ARCTIC HAYES AH650 User manual

AH650
Before using the instrument, please read this
manual carefully, and save for future reference.
HAYES
ARCTIC
INFRARED
DIGITAL THERMOMETER
User Manual
NON CONTACT

Please read the user manual before operating the
instrument. Protection is based on exposure being
limited by the natural aversion response (0.25secs)
Safety Symbols
Warning!
laser must be prevented from aligning itself towards
human eyes or reective surfaces.
1 2
Safety Instructions
Important notices against hazards.
Compliant with EU legal requirements.
Laser Radiation, Do Not stare Into
Beam, Class 2 Laser Product

Laser Radiation
• Do not stare into beam.
Class 2 laser product. Turn the laser beam on only
when using this tool.
1. Do not remove or deface the product labels.
2. Avoid direct eye exposure. The laser beam can
cause ash blindness.
3. Do not operate the tool around children or allow
children to operate the tool.
4. Do not place the tool in a position that may
cause anyone to stare at the laser beam, whether
intentionally or unintentionally.
5. Do not use on surfaces such as sheet steel that
have shiny, reective surfaces. The shiny surface
could reect the beam back at the operator.
6. Always turn the laser tool off when not in use.
Leaving the tool on increases the risk of someone
inadvertently staring into the laser beam.
7. Do not attempt to modify the performance of this
laser device in any way. This may result in a
dangerous exposure to the laser radiation.
8. Do not attempt to repair or disassemble the laser
measuring tool. If an unqualied person attempts
to repair this product, serious injury may occur.
Any repair required on this laser product should
be performed only by qualied service personnel.
2
Safety Instructions Safety Instructions

3 4
Physical Appearance Physical Appearance
1.
2.
3.
4.
5.
6.
7.
8.
9.
Alarm indicator
LCD display
Laser key / digital adjusting control key decreases
Mode key
Backlight key / digital regulation increase key
Laser
Infrared sensor induction zone
Measure trigger switch
Battery cover
Height - 148mm
Width - 102mm
Length - 46mm
Weight - 113g
(without batteries)

4
Physical Appearance
LCD Screen
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
Data hold indicator
Temperature upper limit alarm indicator
Temperature lower limit alarm indicator
Measuring indicator
Laser on indicator
Low battery indicator
Centigrade unit
Fahrenheit degree unit
Maximum display
Maximum indicator
Temperature display
Radiance display

5
Technical
6
LCD Colour LCD
Distance to Spot 12:1
Emissivity 0.10~1.00
Response Spectrum 8~14um
Laser Output <1mW~Class 2
Wavelength λ=630-670nm
Beam Divergence 1mrad
Response Time <0.5S
Automatic Shut-down 30 Seconds
Operational Temperature 0 ~ 40°C
Storage Temperature -10°C~60°C
Power 2 x 1.5V AAA Battery (included)
Infrared Temperature Measuring
Range (non-contact)
-30°C~380°C (-22°F~716°F)
Infrared Accuracy Range -30°C~0°C (-22°F~32°F): ±3°C
0°C~380°C (-32°F~716°F): ±1.5°C

6
Maintenance
Maintenance Information
• Use a dry, clean cloth to clean the instrument.
• Do not use solvents.
• For extra protection, always store the instrument
in the case provided when not in use.
• If there is a sudden change in the environmental
temperature, the instrument should be acclimatised
for a minimum of 30 minutes. This will ensure the
ambient temperature is the same, both inside and
outside of the thermometer.
• The electromagnetic eld from electric welding and
inductive heating must be minimized.
• Do not place the thermometer near to hot objects.
• The meter must be kept clean so that dust is denied
access to the lens cone.

7
Measurement Operation
8
Measurement Operation
Setting the high alarm.
• Pull trigger and press mode key once for two
seconds, then release trigger. This will show HI.
Use the left and right buttons / to set the
required alarm level.
• Once high values are set, press the mode button
one more time & this will show LOW.
Use the left & right buttons / to set the
required low alarm level.
• When alarm levels are reached RED LED light
will illuminate.
Setting the emissivity
• To set the emissivity, pull the trigger and press
mode for two seconds. scroll through by pressing
mode until the display shows E.
The emissivity can now be set (see values on
page 12/13.
Use the left & right buttons / to set the
required emissivity level.
Setting the Celsius & Fahrenheit
• To set the temperature unit, pull the trigger and
press mode for two seconds. scroll through by
pressing mode until the display shows °C.

