Thermador Professional Series User manual

Installation
GUIDE
Professional® Series Chimney Wall Hoods HPCN36WS HPCN48WS
THERMADOR.COM

en-us
2
Table of contents
1 IMPORTANT SAFETY INSTRUCTIONS.................... 3
1.1 Safety definitions....................................................... 3
1.2 General information................................................... 3
1.3 General safety instructions........................................ 3
1.4 Safety codes and standards...................................... 4
1.5 State of California Proposition 65 Warnings .............. 5
2 Before you begin....................................................... 6
2.1 Important notes......................................................... 6
2.2 Distance from cooking surface .................................. 6
2.3 Parts included ........................................................... 6
2.4 Tools and parts needed ............................................ 6
3 Installation requirements and clearances............... 7
3.1 Appliance dimensions ............................................... 7
3.2 Clearances................................................................ 8
3.3 Hood width................................................................ 8
3.4 Distance from cooking surface .................................. 8
3.5 Unit weight ................................................................ 8
3.6 Support structure ...................................................... 8
3.7 Venting...................................................................... 8
3.8 Electrical requirements.............................................. 8
4 Preparing the installation....................................... 10
4.1 Ductwork preparation.............................................. 10
4.2 Choosing the correct blower.................................... 12
4.3 Hood transition........................................................ 13
5 Installation............................................................... 13
5.1 Installation height.................................................... 13
5.2 Wiring preparation................................................... 14
5.3 Back wall preparation.............................................. 15
5.4 Hanging the chimney wall hood .............................. 15
5.5 Blower motor installation......................................... 16
5.6 Make-up air damper relay switch (optional)............. 19
5.7 Built-in remote control accessory (optional)............. 19
5.8 Duct cover extension (optional)............................... 20
5.9 Installing the grease trays and filters ....................... 22
6 Installer checklist.................................................... 23
7 Customer Service ................................................... 23
7.1 Model number (E-Nr.) and production number
(FD) ........................................................................ 24
7.2 Rating plate location................................................ 24
7.3 Product registration................................................. 24

en-us
3
Read all instructions carefully before use. These
precautions will reduce the risk of electrical shock, fire and
injury to persons. When using kitchen appliances, basic
safety precautions must be followed including those in the
following pages.
1.1 Safety definitions
Here you can find explanations of the safety signal words
used in this manual.
WARNING
This indicates that death or serious injuries may occur as
a result of non-observance of this warning.
CAUTION
This indicates that minor or moderate injuries may occur
as a result of non-observance of this warning.
NOTICE:
This indicates that damage to the appliance or property
may occur as a result of non-compliance with this
advisory.
Note:This alerts you to important information and/or tips.
1.2 General information
All product manuals may be downloaded online at
www.thermador.com/us/support/owner-manuals.
INSTALLER: Please leave these instructions with this unit
for the owner.
OWNER: Please retain these instructions for future
reference. Read all safety instructions before operating
the appliance. Have the installer show you where the
electric circuit breaker is located so you know how and
where to turn off the electricity to the appliance.
1.3 General safety instructions
WARNING
Turn off power circuit at service panel and lock out panel
before wiring this appliance. Requirement: 120VAC,
60Hz, 15A or 20A for some models. Allow the appliance
to cool after the power has been turned off before
servicing the appliance.
WARNING
Automatically operated device
▶To reduce the risk of injury disconnect from power
supply before servicing.
WARNING
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK,
OR INJURY TO PERSONS, OBSERVE THE
FOLLOWING:
▶Use this unit only in the manner intended by the
manufacturer. If you have questions, contact the
manufacturer.
→ "Customer Service", Page23
▶Before servicing or cleaning the unit, switch power off
at service panel and lock service panel. This will
prevent power from being switched on accidentally.
IMPORTANT SAFETY INSTRUCTIONS
READ AND SAVE THESE INSTRUCTIONS

