Theben eltimo 020 Astro top3 User manual

1
theben-eltimo 020 Astro top3
0200170
307610
08.02.2022
Digital plug-in
time switch
EN
1. Safety information
To rule out the risk of electrical shock or re,
protect the time switch from moisture and heat!
Prior to start-up and using the product, read and
observe all the operating instructions.
!Use a single mains socket (230 V~, 50 Hz, earthed) for the
power supply.
!Do not plug time switches into each other.
•The time switches conform to EN 60669-2-1 if correctly
installed and type 1 BSTU in accordance with IEC/
EN 60730-2-7.
•Power reserve (6 years) is reduced when Bluetooth
OBELISK top3 is connected (in battery mode).
2. Proper use
•This digital plug-in astro time switch with weekly pro-
gram is suitable for indoor use (oor lamp, aquarium,
Christmas lights, etc.)
•Astronomical switch function (automatic calculation of
sunrise/sunset times for the whole year)
•Interface for Bluetooth OBELISK top3 (+ app)
•For earthed sockets (plug type F)
•Only use in dry, enclosed rooms
!Do not use on safety devices, e.g. escape route doors, re
safety equipment, etc.
3. Installation and connection
Plug the time switch into a 230 V earthed wall socket and
plug the selected device into the socket (F) on the time
switch.
4. Device description
Digital plug-in time switch
1
2
3
4
1 Display with date, time, week days,
astro ( ) etc.
4 buttons to operate the device
Interface for OBELISK top3 memory
card (9070130)
Socket F (and plug on the rear)
2
3
4
Display and buttons

06
12 18 24
MENU OK
OKMENU
Programmed
switching times
Date display
Channel status
On, Off
Time display
Sunrise/sunset
display
Days of the week
from 1 to 7
Display of the active buttons
with the relevant function
–Activate display
–Open menu
–Cancel menu
–ESC
(leave menu)
–Save selection
–Confirm selection

Options
are displayed
Operating instructions
YES
Confirmation
Press
OK
NO
Modify/
Change
Press
t u
1. Read text line
text/symbol
represents query
2. Make a decision

2
Overview of menu selection
ASTRO
MANUAL
PROGRAM
OPTIONS
TIME/DATE
END
MENU
u u u
ASTRO-
TIMES
TOTAL
SIMULATION
u
uu
OFFSET
ASTRO-
MODE
LOCATION
END
NEW
CHECK
MODIFY
DELETE
TOTAL
SIMULATION
END
TIME
SET DATE
SU-WI
WEEK DAY
FORM DATE
FORM TIME
END
PERM ON
PERM OFF
OVERRI ON
TIMER
HOLIDAY
END
OPERATING
HOUR
LCD-ILLUMI-
NATION
LANGUAGE
FACTORY
SETTINGS
INFO
END
Initial start-up
GERMAN
GERMANY
RETAIN
PROGRAMS
STUTTGART
COUNTRY
FORM
DATE
MENU
u u u
ENGLISH
ITALIANO
u
uu
NEDERLANDS
DELETE
PROGRAM
COORDINATES
ITALIA
NEDERLAND
SVERIGE
GREAT
BRITAIN
BERLIN YEAR
BREMEN MONTH
DRESDEN
DUESSELDORF
DAY
FORM TIME
HOUR
MINUTE
SUM-WI
EUROPE
28 10 21
ON
9:4046
...
...
...
Set language, country, town/city, date, time as well as
summer/winter time (SO-WI).
Press any button and follow on-screen instructions (see
gure).
5. Settings and functions
ASTRO menu
In the ASTRO menu astro times, complete simulation, offset,
astromode as well as position (location) can be viewed or
changed.
•Astro times
Display of the astro times (including the offsets) for the
current day
•Total simulation
Display of the switching behaviour with a freely selecta-
ble Start date (the holiday program is not displayed)
•Offset
The offset (adjustment value) can be used to shift cal-
culated astro times +/– 120 min. This enables the Astro
switch-on and switch-off times to be adapted to local
circumstances (e.g. mountains, high buildings etc.) or to
personal requirements.

