TIP TEMPerature Products METINF006 User manual

Non-contact Forehead Thermometer
Functions
Forehead temperature The thermometer has been designed for home use. It’s not meant to replace a visit to the
doctor. Please also remember to compare the measurement result to your regular body
temperature. Please consult with doctor if you have health concerns.
 Please see the “Use of the thermometer” section to learn how to measure the body
temperature.
Surface temperature The surface mode shows the actual and unadjusted surface temperature which is different from
the body temperature. It can help you monitor if the object temperature is suitable for the baby
or patient for example the baby’s milk.
 Please see the “Use of the thermometer” section to learn how to measure the object
temperature.
Temperature indicator If the thermometer detects a temperature ≧99.5°F (or 37.5°C) under forehead mode three
short beep sound will follow one long beep sound to warn the user for the temperature is above
99.5°F (37.5°C).
Memory locations There are total 25 sets of measurement condition for body temperature.
 When power on press the “ON/MEM” button to see the temperature records with icon.
°F / °C switch In “Power Off” mode press and hold the “START” button then press the “ON/MEM” button for
3 seconds icon “°F” will be switched to icon “°C”. You can also use the same process to
change the LCD display from °C to °F.
NOTE: Memory clear and Celsius/Fahrenheit switch are together. When you switch Celsius and
Fahrenheit the Memory will be cleared.

www.tiptemp.com
TIP TEMPerature Products – 340 W Broad Street, Burlington, NJ 0801 – 1-800-TIP-TEMP – [email protected]
INSTRUCTIONS: METINF006
Intended operator: At least 11 years old (5 years intensive reading experience) no maximum.
Specifications Temperature measurement range:
Forehead mode: 93.2~108°F (34~42.2°C)
Surface mode: -7.6~176°F (-22~80°C)
Operating temperature range: 50~104°F (10~40°C) 15%~85% RH
Storage temperature range: It should be stored at room temperature between
-4~122°F (-20~+50°C) RH≦85%
Transportation temperature shall be less than 158°F (70°C) RH≦95%
Atmospheric pressure: 800~1013 hPa
Comply with ASTM E1965-98 EN ISO 80601-2-56 IEC/EN60601-1-2(EMC)
IEC/EN60601-1(Safety) standards ISO10993 RoHS.
Accuracy:
Forehead mode: ±0.4 °F (0.2 °C ) within 95~107.6°F (35~42°C)
±0.5 °F (0.3 °C ) for other range.
Surface mode: ±0.5°F (0.3°C) within 71.6~108°F (22~42.2°C)
others ±4% or ±4°F (2°C) whichever is greater.
Temperature indicator memory and °F / °C switch function
Battery: AAA x 2 pcs
Battery life: around 3 000 continuous readings.
Expected Service Life: 4 years
This thermometer converts the forehead temperature to display its “oral equivalent.”
(according to the result of the clinical evaluation to get the offset value)
Blue LED Backlight
Blue LED backlight will be automatically turned on after measurement and
automatically turned off after 5 seconds.
Enclosure Rating: IP22
Dimensions: 158.0 x 48.0 x 40.2 mm
Weight: 100 grams including battery
The device should not submerge into any liquids and expose it to direct moisture.
There is no gender and age limitation for using the infrared thermometer.
This is not an AP or APG product.

