Tibo TI430 User manual

User Guide
TI430 BT/Amplifier
Turn it back on
Please read this user manual carefully before using your TI430 BT/Amplifier system and retain for future reference.

3
Turn it back on
3
Turn
it
back
on
CONTENTS
SAFETY
Safety precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Important safety instruction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
INCLUDED IN THE BOX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
SETTING UP THE SYSTEM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
REMOTE CONTROL
Installing batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Using the remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Remote control functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
AMPLIFIER
Front panel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Using the function menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Bluetooth Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Bass . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Treble . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Balance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Loudness . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
TECHNICAL DATA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
TROUBLE SHOOTING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
INDEX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
CONTACTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

4
Turn it back on
A triangle with a
lighting symbol draws
the user’s attention to
“dangerous voltage”
without insulation in the cabinet,
which may be high enough to
entail a risk of an electric shock.
A triangle with an ex-
clamation mark draws
the user’s attention to
important instructions
for use and maintenance in the ac-
companying manual, which should
be studied and adhered to.
The symbol for a
CLASS II (double
insulation) product.
Safety precautions
Warning:
To minimise the risk of re or electric shock, do not expose the unit to liquid or moisture. Do not open the cabinet
as it contains dangerous voltages. Only qualied technicians are allowed to carry out repair and service of this
system.
If the plug of the power cord needs to be replaced. It is important that the replacement is identical to the plug that
needs to be replaced, or that the new plug has been recommended by the manufacturer.
Caution:
To avoid electric shock, it is important to insert the plug correctly into the wall outlet.
Warning:
It is important that you read and observe both the instructions in this manual and the instruction on the unit.
Keep this manual for safe future reference. This unit was designed and manufactured with a view to providing
maximum safety for the user. Incorrect use of the unit may cause an electric shock or re. The protection devices
built into this unit will protect the user if the procedures below are observed in connection with installation, use
and repair. This unit is fully electronic and contains no parts that can be repaired by the user.
Do not remove the covers. Risk of dangerous voltage. Only qualied technicians are allowed to repair the unit.
Important safety instructions
Read the manual
After unpacking the unit, please read the manual care-
fully and observe all the instructions given.
Power supply
Only the power supply indicated on the rating plate
must be used for this unit. If you are not sure which
power supply you have, please contact your local
dealer.
Earthing or polarisation
If the plug cannot be inserted properly into the socket,
or if the plug does not t, the unit must not be used in
your country.
Ventilation
The cabinet is provided with slots and openings to
ensure ventilation and reliable operation to protect the
unit against overheating. Do not block or cover these
openings. The openings must never be blocked, for
instance by placing the unit on a bed, a sofa, a carpet
or similar surface.
Heat
Do not place the unit near sources of heat such as
radiators, ovens or other units that produce heat.
Water and moisture
The unit must not be placed close to water, such
as bathtub, wash basin, kitchen sink or washing
machine, in a damp cellar or close to a swimming
pool, etc.
Cleaning
Unplug the unit before cleaning. Do not use liquid de-
tergents and aerosol cleaning agents. Use a dry cloth.
Power cords
Wiring must be organised to prevent people from step-
ping on the cables and to avoid pinching by objects
placed on or beside them. Take special care around
sockets and plug boxes and where the power cords
leave the unit.
Lightning
Unplug the unit for additional protection during storms
or when the unit is not used for prolonged periods.
This will prevent damage to the unit from lightning and
power surges.
SAFETY

