Teknim TFS-1182R User manual

Release Date: 05/01/2021
Rev:01
Warnings
General
✓Read this manual carefully before operating the device and retain it for future reference
✓Pay attention to all warnings and precautions described in the manual.
✓Keep devices away from water and moisture utunuz.
Service
Do not attempt to repair the device by yourself, you may be exposed to electric shock if you open the device
cover.
In the event of any malfunction, contact your dealer or authorized service. Technical intervention to the device
must be performed by qualified service personnel.
Fault Conditions Requiring Service
In the event of any malfunction or in the following cases, contact your authorized service or dealer.
✓When the power cord or plug is damaged,
✓When any liquid flows into the device or the object falls,
✓When exposed to water and rain,
✓If the device has been dropped or the housing has been damaged
✓If the device has noticeable performance changes,
✓If the device does not operate normally according to the operating instructions specified
Call for service as incorrect operations can cause other malfunctions.
Maintenance on your own
Do not try to fix the device on your own. Removal of cover may end up with electricity shock. In case of any
defect or malfunction, contact with your dealer or with authorized service. All the technical interventions have
to be done by technicians of company. Device must be cleaned up with a dry fabric. No-chemicals are allowed
for cleaning.
Transportation
Device must be carefully transported avoiding all physical bump, stroke and possible fluid entry. Malfunctions
that caused by improper transportation is not under warranty.
Human and Environmental Health
This device contains no chemical or biological elements that could harm human condition.
Sub Models
TFS-1182R
Intelligent Addressable Sounder & Flasher with Built-in Isolator, RED
TFS-1182W
Intelligent Addressable Sounder & Flasher with Built-in Isolator, WHITE
Technical Features
Power
15VDC –32VDC (Nom.27VDC)
Current Consumption
~90 µA ( @27VDC )
Start Time
15 sec.
Alarm Consumption (Default Tone)
~Min.=6.74mA, Nom.=11.06Ma, Max.=15.1mA.(27VDC )
Sound Level
89.4 / 94.3 / 97 dB±2 dB (@27VDC, at 1 meter)
Sound Tone
42 Different Tone
Flash Mode
3 (Slow, Normal, Fast)
Protection Class
IP21C
Operating Temperature Range
-10C ~ 55C
Humudity
Between %0 - %95 at +40°C
Dimentions (mm)
Ø:110mm, h:55mm (Include Base Bracket)
Body Material
Red –Transparent, UL94 Policarbonite
White, UL94 Policarbonite
Cable Selection
0.8mm ² ~ 1.5mm ²
Weight (W –WO Base)
207.7Gr.
Leds
Wide Range 7 Bright LED
Heart Led
20s period - 1182R: RED, 1182W: White
Piezo
Sealed Piezo
Coverage
W-2,4-4
Usage
Internal Usage / Siren Type : Type A
Isolator
Avarage Consumption @24V
15uA
Vmax.
32V
Vnom.
28V
Vmin.
15V
Vso_max.
18V
Vso_min.
9V
Vsc_max.
5V
Vsc_min.
0,7V
Ic_max.
0,5A
Is_max.
3A
IL_max.
0,026A
Zc_max.
0,026Ω
Indicator Lights
White Led
RED / White LEDs
(7 pcs)
Yellow LEDs
The device is in normal working
condition (can be off through CP)
20s Flashing
x
X
Alarm Condition
X
Yes
X
Shortcircuit
X
X
Constant Lit
Terminals
1 -
Loop (-) IN
2 -
Loop (-) OUT
3 -
4 -
Loop (+) IN, OUT
Attention: Do not attempt to remove the card from its plastic housing. Completely closed for
your safety. Users must avoid Intervention.
TFS-1182R / TFS-1182W
Intelligent Addressable Fire Alarm Sounder &
Flasher With Built-in Isolator
Installation Manual

