Thermador PRG304EG User manual

ForThermadorProfessional®PRO-GRAND™
Gas Ranges
INSTALLATION
INSTRUCTIONS Models
PG30
PG36
PG48
Pour toutes cuisinières à gaz Thermador Professional®
PRO-GRAND™
INSTRUCTIONS
D’INSTALLATION

IMPORTANT: Save these instructions for the Local Gas Inspector’s use.
INSTALLER: Please leave these Installation Instructions with this unit for the owner.
OWNER: Please retain these instructions for future reference.
Please Read Entire Instructions
Before Proceeding
For Massachusetts Installations:
1. Installationmustbeperformedbyaqualified
or licensed contractor, plumber or gas fitter
qualifiedorlicensedbythestate,provinceor
region where this appliance is being in-
stalled.
2. Shut-off valve must be a “T” handle gas
cock.
3. Flexible gas connector must not be longer
than 36 inches.
IMPORTANT
Local codes vary. Installation, gas
connections and grounding must
comply with all applicable codes.
WARNING
Disconnect power before installing. Before
turning power ON, be sure that all controls
are in the OFF position.
If the information in this manual is not
followed exactly, a fire or explosion may
result causing property damage, personal
injury or death.
— Do not store or use gasoline or other flam-
mablevaporsandliquidsinthevicinityofthis
or any other appliance.
— WHAT TO DO IF YOU SMELL GAS
■Do not try to light any appliance.
■Do not touch any electrical switch.
■Do not use any phone in your building.
■Immediately call your gas supplier from a
neighbor’s phone. Follow the gas supplier’s
instructions.
■Ifyoucannotreachyourgassupplier,callthe
fire department.
—Installationandservicemustbeperformedby
aqualifiedinstaller,serviceagencyorthegas
supplier.
TO REDUCE THE RISK OF TIPPING OF THE
APPLIANCE, IT MUST BE SECURED BY A
PROPERLY INSTALLED ANTI-TIP DEVICE.
VERIFYTHATTHEANTI-TIPDEVICEISENGAGED
PER INSTALLATION INSTRUCTIONS. (NOTE:
ANTI-TIPDEVICEISREQUIREDONALL30"AND
36" RANGES)
Note: This Range is NOT designed for installa-
tioninmanufactured(mobile)homesorforinstal-
lation in Recreational Park Trailers.
Do Not install this range outdoors.
WARNING
■All Ranges can tip
■Injury to Persons
could result
■InstallAnti-TipDevice
■SeeInstallation
Instructions
WARNING:

Contents
ImportantInstallationInformation .................1
Step1:VentilationRequirements................2
Step 2: Cabinet Preparation.................3 – 7
Step3:Unpacking,Moving
andPlacingtheRange .........................8 – 9
Step4:InstallingAnti-TipDevice ......10 – 11
Step5:GasRequirementsandHookup....12
Step6: ElectricalRequirements,
ConnectionandGrounding .......................13
Step7:BackguardInstallation ..................14
Step8:DoorRemovalandInstallation ......15
Step9:BurnerTestandAdjustment..16 – 17
InstallerChecklist......................................18
ToCleanandProtectExteriorSurfaces....18

