Tiger TWR-180 User manual

© 2004 Alamo Group Inc.
OPERATOR'S MANUAL
This Operator's Manual is an integral part of the safe operation
of this machine and must be maintained with the unit at all
times. READ, UNDERSTAND, and FOLLOW the Safety and
Operation Instructions contained in this manual before
operating the equipment.
Published 12/04 Part No. C314TG010C
ROTARY CUTTER
$0.00
Tiger Corporation
3301 N. Louise Ave.
Sioux Falls, SD
57107
1-800-843-6849
1-605-336-7900
TWR-180
TWR-120

TO THE OWNER/OPERATOR/DEALER
All implements with moving parts are potentially hazardous. There is no substitute for a cautious, safe-minded
operator who recognizes the potential hazards and follows reasonable safety practices. The manufacturer has
designed this implement to be used with all its safety equipment properly attached to minimize the chance of
accidents.
BEFORE YOU START!! Read the safety messages on the implement and shown in your manual.
Observe the rules of safety and common sense!
WARRANTY INFORMATION:
Read and understand the complete Warranty Statement found in this Manual. Fill out the Warranty Registration
Form in full and return it to Alamo within 30 Days. Make certain the Serial Number of the Machine is recorded on
the Warranty Card and on the Warranty Form that you retain.

TABLE OF CONTENTS
TigerCorporationis registeredtrademarksofAlamoGroupInc.
SAFETYSECTION ........................................................................................................................................1-1
SafetyInformation...................................................................................................................................1-2
Safety Decal Location ..........................................................................................................................1-12
Safety Decal Description ......................................................................................................................1-14
Federal Laws & Regulations.................................................................................................................1-18
INTRODUCTIONSECTION ...........................................................................................................................2-1
Introduction .............................................................................................................................................2-2
ASSEMBLYSECTION ..................................................................................................................................3-1
General....................................................................................................................................................3-2
Connection to Tractor .............................................................................................................................3-2
LoweringWings.......................................................................................................................................3-3
Leveling ...................................................................................................................................................3-3
DrivelineShield Chains ...........................................................................................................................3-4
LamintatedTires .....................................................................................................................................3-4
Center Section Wheel Standards ...........................................................................................................3-4
Wing Lift Spacer Plates..........................................................................................................................3-5
Blade Rotations ......................................................................................................................................3-5
HydraulicPhasing Cylinders ..................................................................................................................3-6
RephasingGroove...................................................................................................................................3-6
Spool Valve Kit .......................................................................................................................................3-7
OPERATIONSECTION .................................................................................................................................4-1
MAINTENANCESECTION ............................................................................................................................5-1
Blades .....................................................................................................................................................5-2
Cutter Pan Retaining Nuts......................................................................................................................5-2
Hubs and Spindles...............................................................................................................................5-2,4
Hydraulics ...............................................................................................................................................5-3
Nuts and Bolts ........................................................................................................................................5-5
PanRemoval ...........................................................................................................................................5-6
Slip Clutches...........................................................................................................................................5-6
Tires.........................................................................................................................................................5-6
Lubrication............................................................................................................................................5-7,9
Storage....................................................................................................................................................5-9

SAFETY
SECTION

Safety Section 1-2
SAFETY
SAFETY
TWR-180/TWR-120 12/04
©2004AlamoGroupInc.
A safe and careful operator is the best operator. Safety is of primary importance to the
manufacturer and should be to the owner/operator. Most accidents can be avoided by being
aware of your equipment, your surroundings, and observing certain precautions. The first
section of this manual includes a list of Safety Messages that, if followed, will help protect the
operator and bystanders from injury or death. Read and understand these Safety Messages
beforeassembling,operating orservicingthis implement. Thisequipmentshouldonlybeoper-
ated by those persons who have read the Manual, who are responsible and trained, and who
knowhowtodo sosafelyandresponsibly.
TheSafetyAlertSymbolcombinedwith a Signal Word,as seen below, isused throughout this
manual and on decals which are attached to the equipment. The Safety Alert Symbol means:
“ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED!” The Symbol and Signal
Word are intended to warn the owner/operator of impending hazards and the degree of
possible injury faced when operating this equipment..
CAUTION! The lowest level of Safety Message; warns of possible injury. Decals
located on the Equipment with this Signal Word are Black and Yellow.
WARNING! Serious injury or possible death! Decals are Black and Orange.
DANGER! Imminent death/critical injury. Decals are Red and White. (SG-1)
Practice all usual and customary safe working precautions and
above all---remember safety is up to YOU. Only YOU can prevent
serious injury or death from unsafe practices.

