About this Product Manual
This product manual is divided into five sections to help you find the various topics and procedures. This
manual also contains Appendices.
Section 1 –Product Features:Pg. 5. Details the features and functions of each of the three TLX
Chassis models.
CHS-4 - pg. 6
CHS-2 - pg. 8
CHS-1 - pg. 11
Section 2 –Regulatory and Safety Requirements:Pg. 15. Thinklogical®strongly recommends
that you read this section prior to starting the hardware assembly.
Section 3 –How to Contact Us:Pg. 17. Thinklogical provides the best customer support available.
If you have questions or need to contact us for any reason, please refer to this section of the
manual.
Appendices –Beginning on Pg. 18.
Note and Warning Symbols
Throughout this manual you will notice certain symbols that bring your attention to important information.
These are Notes and Warnings. Examples are shown below.
Note: Important Notes appear in blue text preceded by a yellow exclamation point symbol,
as shown here.
A note is meant to call the reader’s attention to helpful or important information at a point in the text
that is relevant to the subject being discussed.
Warning! All Warnings appear in red text, followed by blue text, and preceded by a red
stop sign, as shown here.
A warning is meant to call the reader’s attention to critical information at a point in the text that is
relevant to the subject being discussed.
Product Serial Number
Thinklogical products have a unique serial number, which includes a date-code, printed on an
adhesive label that is affixed to the unit. The format for the date-code is 2 digits for the month,
dash, 2 digits for the year, plus at least four digits for a unique unit number. For example:
12-190648 indicates the unit was built in the 12th month of 2019 and is unit number 648.
Connection to the Product
Connections and installation hardware for our products use industry-standard devices
and methods. All wiring connections to the customer equipment are designed to minimize
proprietary or customized connectors and cabling. Power connections are made with regionally
appropriate power cords and approved methods.