1
Important Installation Information
GAStype verification
Verifythetypeofgassuppliedtothelocation.Ensure
that the appliance is connected to the type of gas for
whichitiscertified.Allrangesarecertifiedforusewith
natural gas or propane (LP) gas. Make certain the
range matches the gas type available.
Important
• Abackguardmustbeutilizedwhenthereislessthan
a12”horizontalclearancebetweencombustiblema-
terialsandthebackedgeoftherange.TheThermador
LowBackbackguardmustbeorderedseparatelyand
installed at the rear of the range. For island installa-
tionsandotherinstallationswithmorethan12”clear-
ance, an optional stainless steel Island Trim is avail-
able to cover the backguard mounting flanges.
• Verifythatthe applianceiscorrectforthetypeofgas
being provided. Refer to Step 5 on Page 12 before
proceedingwith the installation.
GasSupply:
Natural Gas – 6 inch water column. (14.9 mb) min.,
14 inch (34.9 mb) max.
Propane Gas – 11 inch water column. (27.4 mb), min.,
14 inch (34.9 mb) max.
Electric Power Supply:
30" Model:
4 Burners - 120 VAC, 60 Hz., 1Ph., 15 Amp circuit.
36" Models:
6 Burners – 120 VAC, 60 Hz., 1Ph., 15 Amp circuit.
4BurnerswithGrill–120VAC,60Hz.,1Ph.,15Ampcircuit.
4 Burners with Griddle – 120 VAC, 60 Hz., 1Ph., 20 Amp
circuit.
48" Models:
6BurnerswithGrill–120VAC,60Hz.,1Ph.,15Ampcircuit.
6 Burners with Griddle – 120 VAC, 60 Hz., 1Ph., 20 Amp
circuit.
4BurnerswithGrillandGriddle–120VAC,60Hz.,1Ph.,20
Amp circuit.
It is strongly recommended that this appliance be
installedin conjunction witha suitable overheadvent
hood.(SeeStep1forVentilationRequirements.)Due
tothehighheatcapabilityofthisunit,particularatten-
tion should be paid to the hood and duct work instal-
lation to assure it meets local building codes.
Itis the responsibility oftheowner and the installerto
determineifadditionalrequirementsand/orstandards
apply to specific installations.
CAUTION
This unit is designed as a cooking appliance.
Basedonsafetyconsiderations,neveruseitfor
warming or heating a room.
CAUTION
To eliminate risk of burns or fire caused by
reaching over heated surface units, cabinet
storage located above the surface units
should be avoided.
Check local building codes for the proper method of
appliance installation. Local codes vary. Installation,
electrical connections and grounding must comply
with all applicable codes. In the absence of local
codes the appliance should be installed in accor-
dancewiththeNationalFuelGasCodeANSIZ223.1/
NFPA 54 current issue and National Electrical Code
ANSI/NFPA70-currentissue.InCanada, installation
mustbeinaccordancewith theCAN1-B149.1and.2
–InstallationCodesforGasBurningAppliancesand/
or local codes.
Thisappliancecomplieswithoneormore of the following
standards:
• UL858,StandardfortheSafetyofHouseholdElectric
Ranges
• UL923,StandardfortheSafetyofMicrowaveCooking
Appliances
• UL 507, Standard for the Safety of Electric Fans
• ANSI Z21.1, American National Standard for House-
holdCookingGasAppliances
• CAN/CSA-C22.2 No. 113-M1984 Fans and Ventila-
tors
• CAN/CSA-C22.2 No. 61-M89 Household Cooking
Ranges
CAUTION
Whenconnectingtheunittopropanegas,make
certainthepropanegastankisequippedwithits
own high-pressure regulator in addition to the
pressureregulatorsuppliedwiththerange.The
maximum gas pressure to this appliance
must not exceed 14.0 inches water column
(34.9 mb) from the propane gas tank to the
pressure regulator.

2
Step 1: Ventilation Requirements
It is strongly recommended that a
suitableexhausthoodbeinstalled
above the range. Downdraft
ventilationshouldnotbeused.The
table below indicates the
Thermador hoods, by model
number, that are recommended
for use with all ranges.
1. Select Hood and
Blower Models:
• Forwallinstallations,thehood
width must, at a minimum,
equal the width of the range
cooking surface. Where
space permits, a hood larger
in width than the cooking sur-
face may be desirable for im-
proved ventilation perfor-
mance.
• For island installations, the
hood width should, at a mini-
mum, overhang the range
cookingsurfaceby3"oneach
side.
Notes: * For wall installations where adequate space is available, the installer or user may elect to
use a hood that is wider than the rangetop cooking surface. This may be particularly beneficial
for installations having a long duct run or when heavy usage of the grill is anticipated, in which
improved capturing of the cooking exhaust is desired.
** Thermador offers a choice of remote (VTR1030D or VTR1530D) or internal (VTN1030C)
blowers for use in wall installations.
VTR1030D,
VTR1530D,
orVTN1030C
36" RANGE HNI42YS
HTNI42YS VTR1030D orVTR1530D
PH36CS/42CS
PHE36 / 42
WALL INSTALLATION ISLAND INSTALLATION
RANGE WIDTH HOOD* BLOWER** HOOD BLOWER
30" RANGE
PH30CS
PHE30 / 36 VTR1030D,
VTR1530D,
orVTN1030C HNI42YS
HTNI42YS VTR1030D orVTR1530D
48" RANGE
PH48CS/54CS
PHE48 / 60 VTR1030D, VTR1530D,
orVTN1030C HNI48YS /54YS
HTNI48YS/54YS VTR1530D
2. Hood Placement:
• The lower edge of the hood
shouldbeinstalledaminimum
of 36" above the range cook-
ing surface. Also use a 36"
minimumclearanceifthehood
contains any combustible
materialssuchasawoodcov-
ering. (See Figure 1).
3. Consider Make-Up
Air:
• Duetothehighvolumeofven-
tilationair,asourceofoutside
replacement air is recom-
mended. This is particularly
importantfortightlysealedand
insulated homes.
• A qualified heating and venti-
lating contractor should be
consulted.
IMPORTANT:
Ventilationhoodsandblowersare
designed for use with single wall
ducting. However, some local
building codes or inspectors may
require double wall ducting. Con-
sult local building codes and/or
local agencies before starting to
assure that hood and duct instal-
lationwillmeetlocalrequirements.
Do not install a microwave oven /
ventilator combination above the
range, as these types of units do
not provide the proper ventilation
and are not suitable for use with
therange.
HNW36YS VTR1030D,
orVTR1530D
HNW36YS / 42YS VTR1030D,
orVTR1530D
VTR1030D,
orVTR1530D
HNW48YS