Supported Tones
Tone Modes Tone Type Tone Description
TONE 1 (default)
Default tone 1754Hz ~ 2380Hz sinus signal
11 HZ 600 us
TONE 2
Specific tone 1754Hz ~ 2380Hz sinus signal
5 HZ 1333 us
TONE 3
Specific tone 1754Hz ~ 2380Hz sinus signal
1 HZ 6666 us
TONE 4
Specific tone 500Hz ~ 1200Hz sinus signal
0.33 HZ 2594 us
TONE 5
Specific tone 2400Hz ~ 2850Hz sawtooth signal
7 HZ 2197 us
TONE 6
Specific tone 2400Hz ~ 2850Hz sawtooth signal
1 HZ 15384 us
TONE 7
Specific tone 2400Hz ~ 2850Hz sawtooth signal
50 HZ 307 us
TONE 8
Specific tone 300Hz ~ 1200Hz sawtooth signal
1 HZ 400 us
TONE 9
Specific tone 500Hz ~ 1200Hz sawtooths signal
1 HZ 856 us
TONE 10
Specific tone 800Hz ~ 970Hz sawtooth signal
7 HZ 646 us
TONE 11
Specific tone 800Hz ~ 970Hz sawtooth signal
1 HZ 4524 us
TONE12
Specific tone 800Hz ~ 970Hz sawtooth signal
50 HZ 90 us
TONE 13
Specific tone 800Hz ~ 970Hz sawtooth signal
2 HZ 2262 us
TONE14
Specific tone 800Hz ~ 970Hz sawtooth signal
9 HZ 502 us
TONE 15
Specific tone 800Hz ~ 970Hz sawtooth signal
100 HZ 45 us
TONE 16
Specific tone 500Hz ~ 988Hz sawtooths-square signal
321 us 250000 us
TONE 17
Specific tone 500Hz ~ 1200Hz sawtooths-square signal
299 us 500000 us
TONE 18
Specific tone 500Hz ~ 1200Hz sawtooths-square signal
600 us 500000 us
TONE 19
Specific tone 1200Hz ~ 500Hz sawtooths-square signal
600 us 500000 us
TONE 20
Specific tone 2850Hz - 2400Hz square signal (ISO8201)
250000 us 250000 us
TONE 21
Specific tone 1200Hz - 500Hz square signal
500000 us 500000 us
TONE 21
Specific tone 1200Hz - 500Hz square signal
500000 us 500000 us
TONE 22
Specific tone 800Hz ~ 970Hz square signal
500000 us 500000 us
TONE 23
Specific tone 628Hz - 925Hz square signal
250000 us 250000 us
TONE 24
Specific tone 554Hz - 440 square signal
100000 us 400000 us
TONE 25
Specific tone 670Hz - 845Hz square signal
250000 us 350000 us
TONE 26
Specific tone 440Hz - 554Hz square signal (French)
100000 us 400000 us
TONE 27
Specific tone 2850Hz - 0 square signal
500000 us 500000 us
TONE 28
Specific tone 970Hz - 0 square signal (ISO8201)
250000 us 250000 us
TONE 29
Specific tone 925Hz - 0 square signal
150000 us 600000 us
TONE 30
Specific tone 925Hz - 0 square signal
250000 us 1000000 us
TONE 31
Specific tone 800Hz - 0 square signal (ISO8201)
250000 us 1000000 us
TONE 32
Specific tone 660Hz - 0 square signal (Swedish)
150000 us 150000 us
TONE 33
Specific tone 660Hz - 0 square signal
6500000 us 13000000 us
TONE 34
Specific tone 554Hz - 0 square signal
100000 us 400000 us
TONE 35
Specific tone 400Hz continuous
signal
TONE 36
Specific tone 628HZ
continuous signal
TONE 37
Specific tone 660HZ
continuous signal
TONE 38
Specific tone 750HZ
continuous signal
TONE 39
Specific tone 925HZ
continuous signal
TONE 40
Specific tone 970HZ
continuous signal
TONE 41
Specific tone 2400HZ continuous
signal
TONE 42
Specific tone 2850HZ continuous
signal

EN 54-23 Visual Alarm Devices A –Weighted Sound Level (max.)
Supported Flash Modes
Installation and Connections
1. Remove the head of the sounder from the base.
2. Mount the base part on the wall, using 2 of the 4 markings marked on the base.
3. Connect the cable according to the following diagram.
4. Replace the flasher. Make sure that the line on the head meets the long line on the base.
5. Turn the flasher clockwise to the base, making sure that the terminals are tight.
Test
1. TFS-1182 siren tests can be done in the menu of TFP-12XX Addressable Fire Alarm panels.
2. Check if flasher error occurs when panel is operated.
3. If sounder and flasher error, make sure the connections are made correctly.
4. If no sounder and flasher error, move the panel to the test position from the menus.
5. Run the sounder and flasher test. Observe the sounder and flasher side / flash status during the test
period.
6. If the devices continuous warning lights are flashing during the test, the test is completed.
Manufacture
*2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed of as unsorted municipal waste
in the European Union. For proper recycling, return this product to your local supplier upon the purchase of equivalent
new equipment, or dispose of it at designated collection points. For more information see: www.recyclethis.info.
Warning: The product only works with Teknim TFP-121x, Intelligent Addressable Fire
Alarm panels.
Bilgi Elektronik San. ve Tic. A.Ş.
Dudullu Organize Sanayi Bölgesi 1. Cadde İsmet Tarman İş Merkezi
No:1 Kat:2 No:32 Ümraniye / İstanbul / Türkiye
Telephone: [phone] Fax: [phone]
www.bilgielektronik.com.tr
[e-mail]
[e-mail]
