Siemens Cerberus PRO FS720 User manual

A6V10227652_i_en_-- Building Technologies
2016-05-30 Control Products and Systems
FS720
Cerberus™ PRO
Fire detection system
Components / Spare parts /
Repair parts
IP6

2
Building Technologies A6V10227652_i_en_--
CPS Fire Safety 2016-05-30
Legal notice
Technical specifications and availability subject to change without notice.
Transmittal, reproduction, dissemination and/or editing of this document as well as
utilization of its contents and communication thereof to others without express
authorization are prohibited. Offenders will be held liable for payment of damages.
All rights created by patent grant or registration of a utility model or design patent
are reserved.
Issued by:
Siemens Switzerland Ltd.
Infrastructure & Cities Sector
Building Technologies Division
International Headquarters
Gubelstrasse 22
CH-6301 Zug
Tel. [phone]
www.siemens.com/buildingtechnologies
Edition: 2016-05-30
Document ID: A6V10227652_i_en_--
© Siemens Switzerland Ltd, 2008

3
Building Technologies A6V10227652_h_de_--
Fire Safety 2016-05-30
1About this document...........................................................................5
2Stand-alone fire control panels...........................................................7
2.1 Fire control panels FC721 (1-loop) in housing (Eco)...............................7
2.2 Expansion for fire control panels FC721.................................................8
2.2.1 RS485 module.......................................................................................8
2.2.2 RS232 module.......................................................................................8
2.2.3 Housing Eco (empty) .............................................................................8
2.2.4 Housing Standard (empty) .....................................................................9
2.2.5 Auxiliary power supply ...........................................................................9
2.2.6 Event printer ........................................................................................10
2.3 Accessories for fire control panels FC721 ............................................10
2.3.1 Key switches........................................................................................10
2.3.2 Relay module.......................................................................................10
2.3.3 19" mounting kit ...................................................................................11
2.3.4 Cable kit (communication)....................................................................11
2.3.5 Matrix printer (Extern) ..........................................................................11
3Networkable fire control panels........................................................12
3.1 Fire control panels FC722 (2-loop) in housing (Standard).....................12
3.2 Fire control panels FC723 (Modular) in housing (Large).......................13
3.3 Fire control panels FC724 (4-loop) in housing (Comfort).......................14
3.4 Fire control panels FC726 (Modular) in housing (Large).......................15
3.5 Expansion for fire control panels FC722, FC723, FC724 and FC726....16
3.5.1 License keys........................................................................................16
3.5.2 Event printer ........................................................................................16
3.5.3 Mounting plate.....................................................................................16
3.5.4 Fire brigade periphery module .............................................................17
3.5.5 Sounder module ..................................................................................17
3.5.6 Network module (SAFEDLINK)............................................................17
3.5.7 Repeater (SAFEDLINK).......................................................................18
3.5.7.1 Accessories for repeater ......................................................................18
3.5.8 FCA2007-A1........................................................................................19
3.5.9 FCA2008-A1........................................................................................19
3.5.10 RS485 module.....................................................................................19
3.5.11 RS232 module.....................................................................................20
3.5.12 Loop extension (C-NET) ......................................................................20
3.5.13 Line card (C-NET)................................................................................20
3.5.14 I/O card (RT)........................................................................................21
3.5.15 I/O card (programmable)......................................................................21
3.5.16 I/O card (horn/monitored).....................................................................21
3.5.17 Line card (Interactive) ..........................................................................22
3.5.18 Line card (Interactive-Ex).....................................................................22
3.5.19 Line card (SynoLOOP).........................................................................22
3.5.20 Network components ...........................................................................23
3.5.21 Housing Standard und Comfort (empty) ...............................................24
3.5.22 Housing Comfort und Large (empty) ....................................................25
3.5.23 Operating add-on.................................................................................26
3.5.24 Auxiliary power supply .........................................................................27
3.6 Accessories for fire control panels FC722, FC724 and FC726..............28
3.6.1 Key switches........................................................................................28
3.6.2 Relay module.......................................................................................28
3.6.3 19" mounting kit ...................................................................................29
3.6.4 Cable kit (communication)....................................................................29
3.6.5 Matrix printer (Extern) ..........................................................................29
4Networkable fire terminal ..................................................................30

