THOMSON CS100 User manual

u s e r m a n u a l
CS100
DIGITAL LOGIC DECK
ON•ECO
DIGITAL PLLSYNTHESIZEDTUNER
MUL
TIFUNCTIONLCDDISPLA
Y
TUNING
IR SENSOR
TIMER
PLAYBACK/RECORD
OPEN/
CLOSE
V
O
L
U
M
E
C
O
N
T
R
O
L
CD
Untitled-4 4/10/03, 1:56 PM3

EN
Thomson Information
CAUTION!
Invisible laser radiation when open. Avoid exposure
to beam. Class 1 laser product. This system must be
opened only by qualified technicians to prevent
accidents caused by the laser beam.
LASER λ= 780nm, P max=5 mW
Rating Information : At the bottom/rear of the unit.
This unit complies with the existing requirements.
Please respect the environment
Before throwing any batteries away,
consult your distributor who may be
able to take them back for specific
recycling.
Have a Blast-Just Not in your
eardrums
Make sure you turn down the
volume on the unit before you put
on headphones. Increase the
volume to the desired level only
after headphone is in place.
In accordance with the rating plate of
the unit, this unit current standards
concerning electrical safety and
electromagnetic compatibility.
Safety Information
ADVARSEL!
USYNLIG LASERSTRÅLNING VED ÅBNING NAR
SIKKERHEDSAFBRYDERE ER UDE AF FUNKTION.
UNGDÅ UDSAETTELSE FOR STRÅLNING.
VORSICHT!
UNSICHTBARE LASERSTRALUNG
WENN ABDECKUNG GEÖFFNET UND SICHERHEITS–
VERRIEGELUNG ÜBERBRÜCKT.
NICHT DEM LASERSTRAHL AUSSETZEN!
CAUTION – INVISIBLE LASER RADIATION
WHEN OPEN AND INTERLOCKS FAILED OR
DEFEATED. AVOID EXPOSURE TO BEAM.
ATTENTION –
RAYONNEMENT LASER INVISIBLE
DANGEREUX EN CAS D'OUVERTURE ET LORSQUE
LA SECURITE EST NEUTRALISEE.
EXPOSITION DANGEREUSE AU FAISCEAU.
CLASS 1 LASER PRODUCT
LASER KLASSE 1
APPAREIL A LASER DE CLASSE 1
LUOKAN 1 LASERLAITE
KLASS 1 LASERAPPARAT
VARNING–
OSYNLIG LASERSTRÅLNING NÄR DENNA DEL
ÄR ÖPPNAD OCH SPÄRRAN ÄR URKOPPLADE.
BETRAKTA EJ STRÅLEN.
VARO!
AVAT TAESSA JA SOUJALUKITUS OHITETT
AESSA
OLET AL TTIINA NÄKYMÄTTÖMÄLLE.
LASERSÄTEIL YLLE ÄLÄ KA TSO SÄTEESEEN.
For UK Only
CONNECT THE MAIN LEAD INTO A MAINS POWER
SOCKET
POWER SUPPLY 230V. It must not be connected to
D.C. mains.
Note: The mains lead of the set is fitted with a
moulded plug. If the mains socket are not
compatible or if for any reason the plug is removed
please follow the directions below. The moulded
plug cannot be rewired and if removed must be
disposed of safely.
DO NOT under any circumstances plug the severed
plug into any mains socket as this could result in
electric shock.
Important: If the plug is removed, rewire the new
plug as follow:
The wires in the mains plug are coloured in
accordance to the following code:
BLUE = NEUTRAL/BROWN = LIVE
If the colours of the wires in the mains lead of this
apparatus may not correspond with the coloured
markings identifying the terminals in your plug,
proceed as follows:
BLUE wire to the terminal coded N (Neutral) or
coloured black.
BROWN wire to the terminal coded L (Live) or
coloured red.
DO NOT make any connection to the
terminal in the plug which is marked
by the letter E or by the earth
symbol or coloured green or green
and yellow.
A fused plug must be
fitted with a 3A fuse
approved by ASTA or
BS1362 and fuse covers
must be always be securely
replaced. If you set does
not work, the fuse may be
blown.
Untitled-4 4/10/03, 1:56 PM4

