THORLABS GANYMEDE User manual

GANYMEDE
Spectral Domain OCT System
Operating Manual

Spectral Domain OCT System
21209-D02 Rev D, September 29, 2011 Page 2 www.thorlabs.com
Table of Contents
Part 1. Introduction..................................................................................................................................7
1.1. Safety.........................................................................................................................................................8
1.2. Care and Maintenance.............................................................................................................................9
1.2.1. Optical Cleaning.........................................................................................................................................9
1.2.2. Service......................................................................................................................................................10
1.2.3. Accessories and Customization................................................................................................................10
Part 2. Description .................................................................................................................................11
2.1. Theory.....................................................................................................................................................11
2.1.1. Spectral Domain OCT Technology..........................................................................................................11
2.1.2. Nomenclature in OCT imaging ................................................................................................................12
2.2. System Components...............................................................................................................................14
2.2.1. Packing List..............................................................................................................................................14
2.2.2. Base Unit..................................................................................................................................................16
2.2.3. Imaging Probe ..........................................................................................................................................17
2.2.4. Probe Stand ..............................................................................................................................................20
2.2.5. Graphical User Interface...........................................................................................................................23
2.2.6. SDK..........................................................................................................................................................23
2.3. Warning Text..........................................................................................................................................24
Part 3. Installation .................................................................................................................................25
3.1. Unpacking...............................................................................................................................................25
3.2. System Connections ...............................................................................................................................25
3.3. System Installation.................................................................................................................................27
Part 4. System Operation.......................................................................................................................34
4.1. Starting the System................................................................................................................................34
4.2. Basic Adjustments..................................................................................................................................34
4.2.1. Adjusting the Focus..................................................................................................................................34
4.2.2. Adjusting the Reference Intensity ............................................................................................................35
4.2.3. Adjusting the Reference Length...............................................................................................................35
4.3. Shutting Down the System.....................................................................................................................36
4.4. Example Images .....................................................................................................................................37
Part 5. Imaging Artifacts .......................................................................................................................39
5.1. Saturation and Non-Linearity...............................................................................................................39
5.2. Wrong Reference Intensity Setting.......................................................................................................40
5.3. Auto-Interference...................................................................................................................................41
5.4. Multiple Scattering.................................................................................................................................42
5.5. Phase Wrapping and Fringe Washout.................................................................................................43
5.6. Flipped Image.........................................................................................................................................44
5.7. Shadowing...............................................................................................................................................45

Spectral Domain OCT System
21209-D02 Rev D, September 29, 2011 Page 3 www.thorlabs.com
5.8. Image distortion by Refractive Media..................................................................................................46
5.8.1. The group refraction index.......................................................................................................................47
5.8.2. Measurement Depth in OCT Systems ......................................................................................................48
5.8.3. Distortions in the Image ...........................................................................................................................49
Part 6. Troubleshooting.........................................................................................................................51
6.1. Changing the Input Fuses......................................................................................................................52
Part 7. Certifications and Compliance..................................................................................................53
Part 8. Warranty.....................................................................................................................................54
8.1. Lasers and Imaging Systems.................................................................................................................54
8.2. Non-Warranty Repairs..........................................................................................................................54
8.3. Warranty Exclusions .............................................................................................................................54
Part 9. Specifications .............................................................................................................................55
Part 10. Mechanical Drawings................................................................................................................56
Part 11. Regulatory ..................................................................................................................................58
11.1. Waste Treatment is Your Own Responsibility....................................................................................58
11.2. Ecological Background..........................................................................................................................58
Part 12. Thorlabs Worldwide Contacts ...................................................................................................59