4
Building Technologies A6V10227652_i_en_--
Fire Safety 2016-05-30
4.1 Fire terminal FT724 in housing (Eco) ...................................................30
4.2 Expansion for fire terminal FT724 ........................................................30
4.2.1 License keys........................................................................................30
4.2.2 Event printer........................................................................................30
4.2.3 Network module (SAFEDLINK)............................................................31
4.2.4 RS485 module.....................................................................................31
4.2.5 RS232 module.....................................................................................31
4.2.6 Network components ...........................................................................32
4.2.7 Power supply kit (70 W).......................................................................33
4.2.8 Housing (Eco)......................................................................................34
4.2.9 Operating add-on.................................................................................34
4.2.10 Battery.................................................................................................35
4.3 Accessories for fire terminal FT724......................................................35
4.3.1 Key switches .......................................................................................35
4.3.2 19" mounting kit...................................................................................35
4.3.3 Cable kit (communication)....................................................................35
4.4 Floor repeater display and floor repeater terminal ................................36
4.4.1 Floor repeater terminals.......................................................................36
4.4.2 Floor repeater display..........................................................................37
4.4.2.1 Accessory for floor repeater terminal FT2010-A1 .................................37
4.4.2.2 Accessory for FT2010-A1 and FT2011-A1 ...........................................37
4.5 Mimic display driver .............................................................................38
5Batteries.............................................................................................39
6Spare parts.........................................................................................41
6.1 Cover caps ..........................................................................................41
6.2 Operating units ....................................................................................41
6.3 Operating add-ons...............................................................................42
6.4 Power supply.......................................................................................43
6.5 Printer rolls and typewriter ribbon.........................................................43
7Repair parts .......................................................................................44
7.1 Operating units ....................................................................................44
7.2 Periphery boards .................................................................................45
7.3 Fire terminal board...............................................................................45
7.4 Fire brigade periphery module .............................................................46
7.5 Network module (SAFEDLINK)............................................................46
7.6 Floor repeater terminal and floor repeater display ................................47
8Index...................................................................................................48

About this document
5
Building Technologies A6V10227652_i_en_--
Fire Safety 2016-05-30
1 About this document
Purpose
This document describes all components, spare parts and repair parts for the Cerberus
PRO FS720 fire detection system.
This document is revised and expanded on a continuous basis.
Scope
This document contains information on all available components for IP4.
Target groups
This document arranges itself to all persons.
Reference documents
Refer to the following documents for more information:
A6V10227649 FS720 Fire detection system Product data sheet
A6V10203220 FC721 Fire control panel (1-loop) Product data sheet
A6V10206525 FC722 Fire control panel (2-loop) Product data sheet
A6V10207176 FC724 Fire control panel (4-loop) Product data sheet
A6V10263277 FC726 Fire control panel (Modular) Product data sheet
A6V10207898 FT724 Fire terminal Product data sheet
009393 FT2010-A1, FT2010-C1, FT2011-A1
Floor repeater terminal, floor repeater display
Product data sheet
A6V10082691 FT2001-A1 Mimic display driver, LED flat cable Product data sheet
A6V10210355 FS720 Fire detection system Technical description
A6V10210368 FS720 Fire detection system Characteristic product data
A6V10210362 FS720 Fire detection system Planning
A6V10210390 FS720 Fire detection system Installation
A6V10210416 FS720 Fire detection system Commissioning
A6V10211076 Fx20xx Fire control panel / Fire terminal Operation
009310, 009311 FT2010-A1, FT2010-C1, FT2011-A1
Floor repeater terminal, floor repeater display
Operation
Conventions
(...) Additional information
bold letters Definitions of designations
see Cross-reference
Document identification
Place Signification
Title page –System names
–Product type
–Document purpose
Last page bottom left –Document number
–Version date

About this document
6
Building Technologies A6V10227652_i_en_--
Fire Safety 2016-05-30
Modification index
Version Date Brief description
A6V10227652_a_en 05.2009 Initial edition
A6V10227652_b_en 05.2010 FC726, FH7204-Z3, FH7205-Z3, FCM7212-Y3,
FCL2001-A1, FCI2008-A1
A6V10227652_c_en 07.2010 Panels for version 3.0: New Network components:FN2008-
A1, FN2009-A1, FHA2029-A1, FHA2030-A1
A6V10227652_e_en 05.2012 Corrections for IP4
FCA2008-A, FCM7204-Z3, FCM7205-Y3, FCM7206-H3,
FN2007-A1, FN2007-A1, FCI2007-A1, FCI2009-A1
A6V10227652_f_en 11.2012 New pictures for batteries FA200x-A1 and new dimensions
A6V10227652_g_en 03.2014 New product SV 24V-150W (V24230-Z6-A5),
Update of LPCB numbers, Corrections for IP5
A6V10227652_h_en_-- 23.10.2015 Edition IP6: Formal update, Operating units, Operating add-
ons
A6V10227652_i_en_-- 30.05.2016 Correction of edition IP6: Date corrected
Download
The current issue documentation and photos can be found in the Siemens Intranet.
https://workspace.sbt.siemens.com/content/00001123/default.aspx (STEP, Asset
Portal)

