Eurochron EDT 8002 User manual

c) Countdown Timer
Set Timer
• If in current time display mode, press the START/
STOP (6) to enter timer mode.
• Press TIMER select button (8) to select a timer
T1 or T2
• Rotate the TIMER dial (8) to set a time.
- Clockwise (increase)
- Anticlockwise (decrease)
• Press the corresponding T1 START/STOP (6)
or T2 START/STOP (7) button to start the timer.
Press again to stop the timer.
• The corresponding T1 START/STOP (6) or T2
START/STOP (7) LED will flash green during the
countdown.
• When the countdown is complete:
- An alarm will sound (no alarm will sound if the
sound level switch (13) is set to off ).
- Timer will start to count up automatically.
- The corresponding T1 START/STOP (6) or T2
START/STOP (7) LED will flash red for 1 minute.
• Press the corresponding T1 START/STOP (6) or
T2 START/STOP (7) button to stop the alarm and
return to the pre-set count down time.
Change Increments (H:MM:ss / MM:SS)
Toggle between “H:MM:ss” and “MM:SS” increments
by pressing and holding the TIMER button (8) for 2
seconds.
d) Countdown Timer Memory (M1, M2, M3)
Save Countdown Times
• Set a desired countdown time using the TIMER
dial (8).
• Press and hold M1 (3), M2 (4), or M3 (5) for 2
seconds.
The LCD display (1) will ash and a beeping will
sound to indicate that a countdown time has been
saved.
No beeping will be heard if the sound
level switch (13) is set to off .
• To overwrite the memory, repeat the above steps
entering a different time interval.
Use Timer Memory
• Press TIMER select button (8) to select a timer
T1 or T2.
• Press and M1 (3), M2 (4), or M3 (5) to select the
select a saved time.
• Press the corresponding T1 START/STOP (6) or
T2 START/STOP (7) button to start the countdown.
e) Count Up Timer
• Press CLEAR (2) to reset values to zero.
• Press the corresponding T1 START/STOP (6) or
T2 START/STOP (7) button to begin the timer.
The LED will not ash while counting up.
• Press the corresponding T1 START/STOP (6) or
T2 START/STOP (7) button to stop timing.
f) Clock Display
View Time of Day
In idle mode, press and hold the (7) button for two
seconds to toggle between clock and countdown /
count up display.
Setting Clock
• If in timer mode, stop any timer in progress then
press and hold the T2 START/STOP (7) button for
two seconds to enter clock mode.
• In clock mode, press and hold the T2 START/
STOP (7) button for 2 seconds until the display
begins to flash.
• Rotate the TIMER dial (8) to set 12/24 hour format.
• Press the T2 START/STOP (7) button to begin
setting the time.
• Rotate the TIMER dial (8) to adjust the time.
• Press T2 START/STOP (7) to save the time and
exit settings.
g) Timer Dial (Sensitivity Adjust)
You can adjust the TIMER dial (8) sensitivity level, so
when you rotate the dial numbers change in greater
increments.
• If in timer mode, stop any timer in progress then
press and hold the T2 START/STOP (7) button for
two seconds to enter clock mode.
• Press and hold CLEAR (2) for five seconds until a
number “1-3” flashes on the LCD display (1).
• Rotate the TIMER dial (8) to choose a value
between 1-3 (1 is least sensitive, 3 is most
sensitive).
• Press CLEAR (2) to save the setting.
h) Mounting Options
The table stand (11) may leave marks on
sensitive surfaces.
When using the magnets (9) to attach to
a magnetic surface, make sure the timer
is held securely in place before letting
go.
The surface for installation should be
dry, clean, flat, stable and free from
debris.
If hanging using the wall mounting hole
(10), when drilling or inserting screws,
make sure there are no cables, wires or
pipes located underneath the surface.
Inadvertently drilling through electric
cables can cause life-threatening
danger of an electric shock!
Care and Cleaning
• Do not use any aggressive cleaning agents,
rubbing alcohol or other chemical solutions as
they can cause damage to the housing and
malfunctioning.
• Clean the product with a dry, fibre-free cloth.
Disposal
a) Product
Electronic devices are recyclable
waste and must not be disposed of in
the household waste. At the end of its
service life, dispose of the product in
accordance with applicable regulatory
guidelines.
Remove any inserted batteries and
dispose of them separately from the
product.
b) Batteries
You as the end user are required by law
(Battery Ordinance) to return all used
(rechargeable) batteries. Disposing
of them in the household waste is
prohibited.
Contaminated batteries are labeled with
this symbol to indicate that disposal in
the domestic waste is forbidden. The
designations for the heavy metals
involved are: Cd = Cadmium, Hg =
Mercury, Pb = Lead (name on batteries,
e.g. below the trash icon on the left).
Used batteries can be returned to collection points
in your municipality, our stores or wherever batteries
are sold.
You thus fulfill your statutory obligations and
contribute to the protection of the environment.
Technical Data
Power source.................... 2 x AAA-type batteries
Countdown timer .............. 99 min 59 s
Count up timer.................. 99 hr 59 min 59 s
Operating conditions......... -5 to +50 °C, 10 – 80 %
Relative humidity
Storage conditions............ -20 to +60 °C, 10 – 80 %
Relative humidity
Dimensions (L x W x H).... 90 x 63.5 x 29.5mm
Weight .............................. 74 g
Operating Instructions
2-Line Timer EDT 8002
Item No. 1754734
Intended Use
This product has dual countdown/up timers that can run simultaneously, three timer memories, and
adjustable alarm volumes. It can be hung onto a wall, placed on a desk or attached to a magnetic surface
via the built in magnets.
It is intended for indoor use only. Do not use it outdoors. Contact with moisture, e.g. in bathrooms, must be
avoided under all circumstances.
For safety and approval purposes, you must not rebuild and/or modify this product. If you use the product
for purposes other than those described above, the product may be damaged. In addition, improper use can
result in other hazards. Read the instructions carefully and store them in a safe place. Make this product
available to third parties only together with its operating instructions.
This product complies with the statutory national and European requirements. All company names and
product names are trademarks of their respective owners. All rights reserved.
Delivery Content
• Timer
• Operating instructions
Up-to-date Operating Instructions
Download the latest operating instructions at www.conrad.com/downloads or scan the QR code shown.
Follow the instructions on the website.
Safety Instructions
Read the operating instructions carefully and
especially observe the safety information. If
you do not follow the safety instructions and
information on proper handling in this manual,
we assume no liability for any resulting personal
injury or damage to property. Such cases will
invalidate the warranty/guarantee.
a) General Information
• The product is not a toy. Keep it out of the reach of
children and pets.
• Do not leave packaging material lying around
carelessly. This may become dangerous playing
material for children.
• Protect the product from extreme temperatures,
direct sunlight, strong jolts, high humidity,
moisture, flammable gases, steam and solvents.
• Do not place the product under any mechanical
stress.
• If it is no longer possible to operate the product
safely, take it out of operation and protect it from
any accidental use. Safe operation can no longer
be guaranteed if the product:
- is visibly damaged,
- is no longer working properly,
- has been stored for extended periods in poor
ambient conditions or
- has been subjected to any serious transport-
related stresses.
• Please handle the product carefully. Jolts, impacts
or a fall even from a low height can damage the
product.
• Consult an expert when in doubt about the
operation, safety or connection of the product.
• Maintenance, modifications and repairs must only
be completed by a technician or an authorised
repair centre. If you have questions which remain
unanswered by these operating instructions,
contact our technical support service or other
technical personnel.
b) Batteries
• Correct polarity must be observed while inserting
the battery.
• The batteries should be removed from the product
if it is not used for a long period of time to avoid
damage through leaking. Leaking or damaged
batteries might cause acid burns when in contact
with skin, therefore use suitable protective gloves
to handle corrupted batteries.
• Batteries must be kept out of reach of children. Do
not leave batteries lying around, as there is risk,
that children or pets swallow them.
• All batteries should be replaced at the same time.
Mixing old and new batteries in the product can
lead to battery leakage and product damage.
• Batteries must not be dismantled, short-circuited or
thrown into fire. Never recharge non-rechargeable
batteries. There is a risk of explosion!
Operating Elements
13
12
11
10
9
6
7
8
2
1
1 LCD display
2 CLEAR button
3 M1 button
4 M2 button
5 M3 button
6 T1 START/STOP button with LED indicator
7 T2 START/STOP/ button with LED indicator
8 TIMER select button/dial
9 Magnets
10 Wall mount hole
11 Table stand
12 Battery compartment cover
13 Volume level switch
Operation
a) Inserting / Replacing Batteries
• Remove the battery compartment cover (12).
• Insert 2x AAA batteries, matching polarity as
shown inside the battery compartment.
• Replace the battery compartment cover (11).
Replace the batteries if the LCD
display (1) gets dim or goes blank.
b) Volume Control
Adjust the beeping and alarm sound level using
the volume switch (13). Mute , low , High .
This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com). All rights
including translation reserved. Reproduction by any method, e.g. photocopy, microlming, or the capture in electronic data
processing systems require the prior written approval by the editor. Reprinting, also in part, is prohibited. This publication
represents the technical status at the time of printing.
Copyright 2019 by Conrad Electronic SE. *1754734_v2_0519_02_dh_m_en

c) Countdown Timer
Set Timer
• If in current time display mode, press the START/
STOP (6) to enter timer mode.
• Press TIMER select button (8) to select a timer
T1 or T2
• Rotate the TIMER dial (8) to set a time.
- Clockwise (increase)
- Anticlockwise (decrease)
• Press the corresponding T1 START/STOP (6)
or T2 START/STOP (7) button to start the timer.
Press again to stop the timer.
• The corresponding T1 START/STOP (6) or T2
START/STOP (7) LED will flash green during the
countdown.
• When the countdown is complete:
- An alarm will sound (no alarm will sound if the
sound level switch (13) is set to off ).
- Timer will start to count up automatically.
- The corresponding T1 START/STOP (6) or T2
START/STOP (7) LED will flash red for 1 minute.
• Press the corresponding T1 START/STOP (6) or
T2 START/STOP (7) button to stop the alarm and
return to the pre-set count down time.
Change Increments (H:MM:ss / MM:SS)
Toggle between “H:MM:ss” and “MM:SS” increments
by pressing and holding the TIMER button (8) for 2
seconds.
d) Countdown Timer Memory (M1, M2, M3)
Save Countdown Times
• Set a desired countdown time using the TIMER
dial (8).