Indications for use: The Non-contact Clinical Thermometer Model METINF006 is an infrared thermometer intended
for the intermittent measurement of human body temperature in people of all ages.
Mute mode The device setting with buzzer is on you can set buzzer on/off under Mute mode.
When power on press and hold the “ON/MEM” button for 3 seconds. The icon will flash on
the LCD screen and then release the “ON/MEM” button to set MUTE. Thus you will not hear
beep sounds. You can also use the same process to turn off the Mute function.
NOTE If keep pressing "ON/MEN" button for 5 seconds after icon flashing the device will
be power off WITHOUT setting Mute.
Use of the thermometer
Note If there is any temperature difference between the places where the device is stored and where you are going to measure, subject and the device
should
stay in the same room for at least 15 minutes before measurement.
1. Always make sure the probe lens is clean without any damage and the forehead is clean.
Warning Choking from swallowing small parts and batteries by children or pets is possible, please keep small parts and batteries at places where
children and pets can’t reach.
2. Power on
Press the “ON/MEM” button (see figure 1).
3. Measuring body temperature on the forehead
Press the “ON/MEM” button to power on the device. Forehead mode is the default mode. You can see the icon on the screen
and hear two beep sounds (see figure 1). In this mode you can hold the thermometer within 4 cm from the central forehead (Fig. 2) and press
the "START" button to get the forehead measurement. The time consuming for measurement might be 1 second. After each forehead
measurement wait icon stop flashing to be ready for next measurement. Figure 2
Points for attention
a. Forehead temperature is displayed in oral mode. This mode converts the forehead temperature to display its “oral-equivalent” value.
b. Before the measurement, the subject should stay in a stable environment for 5 minutes and avoid exercise, bath for 30mins.
c. Remember to keep the forehead area clean and away from sweat, cosmetics and scar while taking temperature.
d. The “Clinical Bias” is -2.5 ~ -3.1°F (-1.4 ~ -1.7°C).
e. The “Limits of Agreement” is 0.98.
f. The "Repeatability" is 0.36°F (0.20°C)
4. Measuring surface temperature
4.1 After power on press and hold the “ON/MEM” button and press the “START” button one time for “Infrared thermometer” mode to see icon on your LCD
display. In this mode you can get the target surface temperature.
4.2 When you press the “START” button you will get the real time temperature immediately. If you press and hold the “START” button the reading of measurement
will
be continuously updated.
4.3 Applications include temperature measurements for water milk cloth skin or other objects.
* Note This mode shows the actual and unadjusted surface temperature which is different from the body temperature.
5. Power off
5.1 Device will automatically shut off if left idle for more than 1 minute to extend battery life.
5.2 Manually power off the device by pressing the “ON/MEM” button.
Important Notes
Cleaning
And Storage
Please make sure the probe is clean to ensure an accurate reading.
The probe lens is the most delicate part of the thermometer. Use with care when cleaning the probe lens to avoid damage.
a. Use alcohol swabs or cotton swabs moistened with 70%~75% alcohol to clean the probe lens.
b. Allow the probe to fully dry for at least 1 minute.
c. Keep the unit dry and away from any liquids and direct sunlight.
d. Storage temperature range It should be stored at room temperature between -4~122°F (-20~+50°C), RH≦85%
e. The Probe should not be submerged into liquids.
Holding the thermometer too long may cause a higher ambient temperature reading of the probe.
This could make the body temperature measurement lower than usual.
www.tiptemp.com
TIP TEMPerature Products – 340 W Broad Street, Burlington, NJ 0801 – 1-800-TIP-TEMP – [email protected]
Figure 1

Battery replacement When the “Low Battery” icon indicates the battery is low the battery should be replaced immediately with AAA *2 pcs batteries.
1. Open the battery cover: Use the thumbs to push battery cover out. (See Figure 1)
2. Insert the new AAA *2 pcs batteries. (See Figure 2)
3. Replace the battery cover. (See Figure 3)
Trouble shooting
Error Message Problem Solution
Error 5~9 the system is not functioning properly. Unload the battery wait for 1 minute and repower it. If the
message reappears contact the retailer for service.
Measurement before device stabilization. Wait for “Er1” to disappear.
The ambient temperature is not within the range between 50oF~104oF (10oC~40oC). Allow the thermometer to rest in a room for at least 15 minutes at
room temperature: 50oF~104oF (10oC~40oC).
(1) In forehead mode: Temperature taken is higher than 108°F (+42.2oC)
(2) In surface mode: Temperature taken is higher than 176°F (+80oC)
Please select the target within specifications. If a malfunction still
exists please contact the nearest retailer.
(1) In forehead mode: Temperature taken is lower than 93.2°F (+34oC)
(2) In surface mode: Temperature taken is lower than –7.6°F (-22oC)
Device cannot be powered on to the ready stage. Change with a new battery.
Warranty
Warranty: 12 months
Manufacture Date: as the serial number (please open the battery cover it is shown on the inside of the device.)
Ex.SN:E512A000001 the first “E” is External the second number “5” is the last number of manufacture year the third and the fourth number “12” is the manufacture
Note The thermometer is calibrated at the time of manufacture. If you question calibration mode, the accuracy of temperature measurements or
unexpected events at any time, please contact the dealers or nearest service address.
Warning No modification of this equipment is allowed.
Please read the instructions for use BF type applied part
www.tiptemp.com
TIP TEMPerature Products – 340 W Broad Street, Burlington, NJ 0801 – 1-800-TIP-TEMP – [email protected]
Figure 1 Figure 2 Figure 3

