THORLABS PDA400 User manual

2151-D02 REV F 8/15/2005
Page 1 of 5
PO Box 366, 435 Route 206N, Newton, NJ 07860
Ph [phone], Fax [phone], http://www.thorlabs.com
PDA400 Operating Manual - Switchable Gain, Amplified InGaAs Detector
Description:
The PDA400 is an amplified, switchable-gain, InGaAs detector designed for detection of light signals from DC to 10
MHz. A five-position rotary switch allows the user to vary the gain in 10 dB steps. A buffered output drives a 50Ω
load impedance up to 5 volt. The PDA400 housing includes a removable threaded coupler that is compatible with
any number of Thorlabs 1” threaded accessories. This allows convenient mounting of external optics, light filters,
apertures, as well as providing an easy mounting mechanism using the Thorlabs cage assembly accessories.
The PDA400 has an 8-32 tapped mounting hole with a 0.25” mounting depth and includes a 120VAC power AC/DC
supply. The PDA400-EC has an M4 tapped mounting hole and includes a 230VAC AC/DC power supply.
Specifications:
Note 1: The PDA400 has a 50Ωseries termination resistance (i.e. in series with amplifier output). This forms a voltage divider
with any load impedance (e.g. 50Ωload divides signal in half).
2: Newer PDA’s have a smaller package diameter to easily fit into Thorlabs cage plate assemblies. Also note that the
length includes the SM1T1 mounting adapter and the BNC / power switch.
Setup
•Unpack the optical head, install a Thorlabs TR-series ½” diameter post into the 8-32 (M4 on -EC version) tapped
hole on the bottom of the head, and mount into a PH-series post holder.
•Connect the power supply 5-pin DIN plug into the mating receptacle on the PDA400.
•Plug the power supply into a 50-60Hz, 100-120VAC outlet (220-240VAC for -EC version).
Detector Performance min typical max
Detector InGaAs 0 dB Setting
Active Diameter 1 mm Transimpedance Gain11.5 x 104V/A
Response 800 to 1750 nm Trans. Gain (50Ω)1 0.75 x 104V/A
Peak Response 0.95 A/W @ 1550
nm Bandwidth
10 MHz
Bandwidth DC to 10MHz Noise (RMS)
0.28 mV 0.33 mV 0.44 mV
NEP (1310nm, 0dB) 8.2 x 10-12 W/√Hz Offset
-5 mV 6 mV 15 mV
NEP (1310nm, 10dB) 6 x 10-12 W/√Hz 10 dB Setting
NEP (1310nm, 20dB) 3.8 x 10-12 W/√Hz Transimpedance Gain14.7 x 104V/A
NEP (1310nm, 30dB) 3.4 x 10-12 W/√Hz Trans. Gain (50Ω)1 2.35 x 104V/A
NEP (1310nm, 40dB) 2.9 x 10-12 W/√Hz Bandwidth
2.2MHz
Output Voltage (50Ω)0 to 5V Noise (RMS)
0.30 mV 0.35 mV 0.45 mV
Output Voltage10 to 10V Offset
-5 mV 8 mV 15 mV
Output Impedance150Ω20 dB Setting
Load Impedance1Hi -Z to 50ΩTransimpedance Gain11.5 x 105V/A
Gain Steps 0, 10, 20, 30, 40
dB Trans. Gain (50Ω)1 0.75 x 105V/A
Gain Switch 5-Pos Rotary
Switch Bandwidth
700kHz
On / Off Switch Toggle Noise (RMS)
0.36 mV 0.40 mV 0.46 mV
Output BNC Offset
-10 mV 10 mV 20 mV
Damage Threshold 100mW CW 30 dB Setting
0.5J/cm210ns PW Transimpedance Gain14.7 x 105V/A
Optical Head Size2φ1.425” x 1.45” Trans. Gain (50Ω)1 2.35 x 105V/A
Weight 60 grams Bandwidth
160kHz
Accessories SM1T1 Coupler Noise (RMS)
0.48 mV 0.53 mV 0.60 mV
Storage Temp -40 to 125°C Offset
-20 mV 20 mV 50 mV
Operating Temp -40 to 85°C 40 dB Setting
AC Power Supply AC - DC Converter Transimpedance Gain11.5 x 106V/A
Input Power 100-120VAC, Trans. Gain (50Ω)1 0.75 x 106V/A
(220_240VAC -EC Bandwidth
50kHz
version) Noise (RMS)
0.74 mV 0.81 mV 1.0 mV
50-60Hz, 5W Offset
-100 mV 20 mV 100 mV

