TLX 10G
thinklogical®
Subject: TLX10 and TLX20 CATx Extender Products Manual
Revision: B, August, 2016
Website: www.thinklogical.com
Facebook: www.facebook.com/ThinklogicalUSA
LinkedIn: www.linkedin.com/company/thinklogical
Google+: http://plus.google.com/u/0/109273605590791763795/about
YouTube: www.youtube.com/user/thinklogicalNA
Twitter: @thinklogical

Page 2
TLX CATx Extension Products Manual thinklogical®Rev. B, August 2016
Table of Contents
PREFACE 3
About Thinklogical 3
Note and Warning Symbols 4
The Scope of This Document 4
INTRODUCTION 5
Features of the TLX Extension & Matrix Switch System 5
PRODUCT OVERVIEW 6
DisplayPort and HDMI Connector 6
Form Factor 7
Operating Features 9
Interface Configurations 10
Status Indicator LEDs 12
Supplied Cables 13
TLX10 and TLX20 CATx Cable Configurations 15
FPGA and Firmware Upgrade Applications 15
TLX10 and TLX20 Extender Technical Specifications 16
TLX10 and TLX20 Extender Audio Specifications 17
REGULATORY & SAFETY COMPLIANCE 17
Safety Requirements 17
Symbols Found on the Product 17
Regulatory Compliance 17
North America 17
Australia & New Zealand 18
European Union 18
Standards with which Our Products Comply 18
Supplementary Information 19
Product Serial Number 19
Connection to the Product 19
THINKLOGICAL SUPPORT 19
Customer Support 19
Website 19
Email 20
Telephone 20
Fax 21
Product Support 20
Warranty 20
Return Authorization 21
Our Addresses 21
APPENDIX A: Quick Start Guide 22
APPENDIX B: RJ45 to DB9 Adapter Pin-outs 23
APPENDIX C: FPGA Program Code Update Procedure 24
APPENDIX D: EDID and DDC for TLX Modules 25
How to Change DDC Modes 26
How to Change the IP Address of a CATx Extender 29
How to Configure a PC with a Static Address 31

Page 3
TLX CATx Extension Products Manual thinklogical®Rev. B, August 2016
PREFACE
About Thinklogical
We, the Thinklogical team, are committed to understanding and
exceeding our customers’ requirements, the first time and every time.
Thinklogical is the leading manufacturer and provider of fiber optic and CATx KVM, video,
audio, and peripheral extension and switching solutions used in video-rich, big-data
computing environments.
Thinklogical offers the only fiber-optic KVM matrix switches in the world that are accredited
to the Common Criteria EAL4, TEMPEST Level B, and NATO NIAPC Evaluation Scheme: GREEN
information assurance standards. And Thinklogical Velocity products are the first system with
both KVM and video matrix switching capabilities to be placed on the Unified Capabilities
Approved Product List (UC APL) under the Video Distribution System (VDS) category.
Governments, entertainment, scientific and industrial customers worldwide rely on
Thinklogical’s products and solutions for security, high performance, continuous operation
and ease of integration. Thinklogical products are designed and manufactured in the USA
and are certified to the ISO 9001-2008 standard.
Thinklogical is headquartered in Milford, Connecticut and is privately held by Riverside
Partners, LLC, Boston, MA (http://www.riversidepartners.com). For more information about
Thinklogical products and services, please visit www.thinklogical.com.
Follow Thinklogical on LinkedIn at http://www.linkedin.com/company/thinklogical and on
Facebook at http://www.facebook.com/ThinklogicalUSA

Page 4
TLX CATx Extension Products Manual thinklogical®Rev. B, August 2016
Note and Warning Symbols
Throughout this manual you will notice certain symbols that bring your attention to important information.
These are Notes and Warnings. Examples are shown below.
Note: Important Notes appear in blue text preceded by a yellow exclamation point
symbol, as shown here.
A note is meant to call the reader’s attention to helpful information at a point in the text that is relevant to
the subject being discussed.
Warning! All Warnings appear in red text, followed by blue text, and preceded by a
red stop sign, as shown here.
A warning is meant to call the reader’s attention to critical information at a point in the text that is
relevant to the subject being discussed.
BEFORE STARTING ANY PROCEDURE, IT IS RECOMMENDED
THAT YOU READ THE INSTRUCTIONS THOROUGHLY!
The Scope of This Document
This Product Manual is intended to provide customers with a full overview of the features, functions,
usage and support for Thinklogical’s TLX10 CATx Extender Transmitter (TLX-TCF-U00D10) and
Receiver (TLX-RCF-U00D10), capable of extending a single Video Display and Data at a rate of
4096x2160 @ 30Hz for up to 100m over a single CAT6a 23 AWG Cable…
…and for Thinklogical’s TLX20 CATx Extender Transmitter (TLX-TCF-U00D20) and Receiver (TLX-
RCF-U00D20), capable of extending a single Video Display and Data at a rate of 4096x2160 @ 60Hz for
up to 100m over a pair of CAT6a 23 AWG Cables.