Ref No.：032020
Symbol Descriptions
Caution Please read the instructions for use Battery Recycling
BF type applied part Paper Recycling Stand-by
IP22 Classification for ater ingress and
particulate matter.
Manufacturer’s declaration-electromagnetic emissions
The FT-2020 is intended for use in the electromagnetic environment (for home healthcare) specified belo .The customer or the user of the FT-2020
should assure that it is used in such an environment.
Emissions test Compliance Electromagnetic environment – guidance
(for home healthcare environment)
RF emissions
CISPR 11
Group 1 The FT-2020 uses RF energy only for its internal function. Therefore, its RF emissions are
very lo and are not likely to cause any interference in nearby electronic equipment.
RF emissions
CISPR 11
Class B The FT-2020 is suitable for use in all establishments, including domestic establishments and
those directly connected to the public lo -voltage po er supply net ork that supplies
buildings used for domestic purposes.
Manufacturer’s declaration – electromagnetic immunity
The FT-2020 is intended for use in the electromagnetic environment (for home healthcare) specified belo . The customer or the user of the FT-2020
should assure that it is used in such an environment.
Immunity test EC 60601 test level Compliance level Electromagnetic environment – guidance
(for home healthcare environment)
Electrostatic
discharge(ESD) IEC 61000-
4-2
Contact:±8 kV
Air±2 kV,±4 kV,±8 kV,
±15 kV
Contact:±8 kV
Air±2 kV,±4 kV,±8
kV,±15 Kv
Floors should be ood, concrete or ceramic tile. If floors are
covered ith synthetic material, the relative humidity should be at
least 30%
Po er frequency(50, 60 Hz)
magnetic field IEC 61000-4-
8
30 A/m
50 Hz or 60 Hz
30 A/m
50 Hz and 60 Hz
The FT-2020 po er frequency magnetic fields should be at levels
characteristic of a typical location in a typical home healthcare
environment.
Manufacturer’s declaration – electromagnetic immunity
The FT-2020 is intended for use in the electromagnetic environment (for home healthcare) specified belo . The customer or the user of the FT-2020
should assure that it is used in such an environment.
Immunity test EC 60601 test level Compliance
level Electromagnetic environment – guidance
(for home healthcare environment)
Radiated RF
IEC 61000-4-3
10 V/m
80 MHz – 2,7 GHz
80 % AM at 1 kHz
10 V/m
80 MHz – 2,7
GHz
80 % AM at 1
kHz
Recommended separation distance:
d = 1,2 Error: Reference source not found
d = 1,2 Error: Reference source not found 80MHz to 800 MHz
d = 2,3 Error: Reference source not found 800MHz to 2,7 GHz
Where P is the maximum output po er rating of the transmitter in atts (W) according
to the transmitter manufacturer and d is the recommended separation distance in
www.tiptemp.com
TIP TEMPerature Products – 340 W Broad Street, Burlington, NJ 0801 – 1-800-TIP-TEMP – [email protected]