en-us
4
When the service panel cannot be locked, securely
fasten a prominent warning device, such as a tag to the
service panel.
Do not repair, replace or remove any part of the appliance
unless specifically recommended in the manuals.
Improper installation, service or maintenance can cause
injury or property damage.
▶Refer to this manual for guidance.
▶All other servicing should be done by an authorized
service provider.
WARNING
ELECTRIC SHOCK HAZARD
▶Disconnect power before installing or servicing. Before
turning power ON, be sure that all controls are in the
OFF position.
▶DO NOT remove connections.
▶DO NOT use an extension cord.
▶Improper grounding can result in a risk of electric
shock.
▶Failure to follow these instructions can result in death,
fire, or electrical shock.
GROUNDING INSTRUCTIONS
▶This appliance must be grounded.
▶Grounding reduces the risk of electric shock by
providing a safe pathway for electric current in the
event of a short circuit.
▶Be sure your appliance is properly installed and
grounded by a qualified technician.
▶Installation, electrical connections and grounding must
comply with all applicable codes.
¡If required by the National Electrical Code (or Canadian
Electrical Code), this appliance must be installed on a
separate branch circuit.
WARNING
To reduce the risk of fire or electric shock, do not use this
appliance with any solid-state speed control device.
WARNING
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK,
OR INJURY TO PERSONS, OBSERVE THE
FOLLOWING.
▶Installation work and electrical wiring must be done by
qualified person(s) in accordance with all applicable
codes and standards, including fire-rated construction.
▶Sufficient air is needed for proper combustion and
exhausting of gases through the flue (chimney) of fuel
burning equipment to prevent back drafting. Follow the
heating equipment manufacturer’s guideline and safety
standards such as those published by the National Fire
Protection Association (NFPA), and the American
Society for Heating, Refrigeration and Air Conditioning
Engineers (ASHRAE), and the local code authorities.
▶When cutting or drilling into wall or ceiling, do not
damage electrical wiring and other hidden utilities.
▶Ducted fans must always be vented to the outdoors.
▶USE ONLY METAL DUCTWORK.
▶DO NOT vent exhaust air in spaces with walls or
ceilings or into attics, crawl spaces or garages.
CAUTION
For general ventilating use only.
▶Do not use to exhaust hazardous or explosive materials
and vapors.
WARNING
Never modify or alter the construction of the appliance.
WARNING
Remove all tape and packaging before using the
appliance.
▶Dispose of packaging in an environmentally responsible
manner.
▶Never allow children to play with packaging material.
WARNING
Unit is heavy and requires at least two people or
proper equipment to move and install.
WARNING
Hidden surfaces may have sharp edges.
▶Use caution when reaching behind or under appliance.
CAUTION
An outside fan is to be mounted behind louvers or in a
location where the entrance of drawn in water is unlikely.
1.4 Safety codes and standards
This appliance complies with the latest version of one or
more of the following standards:
¡UL 507 - Electric Fans
¡CAN/CSA C22.2 No. 113 - Fans and Ventilators
IMPORTANT SAFETY INSTRUCTIONS
READ AND SAVE THESE INSTRUCTIONS

en-us
5
It is the responsibility of the owner and the installer to
determine if additional requirements and/or standards
apply to specific installations.
1.5 State of California Proposition 65
Warnings
This product may contain a chemical known to the State
of California, which can cause cancer or reproductive
harm. Therefore, the packaging of your product may bear
the following label as required by California:
IMPORTANT SAFETY INSTRUCTIONS
READ AND SAVE THESE INSTRUCTIONS

