Tiger FLX10 User manual

Published04-06 S/NA10100003306-A10100152509inclusive Part No.A101-01-0C
S/NA10200002306-A10200051405inclusive
OPERATOR'S MANUAL
This Operator's Manual is an integral part of the safe operation
of this machine and must be maintained with the unit at all
times. READ, UNDERSTAND, and FOLLOW the Safety and
Operation Instructions contained in this manual before
operating the equipment.
© 2006Alamo Group Inc.
Flex-Arm
Tiger
3301N. LouiseAve.
SiouxFalls, SD 57107
1-800-843-6849
1-605-336-7900
FLX15/FLX10

TO THE OWNER/OPERATOR/DEALER
All implements with moving parts are potentially hazardous. There is no substitute for a cautious, safe-minded
operator who recognizes the potential hazards and follows reasonable safety practices. The manufacturer has
designed this implement to be used with all its safety equipment properly attached to minimize the chance of
accidents.
BEFORE YOU START!! Read the safety messages on the implement and shown in your manual.
Observe the rules of safety and common sense!
WARRANTY INFORMATION:
Read and understand the complete Warranty Statement found in this Manual. Fill out the Warranty Registration
Form in full and return it to within 30 Days. Make certain the Serial Number of the Machine is recorded on the
Warranty Card and on the Warranty Form that you retain.

DEALER’S PREDELIVERY SERVICE GUIDE
for the SCHULTE FLX15/ FLX10
DETAILS OF ITEMS LISTED BELOWARE COVERED IN THIS OPERATOR’S MANUAL
____ Shipping damage corrected
____ Set up machine as outlined in the shipping instructions attached to these instructions.
____ Check that all safety decals are in good condition, replace if necessary.
____ Check that gearboxes have been filled with oil.
____ Check that all grease fittings have been lubricated.
DEALER’S DELIVERY GUIDE
for the SCHULTE FLX15/ FLX10
____ Mounting and removal from tractor
____ Operation
____ Adjustments
____ Lubrication
____ Maintenance
____ Operator’s safety precautions
____ User’s responsibility and warranty
____ Operator’s manual delivered to owner
____ Operator instructed on contents of owner’s manual

TABLE OF CONTENTS
SAFETYSECTION
Safety Decals..................................................................................................................................1-2
Safety Decal Location ....................................................................................................................1-14
SafetyInformation........................................................................................................................... 1-16
Federal Laws and Regulations .......................................................................................................1-20
INTRODUCTIONSECTION ................................................................................................................... 2-1
ASSEMBLYSECTION ..........................................................................................................................3-1
Assembly From Shipping Position........................................................................................................3-2
Adjustments........................................................................................................................................... 3-3
Setting The Castor Wheels ...................................................................................................................3-3
ConnectionTo Tractor ........................................................................................................................... 3-3
ConnectionTo Cutter.............................................................................................................................3-4
Connection Strut To Cutter.................................................................................................................... 3-5
Connecting Cutter Hoses To Hydraulic Breakaway Stand ...................................................................3-5
General...................................................................................................................................................3-6
OPERATIONSECTION ......................................................................................................................... 4-1
MAINTENANCESECTION .................................................................................................................... 5-1
Condition of Nuts and Bolts...................................................................................................................5-2
CastorCone Spring Tension..................................................................................................................5-2
Bolt Grade and Torque ..........................................................................................................................5-2
Tires .......................................................................................................................................................5-2
Hubs and Spindles................................................................................................................................. 5-2
GreasingInstallations............................................................................................................................5-2
Tightening Instructions For 618 Hubs ...................................................................................................5-4
Hydraulics ..............................................................................................................................................5-4
LubricationGearbox ..............................................................................................................................5-5
UniversalJoint Assemblies ................................................................................................................... 5-6
Frame Pivot Points Lube .......................................................................................................................5-6
Specifications ........................................................................................................................................5-7
Schulte is registered trademarks of Alamo Group Inc.

