Theben SELEKTA 070 top3 UP User manual

1
309713
SELEKTA 070 top3 UP
0700130
Astronomical time switch
EN
1. Safety
Assembly and installation should only be carried
out by a qualied electrician, somebody who has
completed appropriate professional training and
has the knowledge and experience necessary to be
able to recognise and avoid the potential dangers
posed by electricity.
Before assembly/dismounting, disconnect the
power supply and ensure that the parts are no
longer live.
Prior to commissioning and using the product,
read and observe all the operating instructions.
•The astronomical time switch corresponds to type 1
BSTU in accordance with IEC/EN 60730-2-7
•Power reserve (6 years) is reduced when Bluetooth
OBELISK top3 is connected (in battery mode)
2. Proper use
•Digital astronomical time switch with weekly program
and annual program
•3 special programs with date function per channel
•Interface for Bluetooth OBELISK top3
•Programming by app possible
•The astronomical time switch is intended for time-
controlled and manual switching of lights, fans etc.
•Only for use in closed, dry rooms
•The astronomical time switch is designed for wall
mounting (ush-mounting) in an interior switch range
3. Installation and connection
Flush-mounted installation
LWith a standard ush-mounting box (see illustration).
LObserve the recommended installation height of
0.8 m–1.2 m!
Disconnect power source.
Connect the time switch according to the wiring diagram.
Screw down the time switch in the ush-mounted box .
Position the bezel frame on the time switch .
1
2
Ø 60 mm
≥ 40 mm
N
L1
L
LL1‘L1N
!Secure device with an upstream type B or type C circuit
breaker (EN 60898-1) with a maximum of 10.
Connecting the cable
45°
Spring plug-in
terminal opener
Strip cable to 8 mm (max. 9).
Insert cable in the open DuoFix plug-in terminal at 45°.
L2 cables per terminal position possible.
To open the DuoFix plug-in terminal, press screwdriver
downwards.
Disconnecting the cable
Use the screwdriver to push the spring plug-in terminal
downwards.
4. Device description
4 buttons to select the
functions
Bluetooth OBELISK top3
(9070130)
Bezel frame
Display
Right/left buttons (congured as pre-selection)

2
Display and buttons
MENU
–Activate display
–Open menu
– Cancel menu
– ESC
(leave menu)
OK
–Save
selection
– Confirm
selection

Options are
displayed
Time display
Display of
sunrise/
sunset
Date display
Channel status
on
off Weekday from
1–7
Display of active buttons
with the respective functions
Programmed ON
times

06
12 18 24
MENU OK

OKMENU
Operating instructions
YES
Confirma-
tion
Press OK
NO
Modify/
Change
t u
Press
1. Read text line
Text/symbol represents
query
2. Make a decision
Function of the right/left buttons
The right and left buttons can be used, for example, to switch
the light on and off or to control a fan, etc. Pressing the right/
left buttons changes the relay state in question and the pro-
gram performs the next switching operation.
Overview of navigation menu
ASTRO
MANUAL
PROGRAM
OPTIONS
TIME/DATE
END
MENU
u u u
ASTRO
TIMES
TOTAL
SIMULATION
u
uu
OFFSET
ASTRO
MODE
ASTRO TIME
LOCATION
END
STANDARD
SPECIAL 1
ASTRO PROG
SPECIAL 2 ON
SPECIAL 3 OFF
TOTAL
SIMULATION
DELETE ALL
END
TIME
SET DATE
SU-WI
WEEK DAY
DATE
FORMAT
TIME FORMAT
EASTER DATE
END
OPERATING
HOUR
PERM ON
PERM OFF
OVERR ON
TIMER
HOLIDAY
END
LCD LIGHTING
LANGUAGE
PIN
FACTORY
SETTING
INFO
END