3
Step 2: Cabinet Preparation
1. The range is a free standing unit. If the unit is to
be placed adjacent to cabinets, the clearances
shown in Fig. 1 are required. The same clear-
ancesapplytoislandinstallations,exceptforthe
overhead cabinets, which must have a space
wide enough to accept the flared island hood as
indicated in Fig. 1.
2. The 36" ranges may be recessed into the cabi-
netsbeyondtheedgeofthefrontfaceoftheoven
(SeeFigures2Aand2B).The30"and48"ranges
are not approved to be installed flush with the
cabinets.
Note: The maximum depth of over head cabinets
installed on either side of the hood is 13".
A 36-inch minimum clearance is required between
thetopoftherangeandthebottomofanunprotected
cabinet. It is recommended that the bottom of the
wood or metal cabinet be protected by not less than
1/4inchofaflameretardantmaterialcoveredwithnot
less than No. 28 MSG sheet steel, 0.015 inch (0.38
mm)thickstainlesssteel,0.024inch(0.6mm)alumi-
num, or 0.020 inch (0.5 mm) thick copper. Flame
retardant materials bear the following mark:
UNDERWRITERS LABORATORIES INC.
CLASSIFIED MINERAL AND FIBER BOARDS
SURFACE BURNING CHARACTERISTICS
Followed by the flame spread and smoke ratings,
these designations are shown as “FHC (FIame
Spread/SmokeDeveloped).”Materialswith“O”flame
spreadratingsareflameretardant. Local codesmay
allow other flame spread ratings.
3. Thegasandelectricalsupplyshouldbewithinthe
zones shown in Fig. 3A.
4. Any openings in the wall behind the range and in
the floor under the range must be sealed.
5. When there is less than a 12" horizontal clear-
ance between combustible material and the
back edge of the range above the cooking sur-
face, a Thermador Low Back or Pot and Pan
Shelf must be installed. (See Fig. 2A). When
clearanceto combustible material is over 12",
aThermador Island Trimmay be used.(See Fig.
2B). Figures 2A and 2B indicate the space re-
quired for each type of backguard.
6. A three (3) inch minimum clearance is needed
whentherange is installed besideacombustible
side wall.
7. Always keep appliance area clear and free from
combustible materials, gasoline and other flam-
mable vapors and liquids.
8. Do not obstruct the flow of combustion and ven-
tilation air to the unit.
As defined in the “National Fuel Gas Code”
(ANSI Z223.1 / NFPA 54, Current Edition).
CAUTION
Intheseinstallations,thedoorandcabineton
36-inchmodelscancauseapinchinghazard.

4
CAUTION:
Donotinstallthe30"and48"rangessuchthattheovendoorisflush
withthecabinetface.
Aflushinstallationcouldresultindamage to
the cabinets due to exposure to high heat.
Step 2: Cabinet Preparation
For Electrical and Gas Supply Zone,
see Figure 3A. Zone size and position
differ according to the model.
Cooking
Surface
CAUTION: See Figs.
2A, and 2B. 36"
Min. to combustible
material Ð ,
from cooking
surface
asdefinedinthe“NationalFuelGasCode”(ANSIZ223.1,CurrentEdition).
*Therangeheightisadjustable.Theleveloftherangetopmustbeatthesame
levelorabovethecountertoplevel.
Range width
30", 36" or 48"
30"or36"WideHood
36"or42"forIsland
36"or42"WideHood
42"or48"forIsland
48",54",or 60" WideHood
48"or54" forIsland
}
}
}
For 30" Ranges
For 36" Ranges
For 48" Ranges
®
Min. Distance Between Overhead
Cabinets of Combustible Material Ð
30" Range – 30"
36" Range – 36"
48" Range – 48"
®
13" Max.
Cabinet
Depth
}
3" Min. to
combustible
side wall
material Ð ,
(both sides)
18"
Min.
®
®
FIG. 1 Cabinet Clearances
*35-7/8" Min. Range Height
with Leveling Legs fully
retracted
*36-3/4" Max. Range Height
with Leveling Legs fully
extended.
36"minimumfrombottomof
OverheadHoodtocooking
surface(also36"min.ifhood
containscombustible
materials )
®
®
•
®
®
®
®
®
®

5
Step 2: Cabinet Preparation
3/8"
4"
®
®
Note:
For Island Trim installations,
counter surface should have a
cantileveredgemeetingtheback
section of the Island Trim
accessory.
Note:
If an inner wall is used under the
cantilever counter top, there
shouldbea1/8"gapfromtherear
of the range to the inner wall.
Cantilever Countertop
®
®
FIG. 2A - Side View
12" Min. to
Combustibles
with Island Trim
FIG. 2B - Side View
Potand
Pan
Shelf