SAFETY
SECTION
Safety Section 1-1

Safety Section 1-2
FLX15/10 04/06
SAFETY
© 2006Alamo Group Inc.
SAFETY
A safe and careful operator is the best operator. Safety is of primary importance to the
manufacturer and should be to the owner/operator. Most accidents can be avoided by being
aware of your equipment, your surroundings, and observing certain precautions. The first
section of this manual includes a list of Safety Messages that, if followed, will help protect the
operator and bystanders from injury or death. Read and understand these Safety Messages
beforeassembling,operatingorservicing this implement. Thisequipmentshouldonlybe oper-
ated by those persons who have read the Manual, who are responsible and trained, and who
knowhow to doso safely andresponsibly.
TheSafety Alert Symbol combined witha Signal Word, as seenbelow, is used throughout this
manual and on decals which are attached to the equipment. The Safety Alert Symbol means:
“ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED!” The Symbol and Signal
Word are intended to warn the owner/operator of impending hazards and the degree of
possible injury faced when operating this equipment..
CAUTION! The lowest level of Safety Message; warns of possible injury. Decals
located on the Equipment with this Signal Word are Black and Yellow.
WARNING! Serious injury or possible death! Decals are Black and Orange.
DANGER! Imminent death/critical injury. Decals are Red and White. (SG-1)
Practice all usual and customary safe working precautions and
above all---remember safety is up to YOU. Only YOU can prevent
serious injury or death from unsafe practices.
READ, UNDERSTAND, and FOLLOW the following Safety
Messages. Serious injury or death may occur unless care is
taken to follow the warnings and instructions stated in the Safety
Messages. Always use good common sense to avoid hazards.
(SG-2)

Safety Section 1-3
SAFETY
© 2006Alamo Group Inc.
SAFETY
FLX15/10 04/06
Si no lee Ingles, pida ayuda a alguien que si lo lea para que le
traduzca las medidas de seguridad. (SG-3)
PELIGRO!
!LEA EL INSTRUCTIVO!
DANGER! Never operate the Tractor or Implement until you have read and
completelyunderstandthisManual,theTractorOperator’s Manual,
and each of the Safety Messages found in the Manual or on the
Tractor and Implement. Learn how to stop the tractor engine
suddenlyinanemergency. Neverallowinexperiencedoruntrained
personnel too operate the Tractor and Implement without supervi-
sion. Make sure the operator has fully read and understood the
manuals prior to operation. (SG-4)
WARNING! Always maintain the safety decals in good readable condition. If the
decalsaremissing,damaged,orunreadable,obtainandinstallreplace-
ment decals immediately. (SG-5)
WARNING! Operate this Equipment only with a Tractor equipped with an ap-
provedroll-over-protectivesystem(ROPS). Alwayswearseatbelts.
Serious injury or even death could result from falling off the tractor-
-particularly during a turnover when the operator could be pinned
under the ROPS. (SG-7)
WARNING! Do not modify or alter this Implement. Do not permit anyone to
modify or alter this Implement, any of its components or any Imple-
ment function. (SG-8)
DANGER! BEFORE leaving the tractor seat, always engage the brake and/or set
the tractor transmission in parking gear, disengage the PTO, stop the
engine,removethekey,andwaitforallmovingpartstostop. Placethe
tractor shift lever into a low range or parking gear to prevent the tractor
fromrolling. NeverdismountaTractorthatismovingorwhiletheengine
is running. Operate the Tractor controls from the tractor seat only.
(SG-9)
DANGER! NeverallowchildrenorotherpersonstorideontheTractororImplement.
Falling off can result in serious injury or death. (SG-10)
WARNING! Make certain that the “Slow Moving Vehicle” (SMV) sign is installed in
such a way as to be clearly visible and legible. When transporting the
EquipmentusetheTractorflashingwarninglightsandfollowalllocaltraffic
regulations.(SG-6)

Safety Section 1-4
FLX15/10 04/06
SAFETY
© 2006Alamo Group Inc.
SAFETY
DANGER! Neverallowchildrento operate or ride on the TractororImplement.
(SG-11)
WARNING! Do not mount the Tractor while the tractor is moving. Mount the
Tractor only when the Tractor and all moving parts are completely
stopped. (SG-12)
DANGER! Start tractor only when properly seated in the Tractor seat. Starting a
tractor in gear can result in injury or death. Read the Tractor operators
manual for proper starting instructions. (SG-13)
DANGER! NeverworkundertheImplement,theframework,oranyliftedcomponent
unlesstheImplementissecurelysupportedorblockeduptoprevent
suddenorinadvertentfallingwhichcouldcauseseriousinjuryoreven
death. (SG-14)
DANGER! Do not operate this Equipment with hydraulic oil leaking. Oil is
expensiveanditspresencecouldpresentahazard. Donotcheckfor
leaks with your hand! Use a piece of heavy paper or cardboard.
High-pressureoilstreamsfrombreaksinthelinecouldpenetratethe
skin and cause tissue damage including gangrene. If oil does
penetratetheskin,havetheinjurytreatedimmediatelybyaphysician
knowledgeable and skilled in this procedure. (SG-15)
WARNING! Theoperatorandallsupportpersonnelshouldwearhardhats,safety
shoes, safety glasses, and proper hearing protection at all times for
protection from injury including injury from items thrown by the
equipment. (SG-16)

