thomann Harley Benton Dynamic Compressor User manual

Dynamic Compressor
effects pedal
user manual

Musikhaus Thomann
Thomann GmbH
Hans-Thomann-Straße 1
96138 Burgebrach
Germany
Telephone: [phone]
E-mail: [email protected]
Internet: www.thomann.de
31.07.2015, ID: 256813

Table of contents
1 General notes............................................................................................................................................... 4
2 Safety instructions..................................................................................................................................... 6
3 Instructions for use................................................................................................................................. 10
4 Components and functions................................................................................................................ 11
5 Technical specifications....................................................................................................................... 14
6 Protecting the environment.............................................................................................................. 15
Table of contents
Dynamic Compressor
3

1 General notes
This user manual contains important information on safe operation of the device. Read and
follow all safety notes and all instructions. Save this manual for future reference. Make sure
that it is available to all persons using this device. If you sell the device to other users, be sure
that they also receive this manual.
Our products are subject to a process of continuous development. We therefore reserve the
right to make changes without notice.
This section provides an overview of the symbols and signal words used in this user manual.
Signal word Meaning
DANGER! This combination of symbol and signal word indicates an
immediate dangerous situation that will result in death or
serious injury if it is not avoided.
NOTICE! This combination of symbol and signal word indicates a pos‐
sible dangerous situation that can result in material and
environmental damage if it is not avoided.
Symbols and signal words
General notes
effects pedal
4

Warning signs Type of danger
Warning – danger zone.
General notes
Dynamic Compressor
5

2 Safety instructions
This device is intended to be used for sound processing of signals from musical instruments
with electromagnetic pickups. Any other use or use under other operating conditions is con‐
sidered to be improper and may result in personal injury or property damage. No liability will
be assumed for damages resulting from improper use.
This device may be used only by persons with sufficient physical, sensorial, and intellectual
abilities and having corresponding knowledge and experience. Other persons may use this
device only if they are supervised or instructed by a person who is responsible for their safety.
Intended use
Safety instructions
effects pedal
6

DANGER!
Danger for children
Ensure that plastic bags, packaging, etc. are disposed of properly and are not
within reach of babies and young children. Choking hazard!
Ensure that children do not detach any small parts (e.g. knobs or the like) from
the unit. They could swallow the pieces and choke!
Never let children unattended use electrical devices.
NOTICE!
Operating conditions
This device has been designed for indoor use only. To prevent damage, never
expose the device to any liquid or moisture. Avoid direct sunlight, heavy dirt, and
strong vibrations.
Safety
Safety instructions
Dynamic Compressor
7

NOTICE!
External power supply
The device can be powered by an external power supply. Before connecting an
external power supply, ensure that the input voltage (AC outlet) matches the
voltage rating of the device and that the AC outlet is protected by a residual cur‐
rent circuit breaker. Failure to do so could result in damage to the device and pos‐
sibly the user.
Unplug the external power supply before electrical storms occur and when the
device is unused for long periods of time to reduce the risk of electric shock or
fire.
NOTICE!
Risk of fire due to incorrect polarity
Incorrectly inserted batteries may destroy the device or the batteries.
Ensure that proper polarity is observed when inserting batteries.
Safety instructions
effects pedal
8

NOTICE!
Possible damage by leaking batteries
Leaking batteries can cause permanent damage to the device.
Take batteries out of the device if it is not going to be used for a longer period.
Safety instructions
Dynamic Compressor
9

3 Instructions for use
Unpack and carefully check that there is no transportation damage before using the unit. Keep
the equipment packaging. To fully protect the device against vibration, dust and moisture
during transportation or storage use the original packaging or your own packaging material
suitable for transport or storage, respectively.
Handle the device with care.
Do not try to disassemble or repair the device yourself in the unlikely event that it does not
work.
Do not use solvents such as alcohol to clean the device.
Instructions for use
effects pedal
10

4 Components and functions
1SUSTAIN
Use this control to adjust the release time of the compressor.
2DC 9V
Connection for power supply via an external DC 9V adaptor. When using external
power supply, the battery supply is automatically disconnected.
3LEVEL
Turn this knob clockwise to increase the output level.
4ATTACK
Use this control to adjust the attack time of the compressor
5IN
Input socket for a 1/4" standard instrument cable.
6TRUE BYPASS
Foot switch to activate / deactivate the pedal function.
Components and functions
Dynamic Compressor
11

7 This LED lights up when the pedal is in operation. If the LED is not or only slightly lit
when the pedal is in operation, the battery is depleted and must be replaced.
8OUT
Signal outlet. Use a 1/4" standard instrument cable to connect another effects
pedal or amplifier to this socket.
Establish all connections as long as the unit is switched off. Use the shortest possible high-
quality cables for all connections.
You can either use a 9 V battery or the DC 9 V connection for an external power supply. Before
connecting, check for correct polarity.
When you do not use the pedal unplug the instrument cable from the input jack. Otherwise,
the battery will be discharged.
Power supply
Components and functions
effects pedal
12

To insert or change the battery, disconnect a possibly used power adapter from the mains
socket. Turn the pedal over, press lightly on the battery compartment cover and slide it down‐
wards in the direction of the arrow. Remove the back cover. Insert/replace the 9 V DC battery
paying attention to the polarity markings and place the cover again into its original position
until it locks.
Changing the battery
Components and functions
Dynamic Compressor
13

5 Technical specifications
Input impedance 500 kΩ
Output impedance 10 kΩ
Current draw 8 mA
Operating voltage supply 9 V battery (6F22)
9 V power adaptor, inner contact = negative pole
48 V phantom power
Dimensions (L × W × H) 120 mm × 72 mm × 55 mm
Weight 290 g
Technical specifications
effects pedal
14

6 Protecting the environment
For the transport and protective packaging, environmentally friendly materials have been
chosen that can be supplied to normal recycling.
Ensure that plastic bags, packaging, etc. are properly disposed of.
Do not just dispose these materials with your normal household waste, but make sure that
they are fed to a recovery. Please follow the notes and markings on the packaging.
Batteries must not be disposed of as domestic waste or thrown into fire. Dispose of the bat‐
teries according to national or local regulations regarding hazardous waste. To protect the
environment, dispose of empty batteries at your retail store or at appropriate collection sites.
Disposal of the packaging mate‐
rial
Disposal of batteries
Protecting the environment
Dynamic Compressor
15

This product is subject to the European Waste Electrical and Electronic Equipment Directive
(WEEE). Do not dispose with your normal household waste.
Dispose this device through an approved waste disposal firm or through your local waste
facility. When discarding the device, comply with the rules and regulations that apply in your
country. If in doubt, consult your local waste disposal facility.
Disposal of your old device
Protecting the environment
effects pedal
16

Notes
Dynamic Compressor
17

Notes
effects pedal
18

Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de