Safety Section 1-3
SAFETY
SAFETY
©2004AlamoGroupInc.
TWR-180/TWR-120 12/04
READ, UNDERSTAND, and FOLLOW the following Safety
Messages. Serious injury or death may occur unless care is
taken to follow the warnings and instructions stated in the Safety
Messages. Always use good common sense to avoid hazards.
(SG-2)
Si no lee Ingles, pida ayuda a alguien que si lo lea
para que le traduzca las medidas de seguridad. (SG-3)
PELIGRO! ¡LEA EL
INSTRUCTIVO!
DANGER! Never operate the Tractor or Implement until you have read and
completelyunderstand this Manual,theTractorOperator’s Manual,
and each of the Safety Messages found in the Manual or on the
Tractor and Implement. Learn how to stop the tractor engine
suddenlyinanemergency. Never allow inexperienced or untrained
personneltoooperatetheTractorandImplementwithoutsupervision.
Make sure the operator has fully read and understood the manuals
prior to operation. (SG-4)
WARNING! Make certain that the “Slow Moving Vehicle” (SMV) sign is installed in
such a way as to be clearly visible and legible. When transporting the
Equipment use the Tractor flashing warning lights and follow all local
traffic regulations. (SG-6)
WARNING! OperatethisEquipmentonlywithaTractorequippedwithanapproved
roll-over-protectivesystem(ROPS). Alwayswearseatbelts. Serious
injuryorevendeathcouldresultfromfallingoffthetractor--particularly
during a turnover when the operator could be pinned under the
ROPS. (SG-7)
WARNING! DonotmodifyoralterthisImplement. DonotpermitanyonetomodifyoralterthisImplement,
any of its components or any Implement function. (SG-8)
DANGER! BEFORE leaving the tractor seat, always engage the brake and/or set
the tractor transmission in parking gear, disengage the PTO, stop the
engine,removethe key, and wait for all moving parts to stop. Place the
tractor shift lever into a low range or parking gear to prevent the tractor
fromrolling. NeverdismountaTractorthatismovingorwhiletheengine
is running. Operate the Tractor controls from the tractor seat only.
(SG-9)
WARNING! Always maintain the safety decals in good readable condition. If the
decalsaremissing,damaged,orunreadable,obtainandinstallreplace-
ment decals immediately. (SG-5)

Safety Section 1-4
SAFETY
SAFETY
TWR-180/TWR-120 12/04
©2004AlamoGroupInc.
DANGER! NeverallowchildrenorotherpersonstorideontheTractororImplement.
Falling off can result in serious injury or death. (SG-10)
DANGER! Never allow children to operate or ride on the Tractor or Implement.
(SGM-11)
WARNING! Do not mount the Tractor while the tractor is moving. Mount the
Tractor only when the Tractor and all moving parts are completely
stopped. (SG-12)
DANGER! Start tractor only when properly seated in the Tractor seat. Starting a
tractor in gear can result in injury or death. Read the Tractor operators
manual for proper starting instructions. (SG-13)
DANGER! Never work under the Implement, the framework, or any lifted
component unless the Implement is securely supported or blocked
up to prevent sudden or inadvertent falling which could cause
serious injury or even death. (SG-14)
DANGER! Do not operate this Equipment with hydraulic oil leaking. Oil is
expensiveanditspresencecouldpresentahazard. Donotcheckfor
leakswithyourhand! Useapieceofheavypaperorcardboard. High-
pressureoil streams from breaks in the line could penetrate the skin
andcausetissuedamageincludinggangrene. Ifoildoespenetratethe
skin, have the injury treated immediately by a physician knowledge-
able and skilled in this procedure. (SG-15)