• Press and hold M1 (3), M2 (4), or M3 (5) for 2
seconds.
The LCD display (1) will ash and a beeping will
sound to indicate that a countdown time has been
saved.
No beeping will be heard if the sound
level switch (13) is set to off .
• To overwrite the memory, repeat the above steps
entering a different time interval.
Use Timer Memory
• Press TIMER select button (8) to select a timer
T1 or T2.
• Press and M1 (3), M2 (4), or M3 (5) to select the
select a saved time.
• Press the corresponding T1 START/STOP (6) or
T2 START/STOP (7) button to start the countdown.
e) Count Up Timer
• Press CLEAR (2) to reset values to zero.
• Press the corresponding T1 START/STOP (6) or
T2 START/STOP (7) button to begin the timer.
The LED will not ash while counting up.
• Press the corresponding T1 START/STOP (6) or
T2 START/STOP (7) button to stop timing.
f) Clock Display
View Time of Day
In idle mode, press and hold the (7) button for two
seconds to toggle between clock and countdown /
count up display.
Setting Clock
• If in timer mode, stop any timer in progress then
press and hold the T2 START/STOP (7) button for
two seconds to enter clock mode.
• In clock mode, press and hold the T2 START/
STOP (7) button for 2 seconds until the display
begins to flash.
• Rotate the TIMER dial (8) to set 12/24 hour format.
• Press the T2 START/STOP (7) button to begin
setting the time.
• Rotate the TIMER dial (8) to adjust the time.
• Press T2 START/STOP (7) to save the time and
exit settings.
g) Timer Dial (Sensitivity Adjust)
You can adjust the TIMER dial (8) sensitivity level, so
when you rotate the dial numbers change in greater
increments.
• If in timer mode, stop any timer in progress then
press and hold the T2 START/STOP (7) button for
two seconds to enter clock mode.
• Press and hold CLEAR (2) for five seconds until a
number “1-3” flashes on the LCD display (1).
• Rotate the TIMER dial (8) to choose a value
between 1-3 (1 is least sensitive, 3 is most
sensitive).
• Press CLEAR (2) to save the setting.
h) Mounting Options
The table stand (11) may leave marks on
sensitive surfaces.
When using the magnets (9) to attach to
a magnetic surface, make sure the timer
is held securely in place before letting
go.
The surface for installation should be
dry, clean, flat, stable and free from
debris.
If hanging using the wall mounting hole
(10), when drilling or inserting screws,
make sure there are no cables, wires or
pipes located underneath the surface.
Inadvertently drilling through electric
cables can cause life-threatening
danger of an electric shock!
Care and Cleaning
• Do not use any aggressive cleaning agents,
rubbing alcohol or other chemical solutions as
they can cause damage to the housing and
malfunctioning.
• Clean the product with a dry, fibre-free cloth.
Disposal
a) Product
Electronic devices are recyclable
waste and must not be disposed of in
the household waste. At the end of its
service life, dispose of the product in
accordance with applicable regulatory
guidelines.
Remove any inserted batteries and
dispose of them separately from the
product.
b) Batteries
You as the end user are required by law
(Battery Ordinance) to return all used
(rechargeable) batteries. Disposing
of them in the household waste is
prohibited.
Contaminated batteries are labeled with
this symbol to indicate that disposal in
the domestic waste is forbidden. The
designations for the heavy metals
involved are: Cd = Cadmium, Hg =
Mercury, Pb = Lead (name on batteries,
e.g. below the trash icon on the left).
Used batteries can be returned to collection points
in your municipality, our stores or wherever batteries
are sold.
You thus fulfill your statutory obligations and
contribute to the protection of the environment.
Technical Data
Power source.................... 2 x AAA-type batteries
Countdown timer .............. 99 min 59 s
Count up timer.................. 99 hr 59 min 59 s
Operating conditions......... -5 to +50 °C, 10 – 80 %
Relative humidity
Storage conditions............ -20 to +60 °C, 10 – 80 %
Relative humidity
Dimensions (L x W x H).... 90 x 63.5 x 29.5mm
Weight .............................. 74 g
Operating Instructions
2-Line Timer EDT 8002
Item No. 1754734
Intended Use
This product has dual countdown/up timers that can run simultaneously, three timer memories, and
adjustable alarm volumes. It can be hung onto a wall, placed on a desk or attached to a magnetic surface
via the built in magnets.
It is intended for indoor use only. Do not use it outdoors. Contact with moisture, e.g. in bathrooms, must be
avoided under all circumstances.
For safety and approval purposes, you must not rebuild and/or modify this product. If you use the product
for purposes other than those described above, the product may be damaged. In addition, improper use can
result in other hazards. Read the instructions carefully and store them in a safe place. Make this product
available to third parties only together with its operating instructions.
This product complies with the statutory national and European requirements. All company names and
product names are trademarks of their respective owners. All rights reserved.
Delivery Content
• Timer
• Operating instructions
Up-to-date Operating Instructions
Download the latest operating instructions at www.conrad.com/downloads or scan the QR code shown.
Follow the instructions on the website.
Safety Instructions
Read the operating instructions carefully and
especially observe the safety information. If
you do not follow the safety instructions and
information on proper handling in this manual,
we assume no liability for any resulting personal
injury or damage to property. Such cases will
invalidate the warranty/guarantee.
a) General Information
• The product is not a toy. Keep it out of the reach of
children and pets.
• Do not leave packaging material lying around
carelessly. This may become dangerous playing
material for children.
• Protect the product from extreme temperatures,
direct sunlight, strong jolts, high humidity,
moisture, flammable gases, steam and solvents.
• Do not place the product under any mechanical
stress.
• If it is no longer possible to operate the product
safely, take it out of operation and protect it from
any accidental use. Safe operation can no longer
be guaranteed if the product:
- is visibly damaged,
- is no longer working properly,
- has been stored for extended periods in poor
ambient conditions or
- has been subjected to any serious transport-
related stresses.
• Please handle the product carefully. Jolts, impacts
or a fall even from a low height can damage the
product.
• Consult an expert when in doubt about the
operation, safety or connection of the product.
• Maintenance, modifications and repairs must only
be completed by a technician or an authorised
repair centre. If you have questions which remain
unanswered by these operating instructions,
contact our technical support service or other
technical personnel.
b) Batteries
• Correct polarity must be observed while inserting
the battery.
• The batteries should be removed from the product
if it is not used for a long period of time to avoid
damage through leaking. Leaking or damaged
batteries might cause acid burns when in contact
with skin, therefore use suitable protective gloves
to handle corrupted batteries.
• Batteries must be kept out of reach of children. Do
not leave batteries lying around, as there is risk,
that children or pets swallow them.
• All batteries should be replaced at the same time.
Mixing old and new batteries in the product can
lead to battery leakage and product damage.
• Batteries must not be dismantled, short-circuited or
thrown into fire. Never recharge non-rechargeable
batteries. There is a risk of explosion!
Operating Elements
13
12
11
10
9
6
7
8
2
1
1 LCD display
2 CLEAR button
3 M1 button
4 M2 button
5 M3 button
6 T1 START/STOP button with LED indicator
7 T2 START/STOP/ button with LED indicator
8 TIMER select button/dial
9 Magnets
10 Wall mount hole
11 Table stand
12 Battery compartment cover
13 Volume level switch
Operation
a) Inserting / Replacing Batteries
• Remove the battery compartment cover (12).
• Insert 2x AAA batteries, matching polarity as
shown inside the battery compartment.
• Replace the battery compartment cover (11).
Replace the batteries if the LCD
display (1) gets dim or goes blank.
b) Volume Control
Adjust the beeping and alarm sound level using
the volume switch (13). Mute , low , High .
This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com). All rights
including translation reserved. Reproduction by any method, e.g. photocopy, microlming, or the capture in electronic data
processing systems require the prior written approval by the editor. Reprinting, also in part, is prohibited. This publication
represents the technical status at the time of printing.
Copyright 2019 by Conrad Electronic SE. *1754734_v2_0519_02_dh_m_en

c) Countdown Timer
Set Timer
• If in current time display mode, press the START/
STOP (6) to enter timer mode.
• Press TIMER select button (8) to select a timer
T1 or T2
• Rotate the TIMER dial (8) to set a time.
- Clockwise (increase)
- Anticlockwise (decrease)
• Press the corresponding T1 START/STOP (6)
or T2 START/STOP (7) button to start the timer.
Press again to stop the timer.
• The corresponding T1 START/STOP (6) or T2
START/STOP (7) LED will flash green during the
countdown.
• When the countdown is complete:
- An alarm will sound (no alarm will sound if the
sound level switch (13) is set to off ).
- Timer will start to count up automatically.
- The corresponding T1 START/STOP (6) or T2
START/STOP (7) LED will flash red for 1 minute.
• Press the corresponding T1 START/STOP (6) or
T2 START/STOP (7) button to stop the alarm and
return to the pre-set count down time.
Change Increments (H:MM:ss / MM:SS)
Toggle between “H:MM:ss” and “MM:SS” increments
by pressing and holding the TIMER button (8) for 2
seconds.
d) Countdown Timer Memory (M1, M2, M3)
Save Countdown Times
• Set a desired countdown time using the TIMER
dial (8).
• Press and hold M1 (3), M2 (4), or M3 (5) for 2
seconds.
The LCD display (1) will ash and a beeping will
sound to indicate that a countdown time has been
saved.
No beeping will be heard if the sound
level switch (13) is set to off .
• To overwrite the memory, repeat the above steps
entering a different time interval.
Use Timer Memory
• Press TIMER select button (8) to select a timer
T1 or T2.
• Press and M1 (3), M2 (4), or M3 (5) to select the
select a saved time.
• Press the corresponding T1 START/STOP (6) or
T2 START/STOP (7) button to start the countdown.
e) Count Up Timer
• Press CLEAR (2) to reset values to zero.
• Press the corresponding T1 START/STOP (6) or
T2 START/STOP (7) button to begin the timer.
The LED will not ash while counting up.
• Press the corresponding T1 START/STOP (6) or
T2 START/STOP (7) button to stop timing.
f) Clock Display
View Time of Day
In idle mode, press and hold the (7) button for two
seconds to toggle between clock and countdown /
count up display.