3
Initial operation
GERMAN
GERMANY STUTTGART
COUNTRY
DATE
FORMAT
MENU
u u
ENGLISH
ESPANOL
u
uu
FRANCAIS
COORDINATES
SPAIN
ESTONIA
FRANCE
GREAT
BRITAIN
BERLIN YEAR
BREMEN MONTH
DRESDEN
DUESSELDORF
DAY
TIME FORMAT
HOUR
MINUTE
SU-WI
EUROPE
28 10 20
ON
9:4046
...
...
...
Set language, date, time as well as summer/winter time
(SU-WI).
Press any button and follow on-screen instructions (see
picture).
5. Settings and functions
LIn standard setting, an astronomical time switch switches
on during twilight and off during sunrise. Therefore, in
most applications, only one night switch-off (e.g. from
22:00 to 06:00) has to be programmed – and, if needed,
to be copied to all weekdays.
Astronomical time switches can be used for precise switching
of connected consumers based on sunrise and sunset. They
have an additional astro pulse, which can be used for roller
blinds and blinds control.
Furthermore, the astronomical time switched offer a twilight
range in three increments:
•Sunset (civil twilight)
•Twilight (nautical twilight)
•Darkness (astronomical twilight)
ASTRO menu
In the ASTRO menu, astro times, total simulation, offset, astro
mode and position (locations) can be queried or changed.
•Astro times
Display of the astro times (including the offset) for the
current day.
•Total simulation
Display of the switching response with a freely selectable
start date (the holiday program is not shown).
•Offset
The offset (correction value) can be used to shift the
calculated astro times by +/– 120 min. This means that
the astro turn-on and turn-off times can be adapted to
local conditions (e.g. mountains, high buildings etc.) or to
personal requirements.
•Astro mode
–Evenings on, mornings off: At sunset it switches on, at
sunrise it switches off (example: street lighting)
–Evenings off, mornings on: At sunset it switches off, at
sunrise it switches on (example: terrarium)
–Astro not active: The astro times are ineffective (only
the "xed switching time" time switch function)
•Astro time
3 twilight ranges can be set:
–Sunset (civil twilight):
Sunset is the moment in which the upper edge of the
sun disappears behind the horizon.
–Twilight (nautical twilight):
Twilight occurs when the centre of the sun is 6°
below the horizon
–Darkness (astronomical twilight):
The darkness setting (astronomical twilight is the
correct technical term) occurs when the centre of the
sun is 12° below the horizon and stars are visible.
•Location
–Setting the location by selecting a town/city or via
coordinates (latitude/longitude, time zone). By using
the Bluetooth OBELISK top3, up to 10 further towns/
cities (= favourites) can be added.

4
Changing the astro time/location
ASTRO
MENU
u
uu
ASTRO TIMES
TOTAL
SIMULATION
uu
OFFSET
ASTROMODE
ASTRO TIME
LOCATION
END
COUNTRY
COORDINATES
FRANCE
SPAIN
ESTONIA
GERMANY
GREAT BRITAIN
AJACCIO
BAYONNE
BORDEAUX
BREST
...
CAEN
...
E.g. enter a different country, a different town/city
Press MENU (see picture).
Setting the offset function
ASTRO
MENU
u
uu
ASTRO TIMES
TOTAL
SIMULATION
OFFSET
ASTROMODE
OFFSET
MORNING
OFFSET
EVENING
OFFSET
MORNING
00:00
OFFSET
EVENING
00:00
Press MENU.
Select ASTRO and press OK to conrm.
Select OFFSET and press OK to conrm.
Select OFFSET MORNING or OFFSET EVENING and press
OK to conrm.
Set the time and press OK to conrm.
Setting individual twilight ranges
In the ASTRO menu → Astro time, 3 twilight ranges can be
set.
ASTRO
MENU
u
u
ASTRO
TIMES
TOTAL
SIMULATION
OFFSET
SUNSET
TWILIGHT
DARKNESS
ASTRO
MODE
ASTRO TIME
Press MENU.
Select ASTRO and press OK to conrm.
Select ASTRO TIME, conrm with OK.
Select SUNSET, TWILIGHT or DARKNESS, conrm with OK.
Nacht
12° Dunkelheit
6° Dämmerung
Tag
0,833°
Sonnenuntergang
Horizont
Setting the astro pulse
LSuited for blinds and roller blinds control, etc.
ASTRO
MENU
u
uu
u
ASTRO
TIMES
EVENINGS ON
MORNINGS
OFF
EVENINGS AND
MORNINGS
PULSE
DURATION
PULSE
DURATION
0:0101
MORNINGS
ASTROMODE
ASTRO PULSE
...
...
Press MENU.
Select ASTRO and press OK to conrm.
Select ASTROMODE, conrm with OK.
Select ASTRO PULSE, conrm with OK.
▻ EVENINGS AND MORNINGS, EVENINGS, etc. appears.
Select desired time, conrm with OK.
Enter PULSE DURATION.