Safety Section 1-5
SAFETY
SAFETY
©2004AlamoGroupInc.
TWR-180/TWR-120 12/04
WARNING! The operator and all support personnel should wear hard hats,
safety shoes, safety glasses, and proper hearing protection at all
timesforprotectionfrominjuryincludinginjuryfromitemsthrownby
the equipment. (SG-16)
WARNING! Transport only at safe speeds. Serious accidents and injuries can
result from operating this equipment at unsafe speeds. Understand
the Tractor and Implement and how it handles before transporting on
streets and highways. Make sure the Tractor steering and brakes are
in good condition and operate properly.
Before transporting the Tractor and Implement, determine the safe
transport speeds for you and the equipment. Make sure you
abide by the following rules:
Be aware of the operating conditions. Do not operate the Tractor with
weak or faulty brakes. When operating down a hill or on wet or rain
slick roads, the braking distance increases: use extreme care and
reduceyourspeed. Whenoperatingin trafficalways use theTractor’s
flashing warning lights and reduce your speed. Be aware of traffic
around you andwatch out for the other guy. (SG-19)
2. Test the equipment at a slow speed in turns. Increase the speed
through the turn only after you determine that it is safe to operate
at a higher speed. Use extreme care and reduce your speed when
turning sharply to prevent the tractor and implement from turning
over. Determine the maximum safe turning speed for you and this
equipment before operating on roads or uneven ground.
3. Only transport the Tractor and Implement at the speeds that you
have determined are safe and which allow you to properly control the
equipment.
1. Test the tractor at a slow speed and increase the speed slowly.
Apply the Brakes smoothly to determine the stopping
characteristics of the Tractor and Implement.
As you increase the speed of the Tractor the stopping distance
increases. Determine the maximum safe transport speed for
you and this Equipment.
CAUTION! PROLONGED EXPOSURE TO LOUD NOISE MAY CAUSE PER-
MANENT HEARING LOSS! Tractors with or without an Implement
attached can often be noisy enough to cause permanent hearing
loss. We recommend that you always wear hearing protection if the
noise in the Operator’s position exceeds 80db. Noise over 85db
over an extended period of time will cause severe hearing loss.
Noiseover 90db adjacent to the Operator over an extended period of
time will cause permanent or total hearing loss. Note: Hearing loss
from loud noise [from tractors, chain saws, radios, and other such
sources close to the ear] is cumulative over a lifetime without hope
of natural recovery. (SG-I7)

Safety Section 1-6
SAFETY
SAFETY
TWR-180/TWR-120 12/04
©2004AlamoGroupInc.
WARNING! Neverattempttolubricate,adjust,orremovematerialfromtheImplementwhileitisinmotion
or while tractor engine is running. Make sure the tractor engine is off before working on the
Implement! (SG-20)
WARNING! Periodically inspect all moving parts for wear and replace when
necessary with authorized service parts. Look for loose fasteners,
worn or broken parts, and leaky or loose fittings. Make sure all pins
have cotter pins and washers. Serious injury may occur from not
maintaining this machine in good working order. (SG-21)
WARNING! Always read carefully and comply fully with the manufacturers
instructions when handling oil, solvents, cleansers, and any other
chemical agent. (SG-22)
DANGER! Never run the tractor engine in a closed building or without adequate ventilation. The
exhaust fumes can be hazardous to your health. (SG-23)
DANGER! KEEPAWAYFROM ROTATINGELEMENTS toprevententanglement
and possible serious injury or death. (SG-24)
DANGER! Never allow children to play on or around Tractor or Implement. Children can slip or fall off the
Equipment and be injured or killed. Children can cause the Implement to shift or fall crushing
themselves or others. (SG-25)
WARNING! Donot exceed the rated PTOspeedforthe Implement. Excessive PTO
speeds can cause Implement driveline or blade failures resulting in
serious injury or death. (SG-26)
WARNING! DonotmowwithtwomachinesinthesameareaexceptwithCabtractorswiththewindowsclosed.
(SGM-11)

