Tiras AM-IN4 User manual

FIRE ALARM SYSTEMS
Input/output device АМ-IN4
Passport
AAZCh. 425532.015PS
DSTU ISO 9001:2015
Serial number:
Firmware version:

2
This passport contains information on the design, operation and operation rules of the
I/O device AM-IN4 (further - the device), which is used as part of addressable fire alarm
system, based on the fire alarm control panel Tiras PRIME A. The device meets the
requirements of DSTU EN54-17, DSTU EN54-18 standards.
1 LIST OF ABBREVIATIONS
PSU –power supply unit;
SCI - short circuit isolator;
FCP –Fire control panel "Tiras PRIME A";
AFAS - addressable fire alarm system;
AI - addressable interface;
NC - (normally closed) normally closed;
NO - (normally open) normally open.
2 PURPOSE
The device is designed to increase the number of inputs AFAS. The device is produced in
a plastic housing. The appearance of the device with the cover removed is shown in Fig.1.
1. Holes for mounting on the wall.
2. Holes for cable entry.
3. Screws for fixing of a cover of the case.
Figure 1 - Appearance of the device with the cover removed
3 Technical features
3.1 The list of terminals and their functions is given in table. 1. Their location is shown in
Fig.1.

3
Table 1
Terminal
name
Functional characteristic
L+
The Input for the connection of a positive AI wire.
L-
The input for the connection of a negative AI wire. There are two terminals
separated by SCI.
GND
Common input with circuit ground potential.
IN1 - IN4
Universal parametric inputs
3.2 Technical characteristics of the device are given in table 2.
Table 2
Characteristic name
Value
General
Dimensions WxHxD, mm, not more than
10010030
Weight, kg, not more than
0,1
Enclosure protection degree
ІР30
Meantime to failure, hours, not less
40 000
Average lifetime, years, not less
10
Time to detect faults, s, not more than
10
Power supply
Supply voltage through AI, V
20 –25
Current consumption from AI, standby mode/input activation mode, mA, not
more than
0,35/0,60
Current consumption from AI, standby mode/input fault mode, mA, not more than
0,35/0,65
Parametric inputs IN1 - IN4
Line resistance in the short circuit state, kOhm
0 –1,5
Line resistance in the activation state (low level), kOhm
1,6 –24,9
Line resistance in the standby mode, kOm
25 –35
Line resistance in the activation state (high level), kOhm
35,1 - 60
Line resistance in the open circuit state, kOhm
60,1 –∞
SCI
Maximum SCI opening voltage, V
15,0
Minimum SCI restoring voltage, V
4,2
Maximum current through SCI in the closed state, mA
65
Maximum SCI opening current, mA
75
Maximum leakage current through SCI (in the open state), mA
4,2
Maximum transient resistance of SCI in the closed state, Ohm
0,09
3.3 LED indicators located on the board are used to indicate the operating modes and
status of the device. The purposes of the indicators are as follows: (Fig. 1):
1) HL1 (green):
-blinking 1 time in 4 s - standby mode indication;
-blinking with an interval of 0.5 s (for not more than 4 s) - indication of the device
registering process in the AI.
2) alternating blinking indicators HL1, HL2 - the device is marked for visual search in the
zone.

4
4 CONNECTIONS
4.1 To access the terminals of the device, unscrew the 2 screws on the underside of the
housing (Fig. 1) and remove the cover. Connect the device to the AI and actuators according
to Figure 2
.
a)
b)
c)
Figure 2 - Schemes of connections of external circuits to the device terminals.
Figure 2 shows:
a) the scheme of the address line connections:
- Positive wires of AI - wires connected to terminals L1-L4;
- Negative wires of AI - wires connected to terminals G1-G4.
b) connection diagram of the activation device (relay with NO contact) in parallel with the
terminal resistor Rt.
c) connection diagram of the activation device (relay with NC contact) in series with the
terminal resistor Rt.
The connection of inputs IN2 - IN4 is similar to the connection of input IN1.
Positive
wires
of AI
Negative
wires
of AI
Rt
Rl
Rt
Rl