5
Setting a xed switching time (e.g. in standard
program)
MENU
PROGRAM u
STANDARD
SPECIAL 1
ASTRO PROG LIGHT
ON
uu
NEW
CHECK
MODIFY
DELETE
END
COPY
ADD TUESDAY
SAVE
SAVE
Copy switching time to
other days of the week.
The day of the week
always refers to the
start time
or
Switching
time for
one day


Starting
time
FREE 84
NIGHT
BREAK
HOUR
MINUTE
MONDAY
DURATION
UNTIL
...
LA switching time always consists of a start time and an
end time (DURATION UNTIL), e.g. night switch-off on
Monday 23:00 – 05:00.
LThere are 84 memory cells available.
Press MENU.
Select PROGRAM, conrm with OK.
Select STANDARD, conrm with OK.
Select NEW, conrm with OK.
Select NIGHT BREAK or LIGHT ON and press OK to conrm.
Set selected switching times (hours, minutes, day) and
press OK to conrm.
Select COPY or SAVE.
To save press u and press OK to conrm.
To copy press OK.
Setting special programs
•The time switch features 3 special programs (yearly
functions), which can be used for calendar-dependent
switching.
•Each special program can be activated over one or seve-
ral date areas.
•There are 3 types of date areas:
– Fixed date area:
e.g. starting time on 2020-04-02 at 16:00
end time on 2020-04-24 at 10:00
–Yearly repeating date area:
e.g. Christmas:
starting time on 24-12 at 18:00 every year
end time on 26-12 at 23:00 every year
–Date area depending on Easter:
e.g. Whit Sunday and Whit Monday:
starting time 49 days after Easter at 00:00
every year end time: 51 days after Easter at 00:00,
every year
LThe public holiday set is set via app, or OBELISK software.
L24:00 is programmed as 00:00 of the following day.
Holidays depending
on Easter in Germany
Holiday days before/after
Easter Sunday
Start End
Monday before Lent – 48 –47
Good Friday – 2 –1
Easter Monday + 1 + 2
Ascension + 39 + 40
Whit Monday + 50 + 51
Corpus Christi + 60 + 61
•Special program 1
–Astro times active
–Optional 1x night interruption
–Optional 1x daytime switch on
–Active in the programmed date areas
Example: The standard program switches on street
lighting depending on Astro times.
A night interruption is programmed from 23:00 to
04:00. Special program 1 is active within the date
area from April 30 12:00 until May 1, 12:00. Since no
night interruption is programmed, the street lighting
will remain on all night.
•Special program 2
–Permanent ON
–Always on during the programmed date areas
Example: The standard program switches on lighting
of a neon advertising sign only at night. The special
program switches on the neon advertising sign per-
manently during a promotion week from 2020-04-
17, 9:00 until 2020-04-24, 18:00.
•Special program 3
–Permanent OFF
–Always off during the programmed date areas
Example: The standard program switches on the car
park lighting depending on the astro times. The spe-
cial program does not switch on the car park lighting
on July 14, from 00:00 to July 15, 04:00.

6
MENU
PROGRAM u
STANDARD
SPECIAL 1
ASTRO PROG
SPECIAL 2 ON
u
u
u
NIGHT BREAK
DURATION
LIGHT
ON
DURATION
NEW DATE
CHECK SET
DATE
MODIFY DATE
DELETE SET
DATE
END
FREE 84
FIXED DATE DAYS BEFORE/
AFTER EASTER
END YEAR
END MONTH
EVERY YEAR
START YEAR
START MONTH
START DAY
...
...
...
u
Setting summer/winter time
TIME/DATE
MENU
u
u
TIME
SET DATE
SU-WI
WEEK DAY
SU-WI EUROPE
SU-WI GB/
IRL/P
SU-WI FIN/
GR/TR
...
...
Press MENU.
Select TIME/DATE and press OK to conrm.
Select SU-WI and press OK to conrm.
Select region for the SU-WI time and press OK to
conrm.
Switching permanent ON/OFF
MANUAL
MENU
uPERM ON
PERM OFF
OVERR ON
TIMER
HOLIDAY
END
Press MENU.
Select MANUAL, conrm with OK.
Select PERM ON or PERM OFF and press OK to conrm.
Setting holiday function
MANUAL
MENU
u
u
PERM ON
PERM OFF
OVERRIDE OFF
TIMER
HOLIDAY ON
BEGIN HOLIDAY
END HOLIDAY
... ...
Press MENU.
Select MANUAL, conrm with OK.
Select HOLIDAY, conrm with OK.
Select ON, conrm with OK.
Select BEGIN HOLIDAY, conrm with OK.
Enter YEAR, MONTH, DAY, HOUR, conrm with OK.
Select END HOLIDAY and press OK to conrm.
Enter YEAR, MONTH, DAY, HOUR, conrm with OK.
Activating PIN code
The PIN code is set in OPTIONS via the menu.
LIf you have forgotten your PIN, please call the Theben
Hotline.
LHave the serial number of the device ready!

