TIC AVP100 User manual

AVP100
Instruction Manual
100W 4-Zone 70v/100v/4-16Ω
Commerical Mixer Amplifer
CAUTION:
TO PREVENT THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE ANY FRONT/BACK COVERS OR
PANELS. NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED PERSONNEL.
The lightning flash with an arrowhead symbol, within an equilateral triangle, is intended
to alert the user to the presence of uninsulated “dangerous voltage” within the product’s
enclosure that may be of sufficient magnitude to constitute a risk of electric shock to
persons.
The exclamation point within an equilateral triangle is intended to alert the user to the
presence of important operating and maintenance (servicing) instructions in the
literature accompanying the product.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPARATUS TO RAIN
OR MOISTURE.
SOUND WARNING:
Avoid hearing damage by establishing safe listening volumes. Listening to this product at high volumes
or for extended time periods may cause permanent hearing loss. Protect your hearing by establishing
safe volumes. Start with the volume setting control at its lowest setting. Slowly increase the volume until
you can hear it comfortably and clearly without distortion. Reduce the volume or stop listening if you
experience ringing in your ears or any discomfort. Consult with a physician if needed.
CH1
CH2
CH3
CH4
V
+
V
-
MIC1
MIN MAX
AVP100
2 4 6 8 10
MIC1 MI C2 MIC3AUX1 AUX2B ASS TRE BLE

01 02
IMPORTANT SAFETY INSTRUCTIONS:
WARNING: Improper use may potentially cause injury, loss of property and
/or death.
WARRANTY:
1. Read these instructions.
2. Follow all instructions and heed all warnings.
3. Keep this instruction manual in a safe place for future reference.
4. Do not use this apparatus near water.
5. Clean only with a dry cloth.
6. Do not install this apparatus near any heat sources such as radiators, heat
registers, stoves or other apparatus (including amplifiers) that produce heat.
7. Do not block any ventilation openings. Install this apparatus in accordance with the
manufacturer’s instructions.
8. Do not defeat the safety purpose of the polarized or grounding-type plug. A
polarized plug has two blades with one wider than the other. A ground-type plug has
two blades and a third grounding prong. The wide blade or the third prong is provided
for your safety. If the provided plug does not fit into your outlet, consult an electrician
for replacement of the obsolete outlet.
9. Protect the power cord from being walked on or pinched, particularly at plugs,
convenience receptacles and the point where they exit from the apparatus.
10. Use only attachments and accessories specified by the manufacturer.
11. Unplug this apparatus during lightning storms or when unused for long periods of
time.
12. Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as when the power supply cord or
plug is damaged, liquid has been spilled or objects have fallen into the apparatus, or
the apparatus had been exposed to rain or moisture, does not operate normally or
has been dropped.
13. Do not expose this apparatus to dripping or splashing, and ensure that no objects
filled with liquids, such as vases, are placed on the apparatus.
14. To disconnect this apparatus from the AC mains completely, disconnect the
power supply cord plug from the AC receptacle.
15. The mains plug of the power supply cord shall remain readily operable.
16. Do not expose batteries to excessive heat such as sunshine, fire, or the like.
17. This is not a children’s product and is not intended for use by children under 14
years old.
18. Do not place heavy objects on the apparatus.
19. Only install this apparatus in an upright position at a location that is stable and
well-ventilated.
20. If any abnormal conditions are found during use, please turn off the apparatus
and disconnect the power supply immediately. Contact your nearest dealer and do
TIC offers a limited one-year full parts and labor warranty for all of our new products.
Please visit TIC’s warranty page (http://www.ticcorp.com/warranty/ ) for detail to our
latest warranty policy.
TIC Audio Inc. All rights reserved. The TIC logo is a trademark of TIC Audio Inc,
registered in the United States.
Features, specifications, and appearance are subject to change without notice.
For more information, please visit our website: www.ticcorp.com.

03 04
AVP100
Overview:
Features:
Usage:
TIC AVP-100 is a commerical-grade class A/B power amplifer with constant-
voltage options.
• 100 watt total power
• Standard 2U chassis
• 4-zone 70v ouput
• 70v/100v/8Ω single line output
• 3 microphones input, 2 AUX audio input, 1 audio output
• EQ with treble and bass adjustment
• Automatic thermal, overload, circuit protection
• Distortion/clipping indicators
• Built-in MP3 playback capability (via USB port)
Designed for broadcasting audio via a constant-voltage distributed sound system or
high-impedance loudspeaker system. Perfect for public address (PA) and background
music.
Table of Content
1. Safety Instructions.................................................................................1
2. Warranty & Company Info.......................................................................2
3. Overview..............................................................................................4
4. Front Panel...........................................................................................5
5. Rear Panel............................................................................................6
6. Operation...........................................................................................7-9
7. Troubleshooting...................................................................................10
8. Input/output Connection Diagram..........................................................11
9. System Schematics..............................................................................12
10. Specifications....................................................................................13
11. Dimensions........................................................................................14