Spectral Domain OCT System
21209-D02 Rev D, September 29, 2011 Page 4 www.thorlabs.com
Table of Figures
Figure 1 Schematic Diagram of the SD-OCT System ....................................................................... 11
Figure 2 A-scan data set..................................................................................................................... 12
Figure 3 B-scan data set ..................................................................................................................... 12
Figure 4 Rendered volumetric data set............................................................................................... 13
Figure 5 En-Face view or C-scan....................................................................................................... 13
Figure 6 Base Unit.............................................................................................................................. 16
Figure 7 Imaging Probe (front view).................................................................................................. 17
Figure 8 Imaging Probe (rear view) ................................................................................................... 17
Figure 9 Optical Layout of Imaging Probe ........................................................................................ 18
Figure 10 Reference Intensity Adjustment........................................................................................... 18
Figure 11 Reference Length Adjustment ............................................................................................. 19
Figure 12 Probe Stand with Probe........................................................................................................ 20
Figure 13 OCT Stand Coarse Adjustment and Cable Clip(rear view)................................................. 21
Figure 14 OCT Stand Adjusters and Dove Tail Slide.......................................................................... 21
Figure 15 OCT Stand Sample Station.................................................................................................. 22
Figure 16 Laser Emission Warning Labels.......................................................................................... 24
Figure 17 Base Unit Warning Labels................................................................................................... 24
Figure 18 Imaging Probe Warning Label............................................................................................. 24
Figure 19 Rear View of Base Unit....................................................................................................... 25
Figure 20 Top view of the Probe with Interconnections...................................................................... 26
Figure 21 GigE Ethernet adapter for connection to Base Unit............................................................. 26
Figure 22 Mounting the Probe into the dove tail slide of the OCT Stand............................................ 27
Figure 23 CameraLink frame grabber card inside the PC.................................................................... 28
Figure 24 GigE cable connected to base unit (A) and PC (B) ............................................................. 28
Figure 25................................................................................................................................................... 28
Figure 26 Plugging the probe connector into the probe....................................................................... 29
Figure 27 Probe connector plugged into probe.................................................................................... 29
Figure 28 Installation of the fiber at the Probe fiber connector ........................................................... 30
Figure 29 Installing the probe connection at the base unit................................................................... 31
Figure 30 Installation of the fiber at the base unit Connector.............................................................. 32
Figure 31 Protective Cap Removal ...................................................................................................... 33
Figure 32 Basic focus adjustment ........................................................................................................ 34
Figure 33 B-scan of an IR viewing card............................................................................................... 36
Figure 34 B-scan of a nailfold.............................................................................................................. 37
Figure 35 B-scan of a fingertip............................................................................................................. 37
Figure 36 B-scan of a semi-transparent molded plastic cap................................................................. 38
Figure 37 B-scan of a laminated IR card (not included)...................................................................... 38
Figure 38 B-scan of a section of a grape.............................................................................................. 38
Figure 39 High surface reflection causing saturation and nonlinear response of the spectrometer..... 39
Figure 40 Avoiding strong surface reflection by use of an immersed wedge...................................... 40
Figure 41 OCT images acquired with low (A), high (B) and good (C) reference intensity setting..... 40
Figure 42 Auto-interference from a highly reflective sample in a B-scan........................................... 41
Figure 43 Auto-interference with the reference arm of the imaging probe blocked............................ 41
Figure 44 Schematic of a setup to show the influence of multiple scattering...................................... 42
Figure 45 OCT image showing multiple scattering ............................................................................. 42
Figure 46 Sample image showing fringe washout and phase wrapping .............................................. 43

Spectral Domain OCT System
21209-D02 Rev D, September 29, 2011 Page 5 www.thorlabs.com
Figure 47 Correct reference length adjustment for imaging of an IR card .......................................... 44
Figure 48 Incorrect reference length adjustment showing a flipped image ......................................... 44
Figure 49 Rendered volume of a screw on an IR viewing card displaying the shadowing effect ....... 45
Figure 50 Schematic of a setup to show distortions from refractive media......................................... 46
Figure 51 Height shift of OCT imaging through refractive media....................................................... 46
Figure 52 Measurement depth with refractive media........................................................................... 48
Figure 53 Different materials in one measurement.............................................................................. 49
Figure 54 Complex structure in image................................................................................................. 50
Figure 55 Fuse cover on base unit rear panel....................................................................................... 52
Figure 56 base unit dimensions............................................................................................................ 56
Figure 57 Imaging probe dimensions................................................................................................... 56
Figure 58 Dimension of the rotation stage underneath the sample plate ............................................. 57