Page 5
TLX CATx Extension Products Manual thinklogical®Rev. B, August 2016
Introducing Thinklogical’s newest family of switching and extension solutions, for
uncompressed, high resolution video and KVM systems over fewer cables.
Features of the TLX Extension & Matrix Switch System
Offering a higher bandwidth solution, the TLX product line provides 10Gbps
bandwidth per port to preserve signal integrity and provide uncompressed, high
resolution video with no artifacts, latency or lost frames.
The TLX Product Family offers these features to enhance ease of integration:
Hybrid switching solutions (fiber and CATx) start at 12 ports and scale up to 640 ports.
Offers a higher bandwidth solution to address new video resolutions and prepare for future
protocols.
The TLX system reduces cabling by half through higher bandwidth.
Extend and switch:
Single display up to 4096x2160 @ 30Hz with full 4:4:4 color depth, over a single fiber or
CATx cable
(or dual displays up to 1920x1200 @ 60Hz with full 4:4:4 color depth)
Single display up to 4096x2160 @ 60Hz with full 4:4:4 color depth, over two fibers or
CATx cables
(or dual displays up to 4096x2160 @ 30Hz with full 4:4:4 color depth)
Dual displays up to 4096x2160 @ 60Hz with full 4:4:4 color depth, over four fibers.
Dual connectors on TLX Extenders, offering support for both HDMI and DisplayPort, reduces
the number of extenders and converter cables required and enables users to future-proof
system designs.
Connector installed on every Video and KVM extender module.

Page 6
TLX CATx Extension Products Manual thinklogical®Rev. B, August 2016
TLX-TCF-U00D20 60Hz Display Transmitter with USB HID, USB 2.0, RS-232 & Audio
Product Overview
All TLX Extenders are compatible with each other, but not backwards compatible with Velocity
6.25 Gbps transport.
TLX Video and KVM Extension Systems
Video connector supports both HDMI 1.4 (4K @ 30Hz) and DisplayPort 1.2 (4K @ 60Hz) cables
10Gbps bandwidth per port
Extension of up to 100 meters over CAT6a cables, 23 AWG solid S/FTP
Support for a single display up to 4096x2160 @ 30Hz over a single CATx cable
Support for a single display up to 4096x2160 @ 60Hz (DisplayPort only) over two CATx cables
Supports HDCP content
Ethernet port for configuration, management and updates
Supports embedded audio, with ability to de-embed at the Receiver
Supports unbalanced analog audio and serial RS-232
Options include USB HID (1.5 Mbps) and USB 2.0 (480 Mbps)
DisplayPort & HDMI Connector
Thinklogical includes an innovative connector on its TLX Extenders. The connector can receive
either HDMI 1.4 or DisplayPort 1.2 cables, reducing the number of extenders needed and, eliminating
the need for an external adapter or dongle to convert from DisplayPort to HDMI/DVI. It also allows the
customer to upgrade from HDMI to DisplayPort with no change in equipment. When combined with a
Thinklogical TLX Matrix Switch, it’s easy to combine and connect HDMI/DVI and DisplayPort sources
and displays.
Note: DisplayPort 1.2 Video Cables support up to 4K @ 60Hz. HDMI 1.4 Video Cables support
up to 4K @ 30Hz. Install either DisplayPort or HDMI cables at both the Transmitter and
Receiver.
DisplayPort Connector
HDMI Connector

Page 7
TLX CATx Extension Products Manual thinklogical®Rev. B, August 2016
Form Factor
TLX CATx Extension Systems are available in a compact, desk top form factor. The chassis includes a
pair of mounting brackets that can be removed or installed to mount the unit above or below a bench,
desk or shelf.
Height: 1.25” (31.75mm)
Depth: 7.1875” (182.56mm)
Width: 7.625” (193.68mm)
Width (w/ brackets): 8.875” (225.43mm)
The TLX20 Extender and the 19” rack-mountable TLX24 Matrix Switch

Page 8
TLX CATx Extension Products Manual thinklogical®Rev. B, August 2016
Typical TLX CATx Application

Page 9
TLX CATx Extension Products Manual thinklogical®Rev. B, August 2016
Operating Features
DisplayPort 1.2 Video Head
HDMI 1.4 Video Head
Note: Install either DisplayPort or
HDMI cables at both the Transmitter
and Receiver.
Mechanical lock for DiplayPort and HDMI connectors
HDCP Compliant
10.3125G Copper Interface (CATx)
Audio Option
Supports standard L/R Audio; Line/Mic In, Line Out on both TX and RX (pg. 17).
RS-232 Serial Port Extension Option (includes a CAT5 cable and RJ45 to DB9 Adapters)
The Management (MGMT) Port
For module status and software updates
In-band System Management Interface
Ethernet on module (i.e. Wiznet)
Bi-color indicator LEDs
EDID Table DDC Modes: Static, Dynamic, Remote Acquire, Load Custom
Supported Tables:
1024x768 @ 60Hz
1920x1080 @ 60Hz
1920x1200 @ 60Hz
2560x1440 @ 60Hz
3840x2160 @ 30Hz
3840x2160@ 60Hz (DisplayPort only)
4096x2180 @ 24Hz
4096x2160 @ 60Hz (DisplayPort only)
Temperature sensor
TLX Chassis Interface compliant (physical and protocol)
Power: 5V @ 7A Max.
Remote Upgrade of S/W and Firmware
FPGA Configuration supports ‘Golden Boot Image’ as backup for failed upgrade.
Audio De-embedding in Receiver Module
Line Out User Selectable between TLX Line In or De-embedded Audio
HDMI 1.4 or DisplayPort 1.2 cables included, as applicable.