EN
Safety Information
Safety Information
Getting Started ..................1
CD Micro System ................2
Remote Control ..................3
Settings ...............................4
Tuner ....................................5
Tape Deck ............................5
CD Player ............................. 6
Troubleshooting Tips ......... 7
Maintenance .......................8
More Information ..............9
WARNING: TO PREVENT FIRE OR ELECTRICAL
SHOCK HAZARD, DO NOT EXPOSETHIS PRODUCT
TO RAIN OR MOISTURE.
SEE MARKING ON BOTTOM / BACK OF PRODUCT
CAUTION
RISKOFELECTRICSHOCK
DONOTOPEN
THE EXCLAMATION
POINT WITHIN THE
TRIANGLE IS A
WARNING SIGN
ALERTING YOU OF
IMPORTANT
INSTRUCTIONS
ACCOMPANYING
THE PRODUCT.
THE LIGHTNING
FLASH AND ARROW-
HEAD WITHIN THE
TRIANGLE IS A
WARNING SIGN
ALERTING YOU OF
"DANGEROUS
VOLTAGE" INSIDE
THE PRODUCT.
CAUTION: TO REDUCE THE
RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER
(OR BACK). NO USER-
SERVICEABLE PARTS IN-
SIDE. REFER SERVICING
TO QUALIFIED SERVICE
PERSONNEL.
Content
The descriptions and characteristics in this owner’s manual are for the purpose of general reference only and not as a
guarantee. In order to provide you with the highest quality product, we may make changes or modifications without prior
notice. The English version serves as the final reference on all product and operational details should any discrepancies arise
in other languages.
Untitled-4 4/10/03, 1:56 PM5

EN
Unpacking Your System
You should have:
• One main unit (with 2 speakers);
• One remote control;
• One user’s guide;
• One Thomson Warranty Card
Installation
To ensure sufficient ventilation, keep the spacing
shown as below:
Front View
Side View
Getting Started
1
10cm
10cm 10cm
10cm
5cm
Connecting the Speakers
When connecting the speakers, match the red
wires to the red jacks and the black wires to the
black jacks. Each speaker has a black and a red
jack, one for positive and one for negative. The
top two jacks are for the left speaker, while the
bottom two jacks are for the right speaker.
Release tab to lock wire in
the terminal.
NOTE: Make sure the insulation is completely removed from the
ends of the speaker wires at all connection points.
Speaker Wire Connection
Push Speaker terminal tab
down to insert wire.
DIGITAL LOGIC DECK
ON•ECO
DIGITAL PLL SYNTHESIZED TUNER
MULTIFUNCTION LCD DISPLAY
TUNING
IR SENSOR
TIMER
PLAYBACK/ RECORD
OPEN/
CLOSE
V
O
L
U
M
E
C
O
N
T
R
O
L
CD
Using the Antenna
Before you use your audio system, you’ll want to
make sure the FM antenna is positioned properly.
The FM antenna is the coiled wire connected to
the back of the unit. Uncoil it, making sure it is
fully extended (you may even want to tape it to
the wall behind the unit, if possible. The higher,
the better.)
For better AM reception, move or rotate the unit.
RL
Untitled-4 4/10/03, 1:56 PM6

