AST Embedded System Products TSA6000-USB User manual

TSA6000-USBTM
USER GUIDE

Copyright 2004-2005 TSA 6000-USB Version 1.0
i
TABLE OF CONTENTS
1. Quick Start...................................................................................................1
1.1 Activating the TSA 6000-USB............................................................................................. 1
1.2 Recording a Data file ............................................................................................................ 2
1.3 Sending files to a PC............................................................................................................. 2
1.4 Analyzing files ...................................................................................................................... 2
2. System Set-up ...............................................................................................3
2.1 Packing List........................................................................................................................... 3
2.2 Software Installation............................................................................................................. 3
2.3 System Overview .................................................................................................................. 3
3. Front Panel...................................................................................................5
3.1 Audio and Data interfaces..................................................................................................... 5
3.2 Menu Items and Dialog Box................................................................................................. 5
6. Features and Specifications..........................................................................6
6. Features and Specifications..........................................................................7
7. Product Safety & Regulatory .......................................................................9
7.1 Product Approvals ................................................................................................................ 9
7.2 Safety .................................................................................................................................... 9
7.3 FCC & Industry Canada Notices ........................................................................................ 10
7.4 EU Directive Compliance ................................................................................................... 10
7.5 Copyright ............................................................................................................................ 10
7.5 Revisions ............................................................................................................................. 11
8. TSA 6000 Support ......................................................................................12

Copyright 2004-2005 TSA 6000-USB Version 1.0
-1 -
TSA 6000-USBTM
1. Quick Start
1.1 Activating the TSA 6000-USB
Connect the TSA 6000 USB hardware to a PC with the USB cable. Power the
TSA 6000 USB device. Install the TSA 6000 Software. You will be asked for an
activation code to register the TSA 6000 software.
1. Go to www.tsa6000.com, click ‘Software Registration’. Fill out the contact information.
2. Software ID:
a. Run the tsa6000 software, a Software id will be generated as shown above, copy and
paste this into the 'Software ID' box on the web form
3. Hardware Serial #:
a. Locate the hardware id from the back of the TSA 6000 unit, enter it in the 'Hardware
serial #' box on the registration form
4. Click on ‘Register’ after filling in registration form, an activation code will be generated.
5. Copy Activation code and paste into the activation code box in the TSA software as shown
above. Press Activate.
Software ID.
Copy this and
paste into online
registration form.
You have 5
days to register
the software
Copy the
Activation code
from the online
registration form
here

Copyright 2004-2005 TSA 6000-USB Version 1.0
-2 -
1.2 Recording a Data file
Press the button. The status bar will indicate the unit is recording and
display the elapsed time. Press the button to end the recording process.
The data is displayed on the screen for analysis.
1.3 Sending files to a PC
Files are transferred from the TSA 6000 USB hardware as soon as a recording is
stopped. They will appear in the analysis window as they are transferred.
1.4 Analyzing files
Once a file has been downloaded, click on the menu bar to analyze the file.

Copyright 2004-2005 TSA 6000-USB Version 1.0
-3 -
2. System Set-up
2.1 Packing List
•TSA 6000-USB Signal Collection Unit
•USB cable for connecting the TSA 6000-USB to your computer
•AC adapter for powering your TSA 6000-USB
2.2 Software Installation
Make sure you have the following ready:
•CD containing the TSA 6000 software.
•A PC running Windows 95, 98, 2000, XP or NT4.
•Internet Access to www.tsa6000.com
Then:
•Insert the TSA 6000 CD into your computer.
•Follow on screen directions to install the TSA 6000 software
Note: Your software will run for 5 days after installation before you must
register. If not registered, after 5 days, the software is disabled.
2.3 System Overview
The TSA 6000 test system includes two parts. The data capture is handled by
the TSA 6000 hardware. Data Analysis is handled by the TSA 6000 software
application.
Data Capture
The TSA Test device interfaces to a local telephone loop. It collects data
through dual 16-bit analog to digital converters and transfers it to a PC. The
TSA 6000 USB device has a USB connection and the TSA 6000 software
facilitates all control of the data capture via a dialog box on the PC.
Data Analysis
The TSA 6000 software displays and manipulates data graphically. There are
also functions to analyze files for the presence of telephony signals. Filters can
be applied to the data to remove single frequency interference tones from the
signals of interest.