Stand-alone fire control panels
7
Building Technologies A6V10227652_i_en_--
Fire Safety 2016-05-30
2 Stand-alone fire control panels
2.1 Fire control panels FC721 (1-loop) in housing (Eco)
FC721-ZZ Fire control panel (1L) Part no. S54400-C32-A2
FC721-YZ Fire control panel (1L, 1LED) Part no. S54400-C32-A3
Expansion see chapter 2.2
FC721-ZZ
FC721-YZ
With 24 indicator groups, with
each one red and yellow LED
Accessories see chapter 2.3
Product data sheet A6V10203220
–The FC721 in housing (Eco) is compact prefabricated fire control panel with integrated operating unit
capable of processing FD720 device signals.
–The fire control panel may be used as a stand-alone unit only.
–In addition, an Ethernet connection is available at each station. Via this fast Ethernet interface is
remote control service possible.
–The FXS7212 Cerberus-Engineering-Tool permits the system to be adapted to specific customers'
requirements.
–The FC721 is ideally suited for smaller applications, e.g. in workshops, hotels, etc.
Consists of:
–Housing (Eco)
–Operating unit
–Periphery board
–Power supply 70 W, emergency power supply (batteries must be ordered separately)
Technical data
Mains voltage 85…265 VAC
Power supply 70 W
Operating voltage 21…28.6 VDC
Operating current Max. 2.5 A
Battery capacity 2 x 12 V, 7 Ah
Connectable detector series Cerberus PRO FD720 (C-NET)
Number of lines 1 loop or 2 stub lines
Number of addresses Max. 126
Relay output
–RT alarm
–RT fault
1
1
Monitored outputs
–Alarm
–Fault
–Horn
1
1
1
Free programmable inputs/outputs 4
Operating temperature -8…+42 °C
Storage temperature -20…+60 °C
Humidity (no condensation permitted) ≤95 % rel.
Dimensions (W x H x D)
–Without cover cap
–With caver cap
430 x 398 x 80 mm
430 x 398 x 108 mm
Color
–Housing grey, ~RAL 7035
–Cover grey, ~RAL-Design 050 00 00
Protection category IP30
Approvals VdS / LPCB pending / 126bn/05

Stand-alone fire control panels
8
Building Technologies A6V10227652_i_en_--
Fire Safety 2016-05-30
2.2 Expansion for fire control panels FC721
2.2.1 RS485 module
FCA2002-A1 RS485 module (isolated) Part no. A5Q00009923
Application
For periphery devices with RS485 interface, e.g. for FAT (GER).
–Plugged into the back side of the operating unit.
Technical data
Connection terminals 0.2…1.5 mm
2
Dimensions (W x H x D) 50 x 15 x 70 mm
2.2.2 RS232 module
FCA2001-A1 RS232 module (isolated) Part no. A5Q00005327
Application
For periphery devices with RS232 interface, e.g. for event printer FTO2001-A1 or for external matrix
printer DL3750+.
–Plugged into the back side of the operating unit.
Technical data
Connection terminals 0.2…1.5 mm
2
Dimensions (W x H x D) 50 x 15 x 70 mm
2.2.3 Housing Eco (empty)
FH7201-Z3 Housing (Eco) Part no. S54400-B72-A1
Application
–Empty housing for open use, e.g. additional batteries, power supply, event printer or mimic displays.
–Space for batteries
–2 x FA2003-A1 (7 Ah)
Technical data
Dimensions (W x H x D) 430 x 398 x 80 mm
Color
–Housing grey, ~RAL 7035
–Cover grey, ~RAL-Design 050 00 00
Protection category IP30