EN
2
CD Micro System
Front View
ON•ECO – Turns on/off the unit. Remember to
unplug the power cord from the power outlet if
you are not going to use the system for some
time. Press and hold to enter ECO mode. In ECO
mode, the power consumption is below 3W.
CD - Selects CD mode.
TUNER/BAND•APP – Selects tuner mode; selects
radio band in tuner mode; begins auto preset
programming.
TAPE – Selects tape mode.
CLOCK•TIMER - Shows clock time and timer on/
off time; enters clock and timer setting mode;
enable or disable timer mode.
PRESET - / + - In tuner mode - selects preset
station.
PROG•SET•CLEAR – Enters program setting
mode; confirms your settings; clears settings.
REC•II - Starts/pauses recording from CD / Tuner
mode.
RDS - In Tuner mode - Shows RDS information in
FM broadcast (station name (RT), station type
(PTY) and clock time (CT)).
EQ - Selects among different sound effects (flat /
classic / rock / pop / jazz).
X-BASS - Enables / disables X-Bass
PLAY/PAUSE ( ) – In CD mode - Plays and
pauses CD playback.
In Tape mode - Plays and pauses tape playback.
STOP ( ) - In CD mode - Stops CD playback.
In Tape mode - Stops tape playback.
TUNING - / + (SKIP BACKWARD / SKIP
FORWARD ) – In CD mode - skips backward
or forward to the other tracks.
In Tape mode - Rewinds or fast forwards tape.
In tuner mode -searches down or up radio
frequency.
VOLUME CONTROL – adjusts the sound level.
Top View
OPEN/CLOSE - Press to open the CD
compartment door.
PHONES - Jack for connecting headphones.
DIGITAL LOGIC DECK
ON•ECO
DIGITAL PLL SYNTHESIZED TUNER
MULTI FUNCTION LCD DISPLAY
TUNING
IR SENSOR
TIMER
PLAYBACK/ RECORD
OPEN/
CLOSE
V
O
L
U
M
E
C
O
N
T
R
O
L
CD
Untitled-4 4/10/03, 1:57 PM7

EN
Remote Control
3
ON•ECO - Turns the unit on/off
EQ - Selects among different sound effects (flat / classic /
rock / pop / jazz)
REPEAT - In CD mode - toggles repeat options (repeat disc /
repeat track / repeat off).
MIX - Selects random playback in CD mode.
CD - Selects CD player.
X-BASS - Enable and disables X-Bass.
INTRO - Selects Intro play in CD mode.
DISPLAY - In CD mode - toggles among displaying track
elapse time, track remain time and disc remain time.
In FM Tuner mode - toggles RDS station information
(Frequency, RDS name, Radio text, RDS type, Clock timer,
RDS day and PI code)
TAPE - Selects tape player.
ST•MO - Toggles stereo and mono mode in FM tuner.
RDS - In Tuner FM mode - Enters to select RDS PTY; radio
text (INFO ON/OFF); RDS Clock/day (SYNC ON/OFF).
BAND/APP - Selects radio bands; starts auto preset
programming.
TUNER - Selects radio tuner.
REC•II - Starts recording or pause recording.
CLK•TIMER - Enters clock and timer setting mode.
SLEEP - Selects sleep time.
PRESET + / - - Selects next / previous preset stations.
SKIP BACKWARD / SKIP FORWARD - In Tuner
mode - Searches down or up radio frequency.
In CD mode - Skips to the previous or next track.
PLAY/PAUSE - In CD mode - Plays disc and pauses CD
playback.
In Tape mode - Plays tape and pauses tape playback.
STOP - Stops CD and tape playback.
MUTE - Mutes Volume.
VOL + / - - Turns up or down volume level.
PROG•SET•CLEAR - Enters program setting mode; confirms
your settings; clears preset station in tuner programming
mode; clears CD program in CD programming mode and
resets tape counter in tape mode.
Installing Batteries
The remote control must be inserted with 2 “AA” or “UM-3” or “R6” batteries prior use. Follow the
steps below to ensure correct installation.
1. Remove the battery compartment door (located at the back of the remote control) by sliding the
compartment door in the direction of the arrow and then lifting the door out and off the cabinet.
2. Before inserting the batteries, observe the polarities (that is, + and -) of the battery, then relate the
polarities to the engraved diagram inside the battery compartment. Now insert the batteries.
3. After installation of the batteries, replace and fit the lid to cover the batteries. Lightly push it close
with a snap.
Untitled-4 4/10/03, 1:57 PM8