Spectral Domain OCT System
21209-D02 Rev D, September 29, 2011 Page 6 www.thorlabs.com

Spectral Domain OCT System
21209-D02 Rev D, September 29, 2011 Page 7 www.thorlabs.com
Part 1. Introduction
ATTENTION
Please read the instruction manual carefully before operating the SD-OCT system. All
statements regarding safety and technical specifications will only apply when the unit is
operated correctly.
This equipment is intended for laboratory use only and is not certified for medical
applications, including but not limited to life support situations.
Refer to this manual whenever the following symbols are encountered on the SD-OCT system:
Attention symbol indicates that additional information is given in this manual.
Laser Safety symbol indicates that laser radiation is present.
ATTENTION
Check the supply voltage of the system before plugging in the computer. Make sure the
included power cords for the base unit, computer, and monitor are connected to a properly
grounded outlet (100 –240 VAC; 50 –60 Hz).
Transportation and delivery may cause the SD-OCT system to be warm or cool upon receipt.
Please wait for the system to reach room temperature before attempting to operate.
Operate this system on a flat, dry, and stable surface only.
WARRANTY WARNING
Do not open the base unit, Imaging probe or PC. There are no user serviceable parts in this
product. Opening the device will void your warranty. Any modification or servicing of this
system by unqualified personnel renders Thorlabs free of any liability. This device can only
be returned when packed into the complete original packaging, including all foam packing
inserts. If necessary, ask for replacement packaging.

Spectral Domain OCT System
21209-D02 Rev D, September 29, 2011 Page 8 www.thorlabs.com
1.1. Safety
SHOCK WARNING –HIGH VOLTAGE
Before applying power to the system, make sure that the protective conductor of the three-
conductor mains power cord is correctly connected to the protective earth contact of the
socket outlet. Improper grounding can cause electrical shock resulting in severe injury or
even death. Make sure that the line voltage rating agrees with your local supply and that the
appropriate fuses are installed. Fuses should only be changed by qualified service personnel.
Contact Thorlabs for assistance. Do not operate without cover installed. Refer servicing to
qualified personnel.
ATTENTION
Do not obstruct the air-ventilation slots in the computer housing. Do not obstruct air-
ventilation into the bottom of the base unit or out of the exhaust fan on the rear of the unit.
Mobile telephones, cellular phones, or other radio transmitters are not to be used within the
range of three meters of this unit, since the electromagnetic field intensity may exceed the
maximum allowed disturbance values according to IEC 61000-6-1:2005.
LASER RADIATION WARNING
Laser emission may be emitted
a) from the scan lens of the probe (intended use)
b) from the back of the base unit when the fiber cap is removed and the fiber disconnected
c) from the output of the fiber when the fiber is not connected to the probe
Do not look into the optical output when the device is operating. The laser radiation is not
visible to the human eye and can cause serious damage to your eyesight.
UNSICHTBARE LASERSTRAHLUNG
NICHT DIREKT MIT OPTISCHEN
INSTRUMENTEN BETRACHTEN
LASER KLASSE 1M
KLASSIFIZIERT NACH DIN EN 60825-1:2008
INVISIBLE LASER RADIATION
DO NOT STARE INTO BEAM OR VIEW
DIRECTLY WITH OPTICAL INSTRUMENTS
CLASS 1M LASER PRODUCT
CLASSIFIED ACCORDING TO DIN EN 60825-1:2008

