Green Brook T105A-C Installation and user guide

lease read the instructions fully before
attempting installation.
IMPORTANT
Thi unit hould be in talled to current
IET wiring regulation if in doubt
con ult a qualified electrician.
• Timer must not be mounted on a
flammable surface.
• Ensure that the timer does not come into
contact with any combustible materials
such as towels or bedding.
• Ensure at least a 300mm air space is
allowed around the timer.
• repare cable ends for connection to
terminals.
• Remove the 2 screws holding the
timeswitch cover to the backplate.
Remove cover leaving the timeswitch
hanging loose by its connection wires
to the backplate. DO NOT INTERFERE
WITH THESE FIXED CONNECTIONS.
Installation / Operating
Instructions for 7 Day
Electronic Socket Box Timer
- T105A-C
INSTALLATION
WIRING
2. ress Y to enter function setup. (Note:
if another button is not pressed within 10
seconds the display will revert to the
normal screen).
3. Use the + or - button to scroll to the clock
icon (flashing) and press Y to enter the
current time setting mode (hours
flashing).
4. If you keep the + or - buttons pressed for
more than 3 seconds, the display will
enter fast scroll mode.
5. Use the + or - button to adjust the hours
and press Y to confirm, minutes will flash.
6. Use the + or - button to adjust the
minutes and press Y to confirm, day will
flash.
7. Use the + or - button to adjust the day
and press N to exit.
1. ress the R button to reset the timer to its
default settings, activate using a pencil
or simular pointed instrument. (pressing
R will delete all stored programmes).
1. There are 24 ON/OFF programmes
available.
2. ress the Y button twice to enter the
programming setting mode.(Note: if
another button is not pressed within 10
seconds the display will revert to the
normal screen).
3. Default is programme 01 ON, this can be
changed if required by pressing + or -
button to scroll through the 24 ON/OFF
programmes as required, pressing the Y
will confirm the programme.
4. ress the Y button to confirm programme
01 ON, hours will flash.
5. Use the + or - button to adjust the hours
and press Y to confirm, minutes will flash.
6. Use the + or - button to adjust the
minutes and press Y to confirm, days will
flash.
7. Apart from individual days of the week,
the following day combinations of
multiple day blocks can be selected by
pressing the + or - buttons.
• Monday to Sunday
• Monday to Friday
• Saturday to Sunday
• Monday to Saturday
• Monday + Wednesday + Friday
• Tuesday + Thursday + Saturday
• Monday + Tuesday + Wednesday
• Thursday + Friday + Saturday
8. Select day or day block as required and
press the Y button to confirm.
9. ress the + button, this will select the
programme 01 OFF, press Y to confirm.
10.Follow 4 to 7 above to set the 01 OFF
programme (day or day block must be
the same as programme ON).
11.If no more programmes are required,
press the N button to exit.
12.If more programmes are required follow
3 above.
13.To cancel a programme once set, press
and hold the N button for more than 3
seconds when the desired programme
number is flashing i.e. to cancel
programme 01 ON, press the Y button
twice and hold the N button down for
more than 3 seconds to delete. ressing
the + button again will select 01 OFF.
14.Repeat 13 to delete 01 OFF. This
procedure can be repeated to delete
any of the 24 programmes.
CURRENT TIME AND
DA SETTING
PROGRAMMING THE
SWITCHING TIMES
16AMP(2)
• Connect all earth wires to earthing point
in wall box.
• Offer up the backplate to the wall box
and connect the wiring as shown in
diagram below.
• When the wiring is complete screw the
backplate to the fitted wall box using
3.5mm screws.
• ush the timeswitch back in to its seating
on the backplate, taking care that all the
wires are tucked in. Fit the cover and
tighten the two screws.
IMPORTANT:
Ensure all Terminal screws are fully tightened.

MANUAL OVERRIDE
SUMMER TIME SETTING
TECHNICAL INFORMATION
RESET
TIMER COUNTDOWN
FUNCTION
READING OUR
PROGRAMMED TIMES
1. Timer has a 100 hour countdown feature
i.e. the timer can be set to any period
from 1 minute to 100 hours and will
countdown in the ON state and turn OFF
at the end of the countdown period.
2. ress the Y button then use the + or -
button to select the “down” icon on the
right hand side of the display, press Y
again to enter the countdown mode.
3. Use the + or - button to adjust the hours
and press Y to confirm. minutes will flash.
4. Use the + or - button to adjust the
minutes and press Y to confirm and
complete the countdown time setting.
5. ress the N button to start the
countdown.
6. Output switched to ON during the
countdown period.
7. ress the N button to pause the
countdown (output switched to OFF)
8. To resume countdown simply press the N
button again.
9. ress and hold the N button for more
than 3 seconds to exit the countdown
function.
CE INFORMATION
ACTION TY E: IB
OLLUTION SITUATION: NORMAL
CLASS 2 INSULATION:
:MICRO-DISCONNECTION LIVE
OLE ONLY
1. When in normal clock mode, pressing
the N button will scroll through the
following switching options.
• ALWAYS ON - timer is permanently ON.
• ROG - timer is in programme ON
mode, will switch off at the next
programme OFF time.
• ALWAYS OFF - timer is permanently OFF.
• ROG - timer is in programme OFF
mode, will switch on at the next
programme ON time.
1. ress the Y button, then use the + or -
buttons to scroll through to “summer”
(flashing).
2. ress the Y button again to access the
summer time setting.
3. ress the + or - button to change
between summer on or off.
4. ress Y to confirm summer setting, time
will advance 1 hour.
5. A “SUMMER” icon will appear in the
display.
6. Use the same procedure to remove the
“SUMMER” icon when reverting to GMT
in the winter.
6. Timer will now operate in the random
mode.
7. To cancel random feature use the
procedure above to remove the
“RANDOM” icon from the display.
ressing the reset button R with a pencil or
similar will reset all programmed times and
set time of day to zero.
1. ress Y button twice to enter programme
mode.
2. ress the + or - buttons to scroll through
the 24 ON/OFF programmes to check
settings.
3. ress the N button to exit and revert to
clock mode.
Switching Capacity: 230V AC,16A resistive,
2A Inductive
Ambient Temperature: -10°C to + 55°C
Battery Back Up: 150 hours
Memory Location: 24
Shortest Switching Time: 1 minute
Wattage: 3000W
Conforms To: BS EN 60730-1,
BS EN 60730-2-7
RANDOM SETTING
The random setting allows the timer to
switch ON and OFF with a random delay of
between 2 and 32 minutes. This function will
only
operate if one or more programmes have
been programmed into the timer.
1. ress the Y button, then use the + or -
buttons to scroll through to “RANDOM”
(flashing).
2. ress the Y button again to access the
random setting.
3. ressing the + or - buttons will toggle the
random icon on and off.
4. ress the Y button to confirm random
function.
5. A “RANDOM” function icon will appear
in the display.
Issue no: 704704
WEST ROAD . HARLOW
ESSEX . CM20 2BG . UK
[e-mail]
www.greenbrook.co.uk
GUARANTEE
Your GreenBrook 7 Day Electronic Timer
i guaranteed for 1 year from
the date of purcha e.
Thi i in addition to your tatutory right .
PLEASE KEEP THESE INSTRUCTIONS
SAFE FOR FUTURE REFERENCE