Stand-alone fire control panels
9
Building Technologies A6V10227652_i_en_--
Fire Safety 2016-05-30
2.2.4 Housing Standard (empty)
FH7202-Z3 Housing (Standard) Part no. S54400-B70-A1
Application
–Empty housing for open application, e.g. additional batteries, for operating add-on or for the event
printer.
–Space for batteries
–2 x FA2003-A1 (7 Ah) or
–2 x FA2004-A1 (12 Ah) or
–2 x FA2006-A1 (26 Ah)
Technical data
Dimensions (W x H x D) 430 x 398 x 160 mm
Color
–Housing grey, ~RAL 7035
–Cover grey, ~RAL-Design 050 00 00
Protection category IP30
2.2.5 Auxiliary power supply
FP2003-A1 Power supply kit (70 W) Part no. A5Q00016005
Application
Auxiliary power supply to all stations (control panels and terminals).
Function
Converts mains voltage to system voltage. Monitors mains voltage and batteries.
Technical data
Mains voltage 85…265 VAC
Current 0.5…1 A
Power consumption Max. 90 VA
Dimensions (W x H x D) 95 x 170 x 54 mm
FP2004-A1 Power supply kit (150 W, A) Part no. A5Q00020825
Application
–Power supply kit (150 W, A) as auxiliary power supply for installation into empty housing.
Function
Converts mains voltage to system voltage. Monitors mains voltage and batteries.
Technical data
Mains voltage 230 VAC
Current 1.2 A
Power consumption Max. 300 VA
Dimensions (W x H x D) 130 x 150 x 70 mm

Stand-alone fire control panels
10
Building Technologies A6V10227652_i_en_--
Fire Safety 2016-05-30
2.2.6 Event printer
FTO2001-A1 Event printer Part no. A5Q00010126
Including cable for interface,
power supply and paper roll
Application
The event printer can be used in all control panels, terminals or in all empty housings if space is
available.
Function
The event printer is a thermal printer that logs alarms, faults and all messages.
–The RS232 module FCA2001-A1 is required to operate the printer.
–The RS232 module must be ordered separately.
Technical data
Operating voltage 9…48 VDC
Operating current quiescent
at 9 VDC
at 48 VDC
50 mA
3 A
0,7 A
Interface RS232 serial
Operating temperature 0…+50 °C
Storage temperature -20…+70 °C
Humidity (no condensation permitted) ≤95 % rel.
Dimensions (W x H x D) 85 x 85 x 55 mm
2.3 Accessories for fire control panels FC721
2.3.1 Key switches
FTO2005-C1 Key switch (Kaba) Part no. A5Q00010113
FTO2006-B1 Key switch (Nordic) Part no. A5Q00010129
FTO2005-C1
FTO2006-B1
Features
Kaba or Nordic key switch with mounting accessories and key as an option for operating access
(operating unit).
Technical data
Lock Kaba, Nordic
Key Kaba 8 #100, Nordic
2.3.2 Relay module
Z3B171 Relay module 250 VAC, 10 A Part no. BPZ: 4843830001
Application
To connect fire control, e.g. fire doors, fans, elevators, etc.
1 changeover contact 250 VAC / 10 A
–Is mounted on existing DIN rail TS35.
Technical data
Dimensions (W x H x D) 70 x 50 x 15 mm

Stand-alone fire control panels
11
Building Technologies A6V10227652_i_en_--
Fire Safety 2016-05-30
2.3.3 19" mounting kit
FHA2016-A1 19" mounting kit Part no. A5Q00020179
Application
To install fire control panels and fire terminals in a 19" third-party housing.
Technical data
Dimensions (W x H x D) 430 x 100 x 324 mm
2.3.4 Cable kit (communication)
FCA2014-A1 Cable kit (communication) Part no. A5Q00023027
Application
For flexible cable connections to the modules on the PMI-& main board.
2.3.5 Matrix printer (Extern)
DL3750+ Matrix printer (Extern) Part no. A5Q00023962
Application
The Fujitsu DL3750+ is a compact, noiseless A4 matrix printer. It is used for documenting relevant
information in a system on continuous paper. The printer is constantly supervised by the fire control
panel. The type of events to be printed is configurable. It offers a maximum of speed and reliability.
–The RS232 module FCA2001-A1 is required to operate the printer.
–The RS232 module must be ordered separately.
Technical data
Interface RS232 serial
Resolution 360 x 360 dpi
Character set 6
Number of copies 5 incl. original
Operating temperature +5…+38 °C
Storage temperature -15…+60 °C
Humidity (no condensation) ≤95 % rel.
Dimensions (W x H x D) 415 x 120 x 330 mm