Spectral Domain OCT System
21209-D02 Rev D, September 29, 2011 Page 9 www.thorlabs.com
1.2. Care and Maintenance
Handle the system with care during transportation and unpacking. Banging or dropping the system can
damage the unit or lower system performance. If the system is mishandled during shipment, the optical
components may become misaligned, which could lead to a decrease in image quality. If this occurs, the
system will need to be realigned by qualified personnel. If the system is dropped from a height greater
than 15", Thorlabs will need to perform an electrical security check. Please contact Thorlabs Technical
Support for more information.
Do not store or operate in a damp, closed environment.
Do not store or operate on surfaces that are susceptible to vibrations.
Do not expose to direct sunlight.
Do not use solvents on or near the equipment.
Keep away from dust, dirt, and air-borne pollutants (including cigarette smoke). The system is
not designed for outdoor use. Protect the equipment from rain, snow, and humidity.
Do not expose to mechanical and thermal extremes. Protect the equipment from rapid variation
in temperature.
Handle all connectors, both electrical and optical, with care. Do not use unnecessary force, as
this may damage the connectors.
Handle the optical fiber with care. Mechanical stress can decrease performance and potentially
destroy the fiber. Continual bending of the optical fiber can cause damage. It is important,
therefore, to keep the optical fiber patch cable as straight as possible to minimize bending.
Note: The most common cause of low signal intensity is contamination of the fiber due to airborne
pollutants. To minimize exposure, avoid unnecessarily disconnecting the optical fiber patch cable. In
addition, it is advisable to check the fiber before making other adjustments to the optical system, such as
changing the focus or optical path length. Be sure to check the patch cord for a loose connection, and
make sure that the fiber is kept as straight as possible.
All lasers, especially lasers with resonator cavities that are defined by mechanical tolerances, are
delicate precision instruments and must be handled accordingly. The SD-OCT system is designed to
withstand normal transportation and operating conditions. Do not move the system while it is connected
and in operation.
1.2.1. Optical Cleaning
Good performance and image quality of the OCT microscope relies on clean optical connections.
Whenever using the Thorlabs OCT system, the following guidelines for optical fiber connection should
be followed:
1) Always inspect and clean the fiber end before plugging it into a receptacle.
2) Always cover the fiber end that is not in use with a fiber cap or dust protection cover.

Spectral Domain OCT System
21209-D02 Rev D, September 29, 2011 Page 10 www.thorlabs.com
1.2.2. Service
Only trained and approved Thorlabs personnel are allowed to service the system. Please contact
Thorlabs Technical Support for more information.
1.2.3. Accessories and Customization
The GANYMEDE Spectral Domain OCT System can easily be adapted for custom interfaces. To
achieve the listed specifications however this system should only be used with the accessories that
Thorlabs provides. Any modification or maintenance by unqualified personnel will render the warranty
null and void, leaving Thorlabs free of liability. Please contact Thorlabs Technical Support for questions
on customization.

Spectral Domain OCT System
21209-D02 Rev D, September 29, 2011 Page 11 www.thorlabs.com
Part 2. Description
2.1. Theory
2.1.1. Spectral Domain OCT Technology
Spectral Domain Optical Coherence Tomography (SD-OCT) is a measurement method based on the
detection of optical path length differences. It incorporates a broadband light source with a high-speed
spectrometer to provide depth profiles that can be added to cross-sectional images. These cross-sectional
images can be used for 3-dimensional reconstructions.
SD-OCT uses Fourier Domain technology to determine the optical properties of an unknown sample by
analyzing the back-reflected and scattered light from an illuminated volume of the sample. The light of a
broadband source travels to the sample and illuminates it perpendicularly and with a small focus that
provides a good lateral resolution. The back-scattered light travels to the spectrometer where the unique
phase delay for each wavelength is detected. The depth information is acquired using a Fast Fourier
Transformation (FFT).
Figure 1 Schematic Diagram of the SD-OCT System
When added to a 2-dimensional image, the two main features of the scanned image are the axial and
lateral resolutions. The axial resolution does not depend on the optics; it is driven by the spectral
bandwidth of the light. The lateral resolution, on the other hand, is affected by the chosen application
optics.