en-us Before you begin
6
Before you begin
2 Before you begin
Before you begin
Read these instructions before you begin to install your
appliance.
2.1 Important notes
WARNING
Improper installation of gas appliances and ventilation
hoods can create a risk for carbon monoxide which can be
harmful. To reduce the risk of carbon monoxide poisoning,
ensure the gas appliance is properly installed according to
the manufacturer’s instructions, as well as ensuring the
hood is vented to the outside for proper exhausting of
gases or fumes.
¡Gas cooking appliances release carbon monoxide that
can be harmful or fatal if inhaled. To reduce the risk of
fire and to properly exhaust air, the exhaust gases
extracted by the hood should be vented outside of the
building only.
¡Consult local building codes for requirements or
restrictions related to installation of ventilation products
in recirculation mode.
¡Hood installation height above a cooktop, rangetop or
range can vary. To obtain the necessary installation
height above a cooktop, rangetop or range, consult the
appliance's installation manual or combination matrix.
NOTICE:
The hood can be damaged from excessive heat if a range
or rangetop is operated with multiple burners at high
settings under a hood that is installed at minimum
clearances and is turned off.
2.2 Distance from cooking surface
The installation height above a cooktop, rangetop or range
is recommended as a minimum height of 30" (762mm);
however, it is necessary to follow the cooking appliance
manufacturer's installation instructions for proper hood
height.
Refer to local building codes for the latest requirements or
restrictions when installing ventilation products in
recirculation mode.
2.3 Parts included
After unpacking all the parts, check for any damage in
transit and for completeness of delivery.
¡Metal transition with backdraft damper
¡Baffle filters
¡Grease trays
¡Blower adapter
¡Wood support bracket used as hood mounting bracket
(needed for installation - DO NOT THROW AWAY)
¡Literature packet with fastener assortment
Hardware provided is for mounting through standard
thickness drywall or plaster into wood studs. Installers
are responsible to provide hardware for other types of
mounting situations.
2.4 Tools and parts needed
Prepare these tools and accessories before you start to
install your appliance.
¡Blower (Refer to the Ventilation Planning Guide for
compatible blowers)
¡Ducting as needed (Refer to table Equivalent duct
lengths for commonly used transitions. → Page11 )
¡Aluminum tape (DO NOT use insulating or cloth duct
tape)
¡½" (13mm) conduit if required
Follow local codes
¡1" (25.4mm) strain relief
¡Cross head screwdriver
¡T20 star bit screwdriver
¡¹¹⁄₃₂" nut driver or socket and ratchet
¡Drill with ³⁄₁₆" (4.76mm) drill bit
¡Wire stripper
¡Measuring tape
¡Pencil
¡Level
¡Safety gloves
IMPORTANT: DO NOT throw away any packaging until
appliance is fully installed.
Optional accessories available for separate
purchase
Refer to www.thermador.com for details.
Accessory Description
EXTNCB25W 25ft. remote and in-line blower
extension cable
EXTNSET4 25ft. remote and in-line blower
extension cable adapter kit
CHMHP**W 6" tall duct cover
CHMHP**TW 18-35" tall telescoping duct cover
CHMHP**XTW 42-59" extended telescoping duct cover
RFPLT600P Roof plate for use with
¡600CFM remote blower VTR630
RFPLT1000P Roof plate for use with
¡1000CFM remote blower VTR1030
¡1300CFM blower VTR1330
REMCPW Remote control panel

Installation requirements and clearances en-us
7
Installation requirements and clearances
3 Installation requirements and clearances
Installation requirements and clearances
3.1 Appliance dimensions
This model series is 24" (610mm) in depth and features brushed stainless-steel canopy with LED lights.
36" (914mm) 48" (1,219mm)
A 21" (533 mm) 33" (838 mm)
B 35¹⁵⁄₁₆" (913 mm) 47¹⁵⁄₁₆" (1,218 mm)
C 10½" (165 mm) 16½" (419 mm)
Note:The transition is centered horizontally.
IMPORTANT: The hood needs to be centered over the
cooking surface for best performance.