Networkable fire control panels
12
Building Technologies A6V10227652_i_en_--
Fire Safety 2016-05-30
3 Networkable fire control panels
3.1 Fire control panels FC722 (2-loop) in housing (Standard)
FC722-ZZ Fire control panels (2L) Part no. S54400-C29-A5
FC722-YZ Fire control panels (2L, 1LED) Part no. S54400-C29-A4
Expansion see chapter 0
FC722-ZZ
FC722-YZ
With 24 indicator groups, with
each one red and yellow LED
Accessories see chapter 3.6
Product data sheet A6V10206525
–The FC722 in housing (Standard) is a compact, prefabricated fire control panel with integrated
operating unit capable of processing FD720 device signals.
–The fire control panel may be used as a stand-alone unit or networked.
–Up to 32 fire control panels and fire terminals can be connected in a single cluster (C-
WEB/SAFEDLINK network), or up to 16 panels when the cluster is connected to a danger
management system. Using a fiber-optic backbone (C-WEB/LAN) up to 14 of these clusters with up
to 16 panels each can be networked. This topology enables the construction of an EN 54-compliant
network with up to 64 fire control panels and fire terminals.
–The FXS7212 Cerberus-Engineering-Tool permits the system to be adapted to specific customers'
requirements.
–Connection of Siemens Danger Management System.
–Suitable for smaller applications, e.g. workshops, hotels, etc.
Consists of:
–Housing (Standard)
–Operating unit
–Periphery board
–Power supply 70 W, emergency power supply (batteries must be ordered separately)
Technical data
Mains voltage AC 85…265 V
Power supply 70 W
Operating voltage DC 21…28.6 V
Operating current Max. 2,5 A
Battery capacity 2 x 12 V, 7…12 Ah
Connectable detector series Cerberus PRO FD720 (C-NET)
Number of lines 2 (4) loops or 4 (8) stub lines
Number of addresses Max. 252
Relay output
–RT alarm
–RT fault
1
1
Monitored outputs
–Alarm
–Fault
–Horn
1
1
1
Free programmable inputs/outputs 8
Operating temperature -8…+42 °C
Storage temperature -20…+60 °C
Humidity (no condensation permitted) ≤95 % rel.
Dimensions (W x H x D)
–Without cover cap
–With cover cap
430 x 398 x 160 mm
430 x 398 x 188 mm
Color
–Housing grey, ~RAL 7035
–Cover grey, ~RAL-Design 050 00 00
Protection category IP30
Approvals VdS / LPCB G209076 / 126bn/06

Networkable fire control panels
13
Building Technologies A6V10227652_i_en_--
Fire Safety 2016-05-30
3.2 Fire control panels FC723 (Modular) in housing (Large)
FC723-ZA Fire control panel Part no. S54400-C143-A1
FC723-ZA
Expansion see chapter 0
Accessories see chapter 3.6
Product data sheet A6V10263277
–The FC723 is a modular fire control panel with integrated operating unit which processes signals from
Cerberus PRO FD720 devices
–An integrated card cage with 2 slots allows:
–C-NET line cards FCL2001-A1 to be used (for extra lines)
–Interactive line cards, FCL 2006-A1
–Interactive-Ex line cards, FCL2007-A1
–SynoLOOP line cards, FCL 7201-Z3
–I/O card FCI2008-A1 (with 12 programmable inputs/outputs)
–Mixed use of all lines and I/O cards possible
–The fire control panel may be used as a stand-alone unit or networked.
–Up to 32 fire control panels and fire terminals can be connected in a single cluster
(C-WEB/SAFEDLINK network), or up to 16 panels when the cluster is connected to a danger
management system. Using a fiber-optic backbone (C-WEB/LAN) up to 14 of these clusters with up to
16 panels each can be networked. This topology enables the construction of an EN 54-compliant
network with up to 32 fire control panels and fire terminals.
–The FXS7212 Cerberus-Engineering-Tool permits the system to be adapted to specific customers'
requirements.
–Connection of Siemens Danger Management System.
–Ideally suited for very large and complex applications, e.g. Hotels, high schools, offices complexes,
etc. The FC723 can be used by the flexible cross-linking possibilities however also for extensive
systems.
Consists of:
–Housing (Large)
–Operating unit
–Periphery board
–Card cage for use of max. 2 line cards and/or I/O card slots
–Power supply 150 W, emergency power supply (batteries must be ordered separately)
Technical data
Mains voltage AC 230 V
Power supply 150 W
Operating voltage DC 21…28.4 V
Operating current Max. 5 A
Battery capacity 2 x 12 V, 45 Ah
Connectable detector series Cerberus PRO FD720 (C-NET)
Number of lines 2 (4) loops or 4 (8) stub lines
Number of addresses max. 756
Relay output
–RT alarm
–RT fault
1
1
Monitored outputs
–Alarm
–Fault
–Horn
1
1
1
Free programmable inputs/outputs 8
Operating temperature -8…+42 °C
Storage temperature -20…+60 °C
Humidity (no condensation permitted) ≤95 % rel.
Dimensions (W x H x D)
–Without cover cap
–With cover cap
430 x 796 x 165 mm
430 x 796 x 188 mm
Color
–Housing grey, ~RAL 7035
–Cover grey, ~RAL-Design 050 00 00
Protection category IP30
Approvals VdS / LPCB pending / pending

