Ins t a llation & O per a ting Instructions
Slimline LED Floodlight
Model: LEDPRO20WH (White)
Model: LEDPRO20B (Black)
Model: LEDPRO50WH (White)
Model: LEDPRO50B (Black)
Model: LEDPRO10WH (White)
Model: LEDPRO10B (Black)
Model: LEDPRO30WH (White)
Model: LEDPRO30B (Black)

1
1. General Information
These instructions should be read carefully and retained for further reference
and maintenance.
2. Safety
• Before installation or maintenance, ensure the mains supply to the luminaire
is switched off and the circuit supply fuses are removed or the circuit breaker
turned off.
• It is recommended that a qualified electrician is consulted or used for
the installation of this luminaire and install in accordance with the
current IEE wiring and Building Regulations.
• Check that the total load on the circuit including when this luminaire is fitted
does not exceed the rating of the circuit cable, fuse or circuit breaker.
3. Technical Specications
• 230V AC, 50Hz
• These luminaires are of class I construction and must be earthed
• Colour Temperature: 4000K
• Energy Efficiency: Class F
• IP65 Rated suitable for restricted external applications
• CE Compliant
LEDPRO10WH & LEDPRO10B
• 10W LED Non replaceable lamp
• Energy Usage: 10Kwh/1000h
• Lumen Output: Black: 1160 lm, White: 1160lm
LEDPRO20WH & LEDPRO20B
• 20W LED Non replaceable lamp
• Energy Usage: 20Kwh/1000h
• Lumen Output: Black: 2350lm, White: 2350lm
LEDPRO30WH & LEDPRO30B
• 30W LED Non replaceable lamp
• Energy Usage: 30Kwh/1000h
• Lumen Output: Black: 3300lm, White: 3300lm
1

1
2
LEDPRO50WH & LEDPRO50B
• 50W LED Non replaceable lamp
• Energy Usage: 50Kwh/1000h
• Lumen Output: Black: 5300lm, White: 5300lm
4. Installation
• Ensure the mains supply is switched off and the
circuit supply fuses are removed or the circuit
breaker turned off.
• An isolating switch should be installed to the
switch the power ON & OFF to the luminaire.
This allows the unit to be easily switched OFF for
maintenance purposes.
• Mark the position of the mounting holes
on the wall using the U bracket supplied
as a template.
• Drill the holes for the wall plugs ensuring
not to infringe with any gas/water pipes
or electrical cables that may be hidden
below the surface.
* 10W & 20W use 6mm screw peg
* 30W & 50W use 7mm screw peg
• Fix the U bracket to the wall using the
correct screws for the wall plugs installed.
Note: Ensure that when you mount this,
the slots at the end of the bracket open
upwards to allow you to easily attach and
secure the floodlight when ready.
• Secure the supply cable into the
junction box through the hole(s)
provided ensuring that a cable gland,
grommet or sealing compound is used
to maintain the IP rating of the
luminaire.
Ø 6mm or 7mm

1
3
• Attach the luminaire to the U
bracket fitted to the wall. You
are able to pre-fit the supplied
fixing screws and washers
to the luminaire before you do
this, the screws will just need to
be loose enough to fit over
the upward facing slots
on the end of the
U bracket. Make sure
the washers are in the
correct order as per the
diagram. When the luminaire is
in place, secure the screws
ensuring not to over-tighten.
• Attach the strain relief to the
luminaire and screw in ensuring
not to over-tighten.
• Terminate the supply cable into the terminal
block (please refer to section 5 connection
diagram) ensuring correct polarity is
observed and that all bare conductors are
sleeved.
• Attach the supplied wall plate to the
luminaire, apply pressure to catches
located on top and bottom, then screw
in on both sides ensuring not to
over-tighten.

Connect the 3 core mains supply cable to the block on the unit as follows:-
LIVE (Brown or Red) L
NEUTRAL (Blue or Black) N
EARTH (Green/Yellow)
5. Connection Diagram
N L L1
MAINS
SUPPLY L
N
E
ISOLATION
SWITCH
Switch
Live
Note: the L1 terminal is a Switch Live 'Live Output' for slave floodlights (when
used in conjunction with the Timeguard LEDPROSLB/WH PIR or LEDPROPCB/WH
Photocell)
1
4

1
5
6. Operation
• Turn the power on to the isolating switch and test for correct operation.
7. Lamp Adjustment
• The lamp can be tilted 360º turn through U-Bracket.
360º turn through
U-Bracket

3 Year Guarantee
In the unlikely event of this product becoming faulty due to defective material or
manufacture within 3 years of the date of purchase, please return it to your
supplier in the first year with proof of purchase and it will be replaced free of
charge. For years 2 and 3 or any difficulty in the first year, telephone the helpline
on 020 8450 0515.
Note: A proof of purchase is required in all cases. For all eligible replacements
(where agreed by Timeguard) the customer is responsible for all shipping/postage
charges outside of the UK. All shipping costs are to be paid in advance before a
replacement is sent.
