Thera-Band VECTOR User manual

OWNER'S MANUAL

Limited Warranty 3
1Safety Warnings 5
2Introduction 7
2.1 Overview 7
2.2 Service and Contact Information 9
3Nomenclature 10
4Operating Instructions 11
5Inspection & Part Replacement 13
5.1 Inspecting TheraBand VECTOR Tubes 13
5.2 Replacing single or multiple TheraBand VECTOR Tubes 15
6Maintenance & Troubleshooting 19
6.1 Preventive Maintenance Tips 19
6.2 Preventive Maintenance Schedule 19
7Specifications 20
OWNER'S MANUAL |2
TABLE OF
CONTENTS

LIMITED
WARRANTY
© 2021 Kayezen LLC by TheraBand. All rights reserved. TheraBand™ is a trademark of TheraBand, LLC. Any use of this
trademark without the express written consent of Kayezen LLC by TheraBand, LLC or its affiliated companies is forbidden.
READ Kayezen WARRANTY TERMS AND CONDITIONS SET FORTH BELOW PRIOR TO USING Kayezen PRODUCTS.
BY INITIAL USE OF Kayezen PRODUCTS YOU ARE CONSENTING TO BE BOUND BY THE FOLLOWING WARRANTY
TERMS AND CONDITIONS. Kayezen LLC by TheraBand (“TheraBand”) warrants to the original buyer of all new equipment
purchased from Kayezen, a Kayezen Authorized Dealer or from a Kayezen Authorized Manufacturing Contractor that these
products will be free from defects in material and workmanship under normal use and service for the following periods and
in the following respects:
THIS LIMITED WARRANTY DOES NOT COVER AND NO WARRANTY
IS GIVEN WITH RESPECT TO:
• Products not manufactured by Kayezen LLC.
• Products which are altered without the express written consent of Kayezen LLC.
• TheraBand TVTs which have been stretched, extended, or forced beyond
stopping point (See Section 4.4).
• Products purchased other than directly from Kayezen LLC.
• Products that are not maintained in compliance with the Kayezen LLC
specifications as shown in the Owner’s Manual and on product labels.
• Products with a missing, unreadable or altered serial tag.
• Labor for components beyond their warranty coverage.
• Products with cosmetic damage including but not limited to,
scratches and dents.
THERABAND
PRODUCTS WARRANTY
VECTOR and Kayezen
branded accessories:
One year from delivery date
TheraBand VECTOR TUBES
(“TVTs”): 60 days from delivery date
VECTOR must only be used
with TheraBand certified accessories
OWNER'S MANUAL |3

• Onsite service calls to provide technical training on the proper
use and servicing of the equipment.
• Freight and handling costs related to the repair of equipment.
This warranty applies under the following conditions:
• Products have not been subjected to misuse, abuse,
modifications not authorized by TheraBand or any damage
caused by improper handling, natural disasters, acts of God
and servicing by non-authorized dealers. This includes the
application of cleaning materials or lubricants not specified by
TheraBand.
• Products remain in possession of the original purchaser.
• Warranty claims are made within the warranty periods
previously shown and that such claims occur within 30 days
after the date of discovery.
• Labor coverage applies only within the United States and
Canada.
• Warranties for parts and labor may vary outside the United
States. Contact the TheraBand Authorized Dealer within your
geographic area for warranty terms.
All warranty periods begin to run from the date of delivery to
the original purchaser. The obligation of TheraBand under this
warranty is limited to repairing or replacing warranted defective
parts, as TheraBand may elect, without charge to purchaser for
either parts or labor.
Purchaser is responsible for all transportation and insurance
costs on returned or replaced equipment to and from
TheraBand’s warehouse.
Any implied warranty, including but not limited to the implied
warranty of fitness for a particular purpose and the implied
warranty of merchantability, is limited to one-year duration from
the date of delivery to the original purchaser. Some states do not
allow limitations on how long an implied warranty lasts, so the
above limitation may not apply to you. The remedy of repair and
replacement is the exclusive and sole remedy of the purchaser.
TheraBand shall not be liable for any special, incidental,
contingent or consequential damages of any kind, including, but
not limited to, damage or loss of property or equipment and lost
profits and revenue. Some states do not allow the exclusion or
limitation of incidental or consequential damages, so the above
limitation or exclusion may not apply to you.
No action for breach of this written limited warranty or an
implied warranty shall be commenced more than one year after
the accrual of the cause of action. This written limited warranty
is the complete, final and exclusive agreement of the parties
with respect to the quality or performance of the goods and
any and all warranties and representations. No modifications
of this limited warranty or waiver of its terms shall be binding
on either party unless approved in writing by an authorized
corporate officer of TheraBand. This limited warranty gives you
specific legal rights, and you may also have other rights which
may vary from state to state. Contact ΚΑΥΖΕΝ by TheraBand,
[email protected] for a list of authorized dealers
before returning any defective equipment.
OWNER'S MANUAL |4