Copyright 2004-2005 TSA 6000-USB Version 1.0
-4 -
Calibration
The TSA 6000 USB runs a calibration routine on the AC channel when the
calibrate button is clicked. Remove any telephone cables connected to the TSA
6000 USB ‘Line’ or ‘Telephone’ jacks before calibrating. Calibration need
only be run once after Software initialization. Calibration data is stored on the
PC, therefore you must calibrate the TSA 6000-USB for each PC that you
install the software on.

Copyright 2004-2005 TSA 6000-USB Version 1.0
-5 -
3. Front Panel
3.1 Audio and Data interfaces
RJ-11 Jacks
The TSA6000-USB has 2 parallel RJ-11 jacks on the front panel.
USB Connector
The TSA6000-USB has a USB jack for connection to a PC
Status LED
When the TSA 6000 USB is powered on and not recording, the Status LED will flash with a
10% duty cycle and a 2Hz rate (“blip” flash). When a file is being recorded the green Status
LED will flash with 50% duty cycle at a 2Hz rate (steady on/off). When the unit is not
connected to the PC with the USB cable, the LED will be on solid to indicate there is power to
the unit.
3.2 Menu Items and Dialog Box
The menu items for the TSA 6000 USB appear in a dialog box on the TSA 6000 software.
Pressing the connect icon will bring up this menu when a USB device is connected.
Simple TSA 6000-USB dialog box:
Toggles
Show more
options
Toggles
Speaker
monitor
ON/OFF
Calibrate
TSA6000-
USB
unit. Remove
all cables from
RJ-11 jacks
before
calibrating
Start Recording
Stop Recording
Instantaneous DC
Voltage
Peak-hold AC voltage
in 100ms intervals
Line and Recording status

Copyright 2004-2005 TSA 6000-USB Version 1.0
-6 -
Advanced TSA 6000-USB dialog box:
If enabled, TSA6000
goes offhook 1.5s
after a power ring
event is detected
Total recording
duration, including
Pre-trigger duration
Amount of signal to
capture before a
trigger event
Event Triggers. See
Help file in TSA
software for details.
If a trigger is
detected a recording
of ‘Total Trigger
Duration’ is
generated.
Pre-dial window,
displays digits
dialed.
Dials any
digits shown in
the Pre-dial
window

Copyright 2004-2005 TSA 6000-USB Version 1.0
-7 -
6. Features and Specifications
The TSA 6000 is designed to collect and analyze the following signals:
•Caller-ID Timing and Signaling
•VMWI Timing and Signaling
•DTMF
•Pulse Dialing
•Call Progress Tones
•Power Ringing
•On Hook and Off Hook Caller-ID Timings and Protocols
•Single frequency interference signals
•Power line harmonics
•ADSI Timing and Signaling
•Wireline SMS Timing and Signaling
•Any FSK signaling (Bell-202 and V.23)
•DC impairments including Open Switch Intervals, Line Reversals, Line States
TSA 6000 Features:
•Capture and record line signaling at the customer premise or anywhere on the customer loop
•Simple to use one button recording
•Graphic display of signaling parameters
•Trigger modes to capture specific signals
•Line Termination and hook switch control to terminate line and decode Type 2 (Off-Hook)
Caller-ID
•Monitor mode -Listen to telephone signals on speaker, play back recorded signals
•Separate AC and DC coupled signal capture channels
•Field Upgradeable Firmware and Software

Copyright 2004-2005 TSA 6000-USB Version 1.0
-8 -
TSA 6000 Specifications:
•Operating Temperature: 0oC to +40oC.
•Storage Temperature: -20oC to +60oC.
•AC Coupled Channel
Dynamic Range Sample Rate Bandwidth Tolerance Sensitivity
4 Vpp 16,000 samples/sec 100-7000 Hz +/-1.0 dB -60 dBm
•DC Coupled Channel
Dynamic Range Sample Rate Bandwidth Tolerance
+/-400 V 1,000 samples/sec DC -150 Hz +/-250mV
•Telephone Interface Impedance
On-hook Off-hook
AC 200 k ohm (min.) 600 ohm +/-5%
DC 1 M ohm (min.) 200 ohm +/-5%