Safety Section 1-5
SAFETY
© 2006Alamo Group Inc.
SAFETY
FLX15/10 04/06
WARNING! Transportonlyatsafe speeds. Serious accidents and injuriescan result
fromoperatingthisequipmentatunsafespeeds. UnderstandtheTractor
and Implement and how it handles before transporting on streets and
highways. MakesuretheTractorsteeringandbrakesareingood condi-
tionandoperateproperly.
BeforetransportingtheTractorand Implement, determine the safe
transportspeeds for you andtheequipment. Make sure you abide by
thefollowingrules:
Be aware of the operating conditions. Do not operate the Tractor with
weakorfaulty brakes. When operating downahillor on wet orrainslick
roads,thebrakingdistanceincreases:useextremecareandreduce your
speed. Whenoperatingintraffic always use the Tractor’s flashingwarn-
ing lights and reduce your speed. Be aware of traffic around you and
watch out for the other guy. (SG-19)
Test the equipment at a slow speed in turns. Increase the speed
through the turn only after you determine that it is safe to operate
at a higher speed. Use extreme care and reduce your speed when
turning sharply to prevent the tractor and implement from turning
over. Determine the maximum safe turning speed for you and this
equipmentbeforeoperating on roads orunevenground.
Only transport the Tractor and Implement at the speeds that you
have determined are safe and which allow you to properly control the
equipment.
Test the tractor at a slow speed and increase the speed slowly.
Apply the Brakes smoothly to determine the stopping
characteristicsofthe Tractor and Implement.
As you increase the speed of the Tractor the stopping distance
increases. Determine the maximum safe transport speed for
you and this Equipment.
2.
1.
3.
WARNING! Never attempt to lubricate, adjust, or remove material from the
Implementwhileitisinmotionorwhiletractorengineisrunning. Make
sure the tractor engine is off before working on the Implement.
(SG-20)
CAUTION! PROLONGED EXPOSURE TO LOUD NOISE MAY CAUSE
PERMANENT HEARING LOSS! Tractors with or without an
Implement attached can often be noisy enough to cause permanent
hearing loss. We recommend that you always wear hearing
protection if the noise in the Operator’s position exceeds 80db.
Noise over 85db over an extended period of time will cause severe
hearing loss. Noise over 90db adjacent to the Operator over an
extended period of time will cause permanent or total hearing loss.
Note: Hearing loss from loud noise [from tractors, chain saws,
radios, and other such sources close to the ear] is cumulative over a
lifetime without hope of natural recovery. (SG-I7)
WARNING! Alwaysreadcarefullyandcomplyfullywiththemanufacturersinstructions
when handling oil, solvents, cleansers, and any other chemical agent.
(SG-22)

Safety Section 1-6
FLX15/10 04/06
SAFETY
© 2006Alamo Group Inc.
SAFETY
WARNING! Periodicallyinspect all movingpartsfor wear andreplace when neces-
sary with authorized service parts. Look for loose fasteners, worn or
brokenparts,and leaky orloosefittings. Makesureallpins have cotter
pins and washers. Serious injury may occur from not maintaining this
machine in good working order. (SG-21)
DANGER! KEEP AWAY FROM ROTATING ELEMENTS to prevent entanglement
and possible serious injury or death. (SG-24)
DANGER! Never run the tractor engine in a closed building or without adequate
ventilation. The exhaust fumes can be hazardous to your health.
(SG-23)
DANGER! Neverallow children toplayon or aroundTractoror Implement. Children
can slip or fall off the Equipment and be injured or killed. Children can
cause the Implement to shift or fall crushing themselves or others. (SG-25)
WARNING! Do not exceed the rated PTO speed for the Implement. Excessive PTO
speeds can cause Implement driveline or blade failures resulting in
serious injury or death. (SG-26)
DANGER! NEVER use drugs or alcohol immediately before or while operating the
Tractor and Implement. Drugs and alcohol will affect an operator’s
alertness and coordination and therefore affect the operator’s ability to
operate the equipment safely. Before operating the Tractor or
Implement,an operator onprescription or over-the-countermedication
must consult a medical professional regarding any side effects of the
medication that would hinder their ability to operate the Equipment
safely. NEVER knowingly allow anyone to operate this equipment
when their alertness or coordination is impaired. Serious injury or
death to the operator or others could result if the operator is under the
influence of drugs or alcohol. (SG-27)
DANGER! OperatetheTractorand/orImplementcontrolsonlywhileproperlyseatedin
theTractorseatwiththeseatbeltsecurelyfastenedaroundyou. Inadvertent
movementoftheTractororImplementmaycauseseriousinjuryordeath. (SG-
29)

