Threshold L-PG080PST-F8 User manual

>> assembly instructions Production No. :20184434
Threshold
style # L-PG080PST-F8
014050900#icpd
alogreP
edahSelbatsujdA’8X’8

Congratulations on your latest Target purchase
Now what? Don’t start sweating over this box of parts. This will be easy. We did the hard work for you.
All you need to do is follow our simple instructions and you’ll be on your way transforming your space in no time.
Good luck-though we’re confident you won’t need it.
Before you begin
1. Questions? Please call 1855-MYTGTHOME (1855-698-4846) for parts and service. For faster service, have the style number
and DPCI number ready when calling.
2. Use the carton as a working surface to prevent product damage during assembly
3. Gather all tools prior to assembly.
Warning:
1. This unit is heavy. Do not assemble this item alone.
2. Read and follow all Warnings & Assembly Instructions before attempting to assemble.
3. KEEP ALL FLAME AND HEAT SOURCES AWAY FROM THE CANOPY.
4. For safety reasons, please keep kids and pets away from the construction area of the pergola. Children and pets should be supervised
when they are in the area of the pergola construction.
5. Keep assembly area at least 6 feet from any obstruction such as a fence, garage, house, overhanging branches, laundry line,
or electrical wires.
6. Some parts may have sharp edges. When assembling and using this product, basic safety precautions should always be followed
to reduce the risk of personal injury and damage to the product.
7. Assemble on level ground.
8. Check all bolts for tightness before use, and periodically check and tighten bolts as necessary.
2

3
Tools needed

4
Table of contents
Introduction
Hardware
Parts list
Assembly
2-3
5
6
7-9
Questions?Please call 855-MYTGTHOME (855-698-4846) for parts and service. For faster service, have the style number and DPCI number ready when calling.

5
Hardware Pack
(AA)x 72
M6 x 15 Bolt
(FF) x 16
Stake Φ8x180
(BB)x 108
M6 Washer
(CC)x 12
M6 x 45 Bolt
(DD)x 24
M6x15 Nut
(W) x 1
M6 Wrench
(EE) x 64
M6 spring washer

6
A
B
B1
C
E
F
G
H
6
2
2
4
2
2
4
4
Top Bar
Fixed Beam
Support Beam
Corner Connector 1
Post 1
Post 2
Stake Base
Base Protestor
I
J
4
4
Arch Support Frame 1
Arch Support Frame 2
K 4Clasp(pre-assembled on Post)
ITEM DESCRIPTION QUANTITY
L 4Small Connector
M 2Beam
N 4Guideway Bar
O 1Canopy
PIC.

7
Step1:
),Spring Washer (EE) and Washer (BB)AA(tloByb)C(rotcennoCrenroChtiw)1B(raBtroppuSdna)B(maeBdexiFtcennoC:1.giF
Note: Make sure the side with Arch Support Frame assembly holes on Support Beam (B1) inwards.
Fig.2: Fix Top Bar (A) to Support Bar (B1) by Bolt (CC) and Washer (BB).
(AA)x 24
M6 x 15 Bolt
(BB)x 36
M6 Washer
(CC)x 12
M6 x 45 Bolt
(W) x 1
M6 Wrench
(EE) x 24
M6 Spring Washer
Do not completely tighten screws until all screws are in place.

8
Step2:
(AA)x 48
M6 x 15 Bolt
(BB)x 72
M6 Washer
(DD)x 24
M6x16 Bolt
(FF) x 16
Stake Φ8x180
Fig.3: Attach Base Protector (H) to Post 1&2 (E&F), fix Post Base (G) to Post (E&F) by using Bolt (DD) and Washer (BB).
Fig.5: Insert Guideway Bar (N) into Small Connector (L) that is on the top of Post 1&2(E&F), then fix them by Bolt (AA) and Washer (BB).
Fig.6: Fix the bottom of Guideway Bar (N) to Small Connector (L) that is on Post 1&2 (E&F) by Bolt (AA) and Washer (BB).
Fig.7: Fix Post 2 (F) to Corner Connector (C) by Bolt (AA), Spring Washer (EE) and Washer (BB). The same way for Post 1 (E).
Fig.4: Put Small Connector (L) onto Guideway Bar (N) through the bottom of Guideway Bar (N).
(EE) x 40
M6 Spring Washer
Do not completely tighten screws until all screws are in place.

9
Step3:
Fig.8: Fix the top of Arch Support Frame 1&2 (I&J) to Fixed Beam (B) and Suppport Bar (B1) by Bolt (AA), Spring Washer (EE) and Washer (BB).
Fig.9: Fix the bottom of Arch Support Frame 1&2 (I&J) to Post (E&F) by Bolt (AA), Spring Washer (EE) and Washer (BB).
Fig.10: Put Canopy (O) on the top of the pergola, then insert the assembled beam (M) to the hemline of the canopy.
Fig.11: Fix Small Connector (L) to Beam (M) by Bolt (DD) and Washer (BB).
Fig.12: Fix the assembled pergola on the ground by Stake (FF). And now your Pergola is ready for use.
Fig.13: When pulling down Canopy (O), make sure it is fixed by Clasp (K) on the Post (E&F).
You are now ready to enjoy your new pergola.

10
Care & Maintenance
Our iron / steel components for garden accessories and furniture are treated with rust inhibiting paint that protect it from rusting. However, due to
the nature of iron / steel, surface oxidation (rusting) will occur once these protective coatings are scratched. This is a natural process and is not a
defect! To minimize this condition, we recommend care to be taken when assembling & handling the product to prevent the paint from being
ylisaeeboslanactsurecafruS.tniapgnitibihnitsurhtiwpu-hcuotetaidemmidnemmocerew,ruccoegamadrognihctarcsynadluohS..dehctarcs
removed with a very light application of common cooking oil. If surface oxidation (rusting) occurs and no measures are taken to prevent this, the
oxidation may start dripping on to the area and cause damaging stains, which may be difficult to remove. This can be prevented if measures are
taken to keep the product from oxidizing.
Limited warranty
This Limited warranty is extended to the original purchaser and applies to defects in materials and workmanship of your item provided the item is
maintained with care and used only for personal, residential purposes.
The item is warranted to be free from defects in material or workmanship for a period of 6 months. We don’t reimburse for transportation or delivery
costs, or compensate the individual or any outside party for assembling or disassembling the product.
Exclusions
Items used for commercial, contract, or other non-residential purposes, or items damaged due to acts of nature, vandalism, misuse, or improper
assembly are not covered. Corrosion or rusting of hardware is not covered. Proof of purchase (dated register receipt) is required for warranty claims.
Warranty is to the original purchaser and is non-transferable. Any replacement of warranted items will be in the original style and color, or a similar
style and color if the original is unavailable or has been discontinued. As some states do not allow exclusions or limitations on an implied warranty,
the above exclusions and limitations may not apply. This warranty gives you specific rights, and you may also have other rights, which vary from
state to state.