Networkable fire control panels
14
Building Technologies A6V10227652_i_en_--
Fire Safety 2016-05-30
3.3 Fire control panels FC724 (4-loop) in housing (Comfort)
FC724-ZA Fire control panels (4L) Part no. S54400-C30-A2
FC724-ZE Fire control panels (4L, 2LED) Part no. S54400-C30-A3
FC724-ZA
FC724-ZE
With 48 indicator groups, with
each one red and yellow LED
Expansion see chapter 0
Accessories see chapter 3.6
Product data sheet A6V10207176
–The FC724 is a compact, prefabricated fire control panel with integrated operating unit capable of
processing FD720 device signals.
–The fire control panel may be used as a stand-alone unit or networked.
–Up to 32 fire control panels and fire terminals can be connected in a single cluster
(C-WEB/SAFEDLINK network), or up to 16 panels when the cluster is connected to a danger
management system. Using a fiber-optic backbone (C-WEB/LAN) up to 14 of these clusters with up
to 16 panels each can be networked. This topology enables the construction of an EN 54-compliant
network with up to 64 fire control panels and fire terminals.
–The FXS7212 Cerberus-Engineering-Tool permits the system to be adapted to specific customers'
requirements.
–Connection of Siemens Danger Management System.
–Ideally suited for large-size applications, e.g. industrial facilities, regional banks, office complexes,
etc. The FC724 can be used by the flexible cross-linking possibilities however also for extensive
systems.
Consists of:
–Housing (Comfort)
–Operating unit
–Periphery board
–Power supply 150 W, emergency power supply (batteries must be ordered separately)
Technical data
Mains voltage AC 230 V
Power supply 150 W
Operating voltage DC 21…28.4 V
Operating current Max. 5 A
Battery capacity 2 x 12 V, 7…26 Ah
Connectable detector series Cerberus PRO FD720 (C-NET)
Number of lines 4 (8) loops or 8 (16) stub lines
Number of addresses Max. 504
Relay output
–RT alarm
–RT fault
1
1
Monitored outputs
–Alarm
–Fault
–Horn
1
1
2
Free programmable inputs/outputs 12
Operating temperature -8…+42 °C
Storage temperature -20…+60 °C
Humidity (no condensation permitted) ≤95 % rel.
Dimensions (W x H x D)
–Without cover cap
–With cover cap
430 x 796 x 160 mm
430 x 796 x 188 mm
Color
–Housing grey, ~RAL 7035
–Cover grey, ~RAL-Design 050 00 00
Protection category IP30
Approvals VdS / LPCB G209077 / 126bn/07

Networkable fire control panels
15
Building Technologies A6V10227652_i_en_--
Fire Safety 2016-05-30
3.4 Fire control panels FC726 (Modular) in housing (Large)
FC726-ZA Fire control panels (4L) Part no. S54400-C87-A1
FC726-ZA
Expansion see chapter 3.5
Accessories see chapter 3.6
Product data sheet A6V10263277
–The FC726 is a modular fire control panel with integrated operating unit which processes signals from
Cerberus PRO FD720 devices
–An integrated card cage with 5 slots allows:
–C-NET line cards FCL2001-A1 to be used (for extra lines)
–I/O card FCI2008-A1 (with 12 programmable inputs/outputs)
–Mixed use of all lines and I/O cards possible
–The fire control panel may be used as a stand-alone unit or networked.
–Up to 32 fire control panels and fire terminals can be connected in a single cluster (C-
WEB/SAFEDLINK network), or up to 16 panels when the cluster is connected to a danger
management system. Using a fiber-optic backbone (C-WEB/LAN) up to 14 of these clusters with up to
16 panels each can be networked. This topology enables the construction of an EN 54-compliant
network with up to 64 fire control panels and fire terminals.
–The FXS7212 Cerberus-Engineering-Tool permits the system to be adapted to specific customers'
requirements.
–Connection of Siemens Danger Management System.
–Ideally suited for very large and complex applications, e.g. Hotels, high schools, offices complexes,
etc. The FC726 can be used by the flexible cross-linking possibilities however also for extensive
systems.
Consists of:
–Housing (Large)
–Operating unit
–Periphery board
–Card cage for use of max. 5 line cards (C-NET) and/or I/O cards.5 slots
–Power supply 150 W, emergency power supply (batteries must be ordered separately)
Technical data
Mains voltage AC 230 V
Power supply 150 W
Operating voltage DC 21…28.4 V
Operating current Max. 5 A
Battery capacity 2 x 12 V, 45 Ah
Connectable detector series Cerberus PRO FD720 (C-NET)
Number of lines 4 (8) loops or 8 (16) stub lines
Number of addresses Max. 1512
Relay output
–RT alarm
–RT fault
1
1
Monitored outputs
–Alarm
–Fault
–Horn
1
1
2
Free programmable inputs/outputs 12
Operating temperature -8…+42 °C
Storage temperature -20…+60 °C
Humidity (no condensation permitted) ≤95 % rel.
Dimensions (W x H x D)
–Without cover cap
–With cover cap
430 x 796 x 260 mm
430 x 796 x 288 mm
Color
–Housing grey, ~RAL 7035
–Cover grey, ~RAL-Design 050 00 00
Protection category IP30
Approvals VdS / LPCB G201084 / 126bn/08