Safety Section 1-7
SAFETY
SAFETY
©2004AlamoGroupInc.
TWR-180/TWR-120 12/04
DANGER! NEVER use drugs or alcohol immediately before or while operating
theTractor and Implement. Drugs and alcohol will affect an operator’s
alertness and coordination and therefore affect the operator’s ability to
operate the equipment safely. Before operating the Tractor or
Implement, an operator on prescription or over-the-counter
medication must consult a medical professional regarding any side
effects of the medication that would hinder their ability to operate
the Equipment safely. NEVER knowingly allow anyone to operate
this equipment when their alertness or coordination is impaired.
Serious injury or death to the operator or others could result if the
operator is under the influence of drugs or alcohol. (SG-27)
WARNING! Mow only in conditions where you have clear visibility in daylight or with
adequate artificial lighting. Never mow in darkness or foggy conditions
whereyoucannotclearly seeat least100yardsinfront andto thesidesof
the tractor and mower. Make sure that you can clearly see and identify
passersby,steepslopes,ditches,drop-offs,overheadobstructions,power
lines,debris and foreign objects. If youareunableto clearly see this type
of items discontinue mowing. (SGM-1)
DANGER! There are obvious and hidden potential hazards in the operation of
this Mower. REMEMBER! This machine is often operated in heavy
brush and in heavy weeds. The Blades of this Mower can throw
objectsifshields arenot properly installedand maintained. Serious
injury or even death may occur unless care is taken to insure the
safety of the operator, bystanders, or passersby in the area. Do not
operate this machine with anyone in the immediate area. Stop
mowing if anyone is within 100 yards of mower. (SGM-2)
DANGER! AllSafetyShields,GuardsandSafetydevicesincluding
(butnotlimitedto)-theDeflectors,ChainGuards,Steel
Guards, Gearbox Shields, PTO integral shields , and
Retractable Door Shields should be used and main-
tained in good working condition. All safety devices
should be inspected carefully at least daily for missing
orbrokencomponents. Missing,broken,or wornitems
must be replaced at once to reduce the possibility of
injury or death from thrown objects, entanglement, or
blade contact. (SGM-3)
DANGER! Therotatingpartsofthismachinehavebeendesignedandtestedfor
ruggeduse. However,thebladescouldfailuponimpactwithheavy,
solidobjectssuchasmetalguardrailsandconcretestructures. Such
impactcouldcausethe broken objects to be thrown outward at very
highvelocities. Toreducethepossibilityofpropertydamage,serious
injury,or even death, never allowthe cutting blades to contact such
obstacles. (SGM-4)

Safety Section 1-8
SAFETY
SAFETY
TWR-180/TWR-120 12/04
©2004AlamoGroupInc.
WARNING! Many varied objects, such as wire, cable, rope, or chains, can become
entangledin theoperating parts ofthe mowerhead. Theseitems could
then swing outside the housing at greater velocities than the blades.
Suchasituationisextremelyhazardousandcouldresultinseriousinjury
orevendeath. Inspectthecuttingareaforsuchobjectsbeforemowing.
Remove any like object from the site. Never allow the cutting blades to
contact such items. (SGM-6)
WARNING! Mowatthespeedthatyoucansafelyoperateandcontrolthetractorand
mower. Safe mowing speed depends on terrain condition and grass
type, density, and height of cut. Normal ground speed range is from 0
to 5 mph. Use slow mowing speeds when operating on or near steep
slopes, ditches, drop-offs, overhead obstructions, power lines, or when
debris and foreign objects are to be avoided. (SGM-7)
WARNING! Mowonlyinconditionswhereyouhaveclearvisibilitiesindaylightor
with adequate artificial lighting. Never mow in darkness or foggy
conditions where you cannot clearly see at least 100 yards in front
and to the sides of the Tractor and Mower. Make sure that you can
clearlysee and identify passersby, steep slopes, ditches, drop-offs,
overhead obstructions, power lines, gas lines, debris, and foreign
objects. If you do not have clear and safe visibility discontinue
mowing. (SGM-11)
WARNING! MowatthespeedthatyoucansafelyoperateandcontroltheTractor
and Mower. Safe mowing speed depends on terrain condition and
grass type, density, and height of cut. Normal ground speed range
is from 0 to 5 mph. Use slow mowing speeds when operating on or
nearsteepslopes,ditches,drop-offs,overheadobstructions,power
lines,gaslinesorwhendebris,andforeignobjectsaretobeavoided.
(SGM-12)
WARNING! Extremecareshouldbetakenwhenoperatingnearlooseobjectssuch
as gravel, rocks, wire, and other debris. Inspect the area before
mowing. Foreignobjectsshouldberemovedfromthesitetoprevent
machinedamageand/orbodilyinjuryorevendeath. Anyobjectsthat
cannotberemovedmustbeclearlymarkedandcarefullyavoidedby
the operator. Stop mowing immediately if blades strike a foreign
object. Repair all damage and make certain rotor or blade carrier is
balancedbeforeresumingmowing. (SGM-5)
WARNING! Avoid mowing in reverse direction when possible. Check to make sure
there are no persons behind the mower and use extreme care when
mowinginreverse. Mowonlyataslowgroundspeedwhereyoucansafely
operateandcontrolthetractorandmower. Nevermowanarea thatyou
havenot inspected and removed debris orforeignmaterial. (SGM-8)
WARNING! Donotput hands or feet under mower decks. Blade Contact can result
seriousinjuryorevendeath. Stayawayuntilallmotionhas stoppedand
the decks are securely blocked up. (SGM-9)
DANGER! Replacebentorbrokenbladewithnewblades. NEVERATTEMPTTO
STRAIGHTEN OR WELD ON BLADES SINCE THIS WILL LIKELY
CRACK OR OTHERWISE DAMAGE THE BLADE WITH SUBSE-
QUENTFAILUREANDPOSSIBLESERIOUSINJURYFROMTHROWN
BLADES. (SGM-10)