1
SAFETY
WARNINGS
All precautions should be taken to minimize the risk
of injury and to prevent damage to the equipment.
Read the entire Owner’s Manual before using the
VECTOR and always observe the following safety
precautions.
SERIOUS INJURY OR DEATH CAN OCCUR WHILE
USING THIS PRODUCT IF PRECAUTIONS ARE NOT
OBSERVED. READ ALL INSTRUCTIONS BEFORE
USING THIS EQUIPMENT.
DANGER
SERIOUS INJURY AND/OR DEATH WILL OCCUR
IF THE FOLLOWING PRECAUTIONS ARE NOT
FOLLOWED
WARNING
SERIOUS INJURY AND/OR PROPERTY DAMAGE
MAY OCCUR IF THE FOLLOWING PRECAUTIONS
ARE NOT FOLLOWED
• Before each use remove cover and review all warnings on internal shaft.
• The VECTOR must be attached to an anchor point that is capable of
resisting loads of at least 91 Kg.
• Connect the VECTOR to an anchor point using only carabiners load rated
for at least 91 Kg or those supplied by TheraBand. TheraBand assumes no
liability for damage or injury caused by carabiners supplied by any third
party.
• Never pull TVTs beyond stopping point.
• Never release Cap Assembly from extended position
• Inspect TVTs weekly. Replace any TVTs that appear worn or abraded prior
to use.
• Replace all TVTs every six months or sooner if they appear worn or
abraded.
• Keep children under age 13 away from this machine. Supervise use by
teenagers.
• Use VECTORS with only Kayezen certified accessories.
• Obtain a medical exam before beginning an exercise program.
• Stop exercising immediately if you feel pain, become dizzy, faint or short
of breath.
• DO NOT use if the product appears damaged or inoperable. Report
problems to staff if using in a commercial environment.
• Obtain instruction and/or refer to the manual before using. Read all
warnings before using.
• Avoid contact between the Cover Tube and any fixed object when in use.
Breakage and injury may result.
• Keep hair, body parts and clothing clear of moving parts.
OWNER'S MANUAL |5

1
CAUTION
INJURY AND/OR PROPERTY DAMAGE MAY OCCUR IF
THE FOLLOWING PRECAUTIONS ARE NOT FOLLOWED
• Do not attempt any maintenance or repair procedure
unless you are qualified and equipped to perform the
procedure properly and safely.
E-Mail: [email protected]
• Make sure that the exercise area around the equipment
is clear of any obstructions or tripping hazards prior to
exercising on the equipment.
• Make sure that the floor around the equipment is dry and
free of any materials or liquids that may make the floor
slippery.
SAVE THIS MANUAL FOR FUTURE REFERENCE
OWNER'S MANUAL |6