3
•Astro mode
–Evenings on, mornings off Switches: on at sunset,
switches off at sunset (Example: street lighting)
–Evenings off, mornings on Switches off: at sunset,
switches on at sunrise (Example: terrarium).
–Astro inactive: The astro times are ineffective (timer
function only).
•Position
–Location set by selecting a city or by coordinates
(latitude/longitude, time zone). The Bluetooth OBE-
LISK top3 allows up to 10 further cities (= favourites)
to be entered.
Change astro time/position
ASTRO
MENU
u
uu
ASTRO TIMES
TOTAL
SIMULATION
uu
OFFSET
ASTROMODE
LOCATION
END
COUNTRY
COORDINATES
ITALIA
GREAT BRITAIN
DEUTSCHLAND
SUOMI
SVERIGE
ALESSANDRIA
ANCONA
AOSTA
BARI
...
CAEN
...
E.g. enter a different country, a different town/city
Press MENU (see picture).
Setting the offset function
ASTRO
MENU
u
u u
ASTRO TIMES
TOTAL
SIMULAION
OFFSET
ASTROMODE
OFFSET
MORNING
OFFSET
EVENING
OFFSET
MORNING
00:00
OFFSET
EVENING
00:00
...
Press MENU.
Select ASTRO and press OK to conrm.
Select OFFSET and press OK to conrm.
Select OFFSET MORNING or OFFSET EVENING and press OK
to conrm.
Set the time and press OK to conrm.
Set xed switching time
LIGHT ON
MENU
u u
NEW
CHECK
MODIFY
DELETE
TOTAL-
SIMULATION
END
COPY
ADD TUESDAY
SAVE
SAVE
Copy switching to other
days of the week.
The day of the week
always relates to a
start time
PROGRAM
or
Switching
time for
one day


Start
MEM FREE 56
NIGHT BREAK
HOUR
MINUTE
MONDAY
DURATION
UNTIL

LA switching time always consists of a start time and an
end time (LASTS UNTIL). e.g. night switch-off on Monday
23:00 – 05:00 hrs.
LThere are 56 memory cells available.
Press MENU.
Select PROGRAM and press OK to conrm.
Select NEW and press OK to conrm.
Select NIGHT SWITCH OFF or DAY SWITCH ON and press OK
to conrm.
Set selected switching times (hours, minutes, day) and
press OK to conrm.
Select COPY or SAVE.
To save press u and press OK to conrm.
To copy press OK.
Setting summer/winter time
TIME/DATE
MENU
u
u
TIME
SET DATE
SU-WI
WEEK DAY
SU-WI EUROPE
SU-WI GB/
IRL/P
SU-WI FIN/
GR/TR
...
...
Press MENU.
Select TIME/DAT and press OK to conrm.
Select SO-WI and press OK to conrm.
Select region for the SO-WI time and press OK to conrm.

4
Switch Permanent ON /OFF
MANUAL
MENU
uPERM ON
PERM OFF
OVERRI ON
TIMER
HOLIDAY
END
Press MENU.
Select MANUAL and press OK to conrm.
Select PERM ON or PERM OFF and press OK to conrm.
Setting holiday function
MANUAL
MENU
u
u
PERM ON
PERM OFF
OVERR ON
ON
BEGIN HOLIDAY
END HOLIDAY
... ...
TIMER
HOLIDAY
END
Press MENU.
Select MANUAL and press OK to conrm.
Select HOLIDAY and press OK to conrm.
Select ON and press OK to conrm.
Select START HOLIDAY and press OK to conrm.
Enter YEAR, MONTH, DAY, HOUR and press OK to conrm.
Select END HOLIDAY and press OK to conrm.
Enter YEAR, MONTH, DAY, HOUR and press OK to conrm.
Setting manual or permanent switching
Manual or permanent switching can be set via the menu in
MANUAL or (in the automatic screen) by button combination
(see picture).
•Manual control:
Reversing the channel status to the next automatic or
programmed switching.
•Permanent switching:
As long as a permanent switching (on or off) is activated,
the programmed switching times are ineffective
ok
Activating manual control
Briey press both buttons simultaneously.
Activating permanent switching
Press both buttons simultaneously for 2 seconds.
Cancelling manual/permanent switching
Press both buttons simultaneously.
Hour counter
The operating hours of the channel (relay) are displayed and
deleted in the OPTIONS menu. If the number of operating
hours exceeds the value set in the Service menu, SERVICE will
appear in the display.
Example: Replace a lamp after after 5,000 h.
Delete operating hours or set a higher value in Service
(e.g. to 10,000 h)
Using Bluetooth OBELISK top3
All functions can also be transferred to the time switch using
the Bluetooth OBELISK top3 memory card (9070130).
9070130
IP 40
Copying OBELISK → TIME SWITCH
This copies the switching program and optionally all time
switch settings (e.g. time format etc.) from the memory card
in the time switch.
Copying TIME SWITCH → OBELISK
This copies all switch programmes and settings from the time
switch to the memory card.
Starting OBELISK program
Takes on the switching times that are programmed on the
memory card.
As soon as the memory card is removed, the switching times
of the time switch are re-activated.

