thomann harley benton User manual

Dual Looper
looper
user manual

Musikhaus Thomann
Thomann GmbH
Hans-Thomann-Straße 1
96138 Burgebrach
Germany
Telephone: [phone]
E-mail: [email protected]
Internet: www.thomann.de
24.02.2017, ID: 402772

Table of contents
1 General information................................................................................................................................. 4
1.1 Further information........................................................................................................................... 5
1.2 Notational conventions.................................................................................................................... 6
1.3 Symbols and signal words............................................................................................................... 6
2 Safety instructions..................................................................................................................................... 8
3 Features....................................................................................................................................................... 11
4 Notes on use............................................................................................................................................... 12
5 Controls and functions......................................................................................................................... 13
6 Operating.................................................................................................................................................... 18
7 Technical specifications....................................................................................................................... 22
8 Protecting the environment.............................................................................................................. 23
Table of contents
Dual Looper
3

1 General information
This manual contains important instructions for the safe operation of the unit. Read and follow
the safety instructions and all other instructions. Keep the manual for future reference. Make
sure that it is available to all those using the device. If you sell the unit please make sure that
the buyer also receives this manual.
Our products are subject to a process of continuous development. Thus, they are subject to
change.
General information
looper
4

1.1 Further information
On our website (www.thomann.de) you will find lots of further information and details on the
following points:
Download This manual is also available as PDF file for you to download.
Keyword search Use the search function in the electronic version to find the topics of
interest for you quickly.
Online guides Our online guides provide detailed information on technical basics
and terms.
Personal consultation For personal consultation please contact our technical hotline.
Service If you have any problems with the device the customer service will
gladly assist you.
General information
Dual Looper
5

1.2 Notational conventions
This manual uses the following notational conventions:
The letterings for connectors and controls are marked by square brackets and italics.
Examples: [VOLUME] control, [Mono] button.
Texts and values displayed on the device are marked by quotation marks and italics.
Examples: ‘24ch’, ‘OFF’.
1.3 Symbols and signal words
In this section you will find an overview of the meaning of symbols and signal words that are
used in this manual.
Letterings
Displays
General information
looper
6

Signal word Meaning
DANGER! This combination of symbol and signal word indicates an
immediate dangerous situation that will result in death or
serious injury if it is not avoided.
NOTICE! This combination of symbol and signal word indicates a pos‐
sible dangerous situation that can result in material and
environmental damage if it is not avoided.
Warning signs Type of danger
Warning – danger zone.
General information
Dual Looper
7

2 Safety instructions
This device is used to record instrument signals and to play them back by means of suitable
devices in an endless loop. Use the device only as described in this user manual. Any other use
or use under other operating conditions is considered to be improper and may result in per‐
sonal injury or property damage. No liability will be assumed for damages resulting from
improper use.
This device may be used only by persons with sufficient physical, sensorial, and intellectual
abilities and having corresponding knowledge and experience. Other persons may use this
device only if they are supervised or instructed by a person who is responsible for their safety.
Intended use
Safety instructions
looper
8

DANGER!
Danger for children
Ensure that plastic bags, packaging, etc. are disposed of properly and are not
within reach of babies and young children. Choking hazard!
Ensure that children do not detach any small parts (e.g. knobs or the like) from
the unit. They could swallow the pieces and choke!
Never let children unattended use electrical devices.
NOTICE!
Operating conditions
This device has been designed for indoor use only. To prevent damage, never
expose the device to any liquid or moisture. Avoid direct sunlight, heavy dirt, and
strong vibrations.
Safety
Safety instructions
Dual Looper
9

NOTICE!
External power supply
The device is powered by an AC adaptor plug. Before connecting the AC adaptor
plug, ensure that the input voltage (AC outlet) matches the voltage rating of the
device and that the AC outlet is protected by a residual current circuit breaker.
Failure to do so could result in damage to the device and possibly the user.
Unplug the AC adaptor plug before electrical storms occur and when the device is
unused for long periods of time to reduce the risk of electric shock or fire.
Safety instructions
looper
10

3 Features
nDual-channel looper
nUp to 10 minutes recording time
nUnlimited overdubbing
nVariable playback speed
nReverse playback possible
nWindows software for data transmission available from our product website
nRecording format WAV audio with 48 kHz / 24 bit
nOperation via power supply (not supplied)
Features
Dual Looper
11

4 Notes on use
Unpack and carefully check that there is no transportation damage before using the unit. Keep
the equipment packaging. To fully protect the device against vibration, dust and moisture
during transportation or storage use the original packaging or your own packaging material
suitable for transport or storage, respectively.
Handle the device with care.
Do not try to disassemble or repair the device yourself if it should not work.
Set the volume of a connected amplifier to minimum before plugging or unplugging an instru‐
ment cable. This prevents loud noises.
When using an instrument with a high output level, the sound can be distorted. If distortion
occurs, reduce the volume of the instrument.
Do not use solvents such as alcohol to clean the device.
Notes on use
looper
12

5 Controls and functions
Ins / outs, controllers, LEDs
Controls and functions
Dual Looper
13

1[LEVEL L]
Volume control for the left channel.
2[CHANGE | FORWARD | REVERSE]
When switch in CHANGE position: Recorded loop material is output in the other channel as it was recorded.
When switch in FORWARD position: Recorded loop material is output forwards in the same channel as it was
recorded.
When switch in REVERSE position: When the FX function is activated, recorded loop material is output backwards in
the same channel in which it was recorded.
3[LEVEL R]
Volume control for the right channel.
Controls and functions
looper
14

