Chapter 3 Using the OSA
3.1. Introduction
The Redstone Optical Spectrum Analyzer (OSA) is a general-purpose spectrum
analyzer for optical research and production applications. It has a user-friendly
Graphical User Interface (GUI) and can be controlled from a Windows®10 PC via
a High-Speed USB 3.0 port. It is equipped with an FC/PC fiber input receptacle
and a free-space input window for collimated beams up to Ø10 mm; however,
special designs with other input receptacles are available on request. The
frequency-locked reference laser can be accessed via the FC/APC connector on
the front panel. The instrument is designed for measurements of continuous-wave
(CW) light sources but works in some applications where pulsed light is used.
Please contact Technical Support at [e-mail] to discuss your
application if you have a pulsed source.
Figure 1 Front View of the Redstone OSA305
3.1.1. Software
The Redstone OSA305 is shipped with the software package pre-installed on the
laptop computer that is included with the purchase of this instrument. The software
has a customizable GUI for acquiring, inspecting, manipulating, and analyzing
spectra and interferograms. The software makes it easy to locate and track
spectral peaks or valleys, measure the optical input power over any wavelength
range, calculate an absorption spectrum in real-time, or track a large number of
parameters over time.
For usage with other computers the software is downloadable from the webpage.
3.2. Setup and Installation
Place the OSA on a flat and stable surface, and if the free-space input is to be
used, it is recommended to use two Thorlabs CF175 clamping forks on the
Fiber Port
Free-Space Port
Calibration Output

Redstone™ OSA305 Chapter 3: Using the OSA
Page 4 STN053070-D03
mounting feet to secure the OSA to an optical table, as shown in Figure 2. This will
lock the interferometer to the optical table and reduce any vibrations that might
interfere with the measurements.
Figure 2 Using two CF175 clamping forks (marked with arrows), the Interferometer
Assembly can be Locked to the Table
Once the OSA is placed correctly on the table, attach the power cable and connect
the OSA to the computer with the OSA software installed (make sure that the
software is installed on the computer before connecting the OSA), using an
available USB 3.0 port on the PC and the included USB cable. After connecting
the instrument to the PC, the operating system will load the appropriate USB
drivers for the OSA. Please wait for this procedure to finish before doing anything
else.
3.2.1. Starting the Application
Start the application “Thorlabs Redstone OSA.”When the Thorlabs OSA
application starts, it will automatically detect all Thorlabs Redstone Optical
Spectrum Analyzers connected to the PC. A list of all connected OSAs can be
seen by clicking the button “Devices” found under the Instrument menu.

Redstone™ OSA305 Chapter 3: Using the OSA
Rev B, December 15, 2021 Page 5
3.2.2. Overview: Software Interface
Figure 3 The main software interface with different menu selections marked with
arrows, as well as the Status bar and Data display window
The Main menu (see Figure 3) contains all the common commands, from starting
a measurement to analysis of the spectrum and mathematical operations. The
Settings bar is located below the Main menu, providing easy access to common
instrument settings and settings for the axes, 2nd x-axis etc. By clicking a Trace
label, the Trace drop down menu is shown, where one can select input source,
load a spectrum, clear the data, display trace data, and more. The bulk of the
window is made up of the Data display area, where the spectra are plotted. The
Status bar, indicating if the instrument is performing a measurement and
information about the last successful measurement, is shown at the very bottom.
3.3. Optical Alignment
When using the fiber input port, no further alignment is necessary; an internal
reflective collimator will collimate the beam and redirect it into the interferometer.
However, when using the free-space port, it is important to ensure good alignment.
This document will give some general tips; for more details, please see the “Free-
space Alignment Tutorial”, which can be opened by clicking the “Help” button in
the Help menu.
Please ensure that the optical power of the input light does not exceed the
maximum allowed power of 10 mW.
Trace Controls
Main Menu
Settings Bar
Status Bar
Data Display