Setting Clock
• If in timer mode, stop any timer in progress then
press and hold the T2 START/STOP (7) button for
two seconds to enter clock mode.
• In clock mode, press and hold the T2 START/
STOP (7) button for 2 seconds until the display
begins to flash.
• Rotate the TIMER dial (8) to set 12/24 hour format.
• Press the T2 START/STOP (7) button to begin
setting the time.
• Rotate the TIMER dial (8) to adjust the time.
• Press T2 START/STOP (7) to save the time and
exit settings.
g) Timer Dial (Sensitivity Adjust)
You can adjust the TIMER dial (8) sensitivity level, so
when you rotate the dial numbers change in greater
increments.
• If in timer mode, stop any timer in progress then
press and hold the T2 START/STOP (7) button for
two seconds to enter clock mode.
• Press and hold CLEAR (2) for five seconds until a
number “1-3” flashes on the LCD display (1).
• Rotate the TIMER dial (8) to choose a value
between 1-3 (1 is least sensitive, 3 is most
sensitive).
• Press CLEAR (2) to save the setting.
h) Mounting Options
The table stand (11) may leave marks on
sensitive surfaces.
When using the magnets (9) to attach to
a magnetic surface, make sure the timer
is held securely in place before letting
go.
The surface for installation should be
dry, clean, flat, stable and free from
debris.
If hanging using the wall mounting hole
(10), when drilling or inserting screws,
make sure there are no cables, wires or
pipes located underneath the surface.
Inadvertently drilling through electric
cables can cause life-threatening
danger of an electric shock!
Care and Cleaning
• Do not use any aggressive cleaning agents,
rubbing alcohol or other chemical solutions as
they can cause damage to the housing and
malfunctioning.
• Clean the product with a dry, fibre-free cloth.
Disposal
a) Product
Electronic devices are recyclable
waste and must not be disposed of in
the household waste. At the end of its
service life, dispose of the product in
accordance with applicable regulatory
guidelines.
Remove any inserted batteries and
dispose of them separately from the
product.
b) Batteries
You as the end user are required by law
(Battery Ordinance) to return all used
(rechargeable) batteries. Disposing
of them in the household waste is
prohibited.
Contaminated batteries are labeled with
this symbol to indicate that disposal in
the domestic waste is forbidden. The
designations for the heavy metals
involved are: Cd = Cadmium, Hg =
Mercury, Pb = Lead (name on batteries,
e.g. below the trash icon on the left).
Used batteries can be returned to collection points
in your municipality, our stores or wherever batteries
are sold.
You thus fulfill your statutory obligations and
contribute to the protection of the environment.
Technical Data
Power source.................... 2 x AAA-type batteries
Countdown timer .............. 99 min 59 s
Count up timer.................. 99 hr 59 min 59 s
Operating conditions......... -5 to +50 °C, 10 – 80 %
Relative humidity
Storage conditions............ -20 to +60 °C, 10 – 80 %
Relative humidity
Dimensions (L x W x H).... 90 x 63.5 x 29.5mm
Weight .............................. 74 g
Operating Instructions
2-Line Timer EDT 8002
Item No. 1754734
Intended Use
This product has dual countdown/up timers that can run simultaneously, three timer memories, and
adjustable alarm volumes. It can be hung onto a wall, placed on a desk or attached to a magnetic surface
via the built in magnets.
It is intended for indoor use only. Do not use it outdoors. Contact with moisture, e.g. in bathrooms, must be
avoided under all circumstances.
For safety and approval purposes, you must not rebuild and/or modify this product. If you use the product
for purposes other than those described above, the product may be damaged. In addition, improper use can
result in other hazards. Read the instructions carefully and store them in a safe place. Make this product
available to third parties only together with its operating instructions.
This product complies with the statutory national and European requirements. All company names and
product names are trademarks of their respective owners. All rights reserved.
Delivery Content
• Timer
• Operating instructions
Up-to-date Operating Instructions
Download the latest operating instructions at www.conrad.com/downloads or scan the QR code shown.
Follow the instructions on the website.
Safety Instructions
Read the operating instructions carefully and
especially observe the safety information. If
you do not follow the safety instructions and
information on proper handling in this manual,
we assume no liability for any resulting personal
injury or damage to property. Such cases will
invalidate the warranty/guarantee.
a) General Information
• The product is not a toy. Keep it out of the reach of
children and pets.
• Do not leave packaging material lying around
carelessly. This may become dangerous playing
material for children.
• Protect the product from extreme temperatures,
direct sunlight, strong jolts, high humidity,
moisture, flammable gases, steam and solvents.
• Do not place the product under any mechanical
stress.
• If it is no longer possible to operate the product
safely, take it out of operation and protect it from
any accidental use. Safe operation can no longer
be guaranteed if the product:
- is visibly damaged,
- is no longer working properly,
- has been stored for extended periods in poor
ambient conditions or
- has been subjected to any serious transport-
related stresses.
• Please handle the product carefully. Jolts, impacts
or a fall even from a low height can damage the
product.
• Consult an expert when in doubt about the
operation, safety or connection of the product.
• Maintenance, modifications and repairs must only
be completed by a technician or an authorised
repair centre. If you have questions which remain
unanswered by these operating instructions,
contact our technical support service or other
technical personnel.
b) Batteries
• Correct polarity must be observed while inserting
the battery.
• The batteries should be removed from the product
if it is not used for a long period of time to avoid
damage through leaking. Leaking or damaged
batteries might cause acid burns when in contact
with skin, therefore use suitable protective gloves
to handle corrupted batteries.
• Batteries must be kept out of reach of children. Do
not leave batteries lying around, as there is risk,
that children or pets swallow them.
• All batteries should be replaced at the same time.
Mixing old and new batteries in the product can
lead to battery leakage and product damage.
• Batteries must not be dismantled, short-circuited or
thrown into fire. Never recharge non-rechargeable
batteries. There is a risk of explosion!
Operating Elements
13
12
11
10
9
6
7
8
2
1
1 LCD display
2 CLEAR button
3 M1 button
4 M2 button
5 M3 button
6 T1 START/STOP button with LED indicator
7 T2 START/STOP/ button with LED indicator
8 TIMER select button/dial
9 Magnets
10 Wall mount hole
11 Table stand
12 Battery compartment cover
13 Volume level switch
Operation
a) Inserting / Replacing Batteries
• Remove the battery compartment cover (12).
• Insert 2x AAA batteries, matching polarity as
shown inside the battery compartment.
• Replace the battery compartment cover (11).
Replace the batteries if the LCD
display (1) gets dim or goes blank.
b) Volume Control
Adjust the beeping and alarm sound level using
the volume switch (13). Mute , low , High .
This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com). All rights
including translation reserved. Reproduction by any method, e.g. photocopy, microlming, or the capture in electronic data
processing systems require the prior written approval by the editor. Reprinting, also in part, is prohibited. This publication
represents the technical status at the time of printing.
Copyright 2019 by Conrad Electronic SE. *1754734_v2_0519_02_dh_m_en

c) Countdown Timer
Set Timer
• If in current time display mode, press the START/
STOP (6) to enter timer mode.
• Press TIMER select button (8) to select a timer
T1 or T2
• Rotate the TIMER dial (8) to set a time.
- Clockwise (increase)
- Anticlockwise (decrease)
• Press the corresponding T1 START/STOP (6)
or T2 START/STOP (7) button to start the timer.
Press again to stop the timer.
• The corresponding T1 START/STOP (6) or T2
START/STOP (7) LED will flash green during the
countdown.
• When the countdown is complete:
- An alarm will sound (no alarm will sound if the
sound level switch (13) is set to off ).
- Timer will start to count up automatically.
- The corresponding T1 START/STOP (6) or T2
START/STOP (7) LED will flash red for 1 minute.
• Press the corresponding T1 START/STOP (6) or
T2 START/STOP (7) button to stop the alarm and
return to the pre-set count down time.
Change Increments (H:MM:ss / MM:SS)
Toggle between “H:MM:ss” and “MM:SS” increments
by pressing and holding the TIMER button (8) for 2
seconds.
d) Countdown Timer Memory (M1, M2, M3)
Save Countdown Times
• Set a desired countdown time using the TIMER
dial (8).
• Press and hold M1 (3), M2 (4), or M3 (5) for 2
seconds.
The LCD display (1) will ash and a beeping will
sound to indicate that a countdown time has been
saved.
No beeping will be heard if the sound
level switch (13) is set to off .
• To overwrite the memory, repeat the above steps
entering a different time interval.
Use Timer Memory
• Press TIMER select button (8) to select a timer
T1 or T2.
• Press and M1 (3), M2 (4), or M3 (5) to select the
select a saved time.
• Press the corresponding T1 START/STOP (6) or
T2 START/STOP (7) button to start the countdown.
e) Count Up Timer
• Press CLEAR (2) to reset values to zero.
• Press the corresponding T1 START/STOP (6) or
T2 START/STOP (7) button to begin the timer.
The LED will not ash while counting up.
• Press the corresponding T1 START/STOP (6) or
T2 START/STOP (7) button to stop timing.
f) Clock Display
View Time of Day
In idle mode, press and hold the (7) button for two
seconds to toggle between clock and countdown /
count up display.
Setting Clock
• If in timer mode, stop any timer in progress then
press and hold the T2 START/STOP (7) button for
two seconds to enter clock mode.
• In clock mode, press and hold the T2 START/
STOP (7) button for 2 seconds until the display
begins to flash.
• Rotate the TIMER dial (8) to set 12/24 hour format.
• Press the T2 START/STOP (7) button to begin
setting the time.
• Rotate the TIMER dial (8) to adjust the time.
• Press T2 START/STOP (7) to save the time and
exit settings.
g) Timer Dial (Sensitivity Adjust)
You can adjust the TIMER dial (8) sensitivity level, so
when you rotate the dial numbers change in greater
increments.
• If in timer mode, stop any timer in progress then
press and hold the T2 START/STOP (7) button for
two seconds to enter clock mode.
• Press and hold CLEAR (2) for five seconds until a
number “1-3” flashes on the LCD display (1).
• Rotate the TIMER dial (8) to choose a value
between 1-3 (1 is least sensitive, 3 is most
sensitive).
• Press CLEAR (2) to save the setting.
h) Mounting Options
The table stand (11) may leave marks on
sensitive surfaces.
When using the magnets (9) to attach to
a magnetic surface, make sure the timer
is held securely in place before letting
go.