Safety Section 1-7
SAFETY
© 2006Alamo Group Inc.
SAFETY
FLX15/10 04/06
WARNING! EngineExhaust, some ofits constituents, andcertain vehicle
componentscontain oremitchemicals knownto thestate of
Californiato causecancer andbirth defectsorother
reproductiveharm. (SG-30)
WARNING! Batteryposts,terminals and related accessoriescontain lead
andlead compounds,chemicals knownto thestate ofCalifor-
niato causecancer andbirthdefects orother reproductive
harm.WashHandsafterhandling. (SG-31)
WARNING! Prolonged operation may cause operator boredom and fatigue affecting safe
operation. Take scheduled work breaks to help prevent these potentially
impaired operating conditions. Never operate the Implement and Tractor in a
fatigued or bored mental state which impairs proper and safe operation. (SG-32)
WARNING! Use extreme caution when getting onto the Implement to perform repairs,
maintenanceandwhenremovingaccumulatedmaterial. Onlystandonsolid
flatsurfaces toensuregoodfooting. Usealadderor raisedstandtoaccess
highspotswhichcannotbereachedfromgoundlevel. Slippingandfallingcan
cause serious injury or death. (SG-33)
WARNING! Avoidcontactwithhotsurfacesincludinghydraulicoiltanks,pumps,motors,
valvesandhoseconnections. Relievehydraulicpressurebeforeperforming
maintenance or repairs. Use gloves and eye protection when servicing hot
components. Contactwithahotsurfaceorfluidcancauseseriousinjuryfrom
burns or scalding. (SG-34)
WARNING! Perform service, repairs and lubrication according to the maintenance
section. Ensuretheunitisproperlylubricatedasspecifiedinthelubrication
schedule and all bolts and nuts are properly torqued. Failure to properly
service,repairandmaintainthisImplementingoodoperatingconditioncould
cause component failure and possible serious injury or even death. (SG-35)
DANGER! DONOToperatethisImplementonaTractorthatisnotproperlymaintained.
Should a mechanical or Tractor control failure occur while operating,
immediately shut down the Tractor and perform repairs before resuming
operation. Seriousinjuryandpossibledeathcouldoccurfromnotmaintaining
this Implement and Tractor in good operating condition. (SG-36)

Safety Section 1-8
FLX15/10 04/06
SAFETY
© 2006Alamo Group Inc.
SAFETY
WARNING! Mow only in conditions where you have clear visibility in daylight or with
adequate artificial lighting. Never mow in darkness or foggy conditions
whereyoucannot clearlyseeatleast100 yards infrontandtothe sides of
the tractor and mower. Make sure that you can clearly see and identify
passersby,steepslopes,ditches,drop-offs,overheadobstructions,power
lines,debrisandforeignobjects. Ifyou are unable to clearly see this type
of items discontinue mowing. (SGM-1)
DANGER! The rotating parts of this machine have been designed and tested for
rugged use. However, the blades could fail upon impact with heavy,
solid objects such as metal guard rails and concrete structures. Such
impact could cause the broken objects to be thrown outward at very
high velocities. To reduce the possibility of property damage, serious
injury, or even death, never allow the cutting blades to contact such
obstacles. (SGM-4)
WARNING! Extremecare shouldbetakenwhenoperatingnearlooseobjectssuch
asgravel,rocks,wire,andotherdebris. Inspecttheareabeforemowing.
Foreign objects should be removed from the site to prevent machine
damageand/or bodily injuryorevendeath. Anyobjects thatcannotbe
removedmustbeclearlymarkedandcarefullyavoidedbytheoperator.
Stop mowing immediately if blades strike a foreign object. Repair all
damage and make certain rotor or blade carrier is balanced before
resuming mowing. (SGM-5)
WARNING! Many varied objects, such as wire, cable, rope, or chains, can become
entangledintheoperatingpartsofthemowerhead. Theseitemscouldthen
swing outside the housing at greater velocities than the blades. Such a
situation is extremely hazardous and could result in serious injury or even
death. Inspectthecuttingareaforsuchobjectsbeforemowing. Removeany
like object from the site. Never allow the cutting blades to contact such
items. (SGM-6)
DANGER! Thereareobviousandhiddenpotentialhazardsintheoperationofthis
Mower. REMEMBER! Thismachineisoftenoperatedinheavybrush
and in heavy weeds. The Blades of this Mower can throw objects if
shields are not properly installed and maintained. Serious injury or
evendeathmayoccurunless careistaken toinsurethesafetyofthe
operator, bystanders, or passersby in the area. Do not operate this
machinewithanyoneintheimmediatearea. Stopmowingifanyone
is within 100 yards of mower. (SGM-2)
DANGER! AllSafetyShields,GuardsandSafetydevicesincluding
(butnotlimitedto)-theDeflectors,ChainGuards,Steel
Guards, Gearbox Shields, PTO integral shields , and
Retractable Door Shields should be used and main-
tained in good working condition. All safety devices
should be inspected carefully at least daily for missing
orbrokencomponents. Missing,broken,or wornitems
must be replaced at once to reduce the possibility of
injury or death from thrown objects, entanglement, or
blade contact. (SGM-3)