Redstone™ OSA305 Chapter 3: Using the OSA
Page 6 STN053070-D03
3.3.1. Optical Setup
To simplify the alignment, two mirrors in kinematic mounts should be used between
the test source and the OSA, where one mirror is close to the source and the other
is close to the OSA free-space port. Please see Figure 4 and Figure 5 for
suggestions of mirror placement. If the beam height of your experimental setup is
not consistent with the free-space input, the two mirrors and the distance between
them make it possible to adjust the beam height to that of the OSA’s input. Note
that there is no need to keep the optical path parallel to the optical table until after
the mirror closest to the OSA.
3.3.2. Initial Visual Alignment
Use the mirror closest to the test source to center the input beam on the OSA input.
A viewing card, such as Thorlabs Item #s VRC2 or VRC6S, and/or an alignment
plate, such as Thorlabs Item # CPA2, can be used to aid in the alignment. Then,
open the “Free-space Alignment” window from the Instrument menu, activate the
alignment beam, and use the mirror closest to the OSAto point the alignment beam
at the center of the input source. Repeat adjusting the two mirrors in turn until both
conditions are fulfilled; the two beams then overlap over the entire beam path. To
further optimize the alignment, the DC signal value of the detectors are shown
whenever the alignment beam is active. Maximizing these values will most often
lead to good interferometric signal values.
3.3.3. Final Alignment using the OSA
Once the system is roughly aligned, deactivate the alignment beam in order to see
a spectrum in the main software window. Change the settings to Low Resolution
and Low Sensitivity and start a continuous measurement. Use the “Free-Space
Alignment” window to adjust the gain levels. First, adjust the gain levels until the
signal values lie between about 10% to 80%. Note that if the source is weak, the
sensitivity may need to be increased, as this enables higher gain levels for some
detectors. However, this will also slow down the measurements. If the source is
strong, the attenuation filters can be activated through the “Free-Space Alignment”
window.
To optimize the alignment, there are several software analysis tools that can be
used. In addition to the signal values in the “Free-Space Alignment” window, it is
recommended to survey the detected optical power by using the Power tool (under
the Analysis menu) and to observe either the interferogram or spectrum. A time
series measurement of the signal and/or power can be started via the “Long-Term”
functionality (see Section “Long-Term Analysis” in the manual) to get a reading of
how these values change as you adjust the two mirrors.
Once the desired software tools are selected, repeat the alignment procedure
described above but utilize the OSA readings instead of the viewing card to
optimize the alignment. Remember to decrease the gain level and/or activate the
attenuation filter if any detector gets close to saturation.

Redstone™ OSA305 Chapter 3: Using the OSA
Rev B, December 15, 2021 Page 7
When the “Free-space Alignment” window is closed, and whenever necessary
during normal operation such as when the input source conditions have changed
considerably, the autogain algorithm will run a series of short sweeps to determine
optimal gain and offset settings. An overlay window will appear during this time
advising the user to wait for optimization to complete.

Redstone™ OSA305 Chapter 3: Using the OSA
Page 8 STN053070-D03
3.3.4. Example setups
Figure 4 and Figure 5 display two common scenarios involving the free-space input
port.
Figure 4 Free-Space setup suitable for a Collimated Source, using a Laser Diode
mounted in a Thorlabs LDM56 Laser Diode Mount. Two mirrors are used to
facilitate the Alignment Process and to adjust beam height.
Figure 5 Free-Space setup suitable for a Broadband Divergent Source, in this case
illustrated with Thorlabs SLS203L Stabilized Light Source. The source is kept at
a short distance from the OSA to minimize input losses.

Redstone™ OSA305 Chapter 3: Using the OSA
Rev B, December 15, 2021 Page 9
3.4. Starting a Measurement
Once the OSA is connected to the PC, the OSA name will appear to the left on the
Settings bar. It can also be found in the list of available devices shown by clicking
the “Devices” button, found under the Instrument menu.
The GUI can assist with selecting acquisition settings suitable for the input source.
Clicking the “Auto setup” button under the Instrument menu will start an automated
process, which will try to determine the nature of the input source and apply
suitable settings.
A measurement is started by clicking the “Single” or “Repeat” buttons under the
Instrument menu, see Figure 3. Information such as gain level etc. is displayed in
the Status bar at the bottom of the screen.
Figure 6 The Trace Drop Down menu, with the Average option marked
It is possible to average multiple spectra, which normally reduces noise levels of
the measurement. It can therefore be beneficial to average a few spectra if the
intensity of the incoming light is low. The averaging is selected under the Trace
drop down menu (see Figure 6); here it is also possible to select the number of
sweeps to include in the average.
3.4.1. Sensitivity and Resolution
The Redstone OSA305 instrument can be set to one of four resolution settings:
High, Medium High, Medium Low, or Low, which correspond to resolutions of
2.0 GHz (0.0625 cm-1), 7.5 GHz (0.25 cm-1), 30 GHz (1.0 cm-1), and 120 GHz
(4.0 cm-1), respectively. The available sensitivity settings are High, Medium, and
Low, corresponding to different speeds of the moving mirror inside the instrument
and controls the number of available detector gain levels. The trade-off is between
higher measurement update frequency, and higher resolution and increased
sensitivity. It is recommended to start in Low Resolution and Low Sensitivity to find
coarse settings of the trace followed by higher resolution measurements, if
needed.