en-us Installation requirements and clearances
8
3.2 Clearances
Hood installation height above a cooktop, rangetop or
range can vary. To obtain the necessary installation height
above a cooktop, rangetop or range, consult the
appliance's installation manual.
X Electrical zone
*Follow cooking appliance manufacturer's
recommendations.
3.3 Hood width
¡The hood width should be no less than the width of the
cooking surface. For proper performance, the housing
must cover the entire cooking surface.
¡For proper performance, the hood must be centered
horizontally above the cooking surface. Where space is
not restricted, a wider hood can be used to increase
capture area.
3.4 Distance from cooking surface
¡Hood installation height above a cooktop, rangetop or
range can vary.
¡The installation height ranges from a minimum height of
30'' (762 mm) to a suggested maximum height of 40''
(1,016 mm). However, it is necessary to follow the
cooking appliance manufacturer’s installation
instructions for proper hood height.
NOTICE:
The hood could incur some damage from heat if a
Thermador Professional® Series range or rangetop is
operated with multiple burners at high settings under a
hood that is installed at minimum clearances while the
hood is turned off.
3.5 Unit weight
¡This vent hood is heavy. Adequate structure and
support must be provided in all types of installations.
¡When calculating the load for the housing support
system, be sure to consider the weight of the ventilation
unit.
Description Weight
HPCN36WS 57 lbs (26 kg)
HPCN48WS 73 lbs (33 kg)
Integral blower model VTN2FZ 19 lbs (8.6 kg)
NOTICE:
The supplied weights address only the ventilation unit and
blower. The installer must account for weight of any
materials of construction when calculating the total dead
weight load of installation, including but not limited to: wall,
tile, mortar, plaster, brick, finishes, partitions, and other
similarly incorporated architectural and structural items. It
is the responsibility of the owner and the installer to
determine if additional requirements and/or standards
apply to specific installations.
3.6 Support structure
¡Due to the weight of the hood, make sure the wood
mounting bracket is attached to all available wall studs.
¡Framing must be fastened together and to ceiling joists
to provide enough structural strength to support the
weight of the hood and internal blower, if applicable.
¡Wall framing should be made of 2"x 4" lumber at
minimum. Proper structural support is required to
accommodate the weight of the hood.
3.7 Venting
¡The hood requires the ducting to be vented to the
exterior of the building.
3.8 Electrical requirements
WARNING
This appliance must be properly grounded.
¡The appliance requires a 120VAC, 60Hz. 15A branch
circuit.

Installation requirements and clearances en-us
9
¡The VTN2FZ blower in conjunction with a PHxxGWS
requires a 20A circuit breaker.
¡The appliance should only be connected to a dedicated
circuit (with ground) that has been installed according to
relevant regulations.
¡When connected to a GFCI-protected supply,
Thermador Professional® Series hoods are suitable for
use in damp locations that are protected from outside
weather conditions and not subject to saturation with
water and other liquids, but can be subject to moderate
degrees of moisture, such as an outdoor covered patio
or lanai area. Refer to local codes, NEC/CEC, and/or
the Authority Having Jurisdiction (AHJ) for additional
information.
¡Check your local building codes for proper method of
installation. This appliance should be installed in
accordance with applicable local codes or, in the
absence of local codes, with the National Electrical
Code, NFPA 70 or the Canadian Electric Code, CSA
C22.1-02.
¡The 25ft. remote and in-line blower extension cable
accessory (EXTNCB25W) will only work for distances
up to 25ft. The accessory cable must be purchased
separately. DO NOT use more than one blower
extension cable per installation.
¡Electrical data:
Refer to the rating plate for product data, including the
model and serial number.
→ "Rating plate location", Page24