Safety Section 1-9
SAFETY
© 2006Alamo Group Inc.
SAFETY
FLX15/10 04/06
DANGER! Replace bent or broken blade with new blades. NEVER ATTEMPT
TO STRAIGHTEN OR WELD ON BLADES SINCE THIS WILL
LIKELY CRACK OR OTHERWISE DAMAGE THE BLADE WITH
SUBSEQUENTFAILUREANDPOSSIBLESERIOUSINJURYFROM
THROWN BLADES. (SGM-10)
WARNING! DonotmowwithtwomachinesinthesameareaexceptwithCabtractors
with the windows closed. (SGM-11)
WARNING! Donot put hands orfeet under mower decks. BladeContactcan result
seriousinjuryorevendeath. Stayawayuntilallmotionhas stoppedand
the decks are securely blocked up. (SGM-9)
Followthese guidelines to reducetherisk of equipmentandgrass fires
whileoperating,servicing,andrepairingtheMowerandTractor:
-Equip the Tractor with a fire extinguisher in an accessible location.
-DoNotoperate the Mower on aTractorwithanunderframe exhaust.
-DoNotsmoke or have anopenflamenearthe Mower andTractor.
-DoNotdrive into burning debris or freshlyburntareas.
-Ensureslip clutchesareproperlyadjustedtopreventexcessiveslippage
andplateheating.
-Neverallow clippings or debristocollect near drivelines,slipclutches,
andgearboxes. Periodically shutdowntheTractorandMowerand clean
clippings and collected debris from the mower deck. (SGM-12)
WARNING!
WARNING! DONOTweldorrepairrotatingmowercomponents. Weldsandother
repairsmaycauseseverevibrationand/orcomponentfailureresulting
in parts being thrown from the mower causing serious bodily injury.
Seeyour AuthorizedDealer forproperrepairs. (SGM-13)
DANGER! TheMowerisdesignedforcertainmowingapplicationsandisratedto
cutup toaspecificsizevegetation(seeMowerStandardEquipment
andSpecifications). DO NOTusethisMowertocutvegetationabove
the Mower’s rated capacity or to cut any type of non-vegetative
material. OnlyoperatethisMoweronaproperlysizedandequipped
Tractor. Operating this Mower in an application for which it is not
designedand/oroperatingtheMowerwiththewrongsizeTractorcan
causeMowercomponentdamageandequipmentfailureresultingin
possible serious injury or death. (SGM-14)
WARNING! Mow at the speed that you can safely operate and control the tractor and
mower. Safemowingspeeddependsonterrainconditionandgrasstype,
density,andheightofcut. Normalgroundspeedrangeisfrom0to5mph.
Use slowmowingspeedswhenoperatingonornearsteepslopes,ditches,
drop-offs,overheadobstructions,powerlines,orwhendebrisandforeign
objects are to be avoided. (SGM-7)
WARNING! Avoidmowinginreversedirectionwhenpossible. Checktomakesurethere
are no persons behind the mower and use extreme care when mowing in
reverse. Mowonlyataslowgroundspeedwhereyoucansafelyoperateand
control the tractor and mower. Never mow an area that you have not
inspectedand removed debrisorforeign material. (SGM-8)