6
GAS AND ELECTRIC SUPPLY ZONES:
Step 2: Cabinet Preparation
NOTE:
Ifnotalready
present, install
gasshut-offvalve
in an easily
accessible
location. Make
sure all users
knowwhereand
how to shut off
the gas supply to
therange.
NOTE:The
installershould
informthe
consumerofthe
locationofthe
gasshut-offvalve.
Typical placement shown.
Other placement of
Electrical Supply and
Receptacle within the
Electrical and Gas Supply
Zone is acceptable.
FIG. 3A Gas & Electrical Supply Zones for All Gas Ranges
The All Gas ranges may be con-
nected to the power supply with a
range supply cord (supplied with
range)orbyhard-wiringtothepower
supply. It is the responsibility of the
installertoprovidetheproperwiring
components (cord or conduit and
wires) and complete the gas con-
nection as dictated by local codes
andordinances,and/ortheNational
Electric Code. The units must be
properly grounded. Refer to Step 6
for details.
The range must be connected
only to the type of gas for which
it is certified. If the range is to be
connected to propane gas, ensure
that the propane gas supply tank is
equippedwithitsownhighpressure
regulator in addition to the pressure
regulator supplied with the range.
(See Step 5.)
3/4" Flex Line to
Appliance
B
A
Centerline of
Electrical
Supply Zone
Gas
Supply
Zone
1/2"
NPT 120 VAC Receptacle
(Shown) or Junction
Box
2" Maximum
Protrusion from Wall
for Gas Supply
®
®
®
®
®
®
C
®
®
D
NOTE:Anyopeninginthewallbehindtheappliance
and any opening in the floor under the appliance
must be sealed.
IMPORTANT:
Thecordsuppliedwithgasrangeshavingelectricgriddlerequires
a NEMA 5-20 receptacle, shown here. Local codes may require
a different wiring method. NEMA 5-20
RECEPTACLE
PLUG
®
®
E
Model A B C D E
30" 8" 12" 10" 6-1/2" 5-1/4"
36" 10-1/2" 15" 10-1/2" 6-1/2" 5-1/4"
48" 16-1/2" 16" 15-1/2" 6-1/2" 5-1/4"
Floor

Step 2: Cabinet Preparation
ELECTRICAL SUPPLY
7
IMPORTANT
Forallgasrangemodels with an electric griddle , a
dedicated 20 Amp service is required for proper
operation.
FIG. 3B Wall Connection
Power Cord & Receptacle
Installationoftherangemustbeplannedsothatthe
rough-in of the junction box for the receptacle or
conduitconnectionwillallowmaximumclearanceto
the rear of the unit.
To minimize binding when the unit is connected to
thereceptacleor junction box, orient thereceptacle
or conduit connector, and slide back into position.

Chart A 30" Range 36" Range 48" Range
Shipping Weight 335 lbs. 444 lbs. 584 lbs.
Weight without 285 lbs. 390 lbs. 524 lbs.
packing materials
Without door(s), 215 lbs. 295 lbs. 395 lbs.
burner caps, front kick
panel and oven racks
8
Step 3: Unpacking, Moving and Placing the Range
CAUTION
Proper equipment and ad-
equate manpower must be
usedinmovingtherangeto
avoid injury, and to avoid
damage to the unit or the
floor. The unit is heavy
and should be handled
accordingly.
• Therangehasan approximate
shipping weight as shown in
Chart A. The grates, griddle
plate and frame, burner caps,
frontkickpanelandovenracks
must be removed to facilitate
handling. This will reduce the
weightasshowninChartAand
allowtherangetopassthrough
30" doorways. See Figs. 2A
and 2B on Page 5. Do not
remove the grill or griddle
assemblies.
• Remove the outer carton and
packingmaterialfromtheship-
ping base. The all gas ranges
are held to the skid by four (4)
bolts (see Fig. 4 and 5). After
removing the bolts the range
mustbeliftedandremovedfrom
the skid.
• IMPORTANT: Do not lift the
range by the oven door's
handle, as this may damage
the door hinges and cause
the door to fit incorrectly to
the oven cavity.
FIG. 4 – Removal of Two Front
Shipping Bolts FIG. 5 – Removal of Two Rear
Shipping Bolts
®
Left Rear
Shipping
Bolt
NOTE: Leave adhesive-backed
foam layer over brushed-metal
surfaces to protect finish from
scratches, until the range is in-
stalled in final position.