EN
Settings
4
Setting Clock Time
Thomson models show time in 24-hour standard.
Manual Setting
1. Press CLOCK•TIMER to enter clock setting
mode. CLK XX:XX will show on the display.
2. Press TUNING - or +to set the hour.
3. Press PROG•SET•CLEAR to shift to the minute
digits.
4. Press TUNING - or +to set the minute.
5. Press PROG•SET•CLEAR to confirm the
setting.
Setting the Timer
1. Press CLOCK•TIMER twice to enter timer on
setting mode. ON XX:XX will show on the
display.
2. Press TUNING - or +to set the hour.
3. Press PROG•SET•CLEAR to move to the
minute digits.
4. Press TUNING - or +to set the minute digits.
5. Press PROG•SET•CLEAR to move to source
selection.
6. Press TUNING - or +to select source (Tape /
Tuner / CD / Rec TU)
7. Press PROG•SET•CLEAR to move to volume
setting.
8. Press TUNING - or +to select desired volume
level.
9. Press PROG•SET•CLEAR to move to timer off
time setting. OFF XX:XX will show on the
display.
10. Repeat steps 3-5 to set timer off hour and
minute.
11. Press PROG•SET•CLEAR to confirm settings.
Timer will be activated automatically after
settings are finished.
Activating the Timer
Press and hold CLOCK•TIMER for 2 seconds on
the main unit to activate and deactivate the timer
function.
If clock time is not set, SET CLK will flash on the
display when you try to activate the timer. Follow
instructions under “Setting Clock Time” to set
clock.
If timer settings have not been entered, SET TMR
will flash on the display when you try to activate
the timer. Follow instructions under ”Setting the
Timer” to enter timer settings.
If timer off time is set as the same as timer on
time, TIMER NG will flash on the display. Set the
correct timer off time again.
Setting Sleep Time
Press SLEEP on the remote control to toggle
among OFF, 90, 80, 70, 60, 50, 40, 30, 20, and 10
minutes.
Sound Features
Preset Equalizer Curves
Press EQ to toggle among FLAT, CLASS, ROCK, POP
and JAZZ.
X-Bass
Press X-BASS to turn on/off the x-bass feature.
Muting Audio
Press MUTE to silence playback.
Display
R
P
Untitled-4 4/10/03, 1:57 PM9

EN
5
Tuner
Searching for a Station
1. Press TUNER/BAND•APP on the main unit or
TUNER on the remote control to select radio
mode.
2. Select a radio band by pressing TUNER/
BAND•APP on the main unit or BAND/APP on
the remote control:
FM – Frequency Modulation
MW – Medium Wave
LW - Long Wave
In FM band, STEREO on the remote to select
between stereo and mono sound.
3. Press TUNING - or +on the main unit or SKIP
BACKWARD or SKIP FORWARD on
the remote control to search for a radio
station. To search automatically, press and
hold TUNING - or + on the main unit or SKIP
BACKWARD or SKIP FORWARD on
the remote control for 1 second.
FM = 87.5 – 108 MHz,
MW = 522 – 1620 KHz,
LW = 150 - 283 KHz
Presetting a Station
1. Press TUNER/BAND•APP on the main unit or
BAND•APP on the remote control to select
band.
2. Press TUNING - or + on the main unit or SKIP
BACKWARD or SKIP FORWARD on
the remote control to select station to be
stored.
3. Press PROG•SET•CLEAR to enter program
mode.
4. Press PRESET - or +to select memory location
(up to 30 memory locations). When you are
selecting the preset location, the preset station
number is flashing.
5. Press PROG•SET•CLEAR to confirm the
setting.
Auto Preset Programming
Press and hold TUNER/BAND•APP on the main
unit or BAND•APP on the remote control to scan
stations in selected band. A maximum of 30
stations can be stored. Beware of your preset
channels being erased accidentally because the
scanning and storing process is automatic upon
pressing the button.
Press any button to stop scanning.
Listening to the Preset
Station
1. Press TUNER/BAND•APP.
2. Press PRESET + / - repeatedly to locate your
desired memory location.
Suppressing Stereo Signal
Press ST•MO on the remote control to toggle
between FM mono and stereo for FM broadcast.
If FM stereo reception is weak, select mono sound
to reduce noise.
Tuning to a RDS Station
(FM only)
1. Press TUNING - or +on the main unit or SKIP
BACKWARD or SKIP FORWARD on
the remote control to select desired frequency
or press PRESET + / - to access preset stations.
2. If RDS station is found, RDS lights on the
display with station name shown.
Displaying RDS station Information
Press DISPLAY on the remote control repeatedly
to display station information:
1. Frequency,
2. RDS name
3. Radio text (RT) “INFO OFF”
Press RDS repeatedly to select “INFO OFF”.
Press PRESET - or +to toggle “INFO OFF” and
“INFO ON”.
4. RDS type (PTY)
RDS NEWS (news), AFFAIRS (current affairs),
INFO (weather, medical), SPORT (sports),
EDUCATE (education), DRAMA (series and
plays), CULTURE (religion), SCIENCE(science and
technology), VARIED (miscellaneous), POP M
(pop music), ROCK M (rock music), MOR M
(middle-of-the road music), LIGHT M (light
music), CLASSICS (classical music), OTHER M
(unclassified music), WEATHER (weather),
Untitled-4 4/10/03, 1:57 PM10