Safety Section 1-10
FLX15/10 04/06
SAFETY
© 2006Alamo Group Inc.
SAFETY
DANGER! Always disconnect the main PTO Driveline from the Tractor before
performing service on the Mower. Never work on the Mower with the
tractor PTO driveline connected and running. Blades or Drivelines could
turn without warning and cause immediate entanglement, injury or death.
(SRM-3)
WARNING! Do not let the Blades turn when the Mower Deck is raised for any
reason, including clearance or for turning. Raising the Mower deck
exposes the Cutting Blades which creates a potentially serious hazard
and could cause serious injury or even death from objects thrown from
the Blades. (SRM-7)
DANGER! Do not turn so sharp or lift mower so high to produce a severe
"knocking" of the Driveline which will cause accelerated wear and
breakage of drive train components and could result inpossible injury
from the separated Driveline sections. (SRM-4)
DANGER! Be particularly careful when transporting the Implement using the tractor.
Turn curves or go up or down hills only at a low speed and at a gradual
steering angle. Make certain that at least 20% of the tractor’s weight is
on the front wheels to maintain safe steerage. Slow down on rough or
uneven surfaces. (STI-1)
DANGER! When the Wings are folded for transport, the center of gravity is raised
and the possibility of overturn is increased. Drive slowly and use
extremecaution when turning on hillsides. Overturning the Implement
could cause the Implement to overturn the Tractor and vice versa resulting
in serious injury or even death. Never fold wings on a hillside...the
Implement may overturn. (STI-2)
DANGER! RotaryMowersarecapable under adverse conditions
of throwing objects for great distances (100yardsor
more) and causing serious injury or death. Follow
safety messages carefully
-Front and Rear Deflectors, Chain Guards, or Bands are installed
and in good, workable condition;
-Mower sections or Wings are running close to and parallel to the
ground without exposed Blades;
-Passerby are outside the existing thrown-object zone;
-All areas have been thoroughly inspected and all foreign material
such as rocks, cans, glass, andgeneraldebrishasbeenremoved.
NOTE: Wherethere are grassandweeds high enoughto hide debris
that could be struck by the blades, the area should be: inspected
andlarge debrisremoved,mowedatan intermediateheight,inspected,
closely with any remaining debris being removed, and mowed again
at desired final height. (This will also reduce power requiredto mow,
reduce wear and tear on the Mower drivetrain, spread cut material
better, eliminate streaking, and make the final cut more uniform.)
(SRM-1)
STOPMOWING IFPASSERSBYARE WITHIN100 YARDS UNLESS:

Safety Section 1-11
SAFETY
© 2006Alamo Group Inc.
SAFETY
FLX15/10 04/06
DANGER! DO NOT allow any person under a folded wing unless wing is securely
locked up or supported. DO NOT approach the Implement unless the
Tractor is turned off and all motion has ceased. Never work under the
frame work, or any lifted component unless the implement is securely
supported or blocked up. A sudden or inadvertent fall by any of these
components could cause serious injury or even death. (STI-3)
WARNING! Never unhitch without using the Tongue Jack. The Tongue is
very heavy. Attempting to lift the Tongue without using the Tongue
Jack could cause strains or other injury. Allowing the tongue to fall
suddenly and unexpectedly could result in crushing injury. Use
the Tongue Jack for lifting the Implement only. Overloading the
Tongue Jack can cause failure with possible serious bodily injury
or even death. (STI-4)
WARNING! Use extreme care when lowering or unfolding the implement’s wings.
Make sure no bystanders are close by or underneath the wings. Allow
ample clearance around the implement when folding or unfolding the
wings. Use extreme caution around buildings or overhead power lines.
(S3PT-5)
DANGER! Make sure the PTO shield, integral driveline shields, and input shields are
is installed when using PTO-driven equipment. Always replace any
shield if it is damaged or missing. (S3PT-8)
DANGER! Do not operate the implement while wearing loose fitting clothing.
Entanglement of the clothing with the rotating elements can result in
serious injury or even death. Stay clear of all rotating elements at all
times. (SSP-3)
CAUTION! On a fully-assembled unit, do not remove the Wing Retaining Strap
until hoses are attached to the tractor and the Wing Cylinders are
filled with oil. Lower the Wings slowly and carefully. Keep bystand-
ers away during operations. (STI-5)
WARNING! SecuretheImplementfortransportbeforetravelingonpublicroads.
Forpull-typeImplements,securethecenteraxleusingcylinderstops
or transport pin and properly attach a safety chain between the
Implement and Tractor. Secure wings in upright position on folding
Implements using wing transport locks. (STI-7)