The surface for installation should be
dry, clean, flat, stable and free from
debris.
If hanging using the wall mounting hole
(10), when drilling or inserting screws,
make sure there are no cables, wires or
pipes located underneath the surface.
Inadvertently drilling through electric
cables can cause life-threatening
danger of an electric shock!
Care and Cleaning
• Do not use any aggressive cleaning agents,
rubbing alcohol or other chemical solutions as
they can cause damage to the housing and
malfunctioning.
• Clean the product with a dry, fibre-free cloth.
Disposal
a) Product
Electronic devices are recyclable
waste and must not be disposed of in
the household waste. At the end of its
service life, dispose of the product in
accordance with applicable regulatory
guidelines.
Remove any inserted batteries and
dispose of them separately from the
product.
b) Batteries
You as the end user are required by law
(Battery Ordinance) to return all used
(rechargeable) batteries. Disposing
of them in the household waste is
prohibited.
Contaminated batteries are labeled with
this symbol to indicate that disposal in
the domestic waste is forbidden. The
designations for the heavy metals
involved are: Cd = Cadmium, Hg =
Mercury, Pb = Lead (name on batteries,
e.g. below the trash icon on the left).
Used batteries can be returned to collection points
in your municipality, our stores or wherever batteries
are sold.
You thus fulfill your statutory obligations and
contribute to the protection of the environment.
Technical Data
Power source.................... 2 x AAA-type batteries
Countdown timer .............. 99 min 59 s
Count up timer.................. 99 hr 59 min 59 s
Operating conditions......... -5 to +50 °C, 10 – 80 %
Relative humidity
Storage conditions............ -20 to +60 °C, 10 – 80 %
Relative humidity
Dimensions (L x W x H).... 90 x 63.5 x 29.5mm
Weight .............................. 74 g
Operating Instructions
2-Line Timer EDT 8002
Item No. 1754734
Intended Use
This product has dual countdown/up timers that can run simultaneously, three timer memories, and
adjustable alarm volumes. It can be hung onto a wall, placed on a desk or attached to a magnetic surface
via the built in magnets.
It is intended for indoor use only. Do not use it outdoors. Contact with moisture, e.g. in bathrooms, must be
avoided under all circumstances.
For safety and approval purposes, you must not rebuild and/or modify this product. If you use the product
for purposes other than those described above, the product may be damaged. In addition, improper use can
result in other hazards. Read the instructions carefully and store them in a safe place. Make this product
available to third parties only together with its operating instructions.
This product complies with the statutory national and European requirements. All company names and
product names are trademarks of their respective owners. All rights reserved.
Delivery Content
• Timer
• Operating instructions
Up-to-date Operating Instructions
Download the latest operating instructions at www.conrad.com/downloads or scan the QR code shown.
Follow the instructions on the website.
Safety Instructions
Read the operating instructions carefully and
especially observe the safety information. If
you do not follow the safety instructions and
information on proper handling in this manual,
we assume no liability for any resulting personal
injury or damage to property. Such cases will
invalidate the warranty/guarantee.
a) General Information
• The product is not a toy. Keep it out of the reach of
children and pets.
• Do not leave packaging material lying around
carelessly. This may become dangerous playing
material for children.
• Protect the product from extreme temperatures,
direct sunlight, strong jolts, high humidity,
moisture, flammable gases, steam and solvents.
• Do not place the product under any mechanical
stress.
• If it is no longer possible to operate the product
safely, take it out of operation and protect it from
any accidental use. Safe operation can no longer
be guaranteed if the product:
- is visibly damaged,
- is no longer working properly,
- has been stored for extended periods in poor
ambient conditions or
- has been subjected to any serious transport-
related stresses.
• Please handle the product carefully. Jolts, impacts
or a fall even from a low height can damage the
product.
• Consult an expert when in doubt about the
operation, safety or connection of the product.
• Maintenance, modifications and repairs must only
be completed by a technician or an authorised
repair centre. If you have questions which remain
unanswered by these operating instructions,
contact our technical support service or other
technical personnel.
b) Batteries
• Correct polarity must be observed while inserting
the battery.
• The batteries should be removed from the product
if it is not used for a long period of time to avoid
damage through leaking. Leaking or damaged
batteries might cause acid burns when in contact
with skin, therefore use suitable protective gloves
to handle corrupted batteries.
• Batteries must be kept out of reach of children. Do
not leave batteries lying around, as there is risk,
that children or pets swallow them.
• All batteries should be replaced at the same time.
Mixing old and new batteries in the product can
lead to battery leakage and product damage.
• Batteries must not be dismantled, short-circuited or
thrown into fire. Never recharge non-rechargeable
batteries. There is a risk of explosion!
Operating Elements
13
12
11
10
9
6
7
8
2
1
1 LCD display
2 CLEAR button
3 M1 button
4 M2 button
5 M3 button
6 T1 START/STOP button with LED indicator
7 T2 START/STOP/ button with LED indicator
8 TIMER select button/dial
9 Magnets
10 Wall mount hole
11 Table stand
12 Battery compartment cover
13 Volume level switch
Operation
a) Inserting / Replacing Batteries
• Remove the battery compartment cover (12).
• Insert 2x AAA batteries, matching polarity as
shown inside the battery compartment.
• Replace the battery compartment cover (11).
Replace the batteries if the LCD
display (1) gets dim or goes blank.
b) Volume Control
Adjust the beeping and alarm sound level using
the volume switch (13). Mute , low , High .
This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com). All rights
including translation reserved. Reproduction by any method, e.g. photocopy, microlming, or the capture in electronic data
processing systems require the prior written approval by the editor. Reprinting, also in part, is prohibited. This publication
represents the technical status at the time of printing.
Copyright 2019 by Conrad Electronic SE. *1754734_v2_0519_02_dh_m_en

c) Countdown Timer
Set Timer
• If in current time display mode, press the START/
STOP (6) to enter timer mode.
• Press TIMER select button (8) to select a timer
T1 or T2
• Rotate the TIMER dial (8) to set a time.
- Clockwise (increase)
- Anticlockwise (decrease)
• Press the corresponding T1 START/STOP (6)
or T2 START/STOP (7) button to start the timer.
Press again to stop the timer.
• The corresponding T1 START/STOP (6) or T2
START/STOP (7) LED will flash green during the
countdown.
• When the countdown is complete:
- An alarm will sound (no alarm will sound if the
sound level switch (13) is set to off ).
- Timer will start to count up automatically.
- The corresponding T1 START/STOP (6) or T2
START/STOP (7) LED will flash red for 1 minute.
• Press the corresponding T1 START/STOP (6) or
T2 START/STOP (7) button to stop the alarm and
return to the pre-set count down time.
Change Increments (H:MM:ss / MM:SS)
Toggle between “H:MM:ss” and “MM:SS” increments
by pressing and holding the TIMER button (8) for 2
seconds.
d) Countdown Timer Memory (M1, M2, M3)
Save Countdown Times
• Set a desired countdown time using the TIMER
dial (8).
• Press and hold M1 (3), M2 (4), or M3 (5) for 2
seconds.
The LCD display (1) will ash and a beeping will
sound to indicate that a countdown time has been
saved.
No beeping will be heard if the sound
level switch (13) is set to off .
• To overwrite the memory, repeat the above steps
entering a different time interval.
Use Timer Memory
• Press TIMER select button (8) to select a timer
T1 or T2.
• Press and M1 (3), M2 (4), or M3 (5) to select the
select a saved time.
• Press the corresponding T1 START/STOP (6) or
T2 START/STOP (7) button to start the countdown.
e) Count Up Timer
• Press CLEAR (2) to reset values to zero.
• Press the corresponding T1 START/STOP (6) or
T2 START/STOP (7) button to begin the timer.
The LED will not ash while counting up.
• Press the corresponding T1 START/STOP (6) or
T2 START/STOP (7) button to stop timing.
f) Clock Display
View Time of Day
In idle mode, press and hold the (7) button for two
seconds to toggle between clock and countdown /
count up display.
Setting Clock
• If in timer mode, stop any timer in progress then
press and hold the T2 START/STOP (7) button for
two seconds to enter clock mode.
• In clock mode, press and hold the T2 START/
STOP (7) button for 2 seconds until the display
begins to flash.
• Rotate the TIMER dial (8) to set 12/24 hour format.
• Press the T2 START/STOP (7) button to begin
setting the time.
• Rotate the TIMER dial (8) to adjust the time.
• Press T2 START/STOP (7) to save the time and
exit settings.
g) Timer Dial (Sensitivity Adjust)
You can adjust the TIMER dial (8) sensitivity level, so
when you rotate the dial numbers change in greater
increments.
• If in timer mode, stop any timer in progress then
press and hold the T2 START/STOP (7) button for
two seconds to enter clock mode.
• Press and hold CLEAR (2) for five seconds until a
number “1-3” flashes on the LCD display (1).
• Rotate the TIMER dial (8) to choose a value
between 1-3 (1 is least sensitive, 3 is most
sensitive).
• Press CLEAR (2) to save the setting.
h) Mounting Options
The table stand (11) may leave marks on
sensitive surfaces.
When using the magnets (9) to attach to
a magnetic surface, make sure the timer
is held securely in place before letting
go.
The surface for installation should be
dry, clean, flat, stable and free from
debris.
If hanging using the wall mounting hole
(10), when drilling or inserting screws,
make sure there are no cables, wires or
pipes located underneath the surface.
Inadvertently drilling through electric
cables can cause life-threatening
danger of an electric shock!
Care and Cleaning
• Do not use any aggressive cleaning agents,
rubbing alcohol or other chemical solutions as
they can cause damage to the housing and
malfunctioning.
• Clean the product with a dry, fibre-free cloth.
Disposal
a) Product
Electronic devices are recyclable
waste and must not be disposed of in
the household waste. At the end of its
service life, dispose of the product in
accordance with applicable regulatory
guidelines.
Remove any inserted batteries and
dispose of them separately from the
product.
b) Batteries
You as the end user are required by law
(Battery Ordinance) to return all used
(rechargeable) batteries. Disposing
of them in the household waste is
prohibited.
Contaminated batteries are labeled with
this symbol to indicate that disposal in
the domestic waste is forbidden. The
designations for the heavy metals
involved are: Cd = Cadmium, Hg =
Mercury, Pb = Lead (name on batteries,
e.g. below the trash icon on the left).
