Timeguard ECO Series Manual

INSTRUCTIONS
ECO CFL
FLOOD LIGHT
WITH PHOTOCELL
Instructions
ECO1DD.1 ECO2DD.1 ECO3DD.1
ECO CFL Flood Light
with Photocell
Model: ECO1DD
Model: ECO2DD
Model: ECO3DD
Installation & Operating Instructions

1
4 x 32mm
ø 6mm
35mm
60mm
6 x 30mm
2x
2x
20W

2
Slaving
For ECO CFL
Flood Light Uncontrolled Unit only
For ECO1DD & ECO2DD only
23W Max

3
For ECO1DD & ECO2DD only
Lamp turns
ON at night.
Lamp turns
ON at day & night.
For ECO3DD only
23W Max
PAN 30º
Tilt 60º

4
1. General Information
This floodlight features an integral daylight sensing motion which will
automatically switch the light on based on environment lux level and at a time set
by the user.
Unit is for outdoor use only. Unit must be mounted as a fixed luminaire, and is not
suitable for portable use.
2. Parts Included
• Low Energy Floodlight with photocell sensor.
• Instruction manual. Please keep safe for future reference.
• Accessory Pack including screws and wall plugs.
• 1pc. 20W low energy Compact Fluorescent Light. (For ECO1DD & ECO3DD)
• 2pcs 20W low energy Compact Fluorescent Light. (For ECO2DD)
3. Tools & Parts Needed
• 3  exible core cable (1.0mm² or 1.5mm²).
• Electric/hand-held drill & bits.
• Terminal or Electricians screwdriver.
• Wire cutters.
Do not attempt to install during wet weather, if you are suffering from nausea or
dizzy spells or on medication with similar side effects.
No User Serviceable Parts Inside

5
IMPORTANT
Switch off the electricity at the fuse box by removing the relevant
fuse or switching off the circuit breaker before proceeding with
the installation (Diagram 2).
4. Installation
After choosing a suitable location install the unit as follows:
The unit is suitable for connection to a 240 V ac 50Hz electricity supply. It is
suggested that 3-core round exible cable of 1mm² or 1.5mm² gauge is used.
An internal switch should be installed to switch the power to the unit .
This allows the unit to be easily switched off when not required or for maintenance
purposes.
This unit uses an integral wall fixing plate, detach the wall fixing plate by unscrewing
and release but do not remove the fixing screw on the underside of the wall plate
(Diagram 3).
Mark the position of the wall xing holes (60mm). Ensure the wall plate is correctly
positioned. Note the “UP” indent on the inside of the wall plate . Drill the holes,
insert the wall plate into the holes.
Pierce and pass the cable through the grommet before securing the wall
plate to the wall.
It is recommended that the grommet is pierced with a screwdriver to ensure a better
seal. (Diagram 4).
Fix the wall plate to the wall with screws provided . Connect the cable to the
terminal block on the unit as follows (Diagram 5):
Neutral (Blue ) N
EARTH (Green/ Yellow)
LIVE (Brown) L’
Ensure Connections are secure.
The unit is supplied with a hanging attachment (tether) to aid installation. Ensure
the tether is securely fixed into the slot before releasing the weight of the unit.
(Diagram 6)

6
To connect another unit of floodlight , connect the looping power cable to the
terminal block on the master unit as follows ( Diagram 7 ):
Neutral (Blue) N
EARTH (Green/ Yellow)
LIVE (Brown) L’
Fit the oodlight to the bracket by inserting the catch in the oodlight into the
recess at the top of the wall plate and locating the floodlight securely over the wall
plate. Fit and fully secure the locating screw (Diagram 3).
For ECO1DD & ECO2DD
To t the CFL, release but do not remove the screw on the front cover of the
floodlight, open and rotate down but do not separate from the main floodlight
body. (Diagram 8)
For ECO3DD
To t the bulb, turn the lamp enclosure 180 anti-clockwise to release from the
bayonet lock. (Diagram 10)
Remove the bulbs from its packaging and t into the lampholders. Ensure the bulb
is fully secured into the lampholder and the support bracket is located around the
bulb.
Close the front cover, ensure the screw is fully tighten.
This floodlight uses a universal joint, it can be directed to suit your installation by
rotating the oodlight left to right and up or down. (Diagram 9)

7
Designed in the U.K. 67-058-423
Timeguard Limited.
Victory Park, 400 Edgware Road,
London NW2 6ND
Sales Office: 020 8452 1112
or email [e-mail]
or email [e-mail]
5. Operation and Testing
Setting Up For Automatic Operation
The Sensor Head can be panned 90 degree to left and 90 degree to the
right. (Diagram 10)
The adjustment controls on the unit (Diagram 11) should be set as follows.
The TIME control determines how long the lamp remains illuminated after
activation (1 hour to 12 hours).
These settings allow the lamp to illuminate for the designated time on period after
darkness falls and the unit is activated.
The DUSK (LUX) control determines the level of darkness required for the unit to
start operating. (Diagram 12)
The setting is best achieved by the procedure below:
Set the DUSK control knob fully anti-clockwise and the Time control to the
required minutes. Wait until darkness falls.
When the ambient light level reaches the level of darkness at which you wish the
lamp to become operative (ie. At dusk), SLOWLY rotate the control in a clockwise
direction until a point is reached where the lamp illuminates. Leave the control set
at this point.
At this position, the unit should become operative at approximately the same level
of darkness each evening. Observe the operation of the unit. If the unit is starting
to operate too early (ie. when it is quite light), adjust the control slightly anti-
clockwise. If the unit starts to operate too late (ie. only when it is very dark), adjust
the control slightly clockwise.
Continue to adjust until the unit operates as desired.

8
6. Technical Specifications
Power Supply
Maximum External Load
No other external loads
can be used.
Lamp Type
E 27 base
Time On Adjustment
Dusk Level Adjustment
Environmental Protection
230V AC ~ 50Hz
Number of Slave Unit
Master ECO1FL ECO2FL ECO3FL
ECO1DD 3 1 3
ECO2DD 2 1 2
ECO3DD 3 1 3
230 AC 20W Compact Fluorescent lamp supplied
23W compact uorescent maximum
Do not use incandescent or halogen bulbs
1 hour to 12 hours
Day & night or night only operation
IP45 (suitable for outdoor use)

9
6. Troubleshooting Guide
Problem
Lamp stays OFF
Solution
• Check that the power is switch ON at the
wall switch.
• Ensure no connections are loose
• Ensure that CFL is seated correctly in the
lamp holder.
• Check the CFL. If the CFL has failed, replace it.
No User Serviceable Parts Inside.
If you experience problems refer to Troubleshooting Guide.
If problems still exist, do not immediately return the unit to store.
Telephone the Timeguard Customer Helpline
020 8450 0515
Qualied Customer Support Co-ordinators will be on-line
to assist in resolving your query.

10
3 Year Guarantee
In the unlikely event of this product becoming faulty due
to defective material or manufacture within 3 years of the
date of purchase, please return it to your supplier in the
first year with proof of purchase and it will be replaced free
of charge. For years 2 and 3 or any difficulty in the first year telephone the
helpline on 020 8450 0515.
Note: the lamp is not covered by the warranty.
first year with proof of purchase and it will be replaced free

Designed in the U.K. 67-058-423
Timeguard Limited.
Victory Park, 400 Edgware Road,
London NW2 6ND
Sales Offi ce: 020 8452 1112
or email [e-mail]
For a product brochure please contact:
Zerofour – August 2011
or email [e-mail]
HELPLINE
020 8450 0515