9
• Dueto the weight, a dolly with soft wheels should
be used to move this unit. The weight must be
supported uniformly across the bottom (See Fig.
6).
• After transporting the professional range by dolly
close to its final location, the range can be tipped
backandsupportedontherearlegswhilethedolly
is carefully removed. THE FLOOR UNDER THE
LEGS SHOULD BE PROTECTED BEFORE
PUSHING THE UNIT INTO POSITION. The
anti-tipdevice mustbeinstalled(Step4),gasand
electrical connections should be made (Steps 5
and 6), and the backguard installed (Step 7)
before the range is placed in its final position.
• For proper performance, the range must be
level. (It is very important for all products that
havethe griddle feature.)The range isleveled by
adjusting the legs with a wrench.
• Replace the kick panel and install the oven door.
To install door, see Page 15. Do not install the
oven door until the range is in its final loca-
tion. It is important that the two (2) screws
retaining the kick panel are secure to prevent
accidental access to hot surfaces.
• Ensure that the burner caps are correctly
seated on the burner bases of the range's
cooktop.
Step 3: Unpacking, Moving and Placing the Range
FIG. 6- Dolly Positioning
Grill / Griddle Tilt Adjustment (Not on all models)
Check the griddle frame adjustment by pouring two tablespoons of water on the back of the griddle
plate. The water should slowly roll into the grease tray. If not, adjust the two screws under the back
of the griddle frame. Start with one half turn CCW of the screws. Further adjustment should be made
by one-quarter turn until water slowly flows into the grease tray.
Remove all tape and packaging before using the
appliance. Destroy the packaging after unpacking
the appliance. Never allow children to play with
packaging material.

10
Step 4: Installing Anti-Tip Device
•Screwdriver,Phillips •Hammer
• Drill, electric or hand • Pencil or other marker
•Measuring tapeor ruler
• 1/8" drill bit (wood or metal wall or floor)
• 3/16" carbide-tipped masonry drill bit (concrete or concrete block wall or floor)
• 3/16" anchors, drywall or concrete, 4 each (not required if mounting bracket is being attached to solid wood or metal)
For all 30" and 36" ranges, an anti-tip device must be installed as per these
instructions.
WARNING
RANGE TIPPING HAZARD
• All ranges can tip and injury can result.
Topreventaccidentaltippingoftherange,
attach it to the floor, wall or cabinet by
installing the Anti-Tip Device supplied.
• A risk of tip-over may exist if the appli-
ance is not installed in accordance with
these instructions.
• If the range is pulled away from the wall
forcleaning,service oranyother reason,
ensure that the Anti-Tip Device is prop-
erlyreengagedwhentherangeispushed
back against the wall. In the event of
abnormalusage(suchasapersonstand-
ing, sitting, or leaning on an open door),
failure to take this precaution can result
in tipping of the range. Personal injury
might result from spilled hot liquids or
from the range itself.
ATTENTION
PROPERTY DAMAGE
• Contact a qualified installer or contrac-
tor to determine the proper method for
drilling holes through the wall or floor
material(suchasceramictile,hardwood,
etc.)
• Do not slide the range across an unpro-
tected floor.
• Failure to follow these instructions may
result in damage to wall or floor cover-
ings.
WARNING
ELECTRICAL SHOCK HAZARD
• Use extreme caution when drilling holes
into the wall or floor. There may be con-
cealedelectricalwireslocatedbehindthe
wall or under the floor.
• Identify the electrical circuits that could
beaffectedbythe installation of the Anti-
Tip Device, then turn off power to these
circuits.
• Failure to follow these instructions may
result in electrical shock or other per-
sonal injury.
WARNING
• ALL RANGES CAN
TIP
• INJURY TO PER-
SONS COULD RE-
SULT
• INSTALL ANTI-TIP
DEVICES
PACKED
WITH
RANGE
• SEE INSTALLATION
INSTRUCTIONS
Tools Needed for Installation of Anti-Tip Device:

11
Step 4: Installing Anti -Tip Device
30" and 36" Ranges (Figures 7A and 7B)
Thermador Service Part No. Qty Description
415078 4 Screw, Phillips, #10 x 1-1/2"
487310 1 Anti-Tip Bracket, Floor-Mounted
• The anti-tip bracket may be attached to a solid
woodcabinethavingaminimumwallthicknessof
3/4".
• Thethickness of the wall orfloor may require use
oflongerscrews,availableatyourlocalhardware
store.
• In all cases, at least two (2) of the bracket mount-
ing screws must be fastened to solid wood or
metal.
• Use appropriate anchors when fastening the
mountingbrackettoanymaterialotherthanhard-
wood or metal.
• Prepare holes at fastener locations as identified
below:
-For walls, wall studs, or floors composed of
solid wood or metal, drill 1/8" pilot holes.
-For walls or floors composed of drywall,
sheet-rockorothersoftmaterials,drill3/16"
holestoaminimumdepthof1-3/4",thentap
plastic anchors into each of the holes using
a hammer.
-For walls or floors composed of concrete or
concrete block, drill 3/16" holes to a mini-
mum depth of 1-3/4", then tap concrete
anchors into each of the holes using a
hammer.
-Forwallsorfloorshavingceramictilecover-
ing,drill3/16"holesthroughthetileonly,then
drill into the material behind the tile as indi-
cated immediately above.
• Iftherangeismovedtoanewlocation,theAnti-
Tip Device must be removed and reinstalled.
MOUNTING ANTI-TIP BRACKET
Thealternativefloormountedbracketshallbeinstalled
as follows:
a) Placebracketonfloor in positionshowninFigure
7B.
b) Secure to floor or wall stud.
c) Later,whentheunitisinstalled,theadjustableleg
will slide under the bracket.
FIG. 7B
2-1/2"
®
®
from edge of range
2-1/2"®
®
(typical -
either side)
FIG. 7A - Mounting Anti-tip Bracket
IMPORTANT INSTALLATION INFORMATION:

12
Step 5: Gas Requirements and Hookup
Verifythetypeofgasbeingusedattheinstallationsite.
Asshippedfromthefactory,unitsare configured
for use with only natural gas or propane (LP) gas.
Make certain the range matches the type of gas
available at this location. These ranges are NOT
convertible between different types of gas.
Forinstallationoftheapplianceathighaltitude,please
consult your local gas company for their recommen-
dation of the correct orifice sizes and any other
necessary adjustments that will provide proper gas
combustion at specified altitudes.
HOOK UP
• A manual gas shut-off valve must be installed
externaltotheappliance,inalocationaccessible
from the front, for the purpose of shutting off the
gassupply.Thesupplylinemustnotinterferewith
the back of the unit. Make sure the gas supply is
turned off at the manual shut-off valve before
connecting the appliance.
• Therangeissuppliedwithits own pressure regu-
lator that has been permanently mounted within
the range body.
• Use 3/4" flex line to connect between the gas
supplyandtheapplianceinletpipe,whichexitsthe
upper rear of the appliance. The appliance pipe
connection has a 3/4" NPT external thread and a
1/2" NPT internal thread. (See Photo A.) Use
caution to avoid crimping the 3/4" flex line when
making bends.
• The gas supply connections shall be made by a
competent technician and in accordance with
local codes or ordinances. In the absence of a
local code, the installation must conform to the
National Fuel Gas Code ANSI Z223.1/NFPA54-
current issue.
• Always use pipe sealing compound or Teflon®
tape on the pipe threads, and be careful not to
apply excessive pressure when tightening the
fittings.
• Leak testing of the appliance shall be in accor-
dance with the following instructions.
• Turn on gas and check supply line connections
for leaks using a soap and water solution.
• Bubbles forming indicate a gas leak. Repair all
leaks immediately after finding them.
• Do not use a flame of any kind to check for
gas leaks.
Natural Gas Requirements:
InletConnection: 3/4" NPT external
1/2" NPT internal
(Minimum 3/4" dia. flex line.)
Supply Pressure: 6"min.to14"max.watercolumn.
(14.9 to 34.9 mb)
Manifold Pressure: 5" water column (12.5 mb)
Propane Gas Requirements:
InletConnection: 3/4" NPT external
1/2" NPT internal
(Minimum 3/4" dia. flex line.)
Supply Pressure: 11"min.to14"max.watercolumn.
(27.4 mb to 34.9 mb)
Manifold Pressure: 10" water column (24.9 mb)
Use3/4"flexlinetoconnectbetweenthegassupply
and the appliance manifold pipe, which exits the
upper left rear of the appliance.
Photo A
Channel
for gas
line
®
WARNING
Gas line must not come in contact with any
components inside back cover of range. Run
gas line in channel in back of range.
CAUTION
When connecting unit to propane gas, make
certainthepropanegastankisequippedwithits
own high pressure regulator in addition to the
pressure regulator supplied with the appliance.
The pressure of the gas supplied to the appli-
ance regulator must not exceed 14"
(34.9 mb) water column.