Used batteries can be returned to collection points
in your municipality, our stores or wherever batteries
are sold.
You thus fulfill your statutory obligations and
contribute to the protection of the environment.
Technical Data
Power source.................... 2 x AAA-type batteries
Countdown timer .............. 99 min 59 s
Count up timer.................. 99 hr 59 min 59 s
Operating conditions......... -5 to +50 °C, 10 – 80 %
Relative humidity
Storage conditions............ -20 to +60 °C, 10 – 80 %
Relative humidity
Dimensions (L x W x H).... 90 x 63.5 x 29.5mm
Weight .............................. 74 g
Operating Instructions
2-Line Timer EDT 8002
Item No. 1754734
Intended Use
This product has dual countdown/up timers that can run simultaneously, three timer memories, and
adjustable alarm volumes. It can be hung onto a wall, placed on a desk or attached to a magnetic surface
via the built in magnets.
It is intended for indoor use only. Do not use it outdoors. Contact with moisture, e.g. in bathrooms, must be
avoided under all circumstances.
For safety and approval purposes, you must not rebuild and/or modify this product. If you use the product
for purposes other than those described above, the product may be damaged. In addition, improper use can
result in other hazards. Read the instructions carefully and store them in a safe place. Make this product
available to third parties only together with its operating instructions.
This product complies with the statutory national and European requirements. All company names and
product names are trademarks of their respective owners. All rights reserved.
Delivery Content
• Timer
• Operating instructions
Up-to-date Operating Instructions
Download the latest operating instructions at www.conrad.com/downloads or scan the QR code shown.
Follow the instructions on the website.
Safety Instructions
Read the operating instructions carefully and
especially observe the safety information. If
you do not follow the safety instructions and
information on proper handling in this manual,
we assume no liability for any resulting personal
injury or damage to property. Such cases will
invalidate the warranty/guarantee.
a) General Information
• The product is not a toy. Keep it out of the reach of
children and pets.
• Do not leave packaging material lying around
carelessly. This may become dangerous playing
material for children.
• Protect the product from extreme temperatures,
direct sunlight, strong jolts, high humidity,
moisture, flammable gases, steam and solvents.
• Do not place the product under any mechanical
stress.
• If it is no longer possible to operate the product
safely, take it out of operation and protect it from
any accidental use. Safe operation can no longer
be guaranteed if the product:
- is visibly damaged,
- is no longer working properly,
- has been stored for extended periods in poor
ambient conditions or
- has been subjected to any serious transport-
related stresses.
• Please handle the product carefully. Jolts, impacts
or a fall even from a low height can damage the
product.
• Consult an expert when in doubt about the
operation, safety or connection of the product.
• Maintenance, modifications and repairs must only
be completed by a technician or an authorised
repair centre. If you have questions which remain
unanswered by these operating instructions,
contact our technical support service or other
technical personnel.
b) Batteries
• Correct polarity must be observed while inserting
the battery.
• The batteries should be removed from the product
if it is not used for a long period of time to avoid
damage through leaking. Leaking or damaged
batteries might cause acid burns when in contact
with skin, therefore use suitable protective gloves
to handle corrupted batteries.
• Batteries must be kept out of reach of children. Do
not leave batteries lying around, as there is risk,
that children or pets swallow them.
• All batteries should be replaced at the same time.
Mixing old and new batteries in the product can
lead to battery leakage and product damage.
• Batteries must not be dismantled, short-circuited or
thrown into fire. Never recharge non-rechargeable
batteries. There is a risk of explosion!
Operating Elements
13
12
11
10
9
6
7
8
2
1
1 LCD display
2 CLEAR button
3 M1 button
4 M2 button
5 M3 button
6 T1 START/STOP button with LED indicator
7 T2 START/STOP/ button with LED indicator
8 TIMER select button/dial
9 Magnets
10 Wall mount hole
11 Table stand
12 Battery compartment cover
13 Volume level switch
Operation
a) Inserting / Replacing Batteries
• Remove the battery compartment cover (12).
• Insert 2x AAA batteries, matching polarity as
shown inside the battery compartment.
• Replace the battery compartment cover (11).
Replace the batteries if the LCD
display (1) gets dim or goes blank.
b) Volume Control
Adjust the beeping and alarm sound level using
the volume switch (13). Mute , low , High .
This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com). All rights
including translation reserved. Reproduction by any method, e.g. photocopy, microlming, or the capture in electronic data
processing systems require the prior written approval by the editor. Reprinting, also in part, is prohibited. This publication
represents the technical status at the time of printing.
Copyright 2019 by Conrad Electronic SE. *1754734_v2_0519_02_dh_m_en

c) Countdown Timer
Set Timer
• If in current time display mode, press the START/
STOP (6) to enter timer mode.
• Press TIMER select button (8) to select a timer
T1 or T2
• Rotate the TIMER dial (8) to set a time.
- Clockwise (increase)
- Anticlockwise (decrease)
• Press the corresponding T1 START/STOP (6)
or T2 START/STOP (7) button to start the timer.
Press again to stop the timer.
• The corresponding T1 START/STOP (6) or T2
START/STOP (7) LED will flash green during the
countdown.
• When the countdown is complete:
- An alarm will sound (no alarm will sound if the
sound level switch (13) is set to off ).
- Timer will start to count up automatically.
- The corresponding T1 START/STOP (6) or T2
START/STOP (7) LED will flash red for 1 minute.
• Press the corresponding T1 START/STOP (6) or
T2 START/STOP (7) button to stop the alarm and
return to the pre-set count down time.
Change Increments (H:MM:ss / MM:SS)
Toggle between “H:MM:ss” and “MM:SS” increments
by pressing and holding the TIMER button (8) for 2
seconds.
d) Countdown Timer Memory (M1, M2, M3)
Save Countdown Times
• Set a desired countdown time using the TIMER
dial (8).
• Press and hold M1 (3), M2 (4), or M3 (5) for 2
seconds.
The LCD display (1) will ash and a beeping will
sound to indicate that a countdown time has been
saved.
No beeping will be heard if the sound
level switch (13) is set to off .
• To overwrite the memory, repeat the above steps
entering a different time interval.
Use Timer Memory
• Press TIMER select button (8) to select a timer
T1 or T2.
• Press and M1 (3), M2 (4), or M3 (5) to select the
select a saved time.
• Press the corresponding T1 START/STOP (6) or
T2 START/STOP (7) button to start the countdown.
e) Count Up Timer
• Press CLEAR (2) to reset values to zero.
• Press the corresponding T1 START/STOP (6) or
T2 START/STOP (7) button to begin the timer.
The LED will not ash while counting up.
• Press the corresponding T1 START/STOP (6) or
T2 START/STOP (7) button to stop timing.
f) Clock Display
View Time of Day
In idle mode, press and hold the (7) button for two
seconds to toggle between clock and countdown /
count up display.
Setting Clock
• If in timer mode, stop any timer in progress then
press and hold the T2 START/STOP (7) button for
two seconds to enter clock mode.
• In clock mode, press and hold the T2 START/
STOP (7) button for 2 seconds until the display
begins to flash.
• Rotate the TIMER dial (8) to set 12/24 hour format.
• Press the T2 START/STOP (7) button to begin
setting the time.
• Rotate the TIMER dial (8) to adjust the time.
• Press T2 START/STOP (7) to save the time and
exit settings.
g) Timer Dial (Sensitivity Adjust)
You can adjust the TIMER dial (8) sensitivity level, so
when you rotate the dial numbers change in greater
increments.
• If in timer mode, stop any timer in progress then
press and hold the T2 START/STOP (7) button for
two seconds to enter clock mode.
• Press and hold CLEAR (2) for five seconds until a
number “1-3” flashes on the LCD display (1).
• Rotate the TIMER dial (8) to choose a value
between 1-3 (1 is least sensitive, 3 is most
sensitive).
• Press CLEAR (2) to save the setting.
h) Mounting Options
The table stand (11) may leave marks on
sensitive surfaces.
When using the magnets (9) to attach to
a magnetic surface, make sure the timer
is held securely in place before letting
go.
The surface for installation should be
dry, clean, flat, stable and free from
debris.
If hanging using the wall mounting hole
(10), when drilling or inserting screws,
make sure there are no cables, wires or
pipes located underneath the surface.
Inadvertently drilling through electric
cables can cause life-threatening
danger of an electric shock!
Care and Cleaning
• Do not use any aggressive cleaning agents,
rubbing alcohol or other chemical solutions as
they can cause damage to the housing and
malfunctioning.
• Clean the product with a dry, fibre-free cloth.
Disposal
a) Product
Electronic devices are recyclable
waste and must not be disposed of in
the household waste. At the end of its
service life, dispose of the product in
accordance with applicable regulatory
guidelines.
Remove any inserted batteries and
dispose of them separately from the
product.
b) Batteries
You as the end user are required by law
(Battery Ordinance) to return all used
(rechargeable) batteries. Disposing
of them in the household waste is
prohibited.
Contaminated batteries are labeled with
this symbol to indicate that disposal in
the domestic waste is forbidden. The
designations for the heavy metals
involved are: Cd = Cadmium, Hg =
Mercury, Pb = Lead (name on batteries,
e.g. below the trash icon on the left).
Used batteries can be returned to collection points
in your municipality, our stores or wherever batteries
are sold.
You thus fulfill your statutory obligations and
contribute to the protection of the environment.
Technical Data
Power source.................... 2 x AAA-type batteries
Countdown timer .............. 99 min 59 s
Count up timer.................. 99 hr 59 min 59 s
Operating conditions......... -5 to +50 °C, 10 – 80 %
Relative humidity
Storage conditions............ -20 to +60 °C, 10 – 80 %
Relative humidity
Dimensions (L x W x H).... 90 x 63.5 x 29.5mm
Weight .............................. 74 g
Operating Instructions
2-Line Timer EDT 8002
Item No. 1754734
Intended Use
This product has dual countdown/up timers that can run simultaneously, three timer memories, and
adjustable alarm volumes. It can be hung onto a wall, placed on a desk or attached to a magnetic surface
via the built in magnets.
It is intended for indoor use only. Do not use it outdoors. Contact with moisture, e.g. in bathrooms, must be
avoided under all circumstances.