5
Turn it back on
Important safety instructions
SAFETY
Penetration of objects and liquid
Never push any foreign objects through the openings into the unit, as they may touch dangerous voltage points
or short-circuit parts and cause re or an electric shock. Do not spill liquid onto the unit.
Accessories
Do not place the unit on unstable surfaces such as a trolley, stand, tripod, shelf or table. The
unit may fall and cause serious injury to persons or damage to the unit. Use only trolley, stand,
tripod, shelf or table that is very stable or provided with the unit. The unit must be installed in
accordance with the manufacturer’s instructions and by means of installation equipment recom-
mended by the manufacturer. If the unit is placed on a trolley, the trolley must be moved very
carefully. Sudden stops, unnecessary force and uneven surfaces may cause the trolley to turn
over.
Loads
Do not place heavy loads on the unit and do not step on it. The load may fall and cause serious injury to persons
or damage to the unit.
Damage
Unplug the unit and contact qualied technicians in the following cases:
A. If the power cord or the plug is damaged.
B. If liquid has been spilled on the unit or objects have
fallen into the unit.
C. If the unit has been exposed to liquid or moisture.
D. If the unit does not work properly after adhering to the instructions in the operation manual. Only the settings
described in the operation manual must be made as incorrect setting may result in damage and often will
make it difficult for a qualied technician to make the unit work properly again.
E. If the unit has been dropped or damaged in any other way.
F. When the operation of the unit changes drastically, the unit requires service.
Service
Do not attempt to carry out any service work by yourself. By opening or removing the cover, you will be exposed
to dangerous voltage or other hazards. Any service work should be carried out by qualied technicians.
Recycling
If at any time in the future you need to dispose of this product please note that waste electrical
products should not be disposed of with household waste. Please recycle where facilities exist.
Check with your Local Authority or retailer for recycling advice.
Approval
This product complies with European Low Voltage and Electromagnetic Compatibility Directives
when used and installed according to this instruction manual.

6
Turn it back on
Please save your packaging as you will need this in the event of warranty/service repair or support. We are
unable to carry out warranty/service if you are unable to package it correctly. The safest way to package your
item in the event of warranty/service repair is in it’s original box/packaging.
INCLUDED IN THE BOX
SETTING UP THE SYSTEM
Accessories
Included with this TI430 BT/Amplier system are the following accessories:
Box 1
1 x User Manual1 x TI430 BT/Amplier
1 x Main Plugs
1 x Remote Control
(2 x AAA batteries included)
User Guide
TI430 BT/Amplifier
Turn it back on
Pleaseread this user manual carefully before using your TI430 BT/Amplifier system and retain for future reference.
BT / Amplier
1. Antenna: For connection of the supplied Bluetooth antenna.
2. Line-out: For connection to an optional powered subwoofer or an external amplier.
3. CD: For connection of the TI 430 CD-PLAYER, or other CD Players.
4. DVD: For connection of a DVD player.
5. Tuner: For connection of the TI 430 FM/DAB TUNER or other tuners.
6. Phono: For connection of a turntable (Note: Additional ground terminal available above inputs).
7. Speaker left & right: For connection of the TI 430 SPEAKERS or other speakers.
Note: The cable ends must not come into contact with each other or the cabinet back panel.
8. AC input: For connection of the mains supply. Make sure that the plug is correctly inserted into the wall outlet.
TI 430 BT/AMPLIFIER
123456 7 8
1 x Bluetooth Antenna

7
Turn it back on
1. Remove the cover as illustrated. 2. Position two batteries of
the type AAA in the battery
compartment. Make sure that
the polarity of the batteries is
correct (see drawing at bottom
of the remote control).
3. Replace the cover.
Installation of batteries
Using the remote control
Direct the remote control at the sensor on the front panel of the unit. When the remote control signal is received,
the unit reacts accordingly. The remote control works within a range of 6 meters.
Sometimes the remote control does not work well in strong light.You may have to move the unit if it is a problem.
Malfunction may occur if other remote controls are used near the unit.
Do not place any objects on the remote control, as the batteries may become at if a key is depressed constantly.
Make sure that there are no obstacles between remote control and the unit.
Do not position the unit behind tinted glass as it may reduce the maximum range of the remote control.
TI 430 BT/AMPLIFIER
Maximum 6m
REMOTE CONTROL
Note:
A) Do not mix new and old batteries and do not use different types of batteries.
B) If the remote control is not used for prolonged periods, remove the batteries from the remote control to
avoid corrosion.