EN
Playing Cassette Tape
1. Press TAPE to select tape mode.
2. Press on the OPEN/CLOSE area to open the
deck door.
3. Load a cassette tape into the deck. Then,
lightly press the deck door closed.
4. Press PLAY/PAUSE to start tape play.
5. Press STOP to stop.
Recording a Radio Program
1. Press TUNER/BAND•APP on the main unit or
BAND•APP on the remote control to select
tuner mode and desired band.
2. Tune to the station you want to record by
pressing TUNING - or + on the main unit or
SKIP BACKWARD or SKIP FORWARD on
the remote control.
3. Press REC•II on the main unit. The REC. icon
will flash on the display. Press REC•II again to
start recording.
4. Press STOP to stop recording.
Press REC•II again to pause recording. To
resume recording, press again.
Tuner
6
Tape Player
FINANCE (financial information), CHILDREN
(children’s program), SOCIAL (social news),
RELIGION (religious program), PHONE IN
(phone-in program), TRAVEL (travel & leisure),
HOBBY (hobby), JAZZ (Jazz music), COUNTRY
(country music), NATIONAL (national), OLDIES
(oldies), FOLK M (folk music), DOCUMENT
(documentary), TEST (test) & ALARM (alarm).
PTY Search
1. Press RDS repeatedly to select “FIND”.
2. Press PRESET - or +to toggle the desired
RDS station type.
3. Press TUNING + or - on the main unit or SKIP
BACKWARD or SKIP FORWARD on the
remote control to begin searching for RDS
stations in the selected category.
4. clock time (CT) - “SYNC OFF”.
Press RDS repeatedly to select “SYNC OFF”. Press
TUNING +or - on the main unit or SKIP
BACKWARD or SKIP FORWARD on the
remote control to toggle “SYNC OFF” and “SYNC
ON”.
5. RDS DAY
6. PI CODE
Recording a CD
1. Press CD to select CD mode.
2. Press SKIP BACKWARD or SKIP FORWARD
to select the track that you want to record.
3. Press REC•II to record. The REC. icon will flash
on the display. Press REC•II again to start
recording. CD automatically starts playback at
the same time.
4. Press STOP to stop recording.
Reset Tape Counter
Press PROG•SET•CLEAR to reset counter.
Untitled-4 4/10/03, 1:57 PM11