Safety Section 1-9
SAFETY
SAFETY
©2004AlamoGroupInc.
TWR-180/TWR-120 12/04
WARNING! Avoid mowing in the reverse direction when possible. Check to
makesure there are no persons behind the mower and use extreme
care when mowing in reverse. Mow only at a slow ground speed
where you can safely operate and control the Tractor and Mower.
Never mow an area in the reverse direction that you have not
inspected and removed debris or foreign material. (SGM-13)
DANGER! Always disconnect the main PTO Driveline from the Tractor before
performing service on the Mower. Never work on the Mower with the
tractor PTO driveline connected and running. Blades or Drivelines could
turn without warning and cause immediate entanglement, injury or death.
(SRM-3)
DANGER! Do not turn so sharp or lift mower so high to produce a severe
"knocking" of the Driveline which will cause accelerated wear and
breakage of drive train components and could result inpossible injury
from the separated Driveline sections. (SRM-4)
WARNING! Do not let the Blades turn when the Mower Deck is raised for
any reason, including clearance or for turning. Raising the
Mower deck exposes the Cutting Blades which creates a
potentially serious hazard and could cause serious injury or even
death from objects thrown from the Blades. (SRM-7)
WARNING! NeverleaveTractorandImplementedunattendedwhiletheimplement
isintheliftedposition. Accidentaloperationofliftingleverorahydraulic
failure maycausesuddendropofunitwith injuryordeathbycrushing.
To properly park the implement when disconnecting it from the tractor,
lowerthestandandputtheretainingpinsecurelyinplace,orputasecure
support under the A-Frame. Lower the implement carefully to the
ground. Do not put hands or feet under lifted components. (S3PT-1)
DANGER! RotaryMowers are capable under adverse conditions
of throwing objects for great distances (100yardsor
more) and causing serious injury or death. Follow
safety messages carefully
-Front and Rear Deflectors, Chain Guards, or Bands are installed
and in good, workable condition;
-Mower sections or Wings are running close to and parallel to the
ground without exposed Blades;
-Passersby are outside the existing thrown-object zone;
-All areas have been thoroughly inspected and all foreign material
such as rocks, cans, glass, andgeneraldebrishasbeenremoved.
NOTE: Wherethere are grass and weeds high enoughto hide debris
that could be struck by the blades, the area should be: inspected
andlargedebrisremoved,mowedatanintermediateheight,inspected,
closely with any remaining debris being removed, and mowed again
at desired final height. (This will also reduce power requiredto mow,
reduce wear and tear on the Mower drivetrain, spread cut material
better, eliminate streaking, and make the final cut more uniform.)
(SRM-1)
STOPMOWING IFPASSERSBY ARE WITHIN100 YARDSUNLESS:

Safety Section 1-10
SAFETY
SAFETY
TWR-180/TWR-120 12/04
©2004AlamoGroupInc.
CAUTION! To prevent tipping of implement when stored in folded position, use
carrying wheels or adequate stands on center frame. (S3PT-6)
DANGER! There are obvious and hidden potential hazards in the operation of
this Implement as in all power-driven or pulled equipment.
REMEMBER! Thismachineisoftenoperatedinroughterrainconditions
thatincludetallgrass,weeds, gullies,holes,slopes,hiddenobstructions
andthelike. Seriousinjuryorevendeathmayoccurunlesscareistaken
toassurethesafety ofthe operatorand bystandersinthearea. Do not
operate this machine with anyone in the immediate area. (S3PT-7)
WARNING! The rotating parts of this machine continue to rotate even after the PTO
has been turned off. The operator should remain in his seat for 60
seconds after the brake has been set, the PTO disengaged, the tractor
turned off, and all evidence of rotation has ceased. (3PT-10)
“Wait a minute...Save a life!”
DANGER! Be particularly careful when transporting the Implement using the
tractor. Turn curves or go up or down hills only at a low speed and at a
gradual steering angle. Make certain that at least 20% of the tractor’s
weight is on the front wheels to maintain safe steerage. Slow down on
rough or uneven surfaces. (STI-1)
DANGER! When the Wings are folded for transport, the center of gravity is raised
and the possibility of overturn is increased. Drive slowly and use
extremecaution when turning on hillsides. Overturning the Implement
could cause the Implement to overturn the Tractor and vice versa
resulting in serious injury or even death. Never fold wings on a
hillside...the Implement may overturn. (STI-2)
DANGER! DO NOT allow any person under a folded wing unless wing is securely
locked up or supported. DO NOT approach the Implement unless the
Tractor is turned off and all motion has ceased. Never work under the
frame work, or any lifted component unless the implement is securely
supported or blocked up. A sudden or inadvertent fall by any of these
components could cause serious injury or even death. (STI-3)
WARNING! Use extreme care when lowering or unfolding the implement’s wings.
Make sure no bystanders are close by or underneath the wings. Allow
ample clearance around the implement when folding or unfolding the
wings. Use extreme caution around buildings or overhead power lines.
(S3PT-5)
DANGER! Make sure the PTO shield, integral driveline shields, and input shields are
is installed when using PTO-driven equipment. Always replace any
shield if it is damaged or missing. (S3PT-8)
WARNING! Relieve hydraulic pressure prior to doing any maintenance or repair work
on the Implement. Place the Implement on the ground or securely
blocked up, disengage the PTO, and turn off the tractor engine. Push
and pull the Remote Cylinder lever in and out several times prior to
starting any maintenance or repair work. (S3PT-9)

Safety Section 1-11
SAFETY
SAFETY
©2004AlamoGroupInc.
TWR-180/TWR-120 12/04
WARNING! Never unhitch without using the Tongue Jack. The Tongue is
very heavy. Attempting to lift the Tongue without using the Tongue
Jack could cause strains or other injury. Allowing the tongue to
fall suddenly and unexpectedly could result in crushing injury.
Use the Tongue Jack for lifting the mower only. Overloading the
Tongue Jack can cause failure with possible serious bodily injury
or even death. (STI-4)
InadditiontothedesignandconfigurationofthisImplement,includingSafetySignsandSafetyEquipment,hazard
control and accident prevention are dependent upon the awareness, concern, prudence, and proper training of
personnel involved in the operation, transport, maintenance, and storage of the machine. Refer also to Safety
MessagesandoperationinstructionineachoftheappropriatesectionsoftheTractorandEquipmentManuals. Pay
close attention to the Safety Signs affixed to the Tractor and Equipment. (SG-18)
CAUTION! On a fully-assembled unit, do not remove the Wing Retaining Strap
until hoses are attached to the tractor and the Wing Cylinders are
filled with oil. Lower the Wings slowly and carefully. Keep bystand-
ers away during operations. (STI-5)
WARNING! Only tow the Implement behind a properly sized and equipped Tractor which exceeds the weight
of the Implement by at least 20%. DO NOT tow the Implement behind a truck or other type of
vehicle. Never tow the Implement and another Implement connected in tandem. Never tow the
Implement at speeds over 20 MPH. (STI-6)
Followtheseguidelinestoreducetheriskofequipmentandgrassfires
whileoperating, servicing, and repairingtheMower and Tractor:
-Equip the Tractor with a fire extinguisher in an accesible location.
-DoNot operate the Mower on a Tractor with an underframe exhaust.
-DoNot smoke or have an open flame near the Mower andTractor.
-DoNot drive into burning debris or freshly burnt areas.
-Ensureslipclutchesareproperlyadjustedtopreventexcessiveslippage
andplate heating.
-Neverallowclippingsordebristocollectneardrivelines,slipclutches,
and gearboxes. Periodically shut down the Tractor and Mower and
WARNING!
PARTSINFORMATION
Tigermowersusebalancedandmatchedsystemcomponentsforbladecarriers,blades,cuttershafts,knives,
knife hangers, rollers, drivetrain components, and bearings. These parts are made and tested to Tiger
specifications. Non-genuine"willfit"partsdonotconsistentlymeetthesespecifications. Theuseof“willfit”
partsmayreducemowerperformance,voidmowerwarranties,andpresentasafetyhazard. UsegenuineTiger
mower parts for economy and safety.
(SPTM-1)
SEEYOURTIGERDEALER