Spectral Domain OCT System
21209-D02 Rev D, September 29, 2011 Page 12 www.thorlabs.com
The SD-OCT system has four main parts: the base unit, a PC and a probe with probe stand (see Figure 1
above for a schematic diagram of the SD-OCT system).
2.1.2. Nomenclature in OCT imaging
As described before, the SD-OCT engine creates a depth profile from the interference of photons sent
into the sample and received back with photons reflected in the reference arm. This depth profile is
referred to as A-scan. Figure 2 shows a tomato’s A-scan data.
Figure 2 A-scan data set
The imaging probe is equipped with two galvanometer driven scanners. When scanning one mirror
while collecting multiple A-scans, a 2-dimensional image is created. This is referred to as a B-scan.
Here, the depth information is typically displayed from top to bottom, while the scan axis in Figure 2 is
from left to right. Figure 3 shows a B-scan data set.
Figure 3 B-scan data set

Spectral Domain OCT System
21209-D02 Rev D, September 29, 2011 Page 13 www.thorlabs.com
When scanning both galvanometer mirrors, a volume can be acquired. This can be imaged by movable
sections through the volume or by 3D rendering (see Figure 4). Please refer to the SD-OCT Software
Manual for all features available.
Figure 4 Rendered volumetric data set
When displaying a plane with both scan directions as axes, an en-face image is created. Here, the
viewing plane is parallel to the image plane of the color camera in the probe. This plane is referred to as
C-scan.
Figure 5 En-Face view or C-scan

Spectral Domain OCT System
21209-D02 Rev D, September 29, 2011 Page 14 www.thorlabs.com
2.2. System Components
2.2.1. Packing List
Refer to the packing lists below to ensure that the system is complete. If any item is missing, contact
Thorlabs for assistance. Do not use your own spare parts. Please use the appropriate tools when
assembling a Spectral Domain SD-OCT system and handle all components of the system with care.
GANYMEDE System Box
This box should contain:
Qty
Part
Part
1
OCT Base Unit GANYMEDE 930nm
1
OCT 3D Probe LSM03
1
Distribution DVD -- OCT System Software
1
Manual SD-OCT Software
1
Manual SD-OCT GANYMEDE
1
Power Cord
1
USB-Cable, 2m, A-B, USB 2.0
2
Fuse 2A (T), 5x20mm, Littlefuse 218P
1
Viewing Card for 400-640nm & 800-1700nm
1
Connection cable set 2m,NIR-a,Base-unit<-->Probe
1
Fiber Patch Cord, nufern-780HP, 2m, FC/APC
1
GigE Data Cable with Neutrik plug (Cat.6)

Spectral Domain OCT System
21209-D02 Rev D, September 29, 2011 Page 15 www.thorlabs.com
Computer Box
This box should contain:
Qty
Part
1
Computer for operating Ganymede
1
Power Cord, for Computer
1
TFT Display for OCT-Computer (AIO)
1
Power Cord, for TFT Display
1
Dell Tastatur Quietkey USB
1
Dell Laser Mouse (6 buttons)
Probe Stand Box
This box should contain:
Qty
Part
1
Baseplate with translation & rotation stage
1
Post
1
Fokus Block
1
Safety Ring
1
1/4"-20 Cap Screw
1
#8-32 Cap Screw
1
3/16" Hex Key
1
9/64" Hex Key
Note: Before operating the system, check to see if any parts have been damaged during transportation. If
so, please contact Thorlabs for further assistance.