Redstone™ OSA305 Chapter 3: Using the OSA
Page 10 STN053070-D03
3.4.2. Saving Your Data
The data can be saved by selecting the File menu (see Figure 7) or by opening the
Trace drop down menu. Saving in Thorlabs’ OSA file format, .spf2 / .spf2x, allows
for easy loading and post-processing using the OSA software. A variety of other
file formats are also available for export including .csv, .txt, .m, and more.
Figure 7 It is possible to save the data after a performed measurement in several
ways.
3.5. Functions and Appearance
3.5.1. Interferogram View vs Spectrum View
The OSA GUI can either display the interferogram or the spectrum. To switch
between the views, use the quick-switch button found in the Settings bar.
Regardless of which view that is displayed, data for both spectrum and
interferogram is still collected. Note that the Interferogram View is disabled for
Basic level users. Open the Settings dialog and switch to Advanced level for
access to interferograms.
For both views, only the analysis tools and math tools available for that particular
view (Spectrum or Interferogram) are enabled.
3.5.2. Using Markers
The movable markers (see Figure 8) can be moved by placing the mouse cursor
over the marker, where the mouse cursor changes into a double arrow. Press and
hold the left mouse button to drag the movable marker to the desired position.
Save to Thorlabs format
Save to Thorlabs format
Export to other formats
Load files for post-processing

Redstone™ OSA305 Chapter 3: Using the OSA
Rev B, December 15, 2021 Page 11
Figure 8 Marker Menu
As long as any movable marker is enabled, the Movable Markers dialog box will
be shown either as a floating window or docked to the main window. The dialog
box shows the position of each enabled line marker, the value of the active trace
at the position of the line marker(s), and the level of each enabled level marker. If
both line markers are enabled, the distance between them and the difference in
value of the active trace at the two positions is shown. If both level markers are
enabled, the difference or quotient between them will be displayed. Which value
to be shown can be changed by clicking the Settings icon displayed above the
marker values.
3.5.3. Analysis Tools
A variety of analytical tools is available under the Analysis menu, such as the Peak
Track and Valley Track (see Figure 9), Curve Fit, Statistics, and more.
Figure 9 Peak Track Tool, used on water absorption seen in a broadband spectrum
3.5.4. Trace appearance
If the color of the trace needs to be changed, this can be done under the Trace
drop down menu, followed by the “Change color” option. The thickness of the
traces can also be changed, under the “Display” tab in the “Settings” dialog.
The order of the traces can be altered by a simple drag-and-drop procedure.
Toggle Peak Track
Data table
Found peaks
Analysis range

Redstone™ OSA305 Chapter 4: Regulatory
Page 12 STN053070-D03
Chapter 4 Regulatory
As required by the WEEE (Waste Electrical and Electronic Equipment Directive)
of the European Community and the corresponding national laws, Thorlabs offers
all end users in the EC the possibility to return “end of life” units without incurring
disposal charges.
This offer is valid for Thorlabs electrical and electronic equipment:
•Sold after August 13, 2005
•Marked correspondingly with the crossed out
“wheelie bin” logo (see right)
•Sold to a company or institute within the EC
•Currently owned by a company or institute within
the EC
•Still complete, not disassembled and not
contaminated
As the WEEE directive applies to self-contained
operational electrical and electronic products, this end of
life take back service does not refer to other Thorlabs products, such as:
•Pure OEM products, that means assemblies to be built into a unit by the
user (e.g. OEM laser driver cards)
•Components
•Mechanics and optics
•Left over parts of units disassembled by the user (PCB’s, housings etc.).
If you wish to return a Thorlabs unit for waste recovery, please contact Thorlabs or
your nearest dealer for further information.
Waste Treatment is Your Own Responsibility
If you do not return an “end of life” unit to Thorlabs, you must hand it to a company
specialized in waste recovery. Do not dispose of the unit in a litter bin or at a public
waste disposal site.
Ecological Background
It is well known that WEEE pollutes the environment by releasing toxic products
during decomposition. The aim of the European RoHS directive is to reduce the
content of toxic substances in electronic products in the future.
The intent of the WEEE directive is to enforce the recycling of WEEE. A controlled
recycling of end of life products will thereby avoid negative impacts on the
environment.
Wheelie Bin Logo

Redstone™ OSA305 Chapter 5: Thorlabs Worldwide Contacts
Rev B, December 15, 2021 Page 13
Chapter 5 Thorlabs Worldwide Contacts
For technical support or sales inquiries, please visit us at
www.thorlabs.com/contact for our most up-to-date contact information.
USA, Canada, and South America
Thorlabs, Inc.
[email protected]
[email protected]
UK and Ireland
Thorlabs Ltd.
[email protected]
[email protected]
Europe
Thorlabs GmbH
[email protected]
Scandinavia
Thorlabs Sweden AB
[email protected]
France
Thorlabs SAS
[email protected]
Brazil
Thorlabs Vendas de Fotônicos Ltda.
[email protected]
Japan
Thorlabs Japan, Inc.
[email protected]
China
Thorlabs China
[email protected]

www.thorlabs.com
