T2GPXXMCGraphicsCard
InstallationManual
Version 1.0— June 2011

Copyright © 2011 Themis Computer, Inc.
ALL RIGHTS RESERVED. No part of this publication may be reproduced in any form, by
photocopy, microfilm, retrieval system, or by any other means now known or hereafter invented without
the prior written permission of Themis Computer.
The information in this publication has been carefully checked and is believed to be accurate. However,
Themis Computer assumes no responsibility for inaccuracies. Themis Computer retains the right to
make changes to this publication at any time without prior notice. Themis Computer does not assume
any liability arising from the application or use of this publication or the product(s) described herein.
RESTRICTED RIGHTS LEGEND: Use, duplication, or disclosure by the United States Government
is subject to the restrictions set forth in DFARS 252.227-7013 (c)(1)(ii) and FAR 52.227-19.
TRADEMARKS
THEMIS®is a registered trademark of Themis Computer, Inc.
AMD® and ATI®are registered trademarks of Advanced Micro Devices, Inc.
Avivo™and Radeon™are trademarks of Advanced Micro Devices, Inc.
VESA®and DisplayPort®are registered trademarks of Video Electronics Standards Association.
All other trademarks or registered trademarks used in this publication are the property of their
respective owners.
Safety Precautions
Instructions regarding safety precautions during installation, operation, or maintenance of the equipment
are given in the section entitled “Safety Instructions” on page iv.
WARNINGS and CAUTIONS
The definitions of WARNINGS and CAUTIONS as used in this document are given in the Preface in
the section entitled “Notes, Cautions, Warnings, and Sidebars”.
T2GPX XMC Graphics Card Installation Manual, Version 1.0
June 2011
Part Number: 118973-024
Themis Customer Support
North America, South America, and Pacific Rim
Telephone: [phone]
Fax: [phone]
E-mail: [e-mail]
Web Site: http://www.themis.com

iii
Themis Computer
T2GPX XMC Graphics Card Installation Manual
VersionRevisionHistory
Version 1.0............................................................................................. June 2011

iv Themis Computer
T2GPX XMC Graphics Card Installation Manual Version 1.0
Safety Instructions
To maximize user safety and ensure correct device operation, all instructions con-
tained in this section should be read carefully.
• The device must be used in accordance with the instructions for use.
• Electrical installations in the room must correspond to the requirements of
respective regulations.
• Take care that there are no cables, particularly mains cables, in areas where
persons can trip over them.
• Do not use a mains connection in sockets shared by a number of other power
consumers. Do not use an extension cable.
• Only use the mains cable supplied.
• The unit is completely disconnected from the power source only when the
power cord is disconnected from the power source. Therefore the power cord
and its connectors must always remain easily accessible.
• Do not set up the device in the proximity of heat sources or in a damp location.
Make sure the device has adequate ventilation.
• All connection cables must be screwed or locked to the chassis housing.
• The device is no longer safe to operate when
— the device has visible damage or
— the device no longer functions.
• In these cases, the device must be shut down and secured against unintentional
operation.
• Repairs may only be carried out by a person authorized by Themis Computer.
• The device may only be opened for the installation and removal of extension
(PCI) cards, memory modules, storage drives, fan housings, power supplies,
and the lithium battery—all in accordance with the instructions given in this
and correlating manuals.
Caution: It is important that the user observe all warnings and instructions
that are on the device and contained in this manual.

v
Themis Computer
T2GPX XMC Graphics Card Installation Manual
• If extensions are made to the device, the legal stipulations and the device spec-
ifications must be observed.
• The device must be switched off when removing the top cover; for example,
before installing extension (PCI) cards.
Electrostatic Discharge (ESD)
A sudden discharge of electrostatic electricity can destroy static-sensitive devices
or micro-circuitry. Proper packaging and grounding techniques are necessary pre-
cautions to prevent damage. Always take the following precautions:
1. Transport boards in static-safe containers such as boxes or bags.
2. Keep electrostatic-sensitive parts in their containers until they arrive at static-
free stations.
3. Always be properly grounded when touching a sensitive board, component, or
assembly.
4. Store electrostatic-sensitive boards in protective packaging or on conductive
foam.
Grounding Methods
Guard against electrostatic damage at workstations by following these steps:
1. Cover workstations with approved anti-static material. Provide a wrist strap
connected to a work surface and properly grounded tools and equipment.
2. Use anti-static mats, heel straps, or air ionizers to give added protection.
3. Handle electrostatic-sensitive components, boards, and assemblies by the case
or the PCB edge.
4. Avoid contact with pins, leads, or circuitry.
5. Turn off power and input signals before inserting and removing connectors or
test equipment.
6. Keep the work area free of non-conductive materials such as ordinary plastic as-
sembly aids and Styrofoam.
7. Use field service tools, such as cutters, screwdrivers, and vacuums that are con-
ductive.