13
Step 6: Electrical Requirements, Connection & Grounding
• Before installing, turn power OFF at the service
panel. Lock service panel to prevent power from
being turned ON accidentally.
CAUTION
Theappliancemustbeisolatedfrom the gassupplypipingsystembyclosingitsindividualmanual shut-
off valve during any pressure testing of the gas supply piping system at test pressures equal to or less
than 1/2 psig (3.5kPa.).
Theappliance and its individual shut off valve mustbe disconnected fromthe gas supply piping system
during any pressure testing of the system at test pressures in excess of 1/2 psig (3.5kPa.).
Whencheckingthemanifoldgaspressure,theinletpressuretotheregulatorshouldbeatleast6.0"(14.9
mb) W.C. for natural gas or 11.0" (27.4 mb) for propane.
Do not attempt any adjustment of the pressure regulator.
• A neutral supply wire must be provided from the
powersource(breaker/fusepanel)becausecriti-
cal range components, including the surface
burner spark re-ignition modules, require 120
VACtooperatesafelyandproperly.Animproper
120 VAC power supply will cause malfunction,
damage to this appliance, and possibly create a
condition of shock hazard. If the correct power
supplycircuitisnotprovided,itistheresponsibil-
ityandobligationoftheinstallerandusertohave
proper power supply connected. This must be
accomplished in accordance with all applicable
localcodesandordinancesbyaqualifiedelectri-
cian. In the absence of local codes and ordi-
nances, the power supply connection shall be in
accordance with the National Electrical Code.
• Observe all governing codes and ordinances
when grounding. In the absence of these codes
or ordinances observe National Electrical Code
ANSI/NFPA No. 70 current issue.
• Electric wiring diagrams and schematics have
been placed in the toe kick area of the range for
access by a qualified service technician.
IMPORTANT
For all gas ranges with electric griddle, dedicated 20 AMP service is required for proper operation.
Before you plug in an electrical cord, be sure all controls are in the OFF position.
Forappliancesequippedwith acordandplug,donotcutorremovethegroundprong.It mustbepluggedinto
a matching grounding type receptacle to avoid electrical shock. If there is any doubt as to whether the wall
receptacle is properly grounded, the customer should have it checked by a qualified electrician.
Installer - show the owner the location of the circuit breaker or fuse. Mark it for easy reference.
Chart B: Electrical Supply Circuit Requirements
MODELTYPE VOLTAGE CURRENTRATING FREQUENCY PHASE
30" 120VAC 15 Amps 60 Hz. Single
36" 120VAC 15 Amps 60 Hz. Single
36" with Grill 120VAC 15 Amps 60 Hz. Single
36" with Griddle 120VAC 20 Amps 60 Hz. Single
48" with Grill 120VAC 15 Amps 60 Hz. Single
48" with Griddle 120VAC 20 Amps 60 Hz. Single
48" with Grill 120VAC 20 Amps 60 Hz. Single
and Griddle

14
The backguard must be attached before sliding the
range into the final installed position. A Low Back or
PotandPanShelfmustbeinstalledwhenthereisless
than a 12" clearance between combustibles and the
back of the range above the cooking surface. (See
Fig. 2A and 2B on Page 5).
AnIslandTrimisavailableforcoveringthebackguard
mountingflangesforislandinstallations,wherethere
is a minimum of 12" of horizontal clearance between
combustiblesandtheback oftherange.(SeeFig.2B
on Page 5).
Thebackguardisinserted,asshowninFig.8,intothe
guide channels on the back of the range. Secure the
backguard with the (4) sheet metal screws provided.
Step 7: Backguard Installation
Chart C: Backguard Kit Model Numbers
Model Width 9" Std. Low Back 12" Low Back 22" Pot and Pan Shelf 3-3/4" Island Trim
30" Included N/A HS30R IT30R
36" N/A LB36R HS36R IT36R
48" N/A LB48R HS48R IT48R
®
Backguard
Installed
Front of Unit
FIG. 8

15
Step 8: Door Removal and Installation
To Remove the Oven Door:
• Open the door fully and use a screwdriver to pry the
hinge clips away from the hinge slots. (See Photo
B.)
• Flip the hinge clip toward you. (See Photo C.)
• Close the door until it stops against the hinge clips.
The open hinge clips will hold the door open at a
slight angle.
• Grasp the door firmly on the ends of the door
handle, and lift the door up. (There will be some
spring resistance to overcome.) When the door is
lifted sufficient to clear the hinge hooks, the door
can be pulled straight out. (See Photo D.)
• Place the door in a safe and stable location.
To Reinstall the Oven Door:
• Position the door at a slight angle and insert the
hinges into the hinge slots - one on each side of the
range. The hinges will securely hook into the slots
when properly installed. Do not force, bend, or twist
the door.
Tip: Rest the door on your foot while using your leg for
stability.
• Open the door fully and use a screwdriver to push
the hinge clips all the way into the hinge slots. Be
careful not to scratch the range during this process.
To Check Door Fit and Operation:
• Openandclosethedoorslowlytotestthemovement
andthefitofthedoortotheovencavity.Donotforce
the door to open or close. If the door is properly
installed, it should move smoothly and rest straight
on the front of the range when closed.
• If the door does not operate correctly, verify that the
hinges are properly seated into the hinge slots, and
that the hinge clips are fully engaged into the slots. Photo D. Hinges removed from oven.
CAUTION
USECAUTIONWHENREMOVINGTHE
DOOR.THEDOORISVERYHEAVY.
• Make sure oven is cool and power to oven has
been turned off. Failure to do so could result in
electrical shock or burns.
• The oven door is heavy and fragile. Use both
hands to remove or replace the door.
• Grasp only the ends of the oven door handle.
• Failure to grasp the oven door firmly and properly
could result in personal injury and product
damage.
• With the door off, never release the levers and
try to close the hinges. Without the weight of the
door, the powerful springs will snap the hinges
closed with great force.
Photo C. Flip hinge clips toward you.
Photo B. Pry hinge clips out using a screwdriver.