en-us Preparing the installation
10
Preparing the installation
4 Preparing the installation
Preparing the installation
4.1 Ductwork preparation
¡The exhaust air is discharged upwards through a duct
or directly through the outside wall into the open.
¡The appliance can be mounted on the wall only with a
vertical discharge.
¡Proper performance is dependent upon proper ducting.
Local building codes may require the use of make-up air
systems when using ducted ventilation systems greater
than specified cubic feet per minute (CFM) of air.
¡The specified CFM varies from locale to locale. It is the
responsibility of the owner and the installer to determine
if additional requirements and/or standards apply to
specific installations.
¡DO NOT USE FLEXIBLE DUCT; it creates back
pressure/air turbulence and reduces performance.
¡Always install a metal vent cover where the ductwork
exits the house.
¡The appliance must be vented to the outside of the
building only.
¡COLD WEATHER installations should have an
additional backdraft damper installed to minimize
backward cold air flow and a nonmetallic thermal break
to minimize conduction of outside temperatures as part
of the ductwork. The damper should be on the cold air
side of the thermal break. The break should be as close
as possible to where the ducting enters the heated
portion of the house.
¡MAKE-UP AIR: Local building codes may require the
use of make-up air systems when using ducted
ventilation systems greater than specified CFM of air
movement. The specified CFM varies from locale to
locale. It is the responsibility of the owner and the
installer to determine if additional requirements and/ or
standards apply to specific installations.
¡To reduce risk of fire and to properly exhaust air, be
sure to duct air outside. Do not vent exhaust air in
spaces with walls or ceilings or into attics, crawl spaces
or garages.
¡Thermador recommends not exceeding 50ft (15.24m)
equivalent of duct.
¡Keep duct runs as short and straight as possible.
Elbows and transitions fittings reduce air flow efficiency.
Back to back elbows and “S” turns give very poor
delivery and are not recommended.
¡A short, straight length of duct at the inlet of a remote
blower gives the best delivery.
¡Hoods are supplied with a 10" (254mm) transition. A
locally supplied transition is required for other sizes.
¡Use the “Equivalent duct lengths for commonly used
transitions” table to compute permissible lengths for
duct runs to outdoors. → Page11

Preparing the installation en-us
11
Equivalent duct lengths for commonly used transitions
Note:These commonly used installation parts can be
purchased at a local hardware store. Thermador does not
manufacture all these parts.

en-us Preparing the installation
12
Common ducting configurations
1
2
3
3
4
5
1
Varies
2
Integral blower
3
Remote blower
4
Inline blower
5
Back-draft damper on transition
Note:The figure does not represent all configurations or
installation methods. The image is to be used as a guide
ONLY.
4.2 Choosing the correct blower
All blower models are sold separately.
It is recommended to use only Thermador blowers with
Thermador Pro ventilation hoods. See the “Ventilation
Planning Guide” for recommended blowers. Contact
Customer Service for additional options.
→ "Customer Service", Page23
You can purchase integral, in-line and remote blowers
through your authorized Thermador dealer. For local
dealer information, visit the "Find a Dealer" section at
www.thermador.com.
The blower performance options vary in cubic feet per
minute (CFM). The required performance is dictated by
the cooking surface, the volume of air that needs to be
moved and the length of the duct run. For long duct runs
with multiple turns and bends, consider using a more
powerful blower. For the most efficient air-flow exhaust,
use a straight run or as few elbows as possible.
→ "Ductwork preparation", Page10
Blower options
Description SKU
Remote blower
Mounted to roof or external wall
VTR2FZ
In-line blower
Mounted between kitchen and
external wall
VTI2FZ
Integrated blower
Mounted inside the hood
VTN2FZ
25ft. remote and in-line blower extension cable
The accessory cable must be purchased separately. DO
NOT use more than one extension cable per installation.

