Three Sixty SC45 Series User manual

Sloped Ceiling
Kit: SC45-XX
Version: 1.0 Date: October 2022
Supports fans with 26mm downrods
only - with or without receivers.
This accessory can be used on ceiling fans with 26mm downrods and supports angles up
to 45° depending on the model and whether a remote receiver unit is installed. Ceiling fans
that use remote receivers will sometimes reduce the angle in some ceiling fans.
IMPORTANT: This accessory must be
installed by a licensed electrician, and all
electriciy must be turned o at the fuse box
prior to installing this accessory. Refer to the
Ceiling Fan’s Owner’s Manual for full safety
and warning information.
Mounting Plate Canopy Hanger Ball
NOTE: Depending on the degree of the ceiling slope, ensure the ceiling fan has sucient drop
from the roof to avoid the blades hitting the ceiling. Install the longer Downrod (ensuring sucient
wiring and/or wiring looms to go through the Downrod) and then follow the instructions of this
Sloped Ceiling Kit Accessory.

2
1. Install the Sloped Ceiling Mounting Plate
Drill a hole in the ceiling board and batten for wiring. Securely attach the Mounting Plate to a
timber batten or other structural support using the two wood screws provided with your ceiling
fan. Fixings must be screwed into a joist and not just the plasterboard.
IMPORTANT! PLEASE READ TO AVOID INSTALLATION ISSUES!
Inside of the Sloped Ceiling Canopy there is a small Tab. In order for this Sloped Ceiling Kit to
work the Mounting Plate, Canopy and Hanger Ball must all align so that the Canopy (when tted
to the Mounting Plate) has the Tab at the LOWEST point on the sloping ceiling.
Earth Wire
Screw
1. Locate the Earth Wire Screw on
the Mounting Plate - this must be
installed so that the Earth Wire Screw
is positioned at the lowest point of the
ceiling slope.
2. Locate the Canopy Tab inside the
Ceiling Canopy. When attached to the
Mounting Plate, the Canopy Tab must
be at the lowest point in the ceiling
slope.
3. The Hanger Ball Keyway will lock into
the Canopy Tab, and must be facing
towards the lowest point of the ceiling
slope.
Canopy Tab
A. Remove the two canopy mounting
screws located 180 degrees apart
on the outside edge of the Mounting
Plate.
B. Loosen the two remaining screws
for the Canopy Mating Slots. This
will make installation of the canopy
easier.
A
A
B
B
NOTE: Installing the Mounting Plate
properly will ensure the Canopy Tab
can be mounted in the correct position.
IMPORTANT: Fixing location must be able to withstand
four times the static weight of the fan.

3
2. Remove Hanger Ball, Ceiling Canopy & Dress Ring
This Sloped Ceiling Kit replaces the ceiling fan’s supplied Hanger Ball, Ceiling Canopy and Dress
Ring, so these parts must be removed from the ceiling fan.
1. Remove the Hanger Ball by loosening
the setscrew until the ball falls freely
down the Downrod. Remove the Pin
from the Downrod, then remove the
Hanger Ball.
2. Remove the Ceiling Canopy.
3. Remove the Dress Ring.
1
2
3
Setscrew
Hanger
Ball
Pin
Ground
Lead
Ceiling
Canopy
Dress
Ring
3. Add the Sloped Ceiling Kit Hanger Ball & Ceiling
Canopy
Slide Ceiling Canopy over the Downrod and then
install the Sloped Ceiling Hanger Ball.
1. Slide the Sloped Ceiling Kit Ceiling
Canopy over the ceiling fan’s Downrod
(threading through the wires). Install
the Sloped Ceiling Kit Hanger Ball by
routing the wires through the ball and
then sliding the Hanger Ball down the
Downrod.
2. Insert the Hanger Ball Pin through the
two holes in the Downrod and align
the Hanger Ball so the Pin is captured
in the groove in the top of the Hanger
Ball. Pull the Hanger Ball up tight
against the Pin and then securely
tighten the primary and secondary
setscrews in the Hanger Ball.
Pin
Primary
Set Screw Secondary
Set Screw
Slide Canopy &
Hanger Ball
down the
Downrod
1
2

4
4. Temporarily hang the fan onto the mounting hook
Carefully lift the assembled fan and temporarily
hang the Canopy on the Mounting Plate Hook
using one of the two mating holes.
This will allow you to complete all wiring as per
the Ceiling Fan’s Owner’s Manual without having
to bear the weight of the ceiling fan.
5. Securely attach the Canopy to the Mounting Plate
IMPORTANT: Ensure all wiring has been completed as per the Ceiling Fan Owner’s Manual
before installing the Ceiling Canopy.
1. Carefully lift the fan from the Mounting
Plate Hook, making sure not to break
any wiring connections.
2. The Canopy has 2 mating slots and
2 mating holes. Position the two
Mating Slots under and in line with
the 2 Mounting Plate screws that were
loosened in Step 1(B).
3. Lift the fan until Mounting Plate Screws
are seated in bottom of slots in Canopy.
4. Rotate the Canopy clockwise until both
Mounting Screws drop into Mating Slot
recesses.
5. Tighten the 2 Mounting Screws
securely.
6. Install the third and fourth screws
into the two Mating Holes and tighten
securely.
IMPORTANT: Slide the remote receiver (at side on top) into the ceiling canopy.
Mating Slots
Receiver
Mating
Holes
Screws
Household Supply
Terminal Block
IMPORTANT: Many 360fans
have ceiling hanger brackets
with a Terminal Block for AC
Household Supply and pre-wired
plugs to connect to the fan and/
or receiver.
We recommend removing the
Terminal Block and wiring from
the Ceiling Fan’s included Hanger
Bracket and using these to
complete the wiring within the
Sloped Ceiling Canopy.
Example wiring (not included) for
illustrative purposes only.