8
Measurement Operation
Use the left & right buttons / to set the
required temperature unit required °C/ °F .
Enabling the Laser
• Enable / disable laser. Press key to enable or
disable laser. The instrument will display the
symbol for laser
Non-contact temperature measurement
• Target the IR thermometer at an object and pull
the trigger. Hold the trigger to take continuous
measurement of temperature.

9
Distance To Spot Ratio (D:S)
10
Distance To Spot Ratio (D:S)
Proportion between the distance from the
instrument to an object and the diameter of
the object to be measured (D:S)
The IR Thermometer has a certain angle and
eld of vision, as shown in the diagram below:
It must be ensured that the object to be measured
is fully within the eld of vision afforded by the
IR Thermometer, that is, the laser ring can see
nothing but the object to be measured. The greater
the object to be measured, the further the distance
between the object & thermometer must be. The
smaller the object is, the shorter the distance
between the object & thermometer must be. The
proportion between the distance to be measured and
the size of the object to be measured (D:S) is 12:1, as
shown on page 10.
The object to
be measured Lens Photosensitive element

10
Distance To Spot Ratio (D:S)
While measuring an object, the instrument will emit
an indicative ring. The measured temperature of the
surface is the internal temperature of the ring.
S
D
1500 1000 500
Unit: mm D:S = 12:1
125 84 42

11
Emissivity
12
Emissivity Reference Table
Emissivity
Emissivity refers to the ability of an object
to emit infrared ray. The greater the emissivity
is, the stronger the emission ability of the
surface of an object is.
The emissivity of most organic substances or
oxidized surfaces of metals falls within the range
of 0.85 ~ 0.98. The default emissivity of this
measurement device is 0.95.
The instrument’s emissivity is set to be consistent
with that of the object to be measured at the
moment of measurement result must be noticed at
the time of measurement.

12
Emissivity Reference Table
Surface measured Emissivity
Aluminium Metal Oxidized
A3003 Alloy Oxidized
A3003 Alloy Rough
0.2 ~ 0.4
0.3
0.1 ~ 0.3
Brass Polished
Oxidized
0.3
0.5
Copper Oxidized
Electronic Terminal Board
0.4 ~ 0.8
0.6
Hastelloy 0.3 ~ 0.8
Chromium Nickel
Iron Alloy
Oxidized
Sandblast
Electro-Polished
0.7 ~ 0.95
0.3 ~ 0.6
0.15
Iron Oxidized
Rusted
0.5 ~ 0.9
0.5 ~ 0.7
Sand-gravel 0.95
Gypsum 0.8 ~ 0.95
Ice 0.98
Limestone 0.98
Paper 0.95
Plastic 0.95
Soil 0.9 ~ 0.98
Water 0.93
Wood (natural) 0.9 ~ 0.95

13
Emissivity Reference Table
14
Battery Replacement
Iron (cast) Oxidized
No Oxidized
Melt & Cast
0.6 ~ 0.95
0.2
0.2 ~ 0.3
Iron (forged) passivated 0.9
Lead Rough
Oxidized
0.4
0.2 ~ 0.6
Mo Oxidized 0.2 ~ 0.6
Nickel Oxidized 0.2 ~ 0.5
Platinum Black 0.9
Steel Cold Rolled
Sanding Plate
Polished Plate
0.7 ~ 0.9
0.4 ~ 0.6
0.1
Zinc Oxidized 0.1
Asbestos 0.95
Asphalt 0.95
Basalt Stone 0.7
Carbon 0.8 ~ 0.9
Non-Oxidized 0.7 ~ 0.8
Graphite 0.9
Silicone Carbide 0.95
Clay 0.95
Concrete 0.95
Fabric 0.95
Glass Plate 0.85

14
Battery Replacement
Battery
When the battery power is low, the battery symbol
indicator will show on the LCD screen. At such
moment you must replace the existing battery.
Open the battery cover and replace the old battery
with two new AAA batteries.
Refer to the diagram below:
Note:
All set values for alarm
& Emissivity will return
to the default readings.
• 2 x AAA battery
(included)

Limited warranty
1 year warranty against any manufacturing
defects or faulty workmanship. This warranty
does not cover fuses, disposable batteries or
damage from accident, neglect, misuse, alteration,
contamination or abnormal conditions of
operation or handling.
WEEE Directive 2012/19/EU At the end of
the product life, dispose of the instrument &
batteries in a corresponding recycling centre.
Do not dispose of the unit with the usual
domestic refuse.
Do not burn the product.