Safety Section 1-12
FLX15/10 04/06
SAFETY
© 2006Alamo Group Inc.
SAFETY
DANGER! ThisImplementiswiderthantheTractor. Becarefulwhenoperating
ortransportingthisequipmenttopreventtheImplementfromrunning
into or striking sign posts, guard rails, concrete abutments or other
solidobjects. SuchanimpactcouldcausetheImplementandTractor
topivotviolentlyresultinginlossofsteeringcontrol,seriousinjury,or
evendeath. NeverallowtheImplementtocontactobstacles. (S3PT-12)
WARNING! DONOTuseaPTOadaptertoattachanon-matchingImplementdriveline
toaTractorPTO. Useofanadaptercandoubletheoperatingspeedofthe
Mower resulting in excessive vibration, thrown objects, and blade and
mower failure. Adapter use will also change the working length of the
drivelineexposingunshieldeddrivelineareas. Seriousbodilyinjuryand/or
equipment failure can result from using a PTO adapter. Consult an
authorizeddealerforassistanceiftheImplementdrivelinedoesnotmatch
the Tractor PTO. (S3PT-14)
WARNING! Relieve hydraulic pressure prior to doing any maintenance or repair work
on the Implement. Place the Implement on the ground or securely
blocked up, disengage the PTO, and turn off the tractor engine. Push
and pull the Remote Cylinder lever in and out several times prior to
starting any maintenance or repair work. (S3PT-9)
WARNING! The rotating parts of this machine continue to rotate even after the PTO
has been turned off. The operator should remain in his seat for 60
seconds after the brake has been set, the PTO disengaged, the tractor
turned off, and all evidence of rotation has ceased. (3PT-10)
“Wait a minute...Save a life!”
DANGER! Always disconnect the main PTO Driveline from the Tractor before
performing service on the Implement. Never work on the Implement with
the tractor PTO driveline connected and running. Rotating Parts, Blades
or Drivelines could turn without warning and cause immediate
entanglement, injury or death. (S3PT-11)
WARNING! Before operating the Mower, check to make sure the Implement input
drivelinewillnotbottomoutorbecomedisengaged. Bottomingoutoccurs
when the inner shaft penetrates the outer housing until the assembly
becomessolid-itcanshortennomore. Bottomingoutcancauseserious
damage to the Tractor PTO by pushing the PTO into the Tractor and
throughthesupportbearingsordownwardontothePTOshaft,breaking
it off. A broken drive line can cause personal injury. (S3PT-18)
WARNING! Allow sufficient clearance for the Implement to swing outward while
turning. ImplementscarriedbehindtheTractorwillswingoutsidethe
tire path when making turns. Contacting a solid object while turning
will cause equipment damage and possible injury. (S3PT-20)

Safety Section 1-13
SAFETY
© 2006Alamo Group Inc.
SAFETY
FLX15/10 04/06
Inaddition to the design and configuration ofthisImplement,includingSafetySignsandSafetyEquipment,hazard
control and accident prevention are dependent upon the awareness, concern, prudence, and proper training of
personnel involved in the operation, transport, maintenance, and storage of the machine. Refer also to Safety
Messages and operation instruction in each of the appropriate sections of the Tractor and Equipment Manuals.
Pay close attention to the Safety Signs affixed to the Tractor and Equipment. (SG-18)
WARNING! WhenattachingtheImplementinputdrivelinetotheTractorPTO,itis
important that the connecting yoke spring activated locking collar
slidesfreelyandthelockingballsareseatedsecurelyinthegrooveon
theTractorPTOshaft. AdrivelinenotattachedcorrectlytotheTractor
PTOshaftcouldcomelooseandresultinpersonalinjuryanddamage
to the Implement. (S3PT-17)
WARNING! Only tow the Implement behind a properly sized and equipped Tractor
which exceeds the weight of the Implement by at least 20%. DO
NOT tow the Implement behind a truck or other type of vehicle. Never
tow the Implement and another Implement connected in tandem.
Never tow the Implement at speeds over 20 MPH. (STI-6)
DANGER! Always shut the Tractor completely down, place the transmission in
park,andsettheparkingbrakebeforeyouoranyoneelseattemptsto
connect or disconnect the Implement and Tractor hitches. (S3PT-15)
WARNING! Relieve hydraulic pressure prior to doing any maintenance or repair
work on the Implement. Place the Mower Head on the ground or
securelysupportedonblocksorstands,disengagethePTO,andturn
off the engine. Push and pull the control Levers or Joystick several
times to relieve pressure prior to starting any maintenance or repair
work. (SBM-6)
PARTSINFORMATION
Tigermowersusebalancedandmatchedsystemcomponentsforbladecarriers,blades,cuttershafts,knives,
knife hangers, rollers, drivetrain components, and bearings. These parts are made and tested to Tiger
specifications. Non-genuine"will fit"partsdonotconsistentlymeetthesespecifications. Theuse of“willfit”
partsmayreducemowerperformance,voidmowerwarranties,andpresentasafetyhazard. UsegenuineTiger
mower parts for economy and safety.
(SPTM-1)
SEEYOURTIGERDEALER