2
INTRODUCTION
2.1 Overview
This section contains a general overview of the
VECTOR resistance technology and information
about how to Service and Support.
Thank you for purchasing the VECTOR by
TheraBand.
The VECTOR is intended for use both indoors
and outdoors in physical therapy, sports
performance and fitness environments.
Heed all warnings and cautions when operating
or maintaining the VECTOR. Contact a qualified
service technician for any procedure that you
cannot perform correctly, completely, and safely.
Follow all instructions carefully.
The VECTOR is intended for use in sports
training, health clubs, gyms, active aging, and
physical therapy facilities. It has been tested and
complies with U.S. and International safety and
durability requirements for use in both home and
commercial environments. This manual will help
you discover and use the equipment’s features.
The patented VECTOR offers a number of significant benefits including:
• Before each use remove cover and review all warnings on internal shaft.
• The ability to change the Weight Equivalent Pull (WEP) level by simply
turning the cap at the top of the VECTOR to select one of three user
configurable resistance levels.
• Fast connect / disconnect from anchor points via a carabiner.
• Improved user safety through use of TVTs. Kevlar® cords inside each elastic
tube limit how far the tube can be stretched during use and reduce a risk
of a band from “snapping back” at the user in the event of an tube failure.
• Outer removable cover that protects the TVTs from UV exposure, dirt,
debris, and contaminants.
• Ability to easily customize the WEP of the VECTOR by changing out TVTs
which are available in different resistance levels. The following chart shows
approximate maximum WEP for various configurations and maximum
allowable stretch. Note that the WEPs are approximate only – the WEP
may vary due to manufacturing tolerances, age of the TVTs, number of
pull cycles on the TVTs, and what percentage of maximum pull length
the cycles were accumulated at (to name some of the variables that will
affect the WEP). Also note that the WEPs shown are just prior to the TVTs
being stretched to the length of the internal Kevlar – once the TVTs are
stretched to the length of the internal Kevlar cord, the load will increase
instantaneously if the user attempts to continue stretching the TVTs.
OWNER'S MANUAL |7

2
The following charts show the approximate WEP
for standard and Group exercise VECTORs.
The vertical axis of the chart is for the various
ways the VECTOR can be configured with the first
letter being the TVTs in disc 1 (L=Light, H=Heavy),
second letter is the TVTs in disc 2 and third letter is
the TVTs in disc 3.
Visit our website regularly: www.kayezen.com
for updates to this manual, important safety
notices, mandatory service bulletins, latest product
offerings and new exercise moves and routines to
optimize your TheraBand experience.
Kevlar® is a registered trademark of E.I. du Pont de Nemours and Company
OWNER'S MANUAL |8

2
2.2 Service and Contact Information
HOW TO OBTAIN PRODUCT SERVICE
1. Verify the symptom and review the operating instructions.
The problem may be unfamiliarity with the product and its
features and workouts.
2. Locate and write down the serial number of the unit,
which is located on the center shaft of the product.
3. Kayezen LLC
E-Mail: [email protected]
OWNER'S MANUAL |9

The following illustrations show the names for various components of the VECTOR as used in this manual.
3
NOMENCLATURE
Cap
Resistance Level Indicator
Cap Assembly
Removable Cover
Cap Release
Base Assembly
Swivel
Carabiner Attachment Loop
Swivel assembly (includes number of discs selected)
Discs 1 through 3 (disc one is closest to swivel)
TVTs (TheraBand Vector Tubes)
Warning Labels (on center shaft of base assembly)
Flower Petal
Internal View – Cap and removable cover not shown
OWNER'S MANUAL |10

The VECTOR is shipped fully
assembled and ready to use.
Simply remove the VECTOR and all
accessories from the packaging and
dispose of the packaging in a proper
manner. Accessories provided with the
VECTOR will depend on the particular
SKU purchased. A video showing how
to use a VECTOR is also available at
www.kayezen.com.
4.1 Attach the VECTOR to an
appropriate anchor point via the
carabiner loop using the carabiner
provided by TheraBand.
WARNING
• VECTOR must be attached to an
anchor point that is capable of
resisting loads of at least 91 Kg.
• Connect the VECTOR to an anchor
point using only carabiners load
rated for at least 12Kn or those
supplied by TheraBand. TheraBand
assumes no liability for damage
or injury caused by carabiners
supplied by any third party.
4.2 Attach the TheraBand certified
accessory for the exercise being
performed to the swivel loop at the
top of the cap assembly. This will
usually be a handle to allow gripping
with the hand, but may be a variety
of accessories to allow resistance to
be applied to various points on the
body.
4
OPERATING
INSTRUCTIONS
OWNER'S MANUAL |11