EN
7
CD Player
Loading and Playing CDs
1. Push lightly to open the CD door. Load a CD
(with labeled side facing up) into the CD
compartment. Then, close the door by pushing
it down lightly.
2. Press CD to select CD mode and the power will
be turned on automatically.
3. Press PLAY/PAUSE to play and pause CD
playback.
You may:
• skip to other tracks by pressing SKIP
BACKWARD or SKIP FORWARD .
Press and hold SKIP BACKWARD or
SKIP FORWARD to search.
• press REPEAT on the remote control once to
repeat all tracks. REPEAT is shown in the
display simultaneously. Press again to play a
particular track repeatedly, at the same time,
REPEAT 1 is displayed. Press a third time to
de-select the function.
• Press to listen to the tracks randomly.
4. Press STOP to stop playback.
Tip:Tip:
Tip:Tip:
Tip: If the CD compartment is not loaded with
a CD or the CD is unreadable, the message
“NO DISCNO DISC
NO DISCNO DISC
NO DISC” will be shown.
Note: Be sure to remove all discs from the
disc compartment before moving or
transporting the unit!
Setting Intro Play
Intro Play lets you enjoy the CD tracks for 10
seconds. When the last track has played for 10
seconds, the Intro Play stops.
1. Follow step 1 and 2 of “Loading and Playing
CDs” above.
2. Press INTRO on the remote control and the
INTRO icon will be shown.
3. Press PLAY/PAUSE to start playback from
the first track. Press SKIP BACKWARD
or SKIP FORWARD to select a particular
track.
4. Press INTRO again to exit intro play.
Programming
1. Select CD mode by pressing CD.
2. Press PROG•SET•CLEAR after the CD has been
loaded into the system. The message “0 PR 1”
will be shown on the display and PROG.
flashes.
3. Press SKIP BACKWARD or SKIP
FORWARD to select a track to be stored
into memory location 1.
4. Press PROG•SET•CLEAR to confirm your
selection and store that track into memory.
Repeat step 3 and this step to store additional
tracks. A maximum of 20 tracks can be stored
into memory.
5. Press PLAY/PAUSE to run the preset
program. When the unit is playing the
program, “PROG” icon will be displayed.
6. Press PROG•SET•CLEAR in CD programming
mode and press and hold STOP to clear the
stored program.
Notes to CD-R/RW
This unit is compatible with CD-RW/ CD-R discs
for playback.
• Do not affix any type of labels to either side
(recordable or labeled side) of a CD-R/RW disc
as this may result in the unit malfunctioning.
• To avoid damages to the CD-R/RW disc, do not
open the disc compartment door while the
disc is being read.
• Do not load an unrecorded CD-R/RW disc into
the unit. This may take a longer time to read
the disc.
• Playback capability for CD-RW discs may
vary due to variations in the quality of
the CD-RW disc and the recorder used to
create the disc.
ON•ECO
DIGITAL PLL SYNTHESIZED TUNER
MULTI FUNCTION LCD DISPLAY
TUNING
IR SENSOR
TIMER
V
O
L
U
M
E
C
O
N
T
R
O
L
CD
Untitled-4 4/10/03, 1:57 PM12

EN
Troubleshooting Tips
Problem
System will
not turn on
No sound
Poor radio
reception
CD does not
play
CD sound
skips
Solution
• Check power cord for a secure
connection.
• Unplug the unit for a moment,
and then plug into power source
again.
• Check the outlet by plugging in
another device.
• Increase the volume setting.
• Check connection to speakers.
• Check that you have selected the
appropriate function: CD, TAPE,
Tuner.
• Make sure mute is off.
• Make sure headphones are not
plugged in.
• Check antenna connection.
• Move antenna.
• Turn off nearby electrical
appliances, such as hair dryer,
vacuum cleaner, microwave,
fluorescent lights.
• Check that CD is in the tray.
• Check that CD label is facing up.
• Check that PAUSE mode is not
on.
• Check that CD function is
selected.
• Use CD lens cleaner.
• Clean the disc.
• Try another disc
• Clean the disc.
• Check disc for warping,
scratches, or other damage.
• Check if something is causing
the system to vibrate. If so, move
the system.
• Make sure the speakers are at
least 3 feet away or on a different
surface from the main unit.
8
Problem
CD button
will not
respond
Distorted or
noisy tape
recordings
Remote
control does
not work
Solution
• Switch to another function (TAPE,
Tuner) and then back to CD.
• Inspect the tape head, clean it if
neccessary.
• Check that the batteries are
properly installed.
• Replace weak batteries.
• Check the system is plugged into
power source.
• Point the remote directly at the
system’s front panel.
• Move closer to the system.
• Remove any obstacles between
the remote and the system.
Untitled-4 4/10/03, 1:57 PM13