Installation en-us
13
Description SKU
25ft. remote and in-line blower
extension cable
Available to connect the hood to the
inline and remote blowers for distances
up to 25 ft.
EXTNCB25W
4.3 Hood transition
Discharge direction
The exhaust air is discharged upwards through a duct or
directly through the outside wall into the open.
The hood can be mounted on the wall only with a vertical
discharge.
Attaching the hood transition
Your hood is supplied with a 10" (254mm) round
transition. A locally supplied transition is required for other
sizes.
1. A minimum height clearance of 6½" (165mm) is
needed above the hood for transition mounting.
2. Align the mounting holes at the base of the transition
over the mounting holes of the ½" (13mm) flange
located at the top of the hood.
3. Fasten the transition to the hood using four (4) ¼"
(6mm) sheet metal screws included with the hood.
Note:Make sure the screws do not hinder the damper
operation.
4. Seal the connection between transition and hood with
aluminum tape. DO NOT use duct tape. Ensure that the
connection is completely sealed.
5. Remove the tape that is holding the damper closed.
Installation
5 Installation
Installation
WARNING
Before installing, turn power OFF at the service panel.
▶Lock service panel to prevent power from being turned
ON accidentally.
5.1 Installation height
Installation height above cooking surface:
¡Minimum height: 30" (762 mm)
¡Suggested maximum height: 40" (1,016 mm)
NOTICE:
Always follow the cooking appliance manufacturer’s
installation instructions for proper installation height.
Calculating the optional chimney extension height
Optional chimney extensions are available for purchase in
6" (153mm) and 18" – 35" (457 – 889mm) sizes to cover
the space between the top of the hood and the ceiling.
Take the measurements indicated in the following image
at your installation location.
NOTICE:
The hood could incur some damage from heat if a
Thermador Professional® series range or rangetop is
operated with multiple burners at high settings under a
hood that is installed at minimum clearances while the
hood is turned off.
1. Measure the height from floor to ceiling (A).
2. Measure the height from floor to cooking surface (B).
3. Measure the hood mounting height from the bottom of
the hood to the cooking surface (C). Dimension must be
a minimum 30" (762mm).
4. Calculate the optional duct cover height (D):
‒D = A – (B + C + 18").

en-us Installation
14
*Follow cooking appliance manufacturer's
recommendations.
5.2 Wiring preparation
IMPORTANT: Cutting off a connector to the appliance,
blower, or to the extension cable kit will void the warranty.
Ensure wiring does not interfere with optional chimney
duct cover, where the cover touches the wall.
Ceiling cutout
¡The junction box is located on the top right side of the
hood.
¡Wiring should enter at least 20" (508mm) above the
bottom of the installation height.
¡Prepare the wire hole cutout in the ceiling with a ⅝"
(16mm) diameter clearance hole for a ½" (12.7mm)
conduit to the junction box.
Chimney hood top view
HPCN36WS HPCN48WS
A 35¹⁵⁄₁₆" (913) 47¹⁵⁄₁₆" (1,218)
B 7½" (190) 7½" (190)
C 21" (533) 33" (838)

Installation en-us
15
HPCN36WS HPCN48WS
D 7½" (190) 7½" (190)
E 9⅝" (244) 10⁹⁄₁₆" (268)
F 18" (457) 24" (610)
5.3 Back wall preparation
IMPORTANT: The hood needs to be centered over the
cooking surface for best performance.
Note:The hardware provided is for mounting through
standard thickness drywall or plaster into wood studs.
Installers are responsible to provide hardware for other
types of mounting situations.
Hanging the wood support bracket
1. Turn power OFF at the service panel. Lock service
panel to prevent power from being turned ON.
2. Calculate the hood installation height as described.
→ Page13
3. Draw a horizontal line at a distance above the cooking
surface equal to the hood installation height plus 16"
(406mm). This line is the mounting location of the wood
bracket shipped with the hood.
A Distance to cooking surface plus 16" (406mm)
B 3" (76mm) screws
C Wood bracket (included)
D Cooktop centerline
E Cooking surface
4. Find the centerline of the hood. Draw a vertical line
along this centerline up to the horizontal line drawn in
the previous step.
5. The hood is mounted to the wall using the wood bracket
shipped with the hood. Remove the wood bracket
located at the back side of the hood by removing the
two shipping screws. Discard the shipping screws.
6. Mark the centerline of the wood bracket.
7. Locate a stud on both sides of the hood centerline to
use for mounting the wood bracket.
8. Align the top of the wood bracket along the horizontal
line drawn earlier. Align the centerlines of the bracket
and cooktop.
9. Drill a 3" (76mm) deep ¼" (6mm) tap hole through the
wood bracket, wall, and into the stud.
10. Remove the bracket and place it on a sturdy surface.
Make the hole larger by drilling a ⁵⁄₁₆" (8mm) hole
through the wood bracket. Use a countersink bit to
make a hole large enough to countersink the screw
heads to prevent interference with the hood.
11. Use two (2), 3" (76mm) screws to attach the wood
bracket to the wall.
12. On the wood bracket, mark the locations used to hang
the hood as shown.
Hood size A
36" (914mm) 7¾" (197mm)
48" (1,219mm) 13¾" (350mm)
13. Drill a ³⁄₁₆" (4.8mm) tap hole through the wood bracket
and wall. These ⅝" (16mm) screws do not need to go
into the studs.
14. Use two (2) 1½" (38mm) screws to secure the wood
bracket leaving ¼" (6mm) of each screw exposed for
hanging the hood.
5.4 Hanging the chimney wall hood
Requirements
¡The transition supplied with the hood connects to
standard 10" round duct. Ensure the transition is
attached and the screws do not hinder damper
operation.
→ "Attaching the hood transition", Page13
¡Installations require a cutout in the ceiling to
accommodate the 10" (254mm) duct.
→ "Ceiling cutout", Page14