4.5 Complete the exercise by returning the cap
assembly to its home position resting on the base
assembly.
WARNING
Never release cap assembly from extended position.
4.4 Perform the exercise by pulling the TheraBand
certified accessory out to the desired range of motion
and back to the start of the desired range of motion.
Repeat as desired.
WARNING
Never pull TVTs beyond stopping point.
4.3 Select the WEP level desired for the exercise by
rotating the cap assembly to engage 1, 2, or 3 discs.
Note: Do not pull the cap assembly up when rotating the
cap. (Reference WEPs levels shown in the User’s Manual
in Section 2.1). Picture illustrates 2 discs being selected
as indicated by the 2 blue lines shown under the arrow
at the bottom of the TheraBand logo.
4
OWNER'S MANUAL |12

This section provides information on
the routine inspection of the VECTOR,
along with replacement of Normal
wear components.
5.1 Inspecting TVTs
WARNING
TVTs must be inspected weekly for
wear and abrasion. Replace any TVTs
that are questionable.
The following procedure is for
inspecting the TVTs. Section 5.2
provides instructions on the procedure
for replacing TVTs.
5.1.1 Remove outer removable
cover by pushing the cover slightly
toward the swivel end of the
VECTOR. The cover is shown in the
picture in the locked position where
the arrow on the upper portion of
the base assembly aligns with the
locked lock icon on the removable
cover.
5.1.2 With the removable cover
pushed toward the swivel end
of the VECTOR, rotate the tube
counter-clockwise (as viewed from
the carabiner loop end) until the
arrow on the base assembly aligns
with the unlocked lock icon to
release the cover. Slide the cover
off the VECTOR over the carabiner
attachment loop.
5
INSPECTION
& PART
REPLACEMENT
OWNER'S MANUAL |13

5.1.3 Visually inspect each TVTs for signs of abrasion
or “pilling” on the surface of the tube concentrating on
the portion of the TVT nearest the swivel end of the
VECTOR. Picture shows a TVT that has snapped with
protective Kevlar string intact.
5.1.5 Re-install the removable cover by sliding the
removable cover over the carabiner attachment loop.
Align the arrow on the base assembly with the unlocked
lock icon and push the removable cover against the
upper portion of the base assembly until it stops.
5.1.4 Replace any TVTs necessary following the
procedure in section 5.2.
5.1.6 Lock the cover by rotating the cover until the
arrow on the base assembly aligns with the locked lock
icon while the removable cover is pushed toward the
swivel end of the VECTOR.
5
OWNER'S MANUAL |14

5.2 Replacing single or
multiple TVTs
WARNING
• Inspect TVTs weekly. Replace any
TVTs that appear worn or abraded
prior to use.
• Replace all TVTs every six months
or sooner if they appear worn or
abraded.
The following section provides
instructions on replacing single or
multiple TVTs. A video showing how
to replace a TVT is also available at
www.kayezen.com.
5.2.1 Release cap by squeezing cap
release tabs together.
5.2.2 Remove cap by sliding cap
toward swivel with the cap release
tabs depressed until top of cap is
past the bottom of the cap release
tabs. Slide cap off of the end of the
VECTOR.
Completely remove the TVT from
the VECTOR. DO NOT remove more
than one TVT at a time. Removal
of multiple TVTs may cause disc
assembly to become unseated
making reassembly much more
difficult.
5
OWNER'S MANUAL |15

5.2.3 Remove outer removable cover by pushing the
cover slightly toward the swivel end of the VECTOR.
The cover is shown in the picture in the locked position
where the arrow on the upper portion of the base
assembly aligns with the locked lock icon on the
removable cover.
5.2.4 With the removable cover pushed toward the
swivel end of the VECTOR, rotate the tube counter-
clockwise (as viewed from the carabiner loop end)
until the arrow on the base assembly aligns with the
unlocked lock icon to release cover. Slide the cover off
of the VECTOR over the carabiner attachment loop.
5.2.5 Release the VECTOR tube from the flower petal
by pulling the ball end of the TVT slightly toward the
carabiner attachment loop and out from the center
shaft.
5
OWNER'S MANUAL |16