vi Themis Computer
T2GPX XMC Graphics Card Installation Manual Version 1.0
8. Always place drives and boards PCB-assembly-side down on the foam.

v
Themis Computer
Table of Contents
Safety Instructions................................................................................................................. iv
Preface.................................................................................................................................. xvii
1. T2GPX Overview and Specifications .......................................................................... 1-1
1.1 Main Features ........................................................................................................ 1-3
1.2 Display and Video Features ................................................................................... 1-3
1.2.1 T2GPX Display Features ........................................................................... 1-4
1.2.2 Graphics Acceleration ................................................................................ 1-5
1.2.2.1 DirectX 10.1 ................................................................................ 1-5
1.2.2.2 Anti-Aliasing Filtering ................................................................ 1-5
1.2.2.3 Anisotropic Filtering ................................................................... 1-5
1.2.2.4 High Efficiency Memory Controller ........................................... 1-5
1.3 Video Display Ports ............................................................................................... 1-6
1.3.1 DisplayPort® ............................................................................................. 1-6
1.3.2 DVI ............................................................................................................ 1-7
1.4 Technical Support .................................................................................................. 1-8
2. Hardware and Software Installation ........................................................................... 2-1
2.1 Hardware Installation ............................................................................................. 2-1
A. Connector Pinouts and LEDs ..................................................................................... A-1
A.1 I/O Port Specifications .......................................................................................... A-1
A.2 DisplayPort®Digital Display Interface ................................................................ A-2
A.3 DVI-I Digital/Analog Video Port ......................................................................... A-3
A.4 XMC Connector .................................................................................................... A-4
A.5 Front-Panel LEDs ................................................................................................. A-7
Appendix B. Solder Beads ................................................................................................B-1
B.1 Factory-Configurable Solder Beads .......................................................................B-1
B.1.1 T2GPX XMC Graphics Card Solder Beads ..............................................B-1

vi Themis Computer
T2GPX XMC Graphics Card Installation Guide Version 1.0
Index ................................................................................................................Index-1
Reader Comment Card

vii
Themis Computer
Table of Contents
List of Figures
Figure 1 T2GPX XMC Graphics Card (Heat Sink Installed) ........................................ xvii
Figure 2 Three-Quarter Front View of the XV1,XV2,LV1 .......................................... xviii
Figure 3 Three-Quarter Front View of the T2GPX......................................................... xix
Figure 4 Front View of the T2GPX ................................................................................ xix
Figure 1-1 T2GPX XMC Graphics Card (Heat Sink Removed)....................................... 1-1
Figure 1-2 T2GPX XMC Graphics Card Block Diagram................................................. 1-2
Figure 1-3 ATI Radeon™ E4690 Graphics Processor...................................................... 1-4
Figure 1-4 T2GPX Front I/O Ports.................................................................................... 1-6
Figure 2-1 Host System Board for the T2GPX ................................................................. 2-2
Figure 2-2 T2GPX XMC Graphics Card........................................................................... 2-2
Figure A-1 T2GPX XMC Graphics Card I/O Ports......................................................... A-1
Figure A-2 T2GPX DisplayPort 1.1a Connector Pinout.................................................. A-2
Figure A-3 T2GPX DVI-I Connector Pinout................................................................... A-3
Figure A-4 T2GPX XMC Connector Pinout.................................................................... A-4
Figure A-5 T2GPX Front-Panel LEDs............................................................................. A-7
Figure B-1 T2GPX XMC Graphics Card Solder-Bead Locations (Bottom Side)............. B-4
List of Tables
Table 1-1 DisplayPort Maximum Pixel Rate Per Lane(s) @ 2.7-GHz Link Rate........... 1-7
Table 1-2 DVI-I Example Dual Link Display Modes...................................................... 1-8
Table A-1 T2GPX DisplayPort 1.1a Signal Descriptions................................................ A-2
Table A-2 T2GPX DVI-I Signal Descriptions................................................................. A-3
Table A-3 T2GPX XMC Signal Descriptions ................................................................. A-5
Table A-4 T2GPX Front-Panel LED Behavior................................................................ A-7
Table B-1 T2GPX XMC Graphics Card Solder-Bead Settings (Bottom Side)................ B-2