Safety Section 1-14
FLX15/10 04/06
SAFETY
© 2006Alamo Group Inc.
SAFETY
50
38
36
37
CanisterManual
Inside
39
40

Safety Section 1-15
SAFETY
© 2006Alamo Group Inc.
SAFETY
FLX15/10 04/06
ITEM PARTNO. QTY. DESCRIPTION
1
2 226-004 1 FemaMember
3 226-044 1 Decal,GreaseNippleOnUnderside
4 226-048 1 Decal, WarningTransport Speed
5 226-049 1 Decal, Use Genuine Schulte Parts
6 226-081 2 Decal,Check OilLevel
7 226-084 1 Decal,MadeIn NorthAmerica
8 226-085 1 Decal,MinimumLubricationRequirements
9 1 SerialPlate
10 31522 2 Decal,TigerLogo,MediumProfile
11 31523 2 Decal,Tiger Logo, LargeProfile
12 226-148 1 Decal,WarningHydraulicPressure
13 226-153 2 RedReflector
14 226-154 2 AmberReflector
15 226-1541 2 AmberReflector
16 226-353 1 Decal, Patent Numbers
17 226-180 3 Decal,4HourGreasing
18 226-181 13 Decal,8Hour Greasing
19 226-182 13 Decal,50HourGreasing
20 226-189 2 Fluorescent
21 226-191 1 Decal,Peligro ReadManual
22 226-314 1 Decal,PeligroDrivelineManual
23 226-316 1 Decal,DangerMultiWarning
24 226-317 1 Decal,DangerDrivelineMaintenance
25 226-318 1 Decal,Notice ToOwner
26 226-323 1 Decal,DrawbarAdjustment
27 226-325 2 Decal,FLX15Logo
28 226-327 1 Decal,WarningTransportSpeed
29 226-328 3 Decal, Danger If Guard MissingOrDamaged
30 226-330 2 Decal,Warning ShearHazard
31 226-332 1 Decal,WarningBladeRotation
32 226-337 1 ColorCoded HoseEnds
33 226-338 1 MaximumOperatingSpeed
34 226-341 2 CheckTirePressure
35 226-364 1 Flex Arm Shaft GreasingDecal
36 256-018 3 Flatwasher1/4"
37 250-002 3 Bolt 1/4"
38 255-025 3 Locknut
39 280-201 1 Canister
40 A101-01-0C 1 OperatorsManual
NOTE: Schulte supplies safety decals on this product to promote safe operation. Damage to the decals may
occur while in shipping, use, or reconditioning. Schulte cares about the safety of its customers, operators, and
bystanders, and will replace the safety decals on this product in the field, free of charge (Some shipping and
handlingcharges may apply).Contact your Schultedealer to orderreplacement decals.

Safety Section 1-16
FLX15/10 04/06
SAFETY
© 2006Alamo Group Inc.
SAFETY
Item 2: FEMA MEMBER DECAL
Item3:GreaseNipple on Underside. Apply
greaseasspecifiedinOwner'sManual.
P/N226-044
Item4:DONOTtransportatspeedshigher
than 20 mph. Only transport behind a
properlysizedandequippedtractor.
P/N226-004
Item5: For safety and to guarantee optium
productreliablityalwaysusegenuine
SCHULTEreplacementparts.
P/N226-049
P/N226-048