en-us Installation
16
1. Installations require a cutout for the ½" (13mm)
electrical conduit.
→ "Ceiling cutout", Page14
X Optional chimney extension
Note:Follow cooking appliance manufacturer’s
recommendations.
2. Use a T-20 star head screwdriver to remove the screw
securing the junction box channel covering the wires.
3. Remove one circular knockout behind the junction box
channel. Secure a 1" (25.4mm) strain relief (not
included).
4. Using two people to lift, rest the hood on the wood
bracket. Make sure the wood bracket fits into the recess
on the back of the hood.
5. From inside the hood, pre-drill the holes labeled “J” in
the hood into the wood bracket with a ⅝" (16mm) drill
bit. Secure the hood to the wood bracket with five (5)
1½'' (38 mm) screws.
6. Connect additional ducting.
5.5 Blower motor installation
CAUTION
To reduce the risk of fire and electric shock, install this
range hood only with the blowers listed in the Ventilation
Planning Guide.
Note:Cutting the plug of the blower will void the warranty
or eligibility for return or exchange.
Installing the integral blower
Integral blower models are integrated into the hood at the
time of installation. Integral blowers should be installed
after the hood is mounted to the wall. For complete
installation instructions, see the instructions supplied with
the blower unit.

Installation en-us
17
Note:Blower and hood image views vary depending on
model.
1. Thread one (1) 4m flange nut (included with the hood)
half-way down each of the two weld studs indicated.
2. Slide the blower mounting plate behind the nuts on the
weld studs.
3. Install two (2) 4m flange nuts (included with hood) to the
top weld studs and tighten.
4. Tighten the two (2) nuts from step 1 to fully secure the
blower to the hood.
5. Connect the blower’s plug connector to the connector
present inside the hood. Route the blower harness
through the self-locking clip.
Installing a remote blower or an in-line blower
Depending on preference and ducting situation these
blowers can be installed outside the kitchen. This reduces
the noise in the kitchen. For complete installation
instructions see the instructions supplied with the blower
unit.
1. Remote blower
Remote blowers can be mounted on the roof or exterior
wall of the home