7
OPTIONS
MENU
u
OPERATING
HOUR
LCD
ILLUMINATION
u
u
u
LANGUAGE
PIN
FACTORY
SETTING
INFO
NO PIN
WITH PIN CURRENT PIN
NEW PIN
00:00
Setting manual control or permanent switching
Manual control or permanent switching can be set via the
menu in MANUAL or (in the automatic display) by button
combination (see picture).
•Manual control:
Reversing the channel status until the next automatic
or programmed switch.
•Permanent switching:
As long as permanent switching (on or off) is activated,
the programmed switching times are ineffective.
Activating manual control
Briey press both buttons simultaneously.
Activating permanent switching
Press both buttons simultaneously for 2 seconds.
Cancelling manual control/permanent switching
Press both buttons simultaneously.
Hour counter
The operating hours of the channel (relay) are displayed and
deleted in the OPTIONS menu. If the number of operating
hours exceeds the value set in the Service menu, SERVICE
will appear in the display.
Example: Replace a lamp after 5,000 h.
Delete operating hours or set a higher value in Service
(e.g. 10,000 h).
Using Bluetooth OBELISK top3
All functions can also be transferred to the time switch
using the Bluetooth OBELISK top3 memory card (accessory
9070130).
Copy OBELISK → TIME SWITCH
This copies the switch programme and optionally all time
switch settings (e.g. time format, etc.) from the memory card
to the time switch.
Copy TIME SWITCH → OBELISK
Copies all switch programmes and settings from the
time switch to the memory card.
Starting OBELISK program
Takes over the switching times that are programmed on the
memory card.
As soon as the memory card is removed, the switching times
of the time switch are re-activated.
uuu
u
u
OBELISK
COPY
OBELISK ->
TIME SWITCH
COPY TIME
SWITCH ->
OBELISK
RUN
OBELISK
CHECK
OBELISK
END
OVERWRITE
OK
u
BLUETOOTH
COPY ALL
DATA
COPY
PROGRAM
END
Connecting time switch, Bluetooth OBELISK top3
and smartphone (via app)
The devices in the top3 range can be programmed using an
app (for Android, iOS) on a mobile end device. Communication
takes place via Bluetooth OBELISK top3. Switch programmes
are transferred and direct switch commands are sent to the
device.
Download the OBELISK top3 app from the App Store or
Google Play Store.
LBluetooth connection only possible in automatic mode, not
in manual mode like OPTIONS, etc.
Open the app and activate using one of the 3 commands,
by pressing "Download" , "Manual command" or
"Upload" .
▻Device/device list appears on the display.

8
Press "Connect".
Press OK on the time switch.
▻ The display shows BLUETOOTH ACTIVE.
Press "Close" in the app within 30 s.
Now, for example, projects can be created and uploaded.
Resetting the time switch
Press the 4 buttons simultaneously.
▻ Now, you can choose between RETAIN PROGRAMS
and DELETE PROGRAMS.
6. Technical data
Operating voltage: 230 V AC, +10% / –15%
Frequency: 50 Hz
Standby: 0.4 W
Max. switching capacity: 10 A (at 250 V AC, cos ϕ = 1)
Switching capacity: 2 A (at 250 V AC, cos ϕ = 0.6)
Min. switching capacity: 10 mA/230 V AC
100 mA/24 V AC/DC
Shortest switching time: 1 min
Switching accuracy: To the second
Protection rating: IP 20 in accordance with EN 60529
Protection class: II in accordance with EN 60730-1
subject to designated installation
Software: Class A
Operating temperature: –5 °C ... + 45 °C
Power reserve: 6 years at +20 °C (without Blue-
tooth OBELISK top3)
Time accuracy (typical): ± 0.25 s/day (25 °C)
Rated impulse voltage: 4 kV
Pollution degree: 2
Contact: NO contact (µ)
Incandescent/halogen lamp load: 2300 W at 25 °C
2000 W at 35 °C
1300 W at 45 °C
Fluorescent lamps (LLB low-loss
ballasts):
uncompensated
series compensated
parallel compensated
2000 VA
2000 VA
1300 VA (130 µF)
Compact uorescent lamps (EVG): 1100 W
LED lamps (< 2 W): 50 W
LED lamps (> 2 W): 600 W
Bluetooth OBELISK top3:
– Protection rating:
– Temperature:
– Range:
IP 40
–30 °C … +55 °C
15 m on open air test site
Cleaning and service
Only use a dry, soft cloth to clean the device surface.
Do not use any cleaning agents or solvents.
Disposal
Dispose of device in environmentally sound manner
(electronic waste).
7. Dimensional drawings

9
8. Contact
Theben AG
Hohenbergstr. 32
72401 Haigerloch
GERMANY
Phone [phone]
Fax [phone]
Hotline
Phone [phone]
[email protected]
Addresses, telephone numbers etc.
www.theben.de

10

11