EN
9
Maintenance
Disconnect the audio system from the power
source before performing any maintenance.
Cleaning
Clean the exterior of the system using a soft dust
cloth.
CD Player
CAUTION! This system operates with a laser. It
must be opened by only a qualified technician.
Tape Player
To prevent deterioration of sound quality,
periodically open the door of each deck and clean
the magnetic heads, pinch roller, and capstan with
a cotton bud dipped in alcohol. Also,
demagnetize the head by playing a
demagnetizing cassette (available through an
audio equipment store).
To protect recordings on one or both sides of a
tape, remove the corresponding tab. If you later
want to record on the tape, affix a piece of
adhesive tape over the hole.
A
Quit Slacking - A little bit of
slack in your tapes can cause
scratches on the tape, or worse
yet, the tape could break. If
you notice some slack in the
tape, use a pencil to tighten it
up before you insert it.
Handling CDs
• Do not touch the signal surfaces. Hold CDs by
the edges, or by one edge and the hole. Do not
affix labels or adhesive tapes to the label surfaces.
Do not scratch or damage the label. CDs rotate at
high speeds inside the player. Do not use
damaged (cracked or warped) CDs
Cleaning CDs
• Dirty CDs can cause poor sound quality. Always
keep CDs clean by wiping them gently with a soft
cloth from the inner edge toward the outer
perimeter.
• If a CD becomes dirty, wet a soft cloth in water,
wring it out well, wipe the dirt away gently, and
then remove any water drops with a dry cloth.
• Do not use record cleaning sprays or antistatic
agents on CDs. Also, never clean CDs with
benzene, thinner, or other volatile solvents which
may cause damage to disc surface
CD Lens Care
When your CD lens gets dirty it can also cause the
system to output poor sound quality. To clean the
lens you will need to purchase a CD lens cleaner
which can maintain the output sound quality of
your system. For instructions
on cleaning the CD lens, refer to the ones
accompanying the lens cleaner.
Untitled-4 4/10/03, 1:57 PM14

EN
More Information
Safety Precautions
• Never open the cabinet under any
circumstances. Any repairs or internal
adjustments should be made only by a trained
technician.
• Never operate this product with the cabinet
removed.
•Do not use your System immediately after
transporting it from a cold place to a warm
place, as condensation may cause the system to
malfunction.
• Keep your unit away from humid areas and
abnormally hot places.
• Do not touch the player with wet hands. If any
liquid enters the player cabinet, take the player
to a trained technician for inspection.
• This compact disc player uses a laser to read the
music on the disc. The laser mechanism
corresponds to the cartridge and stylus of a
record player. Although this product incorporates
a laser pick-up lens, it is completely safe when
operated according to directions.
• Discs rotate at high speed inside the
player. Do not use damaged, warped, or cracked
discs.
• Do not touch the pick-up lens which is located
inside the disc compartment. To keep dust from
collecting on the pick-up lens, do not leave the
compartment door open for an extended period
of time. If the lens becomes dirty, clean it with a
soft brush, or use an air blower brush designed
for camera lenses.
• The apparatus shall not be exposed to dripping
and splashing.
Headset Safety
• Do not play your headset at high volume.
Hearing experts warn against extended high-
volume play.
• If you experience ringing in your ears, reduce
volume or discontinue use.
• You should use with extreme caution or
temporarily discontinue use in potentially
hazardous situations.
Even if your headset is an open-air designed to
let you to hear outside sounds, do not turn up
the volume so high that you are unable to hear
what is around you.
Important Battery
Information
• Remove the batteries to avoid leakage if you
do not use your remote control for more than
one month.
• Discard leaky batteries immediately as leaking
batteries may cause skin burns or other personal
injuries. Dispose of batteries in the proper
manner, according to provincial and local
regulations.
• Any battery may leak electrolyte under the
following circumstances:
- if mixed with a different battery type,
- if inserted incorrectly,
- if all batteries are not replaced at the same
time,
- if disposed of in fire, or
- if an attempt is made to charge a battery not
intended to be recharged
Don’t Infringe
This product should only be used for the
purposes for which it is sold, that is,
entertainment, violating no copyright law. Any
attempts to use this product for which it is not
intended is unlawful and therefore not
condoned by Thomson.
Technical Specification
Power supply: 230V~50Hz
Dimensions ( H x W x D mm):
Unit size - 237 x 146 x 231
Speaker - 237 x 145 x 160
Tape deck: Response curve: 125Hz-8kHz (-5dB)
CD player: Response curve (+/- 2dB): 60Hz to
20 kHz
Rating Plate: Look for it at the back of the set.
10
Untitled-4 4/10/03, 1:57 PM15

THOMSON multimedia
46/47 quai A. Le Gallo
92648 Boulogne Cedex
FRANCE
RCS nanterre
B 322 019 464
55756120
www.thomson-multimedia.com
Untitled-4 4/10/03, 1:56 PM2
