Thule 1190 User manual

C.20100430. 503-1190-02
instructions
1190Kit
KIA Sephia II, 5-dr Hatchback, 98-01
KIA Sephia II, 4-dr Sedan, 98-01
KIA Sephia, 4-dr Sedan, *98-01
KIA Shuma, 5-dr Hatchback, 98-04
KIA Shuma, 4-dr Sedan, 98-04
KIA Spectra, 4-dr Sedan, 01-04 / *00-04
*North America
480
480R
754
750
ISO 11154-E

2 503-1190-02
Kit
207 x 4 06 x 4 x 1
7 kg
15,4 Ibs
xx kg
xx Ibs Max.
165 Ibs
Max.
75kg
km/h
Mph
0
80 km/h
50 Mph
40 km/h
25 Mph
130 km/h
80 Mph
instructions
Kit XXXX
x4
x1 x4
x4
x1
x4
x4
x4
x4
x1 x4
x4
x2x2 x2
x4
x4
x2
x2
x2
x2
x2
x4
x2
750
480
480R / 754

503-1190-02 3
1
2
A
B
C
750
480
480R / 754
480R / 754 480 750

4 503-1190-02
X
1
1
1
1
2
2
2
2
Y
X inch/mm
Y inch/mm
3X / Y
480R
754 750
480
X
KIA Sephia II, 5-dr Hatchback, 98-01 26
KIA Sephia II, 4-dr Sedan, 98-01 26,5
KIA Sephia, 4-dr Sedan, *98-01 26,5
KIA Shuma, 5-dr Hatchback, 98-04 26
KIA Shuma, 4-dr Sedan, 98-04 26,5
KIA Spectra, 4-dr Sedan, 01-04 / *00-04 26,5
Y
KIA Sephia II, 5-dr Hatchback, 98-01 24,5
KIA Sephia II, 4-dr Sedan, 98-01 25
KIA Sephia, 4-dr Sedan, *98-01 25
KIA Shuma, 5-dr Hatchback, 98-04 24,5
KIA Shuma, 4-dr Sedan, 98-04 25
KIA Spectra, 4-dr Sedan, 01-04 / *00-04 25
X inch X mm
KIA Sephia II, 5-dr Hatchback, 98-01 35 7/8 ” 911 mm
KIA Sephia II, 4-dr Sedan, 98-01 36 ” 916 mm
KIA Sephia, 4-dr Sedan, *98-01 36 ” 916 mm
KIA Shuma, 5-dr Hatchback, 98-04 35 7/8 ” 911 mm
KIA Shuma, 4-dr Sedan, 98-04 36 ” 916 mm
KIA Spectra, 4-dr Sedan, 01-04 / *00-04 36 ” 916 mm
Y inch Y mm
KIA Sephia II, 5-dr Hatchback, 98-01 35 1/4 ” 896 mm
KIA Sephia II, 4-dr Sedan, 98-01 35 1/2 ” 901 mm
KIA Sephia, 4-dr Sedan, *98-01 35 1/2 ” 901 mm
KIA Shuma, 5-dr Hatchback, 98-04 35 1/4 ” 896 mm
KIA Shuma, 4-dr Sedan, 98-04 35 1/2 ” 901 mm
KIA Spectra, 4-dr Sedan, 01-04 / *00-04 35 1/2 ” 901 mm

5503-1190-02
207207
207207
06
06
06
06
KIA Sephia II, 5-dr Hatchback, 98-01
KIA Sephia II, 4-dr Sedan, 98-01
KIA Sephia, 4-dr Sedan, *98-01
KIA Shuma, 5-dr Hatchback, 98-04
KIA Shuma, 4-dr Sedan, 98-04
KIA Spectra, 4-dr Sedan, 01-04 / *00-04
4
480R / 754
750
480

6 503-1190-02
5
GB/US Tighten alternately
D Die Schrauben abwechselnd
anziehen
F Serrer alternativement chaque
côté
NL Afwisselend aan de linker- en
de rechterkant aandraaien
I Alternare il serraggio delle viti
E Apretar alternativamente
PT Aperte alternadamente
S Dra åt växelvis
FIN Kierrä vuorotellen
EST Pinguldage vaheldumisi
LAT Pievelciet pamīšus
LIT Užsukinėkite pakaitomis
PL Śruby dokręcaj naprzemiennie
RU Затягивайте попеременно
CZ Pokrętła bagażnika dokręcaj
dokręcaj naprzemiennie.
SK Doťahujte striedavo
SLO Privijajte izmenično.
HR Naizmjenično zategnite
HU Egymástól függetlenül
szorítandó
GR Σφíγγετε εναλáξ
TR Dönüşümlü sıkın
B CA
X mm
KIA Sephia II, 5-dr Hatchback, 98-01 220 mm 650 mm 8 5/8 ” 25 5/8 ”
KIA Sephia II, 4-dr Sedan, 98-01 220 mm 650 mm 8 5/8 ” 25 5/8 ”
KIA Sephia, 4-dr Sedan, *98-01 220 mm 650 mm 8 5/8 ” 25 5/8 ”
KIA Shuma, 5-dr Hatchback, 98-04 220 mm 650 mm 8 5/8 ” 25 5/8 ”
KIA Shuma, 4-dr Sedan, 98-04 220 mm 650 mm 8 5/8 ” 25 5/8 ”
KIA Spectra, 4-dr Sedan, 01-04 / *00-04 220 mm 650 mm 8 5/8 ” 25 5/8 ”
Y mm X inch Y inch
XY

7503-1190-02
A
A
B
B
A
B
1
1
1
2
2
2
i
i
i
6
4 Nm
≈ 3 Nm
*
*
*
3 Nm
480R / 754
750
480

503-1190-02
544 (x4)
596 (x6)
588 (x8)
452 (x12)
510 (x10)
NA
EUR
ASIA
i i
A
AC
D
BB
ww
NA
Thule Sweden AB, Box 69, 330 33 Hillerstorp, SWEDEN
Thule Inc., 42 Silvermine Road, Seymour, Connecticut 06483, USA www.thule.com
[email protected]
customer[email protected]
i
i i
B
A
ABAB
B
B
B
A
A