16
Step 9: Burner Test and Adjustment
WHEN FLAME IS PROPERLY ADJUSTED:
• There should be a flame at each burner port.
• Thereshouldbeno air gap betweentheflame
and burner port.
Install any loose components, such as burner caps
and grates that may have been removed earlier. Be
certainthatburnercapsseatproperlyintotheburner
bases. Before testing operation of the appliance,
verify that the unit and the gas supply have been
carefullycheckedforleaksandthattheunithasbeen
connected to the electrical power supply. Turn the
manual gas shut-off valve to the open position.
Test Rangetop Burners
Test Burner Ignition. Select a rangetop burner
knob. Push in and turn counterclockwise to HI. The
ignitor/spark module will produce a clicking sound.
Once the air has been purged from the supply lines,
the burner should light within four (4) seconds.
TestFlame:High Setting.TurnburnerontoHI.See
Figure 9 for appropriate flame characteristics.
Ifanyoftherangetopburnerscontinuetoburnmostly
or completely yellow, verify that the burner cap is
positionedproperlyontheburnerbase,thenre-test.If
flame characteristics do not improve, call
Thermador®.
Test Flame: Low Setting. Turn burner on to LO.
Verifythattheflamecompletelysurroundstheburner.
Thereshouldbeaflameateachburnerportandthere
should be no air gap between the flame and the
burner. If any burners do not carry over, call
Thermador®.
The two far left burners feature XLO®, causing the
flame to cycle on and off when the knob is set to the
XLO range. This is normal operation.
Repeat the Ignition and Flame Test procedures de-
scribed above for each rangetop burner and the grill
burner (if so equipped).
The gas grill uses a tube-style burner that has an air
shutter which allows adjustment to the amount of
primary air inside the burner tube.
Air shutters of tube-style burners are pre-adjusted at
the factory, and usually do not require re-adjustment
except under rare conditions such as installation at
highaltitude.
If grill burner/flame adjustment is required, go to the
procedure: "Flame Adjustment (if necessary)".
Flame Characteristics
Yellow Flames:
Further adjustment is required.
Yellow Tips on Outer Cones:
Normal for LP Gas.
Soft Blue Flames:
Normal for Natural Gas.
Iftheflameiscompletelyormostlyyellow,verifythatthe
regulator is set for the correct fuel. After adjustment,
retest.
Some orange-colored streaking is normal during the
initialstart-up.
Allowunittooperate4-5minutesandre-evaluatebefore
makingadjustments.
FIG.9

Test Oven Burners
Removetheovenbottomcover.Removethe4screws
thatattachthecovertothebottomoftheoven,thenlift
thecoverandangledbaffleplateout toexposetheU-
shaped bake burner.
Test Bake Burner Ignition
SettheoventoBAKEat350°F.Afterashortdelay,the
burnerwillignite.Theburnerwillstaylituntil350°Fis
reachedandthenshutoff.Fromthispointforward,the
burner will cycle on and off to maintain the tempera-
ture.
Test Bake Burner Flame
While the bake burner is lit, inspect the flame. See
Figure 9 for proper flame characteristics. If the flame
burns completely or mostly yellow, it is necessary to
adjustthebakeburnerairshutter.SeeFigure10and
the Flame Adjustment procedure in the following
section.
Test Broil Ignition
Set cooking mode to BROIL. The broil burners will
ignite after 30-75 seconds.
NOTE: Thetwoinfraredceramicbroilburnersdonot
have air shutters, so no adjustment is provided.
Replace oven bottom cover. Slide cover into place
and reattach to bottom of oven cavity.
Flame Adjustment (if necessary):
Tube-style gas burners used in Thermador© appli-
ances have air shutter systems which are similar to
theillustrationinFigure10,andcanbeadjustedusing
the following method (unless adjustment is not rec-
ommended). It is necessary to remove the burner
from the appliance in order to perform air-shutter
adjustments.
• Loosen shutter screw(s) and turn shutter to new
position.
• Adjust the shutter to more-closed position if the
flame is lifting or blowing, or is not carrying over.
Adjust the shutter to more-open position if the
flame is too yellow. (See Figure 10.)
• Re-tighten the shutter screw(s).
• Afteradjustment,re-installtheburnerandperform
flame evaluation. The air shutter must fit over the
orifice hood for proper operation of the burner.
• Repeat procedure as needed until flame char-
acteristics are acceptable. (See Figure 9.)
Step 9: Burner Test and Adjustment
17
Air
Shutter
Screw
More Open:
Less Yellow Flame
More Closed:
Less Blue Flame
More Carryover
Less Lifting or Blowing
Air Shutter Adjustment (if necessary)
FIG.10
WARNING
Burner adjustments must be performed by a
qualifiedtechnician.Improperadjustmentsmay
cause harmful by-products or void the
appliance's warranty.
Allow burners to cool before attempting to
remove them! Call Thermador® if:
1. Any of the burners do not light.
2. The broil burner or bake burner flame goes
out before the oven heats to the desired
temperature.
3. Anyoftheburnerscontinuetoburnyellow.