4[STOP | FX]
Switch for function control of the right foot switch. [FX]:
When switch in STOP position: The right foot switch [FX] stops loop recording and playback.
When switch in FX position: The right foot switch [FX] turns the function to adjust the playback speed as well as - if
activated - the loop playback backwards on and off.
5[SPEED]
Controls the playback speed and pitch of the loop material.
6[FX]
This LED lights up red when only the FX function is activated, even if the knob to adjust the playback speed is set to
[NORMAL] . It lights up green when also loop playback backwards is activated.
7[DC 9V]
Connector for a 9 V power adapter (not included).
8[LEFT IN]
Input socket left channel: Use a shielded instrument cable with a 1/4" jack to connect the instrument whose signals
are to be processed in the left channel.
Controls and functions
Dual Looper
15

9[RIGHT IN]
Input socket right channel: Use a shielded instrument cable with a 1/4" jack to connect the instrument whose signals
are to be processed in the right channel.
10 [FX]
If the [STOP | FX] switch is in the STOP position, pressing this switch quickly stops the recording or playback. Press and
hold the switch for 2 seconds to irretrievably erase previous recordings.
If the [STOP | FX] switch is in the FX position, the switch turns the function to adjust the playback speed as well as - if
activated - the loop playback backwards on and off.
11 [LOOPER]
This switch is used to start loop recording or playback and to control the Undo / Redo function.
12 [RIGHT OUT]
Output socket right channel: Use a shielded instrument cable with a 1/4" jack to connect another effects pedal, the
input of a suitable instrument amplifier or the right input of a stereo amp.
13 [LEFT OUT]
Output socket left channel: Use a shielded instrument cable with a 1/4" jack to connect another effects pedal, the
input of a suitable instrument amplifier or the left input of a stereo amp.
Controls and functions
looper
16

14 [USB]
USB port to connect a computer for copying the loop material.
15 [LOOPER]
This LED flashes green on stopped playback. Then press the left foot switch [LOOPER] to start playback. The LED lights
up green during playback. During playback, press the left foot switch [LOOPER] to start recording. The recording
cannot start, if the [CHANGE | FORWARD | REVERSE] switch is in the [REVERSE] position. The LED lights up red during
recording.
Controls and functions
Dual Looper
17

6 Operating
Connect the device to the power supply via a suitable mains adapter (not supplied), which
provides 9 V with the negative pole via the centre contact. The device is instantly opera‐
tional. Disconnect the unit from the power supply to switch it off. The recorded loop remains
stored in the device after switching it off.
Connect a mono instrument to the input socket [LEFT IN] or [RIGHT IN] using a shielded instru‐
ment cable with a 1/4" jack. To be able to listen to your playing, connect the corresponding
output jack [LEFT OUT] or [RIGHT OUT] to the input of a suitable instrument amplifier or to
another effects pedal first, using a shielded instrument cable with a 1/4" jack
Interesting effects can also be achieved by connecting a stereo amplifier to the out‐
puts [LEFT OUT] and [RIGHT OUT] and recording loop material in one, and then in the
other channel.
Connect a stereo instrument to the input sockets [LEFT IN] and [RIGHT IN] .
Using the mains adapter
Recording / Overdub / Undo /
Redo
Operating
looper
18

The [LOOPER] LED flashes green, the device is ready to play. Press the foot switch [LOOPER] to
start playback. The [LOOPER] LED lights up green then. If there is not yet any loop material in
the memory, press the foot switch [LOOPER] again to start recording. The [LOOPER] LED lights
up red then. Start playing the instrument. The maximum recording time is 10 minutes. This first
recording defines the length of the loop, which can not be extended by later recordings. After
recording the first layer, press the LOOPER [LOOPER] foot switch to store the recording. The
unit will immediately play your recording in an endless loop, while the [LOOPER] LED lights up
green. A short flicker of the LED indicates the beginning of the loop. Use the controllers
[LEVEL L] and [LEVEL R] to adjust the desired levels for both channels.
To add another layer to your first recording (overdub), press the [LOOPER] foot switch again
and start playing. Proceed accordingly until all desired layers are recorded.
Provided the [STOP | FX] switch is in the [STOP] position, press the [FX] foot switch to stop play‐
back. The [LOOPER] LED flashes green then.
You can delete the last recorded layer (Undo) and then restore it (Redo). To do so in Overdub
and playback mode, hold the [LOOPER] foot switch pressed for about 2 seconds. The [LOOPER]
LED flashes quickly. The loop is then played without the last layer recorded. If you want to
restore the level, hold down the [LOOPER] foot switch again for about 2 seconds. To resume
recording, press the [LOOPER] foot switch and start playing.
Operating
Dual Looper
19

The undo / redo function is still available after disconnection from the power supply.
If the [LOOPER] LED flashes green press the [LOOPER] foot switch to start playback. To change
the channels when playing the loop material, set the [CHANGE | FORWARD | REVERSE] switch in
the [CHANGE] position. To use the effect of variable playback speed and pitch, set the
[STOP | FX] switch in the [FX] position and press the [FX] foot switch. The [FX] LED lights up red
now. Now use the rotary control [SPEED] to select one of the three sped up ([FAST], max. 1.5-
fold speed) or one of the seven slowed down ([SLOW], max. half speed) modes. In the
[NORMAL] position, playback speed is unaffected. Set the [CHANGE | FORWARD | REVERSE]
switch in the position [REVERSE] to let the device play the loop material backwards. The [FX]
LED lights up green now. To disable both effects, press the [FX] foot switch. To stop playback
set the [STOP | FX] switch in the [STOP] position and press the [FX] foot switch. The [FX] LED
turns off.
To delete the entire loop material irretrievably set the [STOP | FX] switch in the [STOP] position
and hold the [FX] foot switch pressed for about 2 seconds, until the [LOOPER] LED turns off.
Playback / Effects
Deleting loop
Operating
looper
20