Networkable fire control panels
16
Building Technologies A6V10227652_i_en_--
Fire Safety 2016-05-30
3.5 Expansion for fire control panels FC722, FC723, FC724 and
FC726
3.5.1 License keys
FCA2033-A1 License key (S1) Part no. S54400-P154-A1
FCA2034-A1 License key (S2) Part no. S54400-P155-A1
FCA2035-A1 License key (S3) Part no. S54400-P156-A1
Application
S1 iButton
S2 iButton
S3 iButton
–New series of license keys to support the growing number of applications
–Replaces license keys L1 and L2.
–Backward compatible
–Type of installed license key is displayed in the Cerberus Engineering Tool
3.5.2 Event printer
FTO2001-A1 Event printer Part no. A5Q00010126
Including cable for interface,
power supply and paper roll
Application
The event printer can be used in all control panels, terminals or in all empty housings if space is
available.
Function
The event printer is a thermal printer that logs alarms, faults and all messages.
–The RS232 module FCA2001-A1 is required to operate the printer.
–The RS232 module must be ordered separately.
Technical data
Operating voltage DC 9…48 V
Operating current quiescent
at DC 9 V
at DC 48 V
50 mA
3 A
0.7 A
Interface RS232 serial
Operating temperature 0…+50 °C
Storage temperature -20… +70 °C
Humidity (no condensation permitted) ≤95 % rel.
Dimensions (W x H x D) 85 x 85 x 55 mm
3.5.3 Mounting plate
FHA2007-A1 Mounting plate Part no. A5Q00010151
Features
The mounting plate can pivot allowing access to the underlying module. E.g. to mount the fire brigade
periphery module or the sounder modules.
–Screwed on to the back wall of the housings.
Technical data
Dimensions (W x H x D) 221 x 241 x 46 mm

Networkable fire control panels
17
Building Technologies A6V10227652_i_en_--
Fire Safety 2016-05-30
3.5.4 Fire brigade periphery module
FCI2001-D1 Fire brigade periphery module Part no. A5Q00013100
Application
For VdS compliant switching to fire department periphery devices (for Germany).
Features
The module has connections for FBF, FSD, ÜE, FSE, ÖA, KL, tamper alarm FSD.
–Mounted in the housing on the mounting plate FHA2007-A1, or on the back wall of the housing.
Technical data
Operating voltage 21…28.6 VDC
Operating current max. 1.6 A
Connection terminals VdS peripheral devices 0.2…1.5 mm
2
Connection terminals for power supply 0.5…2.5 mm
2
Dimensions (W x H x D) 150 x 190 x 40 mm
3.5.5 Sounder module
FCA2005-A1 Sounder module Part no. A5Q00014866
2 mounting feeds
Application
With the sounder module it's possible to split up a collective horn line on 4 lines. Each of this line
controls and monitored each individual sounder. 2 sounder modules can be used, but condition is a
cascading of both.
–The sounder module can be mounted onto the mounting plate FHA2007-A1 or onto the U-rail TS35 in
control panel with the enclosed mounting feeds.
Technical data
Operating voltage 21…28.6 VDC
Operating current Max. 2 A (fused with 2 AT)
Quiescent current 20 mA
Supervised output 4 x 1 A
Cable capacity 0,08…1,5 mm
2
Humidity ≤95 % rel. rel.
Color housing / cover pure white, RAL 9010 / transparent matt
Dimensions (W x H x D) 132 x 90 x 24 mm
3.5.6 Network module (SAFEDLINK)
FN2001-A1 Network module (SAFEDLINK) Part no. A5Q00012851
Application
To network multiple stations C-WEB/SAFEDLINK.
–Plugged into the back side of the operating unit.
Technical data
Connection terminals 0,2…2.5 mm
2
Dimensions (W x H x D) 50 x 20 x 70 mm