viii Themis Computer
T2GPX XMC Graphics Card Installation Guide Version 1.0

xvii
Themis Computer
Preface
This document, entitled T2GPX XMC Graphics Card Installation Guide, provides a
hardware overview of the Themis T2GPX XMC Graphics Card (see Figure 1
below), which is based on the ATI Radeon™E4690 Embedded Graphics Processor
(located under heat sink).
T2GPX XMC Graphics Card is supported by XMC based platforms such as:
• Themis XV2 6RU VME64 Platform single board computer
• Themis XV1 6RU VME64 Platform single board computer
• Themis LV1 6RU VME64 Platform single board computer
(Each product mentioned above can be found in the following figure:
XV1;XV2;LV1, Figure 2 on page xviii).
.
Figure 1. T2GPX XMC Graphics Card (Heat Sink Installed)

T2GPX XMC Graphics Card Installation Manual Version 1.0
xviii Themis Computer
Figure 2. Three-Quarter Front View of the XV1, XV2, LV1

Preface
xix
Themis Computer
T2GPX XMC Graphics Card has been designed to fit on to a standard XMC carrier
board and is provided with heat sink and installation hardware (not shown). The
T2GPX is rugged enough to meet the demands associated with such markets as the
military, aerospace, and telecommunications industries.
Figure 3. Three-Quarter Front View of the T2GPX
Figure 4. Front View of the T2GPX

T2GPX XMC Graphics Card Installation Manual Version 1.0
xx Themis Computer
The T2GPX is based upon a x8 PCI-E gen 2.0 interface through the XMC (male)
connector on the card. The XMC connector also allows for automatic switching
between +12V and +5V VPWR. The XMC connection is fully Vita 42.3 XMC
PCI-E protocol compliant.
T2GPX XMC Graphics Card is based on the functionality and capability of the fol-
lowing AMD chipset:
• ATI Radeon™E4690 Graphics Processor
• 128-bit memory interface and 512 MB GDDR3
An overview of T2GPX XMC Graphics Card design and specifications is given in
Chapter 1, "T2GPX Overview and Specifications", of this manual.
Connector pinout, LED, and solder bead descriptions is given in the Appendices of
this manual.
This manual is intended for an experienced system administrator with a knowledge
of networking, VME based platforms, high-speed single board computers, and cur-
rent OS software.
Website Information
Themis Computer corporate and product information may be accessed on the World
Wide Web by browsing the website http://www.themis.com.
Your Comments are Welcome
We are interested in improving our documentation and welcome your comments and
suggestions. You can email your comments to us at [email protected].
Please include the document part number (116970-024) in the subject line of your
email.

Preface
xxi
Themis Computer
Notes, Cautions, Warnings, and Sidebars
The following icons and formatted text are included in this document for the reasons
described:
Note: A note provides additional information concerning the procedure or action
being described.
Caution: A caution describes a procedure or action that may result in damage to
the equipment. This may involve—but is not restricted to—heavy equipment or
sharpobjects. To reducethe risk, followtheinstructions accompanyingthis symbol.
Warning: A warning describes a procedure or action that may cause injury or death
to the operator as a result of hazardous voltages. To reduce the risk, follow the in-
structions accompanying this symbol.
Sidebar: A “sidebar” adds detail to the section within which it is placed,
but is not absolutely vital to the description or procedure of the section.

T2GPX XMC Graphics Card Installation Manual Version 1.0
xxii Themis Computer

1-1
Themis Computer
1
T2GPX Overview and Specifications
The Themis T2GPX XMC Graphics Card (see Figure 1-1) is a high-resolution 3D
graphics solution that is installed and runs on XMC-based system platforms such as
the Themis XV2 single-board computer. The T2GPX has automatic switching
between +12V and +5V VPWR input from the XMC connector.
Figure 1-1. T2GPX XMC Graphics Card (Heat Sink Removed)
Introductory
Section Chapter

T2GPX XMC Graphics Card Installation Guide Version 1.0
1-2 Themis Computer
Included below is a block diagram of the Themis T2GPX XMC Graphics Card.
On Board
DC/DC
Thermal
Sensor
FRU
M25P10
XMC Connector
DisplayPort DVI-I
AMD
ATI Radeon E4690
Embedded Graphics Processor
Dual Link (digital)
DAC (analog)
DisplayPort
Version 1.1a
SPI
PCI-E x8 gen 2.0
I2C
I2C
P15
Figure 1-2. T2GPX XMC Graphics Card Block Diagram
