Seaside Casual 037 User manual

Page 1
037-REV C 137-REV B
Seaside Casual Furniture | 11 Industrial Drive Coventry, RI 02816 | 800-809-3114 | [e-mail]
1PLEASE READ INSTRUCTIONS COMPLETELY BEFORE BEGINNING.
Carefully remove contents from box. Make sure that all parts and hardware
are included using the Parts List below.
WARRANTY QUESTIONS OR COMMENTS PLEASE CALL TOLL FREE AT 1-800-809-3114
Part Code: 316-8x3/4PPS
Actual Size
3/4” Phillips Pan Head Screw
(137 Only)
Back Assembly
x 1
Right & Left Side Assemblies
80mm Hex Lag
Seat Assembly
x 1
Part Code: 4MMALLEN
Actual Size
4mm Allen Wrench
x 1
137 x 18
x 9
Newport Bench
037 4’ Bench
137 5’ Bench
Part Code: 316-1/4-10-80HL
x 1ea
ASSEMBLY INSTRUCTIONS
4mm Allen Wrench (included); #2 Phillips Head Screwdriver; Rubber Mallet.
Tools Required:
Part Code: 316-8X1-1/4PFDS
Actual Size
1-1/4” Phillips Head Screw
x 4
Actual Size
Lower Stretcher (137 Only)
x 1
5/8“
Right Left
Actual Size
Bungs
137 x 18
037 x 13
037 x 10

Page 2
037-REV C 137-REV B
2ATTACH SIDE ASSEMBLIES TO
SEAT ASSEMBLY
Align Left Side
Assembly with
seat assembly.
Secure using (2)
80MM Hex Lags
through the
c o un te r -b o r ed
holes in front leg into pilot holes in front
apron of seat assembly. Plug holes with
(2) 5/8” taps®.
Repeat process for Right Side.
Align counter-
bored holes in
Rear Left Leg
with Pilot holes in
Back Assembly,
ensuring that the
counter-bores in lower back are facing
outward. Attach using (3) 80mm Hex
Lags. Plug holes with (3) 5/8” taps®.
Repeat process for Right side.
Turn Assembly upside down. Secure
aluminum seat cleat to lower back using
(9) 3/4” Phillips Pan Head Screws.
3ATTACH BACK TO REAR LEGS
5SECURE REAR SEAT CLEAT
TO LOWER BACK (137 ONLY)
Secure Lower
Back Assembly
to Seat Assembly
using (4) 80MM
Hex Lags (3 for
037) thru coun-
ter-bored holes in lower back into pilot
holes in seat supports. Plug holes with (4)
5/8” taps® .
4ATTACH BACK ASSEMBLY TO
SEAT

Page 3
037-REV C 137-REV B
6ATTACH SEAT CLEAT TO SIDE
ASSEMBLY
Align counter-
bored holes in
l o w e r s i d e
stretcher with
Pilot holes in
long stretcher,
making sure that the aluminum in the
long stretcher is facing down. Attach us-
ing (2) 80mm Hex Lags. Plug holes with
(2) 5/8” Bungs using rubber mallet.
Repeat process for other side.
7ATTACH STRETCHER TO SIDE
ASSEMBLIES (137 ONLY)
Secure outer seat cleat to side assembly
using (2) 1-1/4” Phillips Head Screws.
Repeat Process for other side.
