a different city.
 Press MENU (see fig.).
ASTRO ASTRO
TIMES
TOTAL
SIMULATION
OFFSET
ASTROMODE
LOCATION COUNTRY
COORDI
NATES
FRANCE
SPAIN
ESTONIA
DEUTSCHLAND
GREAT
BRITAIN
AJACCIO
BAYONNE
BORDEAUX
BREST
CAEN
...
...

ok

ok

ok 
ok
END

10
Program switching time in standard program
A time switch always consists of a start time and an end time (DURATION UNTIL).
(e.g. night break
on Monday
23:00 – 05:00 hrs)
 Press MENU (see fig.).
There are 84 memory locations available.
PROGRAM CHANNEL C1
STANDARD
EXTRA 1 ASTRO-
PROG
EXTRA 2 ON
EXTRA 3 OFF

ok
NEW

ok
Copy switching to other days of the week.
The day of the week always relates to a start time
Start time
MEM FREE 84
NIGHT BREAK
HOUR
MINUTE
MONDAY
DURATION UNTIL
SAVE
COPY
ADD TUESDAY
SAVE

 

...
or LIGHT ON
Switching
time for
one day

Extra program
• The devices SELEKTA 171 top2 RC and SELEKTA 172 top2 feature 3 special programs,
that can be used for calendar-dependent switching.
• Each special program can be activated over one or several date ranges.
• There are 3 types of date range:
– Fixed date range:
Start time on 02.04.2008 at 16:00 hrs
End time on 24.04.08 at 10:00:00 hrs
– Annually recurring date range,
e.g. Christmas:
Start time on 24.12. at 18:00 hrs each year
End time on 24.12. at 23:00:00 hrs each year
– Easter-dependent date range,
e.g. Whit Sunday and Monday:
Start time: 49 days after Easter at 0:00 hrs, each year
End time: 51 days after Easter at 0:00 hrs, each year
Note: 24:00 hrs is programmed at 0:00 hrs of the following day.
Easter holiday
dates in Germany
Public holiday days before/after
Easter Sunday
Monday before Lent – 48
Good Friday – 2
Easter Monday + 1
Ascension + 39
Whit Monday + 50
Corpus Christi + 60
GB
11

12
• Extra program 1
– Astro times active
– Optional 1x nighttime interruption
– Optional 1x daytime switch on
– Active in the programmed date ranges
Example: The standard program switches on the street lighting in dependence of the astro times.
A nighttime interruption is programmed from 23:00 hrs to 04:00 hrs.
Extra program 1 is active within the date range from April 30, 12:00 hrs until May 12:00 hrs. Since no
nighttime interruption is programmed, the street lighting will remain on all night.
• Extra program 2
– Permanently ON
– Always ON
Example: The standard program switches on lighting of a neon advertising sign only at night.
The extra program switches on the neon advertising sign permanently during a promotion week from
17.04.2008 at 9:00 hrs until 24.04.2008 at 18:00 hrs.
• Extra program 3
– Permanently OFF
– Always off
Example: The standard program switches on the car park lighting in dependence of the astro times.
The extra program does not switch on the car park lighting on July 14 from 0:00 hrs until July 15 at 04:00 hrs.

GB
Program switching time + date range in extra program 1

ok MEM FREE 84
NIGHT BREAK
DURATION UNTIL
LIGHT ON
DURATION UNTIL
NEW DATE
PROGRAM CHANNEL C1
STANDARD

ok

ok
CHECK DATE
MODIFY DATE
DELETE DATE
END
EXTRA 1
ASTROPROG
EXTRA 2 ON
EXTRA 3 OFF
...
FIXE DATE
BEFORE/AFTER
EASTER
EVERY YEAR
START YEAR
START MONTH
START DAY
START
HOUR
END YEAR
END MONTH
ok

ok

...
13

14
Manual and permanent switching
Manual and permanent switching can be set
using the menu in MANUAL or (in the auto-
matic screen) by key combination (see fig).
Activate manual switching
 Briefly press both keys simultaneously.
Activate permanent switching
 Simultaneously press both keys for 2 seconds.
Cancelling manual/permanent switching
 Press both keys simultaneously.
ok
Channel
C1
Channel
C2
Manual control
Reversing the channel status to the next auto-
matic or programmed switching.
Permanent switching
As long as a permanent switching (on or off)
is activated, the programmed switching times
are ineffective.

15
GB
OPTIONS
External input
The EXTERNAL INPUT is set via the menu in OPTIONS (see fig.) to different functions.
OPERATING HOUR
EXT INPUT
LCD-ILLUMINA-
TION
LANGUAGE
PIN
CHANNEL C1
BUTTON
SWITCH

NOT ACTIVE
STAIRCASE
LIGHT
OVERRIDE
TIMER
RESETABLE
EARLY CUTOUT
ok

ok

ok 
ok MINUTES

ok
* Use push button without glow lamp
*
...
Note:
• If a function is activated via an external push button or switch, EXTERNAL will appear in
the display.
• SELEKTA 172 top2 features one channel via 1 external input.