Copyright 2004-2005 TSA 6000-USB Version 1.0
-9 -
7. Product Safety & Regulatory
7.1 Product Approvals
SAFETY EMC / IMMUNITY
CSA60950 FCC Part 15 (Class A)
UL60950 ICES-003, CISPR22 (Class A)
IEC60950: 1999-04, EN 60950:2000 EN 55022, CISPR22 (Class A)
EN 61000-3-2 (Class A)
EN 61000-3-3 (Class A)
EN 50082-1:1997
7.2 Safety
The TSA6000 is intended for use by trained technical, service, field, and lab personnel. When using the
TSA6000, follow these safety precautions to reduce the risk of electric shock and personal injury:
1. Read and understand all instructions.
2. Unplug the unit from the wall outlets before cleaning. Do not use liquid cleaners or aerosol
cleaners. Use a damp cloth for cleaning.
3. Do not use this unit near water.
4. This unit should not be placed near or over a radiator or heat register.
5. Do not overload wall outlets and extension cords as this can result in the risk of fire or electric
shock.
6. Use only the power source supplied with the unit.
7. Do not disassemble this unit; call the manufacturer when service or repair is required. Opening
or removing covers may expose you to dangerous voltages or other risks.
8. Do not use this unit to report a gas leak in the vicinity of this unit.
9. Unplug this product from the wall outlet and refer servicing to qualified service personnel under
the following conditions:
a. When the power supply cord or plug is damaged or frayed.
b. If the product has been exposed to rain, water or liquid has been spilled on the product,
disconnect the unit and allow it to dry out. Once dry, it may be tested too see if it still
operates; however, do not open up the product.
c. If the product housing has been damaged.
d. If the product exhibits a distinct change in performance.
10. Avoid using the product during an electrical storm. There may be a remote risk of electric shock
from lightning.
11. For trained service personnel only: “Disconnect Unit From Telecommunication Network Before
Replacing Battery”, “Bevor Sie die Batterien ersetzen, trennen Sie die Einheit vom
Telekommunikationsnetz”.

Copyright 2004-2005 TSA 6000-USB Version 1.0
-10 -
7.3 FCC & Industry Canada Notices
This unit has been tested and found to comply with the limits for a Class A digital device as specified in
Part 15 of FCC rules. These limits provide reasonable protection against radio and TV interference in a
residential, commercial, or light industrial area. However, your equipment might cause TV or radio
interference even when operating properly. To eliminate interference, try one or more of the following
corrective measures:
•Relocate or reorient the TV or radio.
•To the extent possible, increase the distance between the equipment and the TV or radio.
•Use outlets on different electrical circuits for the equipment and the TV or radio.
This Device complies with Part 15 Class A of the FCC Rules and ICES-003 Class A Canadian EMI
requirements. Operation is subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) This device must accept any interference received, including interference
that may cause undesired operation.
Cet appareil numérique de la Classe A est conforme àla norme NMB-003 du Canada.
Warning: Changes or modifications not expressly approved by the party responsible for compliance could
void the user’s authority to operate the equipment.
7.4 EU Directive Compliance
The CE mark is affixed to this product to confirm compliance with the following European
Community Directives:
1. Council Directive 89/336/EEC of 3 May 1989 on the approximation of the laws of
Member States relating to electromagnetic compatibility; and
2. Council Directive 72/23/EEC of 19 February 1973 on the harmonization of the laws of
Member States relating to electrical equipment designed for use within certain voltage
limits.
7.5 Copyright
This publication may not be reproduced, in whole or in part, without prior expressed written
permission from AST Technology Labs and Embedded Systems Products Inc. All rights
reserved. Copyright 2002/2003/2004/2005 by AST Technology Labs and Embedded Systems
Products Inc. All rights reserved. Patent pending.
AST Technology Labs and Embedded Systems Products Inc. make no representations or
warranties with respect to the contents hereof and specifically disclaim any implied warranties of
merchantability or fitness for any particular purpose. Furthermore, AST Technology Labs and

Copyright 2004-2005 TSA 6000-USB Version 1.0
-11 -
Embedded Systems Products Inc. reserves the right to revise this publication and to make
changes from time to time in the content hereof without obligation of AST Technology Labs and
Embedded Systems Products Inc. to notify any person or organization of such revisions or
changes.
7.5 Revisions
Revision Level Date Description
1.0 November, 2004 First Revision

Copyright 2004-2005 TSA 6000-USB Version 1.0
-12 -
8. TSA 6000 Support
Visit our web site at www.tsa6000.com for useful tips and updates.
If you are having trouble with any aspect of your TSA 6000 contact:
[email protected]