en-us Installation
18
2. In-line blower
In-line blowers can be mounted along the duct line
anywhere between the kitchen and the exterior wall, if
there is easy access to duct line, e.g. in an attic.
3. Remote and in-line blower motor wire connection:
‒Remove junction box channel covering the wires.
‒Remove one circular knockout.
‒Route the blower motor’s plug connector to the hood.
Connect the blower’s harness to the hood harness.
‒Route the blower harness through the self-locking
clip.
Connecting the electrical wires
Notes
¡BSH is not responsible for wiring errors during
installation. Installation wiring errors are not covered by
the Statement of Limited Product Warranty.
¡Refer to the wire diagram included with the appliance.
1. Run a 120V AC, 15A circuit power cable from the
service panel through the strain relief.
→ "Hanging the chimney wall hood", Page15
2. Connect black wire to power supply black wire, white
wire to power supply white wire and green wire to green
wire or bare wire.
A White to white
B Black to black
C Green to green or bare wire
3. Place all wiring connections inside the junction box
channel. Reinstall on the top plate. Ensure that the
wires are secure and that no wires are pinched.
Connecting the extension cable (optional)
EXTNCB25W 25ft. remote and in-line blower extension
cable.
1. Parts included:
– 25ft. cable (1)
– Adapter cables (2) - not needed for all models
2. Route the hood’s internal blower harness through the
strain relief.

Installation en-us
19
3. Connect the 25 ft. extension cable to the blower
harness outside the hood.
A Connects to the hood
B Connects to a remote or in-line blower
Note:Cutting of the connector will void the warranty of
the appliance.
The blower extension cable is compatible with the
following in-line and remote blowers:
Blower Model
Remote blower VTR2FZ
In-line blower VTI2FZ
5.6 Make-up air damper relay switch
(optional)
Local codes may require the use of an additional backdraft
and/or make-up air damper. Contact your local HVAC
professional for specific requirements.
This hood provides a relay switch to connect a make-up
air damper (120V max). Installations will vary according to
the location in the home where the appliance is installed
and the damper used. Use the following illustration as
guidance for your installation. Always comply with local
code requirements.
Connecting the make-up air damper relay switch
1. Access the hood's wiring.
2. Route the make-up air damper harness through the
strain relief to the terminal block.
‒The make-up air kit hot and return connections can
use either terminal connection. There is no polarity
requirement for the two pin terminal block.
3. Secure the ground wire with the green T-20 ground
screw.
5.7 Built-in remote control accessory
(optional)
Before you begin, read these instructions carefully. It is
recommended that the remote control be wired to the
hood after the hood is installed.
IMPORTANT: Cutting off a connector to the appliance or
to the extension cable kit will void the warranty.
REMCPW parts included:
¡Remote control (1)
¡30ft. extension harness (1)
Installing the remote control
1. Prepare the cutout in the wall or similar surface for
installation as shown below (view is shown facing wall).

en-us Installation
20
2. Access the hood’s wiring. Route the 30ft. extension
harness through the strain relief to the square mounting
clip until it clicks.
3. Route the 30ft. extension harness through the cutout
and connect the harness to the back of the remote
control bracket.
4. Press the bracket inside the cutout. Drill a ¼" (6mm)
tap hole through the bracket holes into the wall. Mount
the bracket to the wall using the four (4) screws
provided.
5. Hook up the wire harness connector inside the bracket
to the terminal on the back side of the remote control.
Use either terminal.
6. Snap the remote control into the bracket.
5.8 Duct cover extension (optional)
Optional duct cover extensions and telescoping extensions are used to fill the space between hood and ceiling. The
extensions are available for separate purchase.
¡Use chimney extensions for 8' (2.4 m) ceilings ¡Use telescoping extensions for 10' (3 m) ceilings.
Hood model 6" extension Telescopic extension
HPCN36WS CHMHP366W CHMHP48TW (18"– 35")
CHMHP48XTW (42"–59")
HPCN48WS CHMHP486W CHMHP48TW (18"– 35")
CHMHP48XTW (42"–59")
Installing the duct cover extension
Requirement:IMPORTANT: Secure the chimney wall
hood to the wall before installing the chimney extension.
→ Page15
1. Installation of the chimney hood should maintain a
minimum height of 30" (762mm) from the bottom of the
hood to the cooking surface. To determine placement of
the hood with a chimney extension, the height of the