16
• For connection with a push button:
Manual switching (override): Reversing the channel status to the next automatic or programmed switching
switching.
Timer function: On timer or off timer, adjustable from 1 min to max. 23 h 59 min, can be cleared
by pressing the button >3 s.
– ON timer: press external push button  corresponding channel is switched on for the set time.
– OFF timer: press external push button  corresponding channel is switched off for the set time.
Staircase function (can be retriggered or switched on, adjustable from 1 to 59 min).
– Secondary switching: press external push button  corresponding channel is switched on for the set
time; press external button again within the lapsed time  time starts to run again.
– Can be switched off: press external push button  corresponding channel is switched on for the set
time; press external button again within the lapsed time  time is interrupted.
• For connection with a switch:
Permanently on: press external switch  corresponding channel is switched on as long as the switch
is pressed. The programmed switching times are ineffective.
Permanently off: press external switch  corresponding channel is switched off long as the switch
is pressed. The programmed switching times are ineffective.
Astro only: press external switch  only the astronomically calculated switching times are effective;
Programmed switching times in standard and special program are ineffective.
Extra program 1: press external switch  only special program 1 and the astronomically
calculated switching times are effective. Programmed switching times in standard program are ineffective.

17
GB
PIN code
The PIN code is set in OPTIONS via the menu.
If you have lost your PIN call the Theben Hotline.
Operating hours counter
The operating hours of the channel (relay)
are displayed and deleted in the OPTIONS menu.
If the number of operating hours exceeds the value
set in the Service menu, SERVICE will appear in the
display.
Example: replace a light source after 5,000 h.
 Delete operating hours or increase the value set
in service (e.g. to 10,000 h).
OPTIONS
NO PIN
CURRENT PIN
NEW PIN
00 00

OPERATING
HOUR
EXT INPUT
LCD-ILLUMINA-
TION
LANGUAGE
PIN
FACTORY
SETTINGS
INFO
ok
WITH PIN 
ok

ok

18
OBELISK top2 memory card
Using memory card
 Insert memory card in the time switch.
 Request saved switch timings, read to/from
the time switch or start the Obelisk program.
 Remove OBELISK top2 memory card
(No. 9070404)
(optional) after
programming etc.
and store in cover .
Copy OBELISK  TSWI
• Copy program: Copies only the switching
program (standard and extra programs).
• Copy all data: Copies the switching
program and all settings (e.g. location, offset,
external input, time format etc.).
Copy TSWI  OBELISK
• All switching programs and settings are
copied to the memory card.
COPY
OBELISK
 TSWI
COPY TSWI
 OBELISK
RUN
OBELISK
COPY PROGRAM
COPY ALL
END

ok
...

19
MENU OK
1
SELEKTA 171 top2 RC
LN
Ext1
DATA
0 6 12 18 24
2,5mm2
0,5mm -
2
230-240V~
50-60Hz
R 10a -30T
16(10)A 250V~
1
C1
23
8mm
+
max.100 m
Display RC
Antenna is connected and time signal is received.
Display
Antenna is connected and no time signal is received.
 Check antenna position.
Display RC
GB
 The antenna top2 RC-DCF (9070410) and antenna top2 RC-GPS (9070610) can be
connected to the SELEKTA 171 top2 RC time switch.
 Ensure correct polarity.
 Take length of connection cable into account (max. 100 m: 2 x 1,5 mm2; max. 50 m: 2 x 0,75 mm2)
Reception with top2 RC-DCF antenna and top2 RC-GPS antenna
(optional) (only with SELEKTA 171 top2 RC)

Technical data
Nominal voltage: 230–240 V~, +10 %/-15 %
Frequency: 50–60 Hz
Gap: <3 mm
Power consumption: type 3 VA (SELEKTA 171 top2 RC),
type 6 VA (SELEKTA 172 top2)
Contact material: AgSnO2
Switch output: phase-independent
(zero-cross switching)
Contact: two way switch
Switching capacity: 16 A/250 V~ cos ϕ = 1
Switching capacity: 10 A/250 V~ cos ϕ = 0.6
Switching capacity min.: 10 mA/230 V AC
100 mA/12 V AC/DC
Glow lamp load: 2600 W
Halogen lamp load: 2600 W
Fluorescent lamps (VVG – low-loss series devices):
uncorrected: 2300 VA
Series corrected: 2300 VA
parallel-corrected: 730 VA (80 µF)
Lead-lag circuit (duo): 1000 VA
Fluorescent lamps (EVG – Electronic series devices):
650 VA
Mercury and sodium vapour lamps:
parallel-corrected: 730 VA (80 µF)
Mercury and sodium vapour lamps:
parallel-corrected: 730 VA (80 µF)
Compact fluorescent tubes (EVG): 22x7 W, 18x11 W, 16x15 W,
16x20 W, 14x23 W
Permissible ambient temperature: –30 °C ... +55 °C
Protection class: II in accordance
appropriate installation
Protection rating: IP 20 in accordance with
EN 60529
Pollution degree: 2
Service address/Hotline
Theben AG
Hohenbergstr. 32
72401 Haigerloch
GERMANY
Telephone [phone]
Fax: [phone]
The current OBELISK top2 PC software (with time zone
map) and the online version of the operating manual are
available at www.theben.de
20
Telephone [phone]
Fax [phone]
[email protected]
Addresses, telephone numbers etc.
www.theben.de