8
Turn it back on
Remote control functions
113
2
14
315
16
4
175
6
10
18
7
11
19
8
22
25
20
23
9
12
21
24
1. Power: Sets TI430 BT/AMP, TI430 CDP, TI430 DAB/FM into
standby.
2. 0-9 digits: Selects tracks on the TI430 CDP and pre-set
stations on TI430 DAB.
3. Fast forward: Fast forward playback.
4. Enter: For TI430 DAB only. Conrms selection.
5. Previous: Select the previous track.
6. Stop: Stop playback.
7. Fast rewind: Rewinds playback.
8. Repeat: Repeat a single or all tracks on CD disc.
9. DVD: To activate the DVD source.
10. Line-in: To activate the Line-in source.
11. Function: Enters the menu on the TI430 BT/AMP.
12. Volume decrease: turns down the volume.
13. Eject: Opens and closes the disc tray on the TI430 CDP.
14. +10: Use this button along with the 0-9 digits to select tracks
on the TI430 CDP and pre-set stations on TI430 DAB above
10. For example press the +10 button and the 5 digit to select
track 15 on a disc.
15. Autotune: Press once to automatically tune for a station at a
higher frequency.
16. Info: Displays the RDS and DAB information for the tuner.
17. Next: Selects the next track on.
18. Play/Pause: Starts and pauses playback.
19. Mute: Mutes the sound.
20. Random: All tracks are played in a random order for TI430
CDP only.
21. Phono: To activate the phono function.
22. DAB/FM: To activate the TI430 DAB and FM function.
23. Bluetooth: To activate the Bluetooth audio function.
24. CD: To activate the TI430 CD Player and the TI430 AMP on
and selects the CD input on the TI430 BT/AMP.
25. Volume increase: Turns up the volume.
REMOTE CONTROL
Some of the functions of the unit can only be performed by means of the remote control. Some functions are
connected with the selected signal input source. Some buttons on the remote control may therefore not be
available if the corresponding signal input source has not been selected.

9
Turn it back on
Front panel
TI 430 BT/AMPLIFIER
13711 5913 2481261014
1. Mains switch: Used to turn On/Off the mains power.
2. LED indicator: No light when the amplier is turned On. Blue light in standby mode.
3. Treble: Adjusts the treble level.
4. Volume: Adjusts the master volume, Bass, Treble, Balance and Loudness.
5. Bass: Adjusts the Bass level.
6. Phono: Activates the phono input.
7. Tuner: Activates the tuner input.
8. DVD: Activates the DVD input.
9. CD: Activates the CD input.
10. Bluetooth: Activates the Bluetooth function.
11. Line-in: Activates the line-in.
12. Function: Gives access to menu functions such as Balance and Loudness.
13. Line-in: Connection for line-in input with mini jack.
14. Headphone: 6 mm jack that suits most headphones.
AMPLIFIER
Note: The volume control on the front panel can be turned both clockwise and anticlockwise to change the vol-
ume. The volume control includes 64 steps, from -78, -75 dB for minimum volume and up to 0 dB for maximum
volume.
TI 430 BT/AMPLIFIER
Volume
Using the function menu
The TI430 AMP features a “function menu” that allows the adjustment of the following when accessed via the
remote: Bass, Treble, Balance and Loudness (see menu structure on right side). A description of the individual
functions will follow on the next few pages.
1. Press the VOL+ button on the remote control to increase the volume and press VOL- to reduce the volume.
2. Turn the volume control to the right to increase the volume and turn the volume control to the left to reduce the
volume.
1 2

10
Turn it back on
To pair with a Bluetooth device
1. With your Bluetooth device and the TIBO TI430 BT/Amplier both turned on, press the BLUETOOTH button
on the TI430 BT/Amplier to make the system discoverable.
The BLUE will appear on the TI430 BT/Amplier display to show that the system is discoverable.
2. Set your Bluetooth device to discoverable so it can discover (refer to your Bluetooth device guide for details)
TIBO TI430 BT/Amplier. Locate the Bluetooth device list in the user interface of your device.
3. From the Bluetooth device list, select the device named “TIBO TI430”.
4. If your Bluetooth device prompts you for a passcode, enter digits 0000 (four zeros) and press OK. Some
devices also ask you to accept the connection. Your Bluetooth device indicates when pairing is complete.
Connecting a paired device
To connect a previously paired device.
1. Turn On the device and press BLUETOOTH button until BLUE appears on the TIBO TI430 BT/Amplier
display.
2. From the Bluetooth device list, select the device named “TIBO TI430”.
BLUETOOTH SETUP