5
uuu
u
u
OBELISK
COPY
OBELISK ->
TSWI
COPY TSWI
-> OBELISK
RUN
OBELISK
CHECK
OBELISK
END
OVERWRITE
OK
u
BLUETOOTH
COPY ALL
DATA
COPY
PROGRAM
END
Connecting the plug-in time switch, OBELISK top3
Bluetooth and smartphone (via app)
The devices in the top3 range can be programmed using an
app (for Android, iOS) on a mobile end device. Communication
takes place via Bluetooth OBELISK top3. Switch programmes
are transferred and direct switch commands are sent to the
device.
LTo use the app, you need the OBELISK top3 memory card/
dongle.
Download the OBELISK top3 app from the App Store or
Google Play Store
Open the app and activate using one of the 3 commands,
by pressing „Download“ , „Manual command“ or
„Upload“
▻Device/device list appears on the display.
Press „Connect“.
Press OK on the timer.
▻ The display shows BLUETOOTH ACTIVE.
Press „Close“ in the app within 30 s.
Now, for example, projects can be created and uploaded.
Resetting the time switch
Press the 4 buttons simultaneously.
▻You can choose between KEEP PROGRAM and DELETE
PROGRAM.
6. Technical data
Operating voltage: 230 V AC, +10 % / –15 %
Frequency: 50 Hz
Standby: 0,9 W
Max switching capacity: 16 A (at 250 V, cos ϕ = 1)
Switching capacity: 10 A (at 250 V, cos ϕ = 0,6)
Min. switching capacity: 10 mA/230 V AC
Shortest switching time: 1 min
Switching accuracy: accurate to the second
Protection rating: IP 20 in accordance with
EN 60529
Protection class: II (housing), I (plug system) in
accordance with EN 60730-1
Mode of operation: type 1 BSTU
Operating temperature: –10 °C … +40 °C
Power reserve: 6 years at +20 °C (without Blue-
tooth OBELISK top3)
Time accuracy (typical): ± 0,25 s/day (25 °C)
Glow lamp load: 2600 W
Halogen lamp load: 2600 W
Fluorescent lamp load:
uncorrected, series corrected:
parallel-corrected:
2600 VA
600 VA (72 µF)
Compact uorescent tubes (EVG): 1100 W
Resistive switching load: 3680 W
LED lamps (< 2 W): 30 W
LED lamps (> 2 W): 300 W
Rated impulse withstand voltage: 2,5 kV
Pollution degree: 2
Software class: A

6
Bluetooth OBELISK top3:
– Protection rating:
– Temperature:
– Range:
IP 40
–30 °C to +55 °C
15 m on open air test site
LThe time switch display is only fully functional at temperatures
from +5 °C ... +40 °C.
Cleaning and service
Only use a dry, soft cloth to clean the device surface.
Do not use any cleaning agents or solvents.
Disposal
Dispose of device in environmentally sound manner
(electronic waste).
Dimensional drawings
7. Contact
Theben AG
Hohenbergstr. 32
72401 Haigerloch
GERMANY
Tel. [phone]
Fax [phone]
Hotline
Tel. [phone]
[email protected]
Addresses, telephone numbers etc.
www.theben.de