metres (m).
Field strengths from fixed RF transmitters, as determined by an electromagnetic site
survey, a should be less than the compliance level in each frequency
range.b
Interference may occur in the vicinity of equipment marked ith the
follo ing symbol:
NOTE1 At 80 MHz and 800 MHz, the higher frequency range applies.
NOTE2 These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and reflection from structures,
objects and people.
Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land mobile radios, amateur radio, AM and
FM radio broadcast and TV broadcast cannot be predicted theoretically ith accuracy. To assess the electromagnetic environment due to fixed RF
transmitters, an electromagnetic site survey should be considered. If the measured field strength in the location in hich the FT-2020 is used exceeds
the applicable RF compliance level above, the FT-2020 should be observed to verify normal operation. If abnormal performance is observed,
additional measures may be necessary, such as re-orienting or relocating the FT-2020.
Recommended separation distances between
portable and mobile RF communications equipment and the FT-2020
The FT-2020 is intended for use in an electromagnetic environment (for home healthcare) in hich radiated RF disturbances are controlled. The
customer or the user of the FT-2020 can help prevent electromagnetic interference by maintaining a minimum distance bet een portable and mobile
RF communications equipment (transmitters) and the FT-2020 as recommended belo , according to the maximum output po er of the
communications equipment.
Rated maximum output power
of transmitter
W
Separation distance according to frequency of transmitter
M
150 kHz to 80 MHz
d = 1,2
80 MHz to 800 MHz
d = 1,2
800 MHz to 2,7 GHz
d = 2,3
0,01 N/A 0,12 0,23
0,1 N/A 0,38 0,73
1 N/A 1,2 2,3
10 N/A 3,8 7,3
100 N/A 12 23
For transmitters rated at a maximum output power not listed above the recommended separation distance din meters (m) can be estimated using the equation
applicable to the frequency of the transmitter where Pis the maximum output power rating of the transmitter in watts (W) according to the transmitter
manufacturer.
NOTE 1 At 80 MHz and 800 MHz the separation distance for the higher frequency range applies.
NOTE 2 These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and reflection from structures objects and
people.
Manufacturer’s declaration-electromagnetic immunity
Test specifications for ENCLOSURE PORT MMUN TY to RF wireless communications equipment
The FT-2020 is intended for use in the electromagnetic environment (for home healthcare) specified belo . The customer or the user of the FT-2020
should assure that it is used in such an environment.
Test
frequency
(MHz)
Band a )
(MHz)
Service a) Modulation b) Maximum power
(W)
Distance
(m)
MMUN TY TEST
LEVEL
(V/m)
Compliance
LEVEL
(V/m)
(for home
healthcare)
385 380–390 TETRA 400 Pulse
modulation b)
18 Hz
1,8 0,3 27 27
450 430–470 GMRS 460,
FRS 460
FM c)
 ±5 kHz deviation
1 kHz sine
2 0,3 28 28
www.tiptemp.com
TIP TEMPerature Products – 340 W Broad Street, Burlington, NJ 0801 – 1-800-TIP-TEMP – [email protected]

710
704–787 LTE Band 13,17 Pulse
modulation b)
217 Hz
0,2 0,3 9 9
745
780
810 800–960 GSM 800/900,
TETRA 800,
iDEN 820,
CDMA 850,
LTE Band 5
Pulse
modulation b)
18 Hz
2 0,3 28 28
870
930
1720
1700–
1990
GSM 1800;
CDMA 1900;
GSM 1900;
DECT;
LTE Band 1, 3,
4, 25; UMTS
Pulse
modulation b)
217 Hz
2 0,3 28 28
1845
1970
2450 2400–
2570
Bluetooth,
WLAN,
802.11 b/g/n,
RFID 2450,
LTE Band 7
Pulse
modulation b)
217 Hz
2 0,3 28 28
5240
5100–
5800
WLAN 802.11
a/n
Pulse
modulation b)
217 Hz
0,2 0,3 9 9
5500
5785
NOTE If necessary to achieve the IMMUNITY TEST LEVEL, the distance bet een the transmitting antenna and the EQUIPMENT or
SYSTEM may be reduced to 1 m. The 1 m test distance is permitted by IEC 61000-4-3.
a) For some services, only the uplink frequencies are included.
b) The carrier shall be modulated using a 50 % duty cycle square ave signal.
c) As an alternative to FM modulation, 50 % pulse modulation at 18 Hz may be used because hile it does not represent actual
modulation, it ould be orst case.
www.tiptemp.com
TIP TEMPerature Products – 340 W Broad Street, Burlington, NJ 0801 – 1-800-TIP-TEMP – [email protected]