05 06
Front panel
1Power switch
7Bass EQ control
2Mic 1 volume control
3Mic 2 volume control
4Mic 3 volume control
5AUX 1 volume control
6AUX 2 volume control
8Treble EQ control
9Mic 1 (priority) input
10 Play/Pause (MP3)
11 Previous Track / (hold) decrease volume (MP3)
12 Next Track / (hold) increase volume (MP3)
13 USB port (MP3 playback)
14 Zone 1-4 switches & indictators
15 Power, protection mode, signal, and clipping indictator
Rear Panel
AC 110 V 50Hz
MUT E MIC 2 MIC 3
1 2 3 4 5 6 7 8
1Mute level adjustment
7Zone 1-4 terminals (70v)
2Mic 2 input
3MIC3 input
4AUX 1 input
5AUX 2 input
6LINE output
8Power cord
9100v output terminal
10 70v output terminal
11 4-16Ω output terminal
12 Common terminal
Mic 1 Priority/Mute Function
By default, Mic 1 has priority over all other inputs. When plugged in, the other inputs will
automatically be muted. You can adjust the crosstalk level by turning the dial (0 - 30dB) on the rear
panel.
CH1
CH2
CH3
CH4
V
+
V
-
MIC1
MIN MA X
1 2 3 4 5 6 7 8 9 10 11 12 13
1414
AVP100
2 4 6 8 10
MIC1 MI C2 MIC3AUX1 AU X2BASS T REB LE
9 10 11 12

07 08
Option 1: Single 100v output
Option 2: Single 70v output
Option 3: 4-16Ω output
Zone 1 terminals
Zone 2 terminals
Zone 3 terminals
Zone 4 terminals
AVP100 can be set up in one of four options. Utilizing multiple options simutaneously may
cause issues and damage to the amplifier. Please ensure the polarity of speaker wires are
correctly matched and connected.
Note:
1. Please make sure that the power is turned off during speaker installation. When the power is on,
there may be a risk of electric shock.
2. Please ensure the sum of the power and impedance load of the speakers connected does not
exceed the specified range of the amplifier. Ideally, the total power load doesn't exceed 80% of the
rated output power of the amplifier.
Operation: Option 4: 4-zone 70v output (can be used in any combination of the 4 zones)

09 10
Operation instructions:
V
+
V
-
D. MP3 playback
1. The USB port has an automatic playback capability. It will automatically search the USB storage device
and play any compatible MP3 tracks.
2、Press corresponding buttons to navigate playback (play/pause, next, back).
3、Hold corresponding buttons to adjust volume.
Step-by-Step Instruction:
A. Connecting loudspeakers
1. Ensure power switch is at the OFF position.
2. Connect power cord to power soruce outlet.
3. Determine and prepare the appropriate speaker wire (gauge, insulation type, length).
4. Connect speaker to the appropriate wiring terminals, as instructed in the previous section.
5. Turn down all volume knobs and then turn on power switch.
B. Audio device input
1. Turn down volume before plugging in a new input device.
2. Adjust volume to the desired level.
3. When MIC1 input is plugged in, other input channels will be automatically muted. Only plug in
MIC1 when actively utilized.
C. Power down
1. Turn down the volume knob before turning off the amplifier.
2. After turning off the amplifier, please wait at least 5 seconds before turning on again.
Switching the power on and off in quick sucession may cause device failure.
Troubleshooting
Symptom Cause & Solution
1. Power does not turn on. 1. Power source is disconnected or cut.
2. Protection mode is activated.
4. Volume is low.
5. Sound is distorted. 1. Input level of microphone or external device is too high.
2. Volume level is too high.
2.No sound output.
1. No power is connected.
2. Fuse is blown and needs to be replaced.
3. Volume is turned off completely.
4. No active input.
5. MIC1 (priority) is plugged in but inactive.
6. USB device is plugged in but no MP3 track is found.
3. Sound suddenly stops or is
intermittent during playback.
1. Protection mode is activated due to overheating.
Please wait a few minutes to restart.
2. Poor or broken wire connection.
1. A high-impedance loudspeaker (4-16Ω) is connected to
a low-impedance (70v/100v) output.
2. MIC1 is plugged in but inactive.
3. Volume needs to be turned up.

11 12
Connection Diagram
4-zone 70v terminals
100v/70v/4-16Ω terminals
LINE audio out
AC power cord
CP MP3 Play audio input
Mute
Amplifier
Protective circuitry
LED display
Fan control
Loudspeaker
External audio device input (AUX)
MP3 Module
AC 110 V 50 Hz
MUTE MIC 2 MIC 3

13
Specifications
Output Power 100W
Model AVP100
Output Terminals 4-zone 70v, 4-16Ω, 70v, 100v
Input Sensitivity
Mic 1-3: 5mV/600Ω via unbalanced 1/4"" inputs
AUX 1-2: 350mV/ 10kΩ via unbalanced RCA inputs"
AUX Output Sensitivity &
Impedance 1000mV/470Ω via unbalanced RCA ouput
EQ Bass: ±10dB @ 100Hz; Treble: ±10dB @ 10kHz
Frequency Response 80-16kHz
Channel Crosstalk 50dB (MIC1 takes priority over all other inputs)
Signal-to-Noise Ratio Mic 1-3: 66dB or better
AUX 1-2: 80dB or better
THD less than 0.5% (at 1kHz, typical)
Cooling dynamic fan cooling
Protection Modes thermal overheating, overload, short-circuit
AC Power 100-130V/50Hz
Power Consumption 180W
Weight 19 pounds
Dimension 19.1" w x 15" d x 3.5" h
14
Dimensions
To keep the amplifier properly ventilated, a space of at least 4" should be cleared around the machine in
order to provide enough air circulation and prevent overheating.
4" 4"
4"
CH1
CH2
CH3
CH4
V
+
V
-
MIC1
MIN MAX
AVP100
2 4 6 8 10
MIC1 MIC2 M IC3AUX1 AUX2BASS T REBLE
3.5"
19.1"
4.3"
CH1
CH2
CH3
CH4
V
+
V
-
MIC1
MIN MA X
AVP100
2 4 6 8 10
MIC1 MI C2 MIC3AU X1 AUX2BA SS TRE BLE
17.2"
3.5"
AC 110V 5 0Hz
MUT E M IC 2 MIC 3