For safety and approval purposes, you must not rebuild and/or modify this product. If you use the product
for purposes other than those described above, the product may be damaged. In addition, improper use can
result in other hazards. Read the instructions carefully and store them in a safe place. Make this product
available to third parties only together with its operating instructions.
This product complies with the statutory national and European requirements. All company names and
product names are trademarks of their respective owners. All rights reserved.
Delivery Content
• Timer
• Operating instructions
Up-to-date Operating Instructions
Download the latest operating instructions at www.conrad.com/downloads or scan the QR code shown.
Follow the instructions on the website.
Safety Instructions
Read the operating instructions carefully and
especially observe the safety information. If
you do not follow the safety instructions and
information on proper handling in this manual,
we assume no liability for any resulting personal
injury or damage to property. Such cases will
invalidate the warranty/guarantee.
a) General Information
• The product is not a toy. Keep it out of the reach of
children and pets.
• Do not leave packaging material lying around
carelessly. This may become dangerous playing
material for children.
• Protect the product from extreme temperatures,
direct sunlight, strong jolts, high humidity,
moisture, flammable gases, steam and solvents.
• Do not place the product under any mechanical
stress.
• If it is no longer possible to operate the product
safely, take it out of operation and protect it from
any accidental use. Safe operation can no longer
be guaranteed if the product:
- is visibly damaged,
- is no longer working properly,
- has been stored for extended periods in poor
ambient conditions or
- has been subjected to any serious transport-
related stresses.
• Please handle the product carefully. Jolts, impacts
or a fall even from a low height can damage the
product.
• Consult an expert when in doubt about the
operation, safety or connection of the product.
• Maintenance, modifications and repairs must only
be completed by a technician or an authorised
repair centre. If you have questions which remain
unanswered by these operating instructions,
contact our technical support service or other
technical personnel.
b) Batteries
• Correct polarity must be observed while inserting
the battery.
• The batteries should be removed from the product
if it is not used for a long period of time to avoid
damage through leaking. Leaking or damaged
batteries might cause acid burns when in contact
with skin, therefore use suitable protective gloves
to handle corrupted batteries.
• Batteries must be kept out of reach of children. Do
not leave batteries lying around, as there is risk,
that children or pets swallow them.
• All batteries should be replaced at the same time.
Mixing old and new batteries in the product can
lead to battery leakage and product damage.
• Batteries must not be dismantled, short-circuited or
thrown into fire. Never recharge non-rechargeable
batteries. There is a risk of explosion!
Operating Elements
13
12
11
10
9
6
7
8
2
1
1 LCD display
2 CLEAR button
3 M1 button
4 M2 button
5 M3 button
6 T1 START/STOP button with LED indicator
7 T2 START/STOP/ button with LED indicator
8 TIMER select button/dial
9 Magnets
10 Wall mount hole
11 Table stand
12 Battery compartment cover
13 Volume level switch
Operation
a) Inserting / Replacing Batteries
• Remove the battery compartment cover (12).
• Insert 2x AAA batteries, matching polarity as
shown inside the battery compartment.
• Replace the battery compartment cover (11).
Replace the batteries if the LCD
display (1) gets dim or goes blank.
b) Volume Control
Adjust the beeping and alarm sound level using
the volume switch (13). Mute , low , High .
This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com). All rights
including translation reserved. Reproduction by any method, e.g. photocopy, microlming, or the capture in electronic data
processing systems require the prior written approval by the editor. Reprinting, also in part, is prohibited. This publication
represents the technical status at the time of printing.
Copyright 2019 by Conrad Electronic SE. *1754734_v2_0519_02_dh_m_en

c) Countdown Timer
Set Timer
• If in current time display mode, press the START/
STOP (6) to enter timer mode.
• Press TIMER select button (8) to select a timer
T1 or T2
• Rotate the TIMER dial (8) to set a time.
- Clockwise (increase)
- Anticlockwise (decrease)
• Press the corresponding T1 START/STOP (6)
or T2 START/STOP (7) button to start the timer.
Press again to stop the timer.
• The corresponding T1 START/STOP (6) or T2
START/STOP (7) LED will flash green during the
countdown.
• When the countdown is complete:
- An alarm will sound (no alarm will sound if the
sound level switch (13) is set to off ).
- Timer will start to count up automatically.
- The corresponding T1 START/STOP (6) or T2
START/STOP (7) LED will flash red for 1 minute.
• Press the corresponding T1 START/STOP (6) or
T2 START/STOP (7) button to stop the alarm and
return to the pre-set count down time.
Change Increments (H:MM:ss / MM:SS)
Toggle between “H:MM:ss” and “MM:SS” increments
by pressing and holding the TIMER button (8) for 2
seconds.
d) Countdown Timer Memory (M1, M2, M3)
Save Countdown Times
• Set a desired countdown time using the TIMER
dial (8).
• Press and hold M1 (3), M2 (4), or M3 (5) for 2
seconds.
The LCD display (1) will ash and a beeping will
sound to indicate that a countdown time has been
saved.
No beeping will be heard if the sound
level switch (13) is set to off .
• To overwrite the memory, repeat the above steps
entering a different time interval.
Use Timer Memory
• Press TIMER select button (8) to select a timer
T1 or T2.
• Press and M1 (3), M2 (4), or M3 (5) to select the
select a saved time.
• Press the corresponding T1 START/STOP (6) or
T2 START/STOP (7) button to start the countdown.
e) Count Up Timer
• Press CLEAR (2) to reset values to zero.
• Press the corresponding T1 START/STOP (6) or
T2 START/STOP (7) button to begin the timer.
The LED will not ash while counting up.
• Press the corresponding T1 START/STOP (6) or
T2 START/STOP (7) button to stop timing.
f) Clock Display
View Time of Day
In idle mode, press and hold the (7) button for two
seconds to toggle between clock and countdown /
count up display.
Setting Clock
• If in timer mode, stop any timer in progress then
press and hold the T2 START/STOP (7) button for
two seconds to enter clock mode.
• In clock mode, press and hold the T2 START/
STOP (7) button for 2 seconds until the display
begins to flash.
• Rotate the TIMER dial (8) to set 12/24 hour format.
• Press the T2 START/STOP (7) button to begin
setting the time.
• Rotate the TIMER dial (8) to adjust the time.
• Press T2 START/STOP (7) to save the time and
exit settings.
g) Timer Dial (Sensitivity Adjust)
You can adjust the TIMER dial (8) sensitivity level, so
when you rotate the dial numbers change in greater
increments.
• If in timer mode, stop any timer in progress then
press and hold the T2 START/STOP (7) button for
two seconds to enter clock mode.
• Press and hold CLEAR (2) for five seconds until a
number “1-3” flashes on the LCD display (1).
• Rotate the TIMER dial (8) to choose a value
between 1-3 (1 is least sensitive, 3 is most
sensitive).
• Press CLEAR (2) to save the setting.
h) Mounting Options
The table stand (11) may leave marks on
sensitive surfaces.
When using the magnets (9) to attach to
a magnetic surface, make sure the timer
is held securely in place before letting
go.
The surface for installation should be
dry, clean, flat, stable and free from
debris.
If hanging using the wall mounting hole
(10), when drilling or inserting screws,
make sure there are no cables, wires or
pipes located underneath the surface.
Inadvertently drilling through electric
cables can cause life-threatening
danger of an electric shock!
Care and Cleaning
• Do not use any aggressive cleaning agents,
rubbing alcohol or other chemical solutions as
they can cause damage to the housing and
malfunctioning.
• Clean the product with a dry, fibre-free cloth.
Disposal
a) Product
Electronic devices are recyclable
waste and must not be disposed of in
the household waste. At the end of its
service life, dispose of the product in
accordance with applicable regulatory
guidelines.
Remove any inserted batteries and
dispose of them separately from the
product.
b) Batteries
You as the end user are required by law
(Battery Ordinance) to return all used
(rechargeable) batteries. Disposing
of them in the household waste is
prohibited.
Contaminated batteries are labeled with
this symbol to indicate that disposal in
the domestic waste is forbidden. The
designations for the heavy metals
involved are: Cd = Cadmium, Hg =
Mercury, Pb = Lead (name on batteries,
e.g. below the trash icon on the left).
Used batteries can be returned to collection points
in your municipality, our stores or wherever batteries
are sold.
You thus fulfill your statutory obligations and
contribute to the protection of the environment.
Technical Data
Power source.................... 2 x AAA-type batteries
Countdown timer .............. 99 min 59 s
Count up timer.................. 99 hr 59 min 59 s
Operating conditions......... -5 to +50 °C, 10 – 80 %
Relative humidity
Storage conditions............ -20 to +60 °C, 10 – 80 %
Relative humidity
Dimensions (L x W x H).... 90 x 63.5 x 29.5mm
Weight .............................. 74 g
Operating Instructions
2-Line Timer EDT 8002
Item No. 1754734
Intended Use
This product has dual countdown/up timers that can run simultaneously, three timer memories, and
adjustable alarm volumes. It can be hung onto a wall, placed on a desk or attached to a magnetic surface
via the built in magnets.
It is intended for indoor use only. Do not use it outdoors. Contact with moisture, e.g. in bathrooms, must be
avoided under all circumstances.
For safety and approval purposes, you must not rebuild and/or modify this product. If you use the product
for purposes other than those described above, the product may be damaged. In addition, improper use can
result in other hazards. Read the instructions carefully and store them in a safe place. Make this product
available to third parties only together with its operating instructions.
This product complies with the statutory national and European requirements. All company names and
product names are trademarks of their respective owners. All rights reserved.
Delivery Content
• Timer
• Operating instructions
Up-to-date Operating Instructions
Download the latest operating instructions at www.conrad.com/downloads or scan the QR code shown.
Follow the instructions on the website.
Safety Instructions
Read the operating instructions carefully and
especially observe the safety information. If
you do not follow the safety instructions and
information on proper handling in this manual,
we assume no liability for any resulting personal
injury or damage to property. Such cases will
invalidate the warranty/guarantee.
a) General Information
• The product is not a toy. Keep it out of the reach of
children and pets.
• Do not leave packaging material lying around
carelessly. This may become dangerous playing
material for children.
• Protect the product from extreme temperatures,
direct sunlight, strong jolts, high humidity,
moisture, flammable gases, steam and solvents.
• Do not place the product under any mechanical
stress.