11
Turn it back on
Treble
This amplier features a treble control that allows adjustment of the Treble level. Please note
that the high Treble boost level offered by the Treble control may lead to permanent damage
to your loudspeakers if high volume is used for prolonged period of time.
1. Press the Function button on the remote control to enter the Function menu. Keep
pressing the Function button on the remote control until the display on the amplier shows
Treble.
2. Press VOL+ or VOL- to adjust the Treble level.
3. If you want to adjust the Treble level through the front panel, you must turn the Treble
button clockwise or counter clockwise to adjust the Treble level.
1
2
TREBLE 0
3
Bass
This amplier features a bass control that allows adjustment of the bass level. Please note
that the high bass boost level offered by the bass control may lead to permanent damage to
your loudspeakers if high volume is used for prolonged period of time.
1. Press the Function button on the remote control to enter the Function menu. Keep
pressing the Function button on the remote control until the display on the amplier shows
Bass.
2. Press VOL+ or VOL- to adjust the Bass level.
3. If you want to adjust the Bass level through the front panel, you must turn the Bass button
clockwise or anticlockwise to adjust the Bass level.
BASS 2
3
1
2
Balance
This amplier features a balance control that allows the adjustment of the vol-
ume of one loudspeaker. This function is used to compensate for a non-centred
listening position, and makes it possible to adjust the stereo perspective.
1. Press the Function button on the front panel or the remote control until
information on balance control is displayed.
2. Turn the volume control to adjust the balance.
21
Loudness
This amplier features a loudness function that allows boosting the volume
of the low frequencies at low volume. This function is active at frequencies
between 20 Hz and 800 Hz and the function is dampened when the amplier
volume is increased. When the volume is at the maximum setting, the loudness
function has completely cut out.
1. Press the Function button on the front panel or the remote control until information on loudness is displayed.
2. Turn the volume control to the right to activate the loudness function or to the left deactivate the loudness
function.
AMPLIFIER
Note: If the Bass control is not operated within ve seconds, the display will return to the volume information
display.
Note: If the Treble control is not operated within ve seconds, the display will return to the volume information
display.
Note: If the balance control is not operated within ve seconds, the display will return to the volume
information display.
Note: If the loudness control is not operated within ve seconds, the display will return to the volume
information display.
21

12
Turn it back on
TECHNICAL DATA
We reserve the rights to change the technical data and the design of the product without notice as a result of further development.
Amplier
Max. power consumption:
Signal to noise ratio:
Power output:
Tone controls - Bass:
Tone controls - Treble:
Distortion:
Inputs:
Speaker terminals:
Line-out:
Dimensions (HxWxD):
Weight:
150 Watts
> 90 dB
2 x 60 Watts
+/- 14 dB
+/- 14 dB
< 0.1 % THD
6 x line-in including Bluetooth, 3.5 mm jack and phono
High quality binding posts
1 x line-out
70 x 430 x 285 mm
5.6 kg

13
Turn it back on
TROUBLE SHOOTING
Problem Solution
No power when the amplier is turned On. Turn on the power at the wall outlet.
Check that the plug has been correctly inserted into the wall
outlet.
The internal fuse has blown and must be replaced by a qualied
service technician.
The power cord has been damaged and must be replaced.
The VFD (Vacuum Fluorescent Display) on the amplier
does not display any information.
The amplier is defective and should be serviced by a qualied
technician.
Error 1 message is displayed on the amplier. The amplier is defective and should be serviced by a qualied
technician.
The amplier does not switch between inputs. The amplier is defective and should be serviced by a qualied
technician.

14
Turn it back on
INDEX
AMPLIFIER | Balance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
AMPLIFIER | Bass. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
AMPLIFIER | Bluetooth Setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
AMPLIFIER | Front panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
AMPLIFIER | Loudness . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
AMPLIFIER | Treble. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
AMPLIFIER | Using the function menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
AMPLIFIER | Volume. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
CONTACTS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
INCLUDED IN THE BOX. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
INDEX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
REMOTE CONTROL | Installing batteries. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
REMOTE CONTROL | Remote control functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
REMOTE CONTROL | Using the remote control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
SAFETY | Important safety instruction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
SAFETY | Safety precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
SETTING UP THE SYSTEM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
TECHNICAL DATA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
TROUBLE SHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

15
Turn it back on
CONTACTS
Tibo Ltd.
DSV House
Maidstone Road
Milton Keynes
MK10 0AJ
United Kingdom
tel.: [phone]
e-mail: [e-mail]
Proof of purchase (attach your receipt here).

Turn it back on
www.tibo-electronics.com