5
The activation device is shown as a relay for example.
Also, it is possible to use the button as the activation device, when the resistance of
the line provided according to table 2.
The value of the terminal resistor (Rt) shall satisfy the conditions of formation of the
standby mode in accordance with table 2.
The value of the additional resistor (Rl) must satisfy the conditions of formation of the
active mode (table 2) when the relay (button) triggered.
Notes.
1. When choosing the values of resistances Rt and Rl, you should take into account the
total resistance of the line when the relay is activated, this value should not be equal
to Rd - the resistance of the indeterminate state of the line. Rd is 100 ohms between
the ranges of inputs modes.
2. Switching the device to activation warning mode is only possible from the standby
mode. In the event of a fault (line short circuit or line open circuit), the device can be
restored when returning to the standby mode.
4.2 Wires inside the housing should be laid in such way that they do not interfere with
closing the cover and do not fall between the indicators and the window in the housing cover.
4.3 Wires can only be connected to the terminals of the device when there is no voltage
from external power supplies.
5 SETTINGS
5.1 When the supply voltage appears in the AI on the connected device, the automatic
registration indication (3.3) is switched on. Then the device goes into a mode that depends on
the inputs settings and the state of external devices connected to it (Fig. 2).
The inputs of the device are set according to the FCP operation manual.
5.2 By default, the outputs of the device are set to "Not used".
6 PACKAGING
6.1 After unpacking the device it is necessary:
- visually inspect the device and make sure there is no mechanical damage on it;
- check the delivery set according to table 3.
Table 3
Name
Code
Quantity, pcs
Device AM-IN4
AAZCh.425532.015
1
Passport
AAZCh.425532.015 PS
1
Resistor 0,5W –30 kΩ± 1%
4*
Resistor 0.5 W –10 kΩ± 1%
4**
Notes:
* - Rt for IN1-IN4;
** - Rl for IN1-IN4.
7 OPERATION, STORAGE, AND TRANSPORTATION CONDITIONS
The device is intended for continuous 24h operation in the premises under regulated climatic
conditions. Operating temperature range: from - 10°Сto +55°С, at relative humidity 93%.
Packaged devices are stored in warehouses under the following conditions: air temperature

6
from - 50°Сto +55°С, relative humidity should not exceed 98% at a temperature of 35°С. There
should be no aggressive impurities in the air causing corrosion in the premises where the devices
are stored.
Packaged devices are transported by low-tonnage shipments at any distance by road and rail
in closed vehicles in accordance with the rules of transportation applicable to each type of
transport. When placing and securing boxes with packed devices during transportation, ensure a
stable position of the boxes to prevent shifting and bumps between them. During loading and
transportation, the requirements of handling signs on the packaging should be met.
8 INFORMATION ON DECLARATIONS OF CONFORMITY TO TECHNICAL REGULATIONS
AND CERTIFICATES
This device meets the requirements of following mandatory technical regulations:
-Technical regulations on electromagnetic compatibility of equipment;
-Technical regulations on the restriction of the use of certain hazardous substances in
electrical and electronic equipment.
Certificate of compliance with the requirements of DSTU EN 54 series standards issued
by the State Certification Center of the SES of Ukraine.
The Quality Management System of Tiras-12 LTD is certified in accordance with DSTU ISO
9001: 2015.
The full text of declarations of compliance with technical regulations and certificates are
available on the website https://tiras.technlogy.
9 ACCEPTANCE CERTIFICATES
The device meets the requirements of regulatory and technical documents and is
recognized as suitable for operation. Evidence of acceptance is a sticker on the passport. The
date of acceptance coincides with the date of manufacture.
10 WARRANTIES AND REPAIRS
"Tiras-12" LTD (further - the manufacturer) guarantees compliance of the device with the
requirements of current regulatory and technical documents during the warranty period
under the conditions of transportation, operation and storage.
The warranty period is 36 months and starts at the date of sales specified in the operation
documents for the device or in other accompanying documents (sales contract, invoice, bill,
etc.). If you cannot provide a document confirming the date of sale of the device, the warranty
period starts from the date when the device was produced.
___________________ ____________________
(date of sale) (seller’s signature) Stamp
The device is repaired by the manufacturer. This device is repaired for free, in case the
warranty period is not expired, it was operation in accordance with this passport.
The device is sent for repair, together with a letter, which should include: the description
of the malfunction, the place of operation and the contact phone of the person in charge of
repair.

7
11 LIMITATIONS OF LIABILITY
The manufacturer reserves the right to refuse warranty service of the device in
controversial circumstances. The manufacturer also has the right to make a final decision on
whether the device is to be serviced under the guarantee.
Actions and damages that result in loss of warranty service:
1) damage caused by natural phenomena (fire, flood, wind, earthquake, lightning, etc.);
2) damage caused by a violation of the installation rules or the provision of improper
conditions for the operation of the device, including:
−faulty grounding;
−over-voltage;
−high humidity and vibration;
3) damage caused by foreign objects entering the device, liquids, insects and others;
4) mechanical damage to components of the device (chips, dents, cracks, broken contact
terminals, etc.);
5) damage resulting from unauthorized repair;
6) damage caused by violation of the rules of transportation, storage and operation;
7) changing, removing, rubbing or damaging the serial number of the device (or labels
with serial numbers on the device).
12 DISPOSAL
After the expiry of the service life of the device its utilization is carried out in accordance
with the current legislation, separate from household waste.
In accordance with the EU Directive 2012/19/EU on waste electrical and
electronic equipment, the disposal of device should be done separately from
household waste. To dispose of the device, it should be delivered to a point of
sale or a local processing point.

Edited on 09.09.2022