• If it is no longer possible to operate the product
safely, take it out of operation and protect it from
any accidental use. Safe operation can no longer
be guaranteed if the product:
- is visibly damaged,
- is no longer working properly,
- has been stored for extended periods in poor
ambient conditions or
- has been subjected to any serious transport-
related stresses.
• Please handle the product carefully. Jolts, impacts
or a fall even from a low height can damage the
product.
• Consult an expert when in doubt about the
operation, safety or connection of the product.
• Maintenance, modifications and repairs must only
be completed by a technician or an authorised
repair centre. If you have questions which remain
unanswered by these operating instructions,
contact our technical support service or other
technical personnel.
b) Batteries
• Correct polarity must be observed while inserting
the battery.
• The batteries should be removed from the product
if it is not used for a long period of time to avoid
damage through leaking. Leaking or damaged
batteries might cause acid burns when in contact
with skin, therefore use suitable protective gloves
to handle corrupted batteries.
• Batteries must be kept out of reach of children. Do
not leave batteries lying around, as there is risk,
that children or pets swallow them.
• All batteries should be replaced at the same time.
Mixing old and new batteries in the product can
lead to battery leakage and product damage.
• Batteries must not be dismantled, short-circuited or
thrown into fire. Never recharge non-rechargeable
batteries. There is a risk of explosion!
Operating Elements
13
12
11
10
9
6
7
8
2
1
1 LCD display
2 CLEAR button
3 M1 button
4 M2 button
5 M3 button
6 T1 START/STOP button with LED indicator
7 T2 START/STOP/ button with LED indicator
8 TIMER select button/dial
9 Magnets
10 Wall mount hole
11 Table stand
12 Battery compartment cover
13 Volume level switch
Operation
a) Inserting / Replacing Batteries
• Remove the battery compartment cover (12).
• Insert 2x AAA batteries, matching polarity as
shown inside the battery compartment.
• Replace the battery compartment cover (11).
Replace the batteries if the LCD
display (1) gets dim or goes blank.
b) Volume Control
Adjust the beeping and alarm sound level using
the volume switch (13). Mute , low , High .
This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com). All rights
including translation reserved. Reproduction by any method, e.g. photocopy, microlming, or the capture in electronic data
processing systems require the prior written approval by the editor. Reprinting, also in part, is prohibited. This publication
represents the technical status at the time of printing.
Copyright 2019 by Conrad Electronic SE. *1754734_v2_0519_02_dh_m_en

c) Countdown Timer
Set Timer
• If in current time display mode, press the START/
STOP (6) to enter timer mode.
• Press TIMER select button (8) to select a timer
T1 or T2
• Rotate the TIMER dial (8) to set a time.
- Clockwise (increase)
- Anticlockwise (decrease)
• Press the corresponding T1 START/STOP (6)
or T2 START/STOP (7) button to start the timer.
Press again to stop the timer.
• The corresponding T1 START/STOP (6) or T2
START/STOP (7) LED will flash green during the
countdown.
• When the countdown is complete:
- An alarm will sound (no alarm will sound if the
sound level switch (13) is set to off ).
- Timer will start to count up automatically.
- The corresponding T1 START/STOP (6) or T2
START/STOP (7) LED will flash red for 1 minute.
• Press the corresponding T1 START/STOP (6) or
T2 START/STOP (7) button to stop the alarm and
return to the pre-set count down time.
Change Increments (H:MM:ss / MM:SS)
Toggle between “H:MM:ss” and “MM:SS” increments
by pressing and holding the TIMER button (8) for 2
seconds.
d) Countdown Timer Memory (M1, M2, M3)
Save Countdown Times
• Set a desired countdown time using the TIMER
dial (8).
• Press and hold M1 (3), M2 (4), or M3 (5) for 2
seconds.
The LCD display (1) will ash and a beeping will
sound to indicate that a countdown time has been
saved.
No beeping will be heard if the sound
level switch (13) is set to off .
• To overwrite the memory, repeat the above steps
entering a different time interval.
Use Timer Memory
• Press TIMER select button (8) to select a timer
T1 or T2.
• Press and M1 (3), M2 (4), or M3 (5) to select the
select a saved time.
• Press the corresponding T1 START/STOP (6) or
T2 START/STOP (7) button to start the countdown.
e) Count Up Timer
• Press CLEAR (2) to reset values to zero.
• Press the corresponding T1 START/STOP (6) or
T2 START/STOP (7) button to begin the timer.
The LED will not ash while counting up.
• Press the corresponding T1 START/STOP (6) or
T2 START/STOP (7) button to stop timing.
f) Clock Display
View Time of Day
In idle mode, press and hold the (7) button for two
seconds to toggle between clock and countdown /
count up display.
Setting Clock
• If in timer mode, stop any timer in progress then
press and hold the T2 START/STOP (7) button for
two seconds to enter clock mode.
• In clock mode, press and hold the T2 START/
STOP (7) button for 2 seconds until the display
begins to flash.
• Rotate the TIMER dial (8) to set 12/24 hour format.
• Press the T2 START/STOP (7) button to begin
setting the time.
• Rotate the TIMER dial (8) to adjust the time.
• Press T2 START/STOP (7) to save the time and
exit settings.
g) Timer Dial (Sensitivity Adjust)
You can adjust the TIMER dial (8) sensitivity level, so
when you rotate the dial numbers change in greater
increments.
• If in timer mode, stop any timer in progress then
press and hold the T2 START/STOP (7) button for
two seconds to enter clock mode.
• Press and hold CLEAR (2) for five seconds until a
number “1-3” flashes on the LCD display (1).
• Rotate the TIMER dial (8) to choose a value
between 1-3 (1 is least sensitive, 3 is most
sensitive).
• Press CLEAR (2) to save the setting.
h) Mounting Options
The table stand (11) may leave marks on
sensitive surfaces.
When using the magnets (9) to attach to
a magnetic surface, make sure the timer
is held securely in place before letting
go.
The surface for installation should be
dry, clean, flat, stable and free from
debris.
If hanging using the wall mounting hole
(10), when drilling or inserting screws,
make sure there are no cables, wires or
pipes located underneath the surface.
Inadvertently drilling through electric
cables can cause life-threatening
danger of an electric shock!
Care and Cleaning
• Do not use any aggressive cleaning agents,
rubbing alcohol or other chemical solutions as
they can cause damage to the housing and
malfunctioning.
• Clean the product with a dry, fibre-free cloth.
Disposal
a) Product
Electronic devices are recyclable
waste and must not be disposed of in
the household waste. At the end of its
service life, dispose of the product in
accordance with applicable regulatory
guidelines.
Remove any inserted batteries and
dispose of them separately from the
product.
b) Batteries
You as the end user are required by law
(Battery Ordinance) to return all used
(rechargeable) batteries. Disposing
of them in the household waste is
prohibited.
Contaminated batteries are labeled with
this symbol to indicate that disposal in
the domestic waste is forbidden. The
designations for the heavy metals
involved are: Cd = Cadmium, Hg =
Mercury, Pb = Lead (name on batteries,
e.g. below the trash icon on the left).
Used batteries can be returned to collection points
in your municipality, our stores or wherever batteries
are sold.
You thus fulfill your statutory obligations and
contribute to the protection of the environment.
Technical Data
Power source.................... 2 x AAA-type batteries
Countdown timer .............. 99 min 59 s
Count up timer.................. 99 hr 59 min 59 s
Operating conditions......... -5 to +50 °C, 10 – 80 %
Relative humidity
Storage conditions............ -20 to +60 °C, 10 – 80 %
Relative humidity
Dimensions (L x W x H).... 90 x 63.5 x 29.5mm
Weight .............................. 74 g
Operating Instructions
2-Line Timer EDT 8002
Item No. 1754734
Intended Use
This product has dual countdown/up timers that can run simultaneously, three timer memories, and
adjustable alarm volumes. It can be hung onto a wall, placed on a desk or attached to a magnetic surface
via the built in magnets.
It is intended for indoor use only. Do not use it outdoors. Contact with moisture, e.g. in bathrooms, must be
avoided under all circumstances.
For safety and approval purposes, you must not rebuild and/or modify this product. If you use the product
for purposes other than those described above, the product may be damaged. In addition, improper use can
result in other hazards. Read the instructions carefully and store them in a safe place. Make this product
available to third parties only together with its operating instructions.
This product complies with the statutory national and European requirements. All company names and
product names are trademarks of their respective owners. All rights reserved.
Delivery Content
• Timer
• Operating instructions
Up-to-date Operating Instructions
Download the latest operating instructions at www.conrad.com/downloads or scan the QR code shown.
Follow the instructions on the website.
Safety Instructions
Read the operating instructions carefully and
especially observe the safety information. If
you do not follow the safety instructions and
information on proper handling in this manual,
we assume no liability for any resulting personal
injury or damage to property. Such cases will
invalidate the warranty/guarantee.
a) General Information
• The product is not a toy. Keep it out of the reach of
children and pets.
• Do not leave packaging material lying around
carelessly. This may become dangerous playing
material for children.
• Protect the product from extreme temperatures,
direct sunlight, strong jolts, high humidity,
moisture, flammable gases, steam and solvents.
• Do not place the product under any mechanical
stress.
• If it is no longer possible to operate the product
safely, take it out of operation and protect it from
any accidental use. Safe operation can no longer
be guaranteed if the product:
- is visibly damaged,
- is no longer working properly,
- has been stored for extended periods in poor
ambient conditions or
- has been subjected to any serious transport-
related stresses.
• Please handle the product carefully. Jolts, impacts
or a fall even from a low height can damage the
product.
• Consult an expert when in doubt about the
operation, safety or connection of the product.
• Maintenance, modifications and repairs must only
be completed by a technician or an authorised
repair centre. If you have questions which remain
unanswered by these operating instructions,
contact our technical support service or other
technical personnel.
b) Batteries
• Correct polarity must be observed while inserting
the battery.
• The batteries should be removed from the product
if it is not used for a long period of time to avoid
damage through leaking. Leaking or damaged
batteries might cause acid burns when in contact
with skin, therefore use suitable protective gloves
to handle corrupted batteries.
• Batteries must be kept out of reach of children. Do
not leave batteries lying around, as there is risk,
that children or pets swallow them.
• All batteries should be replaced at the same time.
Mixing old and new batteries in the product can
lead to battery leakage and product damage.
• Batteries must not be dismantled, short-circuited or
thrown into fire. Never recharge non-rechargeable
batteries. There is a risk of explosion!