Safety Section 1-12
SAFETY
SAFETY
TWR-180/TWR-120 12/04
©2004AlamoGroupInc.
44
45
46
43
47

Safety Section 1-13
SAFETY
SAFETY
©2004AlamoGroupInc.
TWR-180/TWR-120 12/04
NOTE: Tigersupplies safety decals on this product topromote safe operation. Damage to the decalsmay occur
whilein shipping, use, or reconditioning. Tiger cares about the safety of its customers, operators, andbystanders,
andwillreplacethesafetydecalsonthisproductinthefield,free of charge (Some shipping and handling charges
mayapply). Contact your Tiger dealerto order replacement decals.
ITEM PARTNO. QTY. QTY. DESCRIPTION
1 00769737 2 1 RotatingBlades
2 D114 1 1 1000 RPM Only
or D103 1 1 540 RPM Only
3 226-148 1 1 Hydraulic Fluid Pressure
4 02978846 6 4 RotatingDriveline
6 02978848 2 2 Red Reflector
7 02978849 4 3 AmberReflector
8 00749117 1 1 MultiWarning
9 D138 2 1 BladeRotation, CW
10 02978851 1 1 MadeinNorthAmerica
11 1 1 Serial Plate
12 02978853 4 3 CheckOil Level
13 02978854 1 1 LubricationRequirements
14 D102 1 1 Safety Chain/ DrawbarAdjustment
15 00769736 1 1 Failure to Maintain Shields
16 00753840 2 2 Stay Clear
17 00763613 1 1 FrozenClutches
18 02978856 3 2 Shield Missing
19 00763977 1 1 NoticetoOwner
20 02978843* 3 2 1000 RPM Logo
21 226-328 3 2 Do Not Operate If Guard Missing
22 D137 1 1 Blade Rotation, CCW
23 02978859 13 10 8 HR Greasing, StandardHitch Units
25 02978861 4 3 4 HR Greasing
26 02978862 2 1 TransportPin Locations
28 02978864 1 1 GreaseNipple Located On Underside
29 226-191 1 1 Read Manual - Spanish
30 00756494 1 1 MakeCertain Driveline Length
31 00773723 1 1 ReadDriveline Manual - Spanish
38 226-042 3 2 Slip ClutchAdjustment
39 03200347 1 1 SMV Emblem
40 00777394 1 1 TransportSpeed
41 00777395 1 1 KeepDeckClear
42 999403 1 10’Counterweight
43 02978516 1 1 ManualCanister
44 10058000 2 2 ¼” Bolt
45 02962363 2 2 ¼” Locknut
46 02978992C 1 1 Operators Manual
* On 1000 RPM Units Only
** Used on 10' Cutter Units Only

Safety Section 1-14
SAFETY
SAFETY
TWR-180/TWR-120 12/04
©2004AlamoGroupInc.
14--D102
30--00756494
4--02978846
19--00763977
3--226-148
29--226-191

Safety Section 1-15
SAFETY
SAFETY
©2004AlamoGroupInc.
TWR-180/TWR-120 12/04
16--00753840
2--D114
2--D103
17--00763613
6--02978848REDREFLECTOR
7--02978849YELLOWREFLECTOR
8--00749117
SEE INSIDE FORNT COVER
11 - - SERIAL PLATE
23-- 02978859 25-- 02978861
12-- 02978853
28-- 02978864

Safety Section 1-16
SAFETY
SAFETY
TWR-180/TWR-120 12/04
©2004AlamoGroupInc.
9--D138
22--D137
31-- 00773723
15-- 00769736
18-- 02978856
20--02978843
(On1000 RPM Units Only)
