Dakota Digital DGS-3 User manual

DGS-3
GEAR SHIFT INDICATOR
Operation:
The DGS-3 gear indicator unit works with Dakota Digital’s gear position sending units (such as
the GSS-1000). The gear sending unit should be setup to for one wire mode (see manual for gear
sender). The DGS unit will then display a letter or number indicating the current gear.
The DGS-3 also has 4 additional indicators. These are, left and right turn signal, high beam
indicator, and a miscellaneous warning light.
Setup:
The wiring chart below describes the color code of the supplied harness. All inputs are +12v.
Color Purpose
Purple High beam indicator
Wht/Blk Warning (negative input)
Wht/Red Warning (positive input)
Green Right turn signal
Orange Left turn signal
Blue Dim
Yellow Gear data
Black GND
Red Ignition
The warning indicator has two possible modes of operation:
For a +12v activated warning signal, connect the White/Black wire to ground and connect the
White/Red wire to the warning signal wire.
For a ground activated warning signal, connect the White/Red wire to +12v and connect the
White/Black wire to the warning signal wire.
The yellow wire should be connected to the one wire signal terminal on the gear sender unit. The
gear sender needs to be setup to use one wire mode or the indicator will not work properly.
Mounting:
The DGS-3 requires a round hole 1-3/8” in diameter. It should be inserted in the opening
from the front and the U-clamp will be installed from the back. Tighten the nut on the U-clamp so
that the display is secure. Display depth to back of case is 2-1/4”. Display depth including the
mounting studs is 3-1/8”.
4510 W. 61ST St. N., Sioux Falls, SD 57107
Phone: [phone] FAX: [phone]
www.dakotadigital.com

TROUBLESHOOTING
PROBLEM CAUSE SOLUTION
Display reads -- Gear data (yellow wire) is
shorted to ground or 12v or
broken.
Gear sender unit not setup for
one wire operation.
Check wire for places it is
pinched or broken. Relocate
pinched wire and repair breaks
or bare spots.
Set up the gear sender to send a
one wire signal instead of wire
per gear mode (see gear sender
manual.)
Display reads ‘E’ Error signal is sent from gear
sender. (See gear sender manual)
Warning indicator doesn’t
light One of the wires for warning indicator are not connected. BOTH wires of the warning indicator must be used for it to
light. For high activated warning,
Wht/Red goes to warning signal
and Wht/Blk MUST go to ground.
For ground activated signal,
Wht/Blk goes to signal and
Wht/Red MUST go to +12v
WARRANTY
All DAKOTA DIGITAL instruments are warranted free of defects in material and
workmanship for 2 years from the date of purchase. In the event of a problem with one of our
products within the warranty period, DAKOTA DIGITAL will replace or repair the instrument at no
charge. (The decision to repair or replace is solely that of DAKOTA DIGITAL. DAKOTA DIGITAL
is not responsible for shipping costs of products returned under warranty or for labor charges for
product installation and removal.) This warranty becomes invalid if the product is misused,
altered or installed incorrectly.
For warranty coverage, you must first call to receive an RMA#. Ship the product
transportation prepaid via UPS or insured Parcel Post. A copy of the original invoice or dated bill
of sale along with a description of the defect is also required. Make sure that the RMA number is
clearly visible on the outside of the package as well as inside on the paper work.
The above warranties, both expressed and implied, do not cover damages caused by
improper installation, misuse, abuse, fire, unauthorized modifications, floods or acts of God, or
reimbursement of customer or shop time. The extent of the warranty is limited only to the product
and does not cover any loss or damage to vehicle, equipment, or non-DAKOTA DIGITAL
products.
SERVICE AND REPAIR
DAKOTA DIGITAL offers complete service and repair of its product line. In addition,
technical consultation is available to help you work through any questions or problems you may
be having installing one of our units.
Should you ever need to send the unit back for repairs, please package the product in a
good quality box along with plenty of packing material. Ship the product by UPS or insured
Parcel Post. Be sure to include your RMA#, a complete description of the problem, your full
name and address (street address preferred), and a telephone number where you can be
reached during the day. A return authorization number (RMA#) for products being return for
repair is required. Do not send any money. We will bill you for the repair charges.
4510 W. 61ST St. N., Sioux Falls, SD 57107
Phone: [phone] FAX: [phone]
www.dakotadigital.com
[email protected]
©Copyright 2005 Dakota Digital Inc.