Operating Elements
13
12
11
10
9
6
7
8
2
1
1 LCD display
2 CLEAR button
3 M1 button
4 M2 button
5 M3 button
6 T1 START/STOP button with LED indicator
7 T2 START/STOP/ button with LED indicator
8 TIMER select button/dial
9 Magnets
10 Wall mount hole
11 Table stand
12 Battery compartment cover
13 Volume level switch
Operation
a) Inserting / Replacing Batteries
• Remove the battery compartment cover (12).
• Insert 2x AAA batteries, matching polarity as
shown inside the battery compartment.
• Replace the battery compartment cover (11).
Replace the batteries if the LCD
display (1) gets dim or goes blank.
b) Volume Control
Adjust the beeping and alarm sound level using
the volume switch (13). Mute , low , High .
This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com). All rights
including translation reserved. Reproduction by any method, e.g. photocopy, microlming, or the capture in electronic data
processing systems require the prior written approval by the editor. Reprinting, also in part, is prohibited. This publication
represents the technical status at the time of printing.
Copyright 2019 by Conrad Electronic SE. *1754734_v2_0519_02_dh_m_en

c) Countdown Timer
Set Timer
• If in current time display mode, press the START/
STOP (6) to enter timer mode.
• Press TIMER select button (8) to select a timer
T1 or T2
• Rotate the TIMER dial (8) to set a time.
- Clockwise (increase)
- Anticlockwise (decrease)
• Press the corresponding T1 START/STOP (6)
or T2 START/STOP (7) button to start the timer.
Press again to stop the timer.
• The corresponding T1 START/STOP (6) or T2
START/STOP (7) LED will flash green during the
countdown.
• When the countdown is complete:
- An alarm will sound (no alarm will sound if the
sound level switch (13) is set to off ).
- Timer will start to count up automatically.
- The corresponding T1 START/STOP (6) or T2
START/STOP (7) LED will flash red for 1 minute.
• Press the corresponding T1 START/STOP (6) or
T2 START/STOP (7) button to stop the alarm and
return to the pre-set count down time.
Change Increments (H:MM:ss / MM:SS)
Toggle between “H:MM:ss” and “MM:SS” increments
by pressing and holding the TIMER button (8) for 2
seconds.
d) Countdown Timer Memory (M1, M2, M3)
Save Countdown Times
• Set a desired countdown time using the TIMER
dial (8).
• Press and hold M1 (3), M2 (4), or M3 (5) for 2
seconds.
The LCD display (1) will ash and a beeping will
sound to indicate that a countdown time has been
saved.
No beeping will be heard if the sound
level switch (13) is set to off .
• To overwrite the memory, repeat the above steps
entering a different time interval.
Use Timer Memory
• Press TIMER select button (8) to select a timer
T1 or T2.
• Press and M1 (3), M2 (4), or M3 (5) to select the
select a saved time.
• Press the corresponding T1 START/STOP (6) or
T2 START/STOP (7) button to start the countdown.
e) Count Up Timer
• Press CLEAR (2) to reset values to zero.
• Press the corresponding T1 START/STOP (6) or
T2 START/STOP (7) button to begin the timer.
The LED will not ash while counting up.
• Press the corresponding T1 START/STOP (6) or
T2 START/STOP (7) button to stop timing.
f) Clock Display
View Time of Day
In idle mode, press and hold the (7) button for two
seconds to toggle between clock and countdown /
count up display.
Setting Clock
• If in timer mode, stop any timer in progress then
press and hold the T2 START/STOP (7) button for
two seconds to enter clock mode.
• In clock mode, press and hold the T2 START/
STOP (7) button for 2 seconds until the display
begins to flash.
• Rotate the TIMER dial (8) to set 12/24 hour format.
• Press the T2 START/STOP (7) button to begin
setting the time.
• Rotate the TIMER dial (8) to adjust the time.
• Press T2 START/STOP (7) to save the time and
exit settings.
g) Timer Dial (Sensitivity Adjust)
You can adjust the TIMER dial (8) sensitivity level, so
when you rotate the dial numbers change in greater
increments.
• If in timer mode, stop any timer in progress then
press and hold the T2 START/STOP (7) button for
two seconds to enter clock mode.
• Press and hold CLEAR (2) for five seconds until a
number “1-3” flashes on the LCD display (1).
• Rotate the TIMER dial (8) to choose a value
between 1-3 (1 is least sensitive, 3 is most
sensitive).
• Press CLEAR (2) to save the setting.
h) Mounting Options
The table stand (11) may leave marks on
sensitive surfaces.
When using the magnets (9) to attach to
a magnetic surface, make sure the timer
is held securely in place before letting
go.
The surface for installation should be
dry, clean, flat, stable and free from
debris.
If hanging using the wall mounting hole
(10), when drilling or inserting screws,
make sure there are no cables, wires or
pipes located underneath the surface.
Inadvertently drilling through electric
cables can cause life-threatening
danger of an electric shock!
Care and Cleaning
• Do not use any aggressive cleaning agents,
rubbing alcohol or other chemical solutions as
they can cause damage to the housing and
malfunctioning.
• Clean the product with a dry, fibre-free cloth.
Disposal
a) Product
Electronic devices are recyclable
waste and must not be disposed of in
the household waste. At the end of its
service life, dispose of the product in
accordance with applicable regulatory
guidelines.
Remove any inserted batteries and
dispose of them separately from the
product.
b) Batteries
You as the end user are required by law
(Battery Ordinance) to return all used
(rechargeable) batteries. Disposing
of them in the household waste is
prohibited.
Contaminated batteries are labeled with
this symbol to indicate that disposal in
the domestic waste is forbidden. The
designations for the heavy metals
involved are: Cd = Cadmium, Hg =
Mercury, Pb = Lead (name on batteries,
e.g. below the trash icon on the left).
Used batteries can be returned to collection points
in your municipality, our stores or wherever batteries
are sold.
You thus fulfill your statutory obligations and
contribute to the protection of the environment.
Technical Data
Power source.................... 2 x AAA-type batteries
Countdown timer .............. 99 min 59 s
Count up timer.................. 99 hr 59 min 59 s
Operating conditions......... -5 to +50 °C, 10 – 80 %
Relative humidity
Storage conditions............ -20 to +60 °C, 10 – 80 %
Relative humidity
Dimensions (L x W x H).... 90 x 63.5 x 29.5mm
Weight .............................. 74 g
Operating Instructions
2-Line Timer EDT 8002
Item No. 1754734
Intended Use
This product has dual countdown/up timers that can run simultaneously, three timer memories, and
adjustable alarm volumes. It can be hung onto a wall, placed on a desk or attached to a magnetic surface
via the built in magnets.
It is intended for indoor use only. Do not use it outdoors. Contact with moisture, e.g. in bathrooms, must be
avoided under all circumstances.
For safety and approval purposes, you must not rebuild and/or modify this product. If you use the product
for purposes other than those described above, the product may be damaged. In addition, improper use can
result in other hazards. Read the instructions carefully and store them in a safe place. Make this product
available to third parties only together with its operating instructions.
This product complies with the statutory national and European requirements. All company names and
product names are trademarks of their respective owners. All rights reserved.
Delivery Content
• Timer
• Operating instructions
Up-to-date Operating Instructions
Download the latest operating instructions at www.conrad.com/downloads or scan the QR code shown.
Follow the instructions on the website.
Safety Instructions
Read the operating instructions carefully and
especially observe the safety information. If
you do not follow the safety instructions and
information on proper handling in this manual,
we assume no liability for any resulting personal
injury or damage to property. Such cases will
invalidate the warranty/guarantee.
a) General Information
• The product is not a toy. Keep it out of the reach of
children and pets.
• Do not leave packaging material lying around
carelessly. This may become dangerous playing
material for children.
• Protect the product from extreme temperatures,
direct sunlight, strong jolts, high humidity,
moisture, flammable gases, steam and solvents.
• Do not place the product under any mechanical
stress.
• If it is no longer possible to operate the product
safely, take it out of operation and protect it from
any accidental use. Safe operation can no longer
be guaranteed if the product:
- is visibly damaged,
- is no longer working properly,
- has been stored for extended periods in poor
ambient conditions or
- has been subjected to any serious transport-
related stresses.
• Please handle the product carefully. Jolts, impacts
or a fall even from a low height can damage the
product.
• Consult an expert when in doubt about the
operation, safety or connection of the product.
• Maintenance, modifications and repairs must only
be completed by a technician or an authorised
repair centre. If you have questions which remain
unanswered by these operating instructions,
contact our technical support service or other
technical personnel.
b) Batteries
• Correct polarity must be observed while inserting
the battery.
• The batteries should be removed from the product
if it is not used for a long period of time to avoid
damage through leaking. Leaking or damaged
batteries might cause acid burns when in contact
with skin, therefore use suitable protective gloves
to handle corrupted batteries.
• Batteries must be kept out of reach of children. Do
not leave batteries lying around, as there is risk,
that children or pets swallow them.
• All batteries should be replaced at the same time.
Mixing old and new batteries in the product can
lead to battery leakage and product damage.
• Batteries must not be dismantled, short-circuited or
thrown into fire. Never recharge non-rechargeable
batteries. There is a risk of explosion!
Operating Elements
13
12
11
10
9
6
7
8
2
1
1 LCD display
2 CLEAR button
3 M1 button
4 M2 button
5 M3 button
6 T1 START/STOP button with LED indicator
7 T2 START/STOP/ button with LED indicator
8 TIMER select button/dial
9 Magnets
10 Wall mount hole
11 Table stand
12 Battery compartment cover
13 Volume level switch
Operation
a) Inserting / Replacing Batteries
• Remove the battery compartment cover (12).
• Insert 2x AAA batteries, matching polarity as
shown inside the battery compartment.
• Replace the battery compartment cover (11).
Replace the batteries if the LCD
display (1) gets dim or goes blank.
b) Volume Control
Adjust the beeping and alarm sound level using
the volume switch (13). Mute , low , High .
This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com). All rights
including translation reserved. Reproduction by any method, e.g. photocopy, microlming, or the capture in electronic data
processing systems require the prior written approval by the editor. Reprinting, also in part, is prohibited. This publication
represents the technical status at the time of printing.
Copyright 2019 by Conrad Electronic SE. *1754734_v2_0519_02_dh_m_en
