thermastor Santa-Fe Crawlspace Alert User manual

Crawlspace Alert™Installation
For small usage:
4201 Lien Rd., Madison, WI 53704 •TOLL-FREE 1-800-533-7533 •www.thermastor.com •[e-mail]
TS-647 07/11
Unit Functionality
• Theamberwarninglampilluminatesiftherelativehumidityinthecrawlspaceexceedsthepresetlimit
(70%RH).
• Iflampisilluminatedthehomeownershouldcalltheircontractor,asthiscouldsignalaserious
moistureissueinthecrawlspace.
• Theoptional“OverowShutoff”(step#2)willshut-offthedehumidierifthecondensatepump
reservoiroverows.
1. Mount the Crawlspace Alert
• Atleast24"abovegroundlevel,makingsurenottomountonanexteriorwall(relativehumiditycan
beaffectedbythewallstemperature).
• LocatetheCrawlspaceAlertwithintwoft.(lengthofpowercord)ofadedicated15ampGFCI
poweroutletandwithin8ftofyourdehumidier.
2. Overow Shutoff feature (optional)
Not using this? Then go to step #3
• Connectthegray2-wirecable(8ft)tothe2whitewiresonthecondensatepumptointerfacewith
theoverowswitch(usesuppliedwirenuts).
• Plug-inthedehumidierpowercordandcondensatepumppowercordtotheoutletsontheside
oftheCrawlspaceAlert(max.12amps).
• Check the Overow Shutoff:
•PlugtheCrawlspaceAlertpowercordintoadedicated15ampGFCIoutlet.
•Whilethedehumidierisoperating,liftuponthesafetyoatswitchorturnthepump
upside-down.Thedehumidiershouldturnoff.
•Iftheoperationisbackwards(dehumidierturnsonwhenthesafetyoatswitchtrips),
thenthepumpswitchterminalswillneedtobeswapped.Mostpumpswitcheshavethree
terminalsyetonlyconnectwirestotwo.Oneofyourwireswasprobablyconnectedtothe
NormallyOpenterminal.YoumustchangeittotheNormallyClosedterminal.Checkthe
functionalityagain.(Proceedtostep#4)
3. Plug-in the power cords
• Plug-intheCrawlspaceAlerttoadedicated15ampGFCIoutlet.
• Plugthedehumidierandcondensatepumppowercordintothesideofthecontrolbox.
4. Install the warning lamp
• Installwarninglampinalocationwhereitcanbeeasilymonitored.Themountingplatecanbe
ushmounted(A)orbracketmounted(B).
A. Flush mount:Flexthetabuntilitbreaksawayfromtheplate.Drilla1/2"diameterinstallation
hole,andpushthelampthroughthehole,thenslidethemountingplateoverthewiresand
pushthelampintotheplate.Attachtheplatetothemountingsurfaceusingadhesiveora
screw.
B. Bracket mount:Bendmountingplatetothedesiredangle.Slidethemountingplateoverthe
wiresandpushthelampintotheplate.Attachthemountingplatetothemountingsurfacewith
ascrew.Tiethelampwiringupalongitspathandbundleanyextrawireup,outoftheway.
• Tiethelampwiringupalongitspathandbundleanyextrawireup,outoftheway.
Note: To reduce the risk of electric shock, this product has a grounding type plug that has a third (grounding) pin. This plug will only fit into a grounding type
power outlet. If this plug does not fit into your outlet, contact a qualified electrician to install the proper outlet. Do not change the plug in any way.

WARRANTOR:
Therma-Stor LLC
4201 Lien Rd
Madison, WI 53704
Telephone: [phone]
WHO IS COVERED: This warranty extends only to the
original residential end-user of the Santa Fe Crawlspace
Alert, and may not be assigned or transferred.
FIRST YEAR WARRANTY: Therma-Stor LLC warrants
that, for one (1) year the Santa Fe Crawl Space Alert
will operate free from any defects in materials and
workmanship, or Therma-Stor LLC will, at its option,
repair or replace the defective part(s), free of any
charge.
END-USER RESPONSIBILITIES: Warranty service must
be performed by a Servicer authorized by Therma-
Stor LLC. If the end-user is unable to locate or obtain
warranty service from an authorized Servicer, he should
call Therma-Stor LLC at the above number and ask for
the Therma-Stor LLC Service Department, which will
then arrange for covered warranty service. Warranty
service will be performed during normal working hours.
The End-user must present proof of purchase (lease)
upon request, by use of the warranty card or other
reasonable and reliable means. The end-user is
responsible for normal care. This warranty only applies
to residential applications and does not cover any
defect, malfunction, etc. resulting from misuse, abuse,
lack of normal care, corrosion, freezing, tampering,
modification, unauthorized or improper repair or
installation, accident, acts of nature or any other cause
beyond Therma-Stor LLC's reasonable control.
LIMITATIONS AND EXCLUSIONS: If any Santa Fe
Crawlspace Alert part is repaired or replaced, the new
part shall be warranted for only the remainder of the
original warranty period applicable thereto (but all
warranty periods will be extended by the period of time,
if any, that the Santa Fe Crawl Space Alert is out of
service while awaiting covered warranty service).
UPON THE EXPIRATION OF THE WRITTEN WARRANTY
APPLICABLE TO THE Santa Fe Crawl Space Alert OR
ANY PART THEREOF, ALL OTHER WARRANTIES IMPLIED
BY LAW, INCLUDING MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE, SHALL ALSO EXPIRE.
ALL WARRANTIES MADE BY THERMA-STOR LLC ARE
SET FORTH HEREIN, AND NO CLAIM MAY BE MADE
AGAINST THERMA-STOR LLC BASED ON ANY ORAL
WARRANTY. IN NO EVENT SHALL THERMA-STOR LLC,
IN CONNECTION WITH THE SALE, INSTALLATION, USE,
REPAIR OR REPLACEMENT OF ANY Santa Fe Crawl
Space Alert OR PART THEREOF BE LIABLE UNDER
ANY LEGAL THEORY FOR ANY SPECIAL, INDIRECT OR
CONSEQUENTIAL DAMAGES INCLUDING WITHOUT
LIMITATION WATER DAMAGE (THE END-USER SHOULD
TAKE PRECAUTIONS AGAINST SAME), LOST PROFITS,
DELAY, OR LOSS OF USE OR DAMAGE TO ANY REAL OR
PERSONAL PROPERTY.
Some states do not allow limitations on how long an
implied warranty lasts, and some do not allow the
exclusion or limitation of incidental or consequential
damages, so one or both of these limitation may not
apply to you.
LEGAL RIGHTS: This warranty gives you specific legal
rights, and you may also have other rights which vary
from state to state.
Crawlspace Alert