Networkable fire control panels
18
Building Technologies A6V10227652_i_en_--
Fire Safety 2016-05-30
3.5.7 Repeater (SAFEDLINK)
FN2002-A1 Repeater (SAFEDLINK) Part no. S24236-B2502-A1
2 mounting feeds
Application
The module is a repeater in the C-WEB. It is used for the extension of the range of the system bus
C-WEB. Between 2 stations max. 1 repeater can be used. The distance between network module and
repeater may be max. 1000 m.
–The repeater can be mount directly on a plane surface, onto a U-rail TS35 with the enclosed mounting
feeds or in a housing FDCH221.
Technical data
Communication protocol SAFEDLINK (UDP/IP)
Operating voltage 9…30 VDC
Operating current Max. 45 mA
Connection terminals 0.08…1.5 mm
2
Humidity ≤95 % rel. rel.
Color housing / cover pure white, RAL 9010 / transparent matt
Protection category EN60529/IEC529 IP30
–with aux. housing FDCH221 IP65
Dimensions (W x H x D) 130 x 90 x 20 mm
3.5.7.1 Accessories for repeater
–U-rail TS35, L=122 mm Part no. BPZ:5644780001
–U-rail TS35, L=288 mm Part no. BPZ:5644230001
Application
Universal mounting rail enables mounting of various equipments.
FDCH221 Housing for input/output modules Part no. S54312-F3-A1
Application
For the mounting of the input/output modules, repeater etc. for wet applications.
Technical data
Protection category EN60529/IEC529 IP65
Color housing / cover white, ~RAL 9010 / transparent matt
Dimensions 207 x 119 x 48 mm

Networkable fire control panels
19
Building Technologies A6V10227652_i_en_--
Fire Safety 2016-05-30
–Metal screwed cable gland M20 x 1.5 Part no. A5Q00004478
–Back nut Part no. A5Q00004479
Application
For surface-mounted feed lines.
Technical data
Cable gland
Dimensions M20 x 1.5
Back nut
Dimensions M20
3.5.8 FCA2007-A1
FCA2007-A1 Card cage (2 slots) Part no. S54400-B38-A1
Application
Enables use of max. 2 module bus cards in any combination (FC723)
Technical data
Connection terminals 0.2…1.5 mm
2
3.5.9 FCA2008-A1
FCA2008-A1 Card cage (5 slots) Part no. S54400-B28-A1
Application
Enables use of max. 5 module bus cards in any combination (FC726)
Technical data
Connection terminals 0.2…1.5 mm
2
Dimensions (W x H x D)
3.5.10 RS485 module
FCA2002-A1 RS485 module (isolated) Part no. A5Q00009923
Application
For periphery devices with RS485 interface, e.g. for FAT (GER).
–Plugged into the back side of the operating unit.
Technical data
Connection terminals 0.2…1.5 mm
2
Dimensions (W x H x D) 50 x 15 x 70 mm

Networkable fire control panels
20
Building Technologies A6V10227652_i_en_--
Fire Safety 2016-05-30
3.5.11 RS232 module
FCA2001-A1 RS232 module (isolated) Part no. A5Q00005327
Application
For periphery devices with RS232 interface, e.g. for event printer FTO2001-A1 or for external matrix
printer DL3750+.
–Plugged into the back side of the operating unit.
Technical data
Connection terminals 0.2…1.5 mm
2
Dimensions (W x H x D) 50 x 15 x 70 mm
3.5.12 Loop extension (C-NET)
FCI2003-A1 Loop extension (C-NET) Part no. A5Q00010136
Application
With the loop extension, the number of connectable loops is doubled from 2 to 4. The number of C-NET
addresses per station remains unchanged.
For each integrated line one loop extension can be equipped.
–Plugged onto the periphery board of the control panel.
Technical data
Number of detector lines 2 loops or 4 stub lines
Connection terminals 0.2…1.5 mm
2
Dimensions (W x H x D) 48 x 20 x 70 mm
3.5.13 Line card (C-NET)
FCL2001-A1 Line card (C-NET) Part no. A5Q00009875
Application
The C-NET line card is an additional card to the integrated C-NET lines.
It is used to expand FC726 with additional C-NET lines. Additionally, it can be applied when modernizing
legacy detector lines to Cerberus. In this case, the legacy line card can simply be replaced by the
C-NET line card.
All C-NET devices can be connected to the line card.
–Is mounted in card cage (5 slots) of FC726 fire control panel.
Technical data
Input current max. 0.8 A
Number of detector lines 4 loops or 8 stub lines
Number of addresses max. 252