Spectral Domain OCT System
21209-D02 Rev D, September 29, 2011 Page 16 www.thorlabs.com
2.2.2. Base Unit
The base unit is the main component of the SD-OCT system. This unit sends light to the application,
communicates with the PC through a USB connection, synchronizes with the camera of the spectrometer
and delivers the measurement data to the PC. The base unit contains a broadband super luminescent
diode (SLD) which is directed through a fiber optical coupler to the probe port at the backside of the
device. The back-scattered and reflected light from the application is returned through the fiber optical
coupler, which directs the light to a spectrometer (as described in Figure 1). Other components in the
base unit include a high-speed linear imaging sensor, analog and digital timing circuitry, analog control
signals for the application, and data acquisition hardware.
Figure 6 Base Unit
The central wavelength of the SLD in this system is 930nm. The use of near-IR broadband sources
balances the desire for low scattering losses with the need to operate within the wavelength range that
will provide higher penetration depth into the sample. Near-IR broadband sources are a perfect
compromise between sufficient transparency and a significantly reduced scattering coefficient.

Spectral Domain OCT System
21209-D02 Rev D, September 29, 2011 Page 17 www.thorlabs.com
2.2.3. Imaging Probe
Thorlabs SD-OCT systems use a common path OCT setup in which the interferometer is located within
the imaging probe (see Figure 7). This integration of the interferometer eliminates the problems
associated with chromatic and polarization mode dispersion that are introduced by differences between
individual fibers in the sample and reference arms. The probe is equipped with a white light illumination
ring.
Figure 7 Imaging Probe (front view)
Figure 8 Imaging Probe (rear view)
Reference Length
Adjustment Knob
Reference Intensity
Adjustment Knob
Ring Light Illumination
Probe Control
Interface
Fiber
Connection
Dove Tail

Spectral Domain OCT System
21209-D02 Rev D, September 29, 2011 Page 18 www.thorlabs.com
Figure 9 Optical Layout of Imaging Probe
Figure 9 illustrates the optical layout of the imaging probe. The output of an FC/APC fiber is collimated
and routed to a beam splitter cube. Here the beam is divided into a sample beam and a reference beam,
similar to a Michelson Interferometer. The sample beam is routed over two galvanometer actuated
mirrors to allow for scanning in two axes. The scan objective then focuses the beam into the sample.
Back-scattered and back-reflected light is collected by the scan objective again and travels back to the
fiber. The light reflected into the reference arm is retro-reflected back into the fiber. There is an
optimum intensity for the reference light that can be adjusted using the reference intensity adjustment
knob which will open or close the variable aperture inside the probe.
Figure 10 Reference Intensity Adjustment
locked
unlocked

Spectral Domain OCT System
21209-D02 Rev D, September 29, 2011 Page 19 www.thorlabs.com
In order to adjust the reference intensity adjustment knob, pull the knob approximately 5mm outwards
(see fig. 10), until you feel the knob coming to a rest. A clock-wise rotation will increase the amount of
reference light. As a qualitative indication, observe the reference intensity bar in the OCT software.
Please refer to the Software Manual and chapter 5.1 in this document for additional guidance.
The length of the reference arm can be adjusted with the reference length adjustment knob (see Figure
11). Adjustment of the reference length may be done in combination with focus height adjustment (using
the OCT stand), so that the focus position in the OCT data is shifted. Also, this adjustment is necessary
when imaging in refractive medium.
Figure 11 Reference Length Adjustment
In order to adjust the reference length adjustment knob, pull the knob approximately 5mm outwards (see
fig.11). A clock-wise rotation will increase the reference length
locked
unlocked

Spectral Domain OCT System
21209-D02 Rev D, September 29, 2011 Page 20 www.thorlabs.com
2.2.4. Probe Stand
The Thorlabs SD-OCT system is shipped with a probe stand. For setting up the probe stand, please
consult the instructions that you find in the probe stand box. The probe stand is equipped with a dove tail
slide for holding the probe.
Figure 12 Probe Stand with Probe