5.2.6 Push the released TVT slightly through the discs
toward the swivel end of the VECTOR until the cone end
of the TVT is accessible, then pull the TVT out through
the disc assembly.
5.2.7 Completely remove the TVT from the VECTOR.
DO NOT remove more than one TVT at a time. Removal
of multiple TVTs may cause disc assembly to become
unseated making reassembly much more difficult.
5.2.8 Take a new TVT and thread the ball end of the
TVT through the empty holes in the disc assembly.
5
5.2.9 Pull the ball end to the carabiner attachment loop
end of the VECTOR until the ball is slightly past the
lower surface of the flower petal. Secure the TVT by
moving the ball end of the TVT toward the center shaft
until the TVT is inside the aperture of the flower petal.
Release the ball end of the TVTs.
5.2.10 Repeat steps 5.2.5 through 5.2.9 for as many
TVTs as necessary.
OWNER'S MANUAL |17

5.2.11 Re-install the removable cover by sliding the
removable cover over the carabiner attachment loop.
Align the arrow on the base assembly with the unlocked
lock icon and push the removable cover against the
upper portion of the base assembly until it stops.
5.2.12 Lock the cover by rotating the cover until the
arrow on the base assembly aligns with the locked lock
icon while the removable cover is pushed.
5.2.13 Replace the cap by sliding it over the swivel
assembly until the cap release tabs snap back to their
home position securing the cap in place.
5
OWNER'S MANUAL |18

6
MAINTENANCE &
TROUBLESHOOTING
This section provides information on
preventative maintenance and troubleshooting
that can be done by the user.
6.1 Preventive Maintenance Tips
Keep the equipment out of use until defective
parts are repaired or replaced. Pay special
attention to parts that are subject to wear,
as outlined below. The following preventive
maintenance tips will keep the VECTOR
operating at peak performance:
• When cleaning the exterior of the unit, a non-
abrasive cleaner and soft cotton cloth are
strongly recommended. Contact Kayezen
Customer Service for more details. Apply
cleaner to the cotton cloth before cleaning.
• DO NOT use ammonia or acid based cleaners.
• DO NOT use abrasive cleaners.
• DO NOT use paper towels.
• DO NOT apply cleaner to decals.
6.2 Preventive Maintenance Schedule
Follow the schedule below to ensure proper operation of the
product. If any of the inspections listed below reveal indications
of excessive wear or degradation, those components should be
replaced by a qualified service representative immediately.
Item Weekly Monthly Qrtrly Semi-
Annual
Annual
Inspect TVTs for wear
Replace all TVTs
Inspect carabiner attachment loop
for any looseness. If any looseness
is found stop using product and
contact TheraBand customer service
immediately.
Inspect swivel and all plastic
components for wear or cracks.
If any wear or cracks are found stop
using product and contact TheraBand
customer service immediately.
Inspect center shaft for looseness to
components on both ends of the shaft.
If any looseness found stop using
product and contact TheraBand
customer service immediately.
Inspect carabiner for wear.
Replace if worn.
OWNER'S MANUAL |19

7
SPECIFICATIONS
Designed usage Heavy duty commercial facilities including rehab, group exercise, and strength and performance training.
Unit is designed to meet in home use per ASTM and CE regulations.
Maximum user weight Not applicable – unit is not designed to carry body weight.
Maximum load Maximum WEP developed by the VECTOR is approximately 50 Kg using heavy TVTs at maximum
extension. Maximum extension is defined as just prior to the internal Kevlar® cords in the TVTs becoming
taut – the stopping point of extension.
WARNING Never Pull TVTs Beyond Stopping Point.
Resistance System TVTs – Elastic tubes with Kevlar® cord run through the center of the tube to limit extension and prevent
“snap back” at the user in case of tube failure. TVTs include terminations that facilitate the removal and
replacement of the TVTs in the VECTOR.
Power Requirements None
Case High Impact Thermoplastic
Attachment rings Stainless Steel
Length VECTOR 45 overall length is 61.5 cm
VECTOR 60 overall length is 74 cm
Diameter 8 cm
Weight VECTOR 45 approx. 0.95 Kg
VECTOR 60 approx. 1.15 Kg
Shipping Box Dimensions 91.5cm × 10cm × 10 cm
Shipping Weight VECTOR 45 approx. 1.28 Kg
VECTOR 60 approx. 1.42 Kg
OWNER'S MANUAL |20
