This THERMADOR®appliance is made by
BSH Home Appliances Corporation
1901 Main Street, Suite 600
Irvine, CA 92614
Questions?
1-800-735-4328
www.thermador.com
We look forward to hearing from you!
Table of
CONTENTS
Safety .....................................................................................2
Important safety instructions ..........................................2
Advance planning ..................................................................4
Before you begin ............................................................ 4
General information ........................................................ 5
Installation instructions ...........................................................6
Installation considerations ............................................... 6
Electrical requirements ...................................................7
Ductwork preparation ....................................................7
Common ducting configurations.....................................8
Choosing the correct blower ..........................................10
Hood transition................................................................10
Preparing the ceiling cutout and housing .......................10
Custom insert installation with hood trims......................11
Blower motor installation ...............................................12
Electrical wire connection................................................14
Make-up air damper relay switch (optional).................... 14
Remote control installation (optional) ............................ 15
Installing filters and grease trays..................................... 16
Installer checklist and service ................................................. 17
Installer checklist ............................................................. 17
Before calling service ...................................................... 17
Product data rating plate ...............................................17
Service, parts, and accessories ..................................back page
Safety
DEFINITIONS
9 WARNING
This indicates that death or serious injuries may occur as a
result of non-observance of this warning.
9 CAUTION
This indicates that minor or moderate injuries may occur as a
result of non-observance of this warning.
NOTICE: This indicates that damage to the appliance or
property may occur as a result of non-compliance with this
advisory.
Note: This alerts you to important information and/or tips.