2151-D02 REV F 8/15/2005
Page 2 of 5
•Attach a 50Ωcoax cable (i.e. RG-58U) to the output of the PDA. When running cable lengths longer than 12” we
recommend terminating the opposite end of the coax with a 50Ωresistor (Thorlabs p/n T4119) for maximum
performance.
Operation
•The PDA400 gain is adjusted using a small slotted screwdriver to turn the internal, gain-setting rotary switch. An
access hole labeled GAIN is provided on the rear panel for this purpose. The gain is set to 0dB, when the slot is
aligned counterclockwise as far as it will go. Each clockwise click of the switch increases the gain by 10 dB. Do
not use excessive force when adjusting the gain switch.
•The PDA400 is switched on by the POWER toggle switch on the rear of the head.
•The light to voltage conversion can be estimated by factoring the wavelength-dependent responsivity of the
InGaAs detector with the transimpedance gain
(e.g. output in volts / watt = transimpedance gain (V/A) x responsivity (A/W) )
•The maximum output of the PDA400 is 10 volts for high impedance loads (5V for 50Ωloads). Adjust the gain so
that the measured signal level out of the PDA400 is below 10 volts (5 volts with a 50Ωload) to avoid saturation.
If necessary, use external neutral density filters to reduce the input light level.
•For maximum linearity performance when measuring focused beams, fiber outputs, or small diameter beams, do
not exceed a maximum intensity of 10mW/cm2.
•Because of the finite gain-bandwidth performance common to all amplifier circuits, the bandwidth of the PDA400
goes down with increased gain settings.
Fiber Adapters and Other Accessories
Thorlabs sells a number of accessories that are compatible with the 1” thread on the PDA housing including FC,
SMA, and ST fiber adapters, stackable lens tubes for mounting optics, and cage assemblies that allow the PDA to
be incorporated into elaborate 3-D optical assemblies.
Caution: The PDA400 was designed to allow maximum accessibility to the photodetector by having the front surface
of the diode extend outside of the PDA housing. When using fiber adapters, make sure that the fiber ferrule does not
crash into the detector. Failure to do so may cause damage to the diode and / or the fiber. An easy way to
accomplish this is to install a SM1RR retaining ring (included with the PDA55) inside the 1” threaded coupler before
installing the fiber adapter.
Also available in the PDA series are and higher bandwidth silicon and InGaAs models.
Maintaining the PDA400
There are no serviceable parts in the PDA400 optical head or power supply. The housing may be cleaned by wiping
with a soft damp cloth. The window of the detector should only be cleaned using optical grade wipes. If you suspect
a problem with your PDA400 please call Thorlabs and an engineer will be happy to assist you.
Gain Switch
position Gain (dB) Transimpedance Gain (V/A)
1 0 1.5 x 104
2 10 4.7 x 104
3 20 1.5 x 105
4 30 4.7 x 105
5 40 1.5 x 106
Table 1. Gain Settings

2151-D02 REV F 8/15/2005
Page 3 of 5
WEEE
As required by the WEEE (Waste Electrical and Electronic Equipment Directive) of the European Community and
the corresponding national laws, Thorlabs offers all end users in the EC the possibility to return “end of life” units
without incurring disposal charges.
This offer is valid for Thorlabs electrical and electronic equipment
•sold after August 13th 2005
•marked correspondingly with the crossed out “wheelie bin” logo (see fig. 1)
•sold to a company or institute within the EC
•currently owned by a company or institute within the EC
•still complete, not disassembled and not contaminated
As the WEEE directive applies to self contained operational electrical and electronic products, this “end of life” take
back service does not refer to other Thorlabs products, such as
•pure OEM products, that means assemblies to be built into a unit by the user (e. g. OEM laser driver cards)
•components
•mechanics and optics
•left over parts of units disassembled by the user (PCB’s, housings etc.).
If you wish to return a Thorlabs unit for waste recovery, please contact Thorlabs or your nearest dealer for further
information.
Waste treatment on your own responsibility
If you do not return an “end of life” unit to Thorlabs, you must hand it to a company specialized in waste recovery. Do
not dispose of the unit in a litter bin or at a public waste disposal site.
Ecological background
It is well known that WEEE pollutes the environment by releasing toxic products during decomposition. The aim of
the European RoHS directive is to reduce the content of toxic substances in electronic products in the future.
The intent of the WEEE directive is to enforce the recycling of WEEE. A controlled recycling of end of live products
will thereby avoid negative impacts on the environment.
Crossed out “wheelie bin” symbol

2151-D02 REV F 8/15/2005
Page 4 of 5
Detector Response Curve
PDA400 Responsivity
0
0.1
0.2
0.3
0.4
0.5
0.6
0.7
0.8
0.9
1
800 900 1000 1100 1200 1300 1400 1500 1600 1700 1800
Wavelength (nm)
Responsivity (A/W)

2151-D02 REV F 8/15/2005
Page 5 of 5
SWITCHABLE GAIN AMPLIFIED InGaAs SENSOR
BB 1 11" = 1"
PDA400
GAIN
OFF
ON
12" CABLE
LENGTH
(TYP)
COM
-12V
EARTH
GND
+12V
N/A
END VIEW OF 5-PIN DIN
RECEPTACLE ON DETECTOR
DC POWER INPUT
0.68" 0.87"
Ø1.43" DIA.
0.67"
0.95"
0.33"
0.05"
1.035-40 THREAD
#8-32 TAPPED TO 1/4" DEPTH
(M4 TAP FOR -EC VERSION)
SM1T1 THEADED
COUPLER (REMOVABLE)
CROSS SECTION VIEW X-X
XX
Ø1mm InGaAs DETECTOR
COPYRIGHT ©2002 by THORLABS INC.
INFORMATION ONLY, NOT FOR MANUFACTURING
