Titan TTS-S08 Series User manual

1
Welcome
Thank you for choosing our video endoscope TTS-S08. The camera helps you to inspect inaccessible locations.
This practical tool allows you to take high resolution photos or videos..
Camera cable and camera head are water- and dustproof according to I 58/I 67.
Please read these operating instructions carefully before using the device.
Intended use
•
The device must not be used for medical or veterinary purposes.
•
Any changes or modifications not expressly approved by TITAN could void the user’s authority to operate this
device.
•
Should the device be tampered in any matter, the warranty is cancelled and TITAN is e empt from
liability. If the warranty is still valid in case of defects or problems please send the entire device
together with all accessories wherever you purchased it or directly to TITAN. Please add a detailed
fault description.

2
Instructions for safe use
•
Before using the camera cable or switching on the LED illumination at the camera head, please always remove
the small black protective cap at the camera head. Otherwise protective cap and camera head could be
damaged by overheating.
•
Do not use the device in areas with danger of explosion.
•
lease do not rotate the main unit while holding the camera cable or do not hardly pull the camera cable as
these could damage the cable.
•
rotect the camera cable and also the movable front part of the cable against harmful external influences.
Avoid strong drawing and bending.
•
The camera cable should not come into contact with corrosive liquids. Avoid the contact with other liquids than
water, salt water, machine oil or diesel oil, to prevent damage to the cable.
•
Avoid liquid ingress to the main unit /monitor. It could cause electric shock because the main unit is not
waterproof.
•
Do not operate or store the unit at temperatures over 60° C or under -20° C.
•
During operation the camera cable should always be flat and unrolled.
•
Do not swivel the camera head during pulling out the cable anywhere.
•
Under no circumstances may you bend the swiveling part at the front of the camera cable left/right or up/down!

3
Contents
Welcome – Intended use 1
Instructions for safe use 2
Contents 3
Scope of delivery 4
Installation 5
Use of the extension cable – Charging the built-in battery 6
Inserting the SD memory card 7
arts and their functions 8
Basic operation - Connection sockets 9
Connection sockets – Use as external drive – Operating modes 10
Control buttons and their functions 11
Camera settings in preview mode (effect) 12
Camera settings in preview mode (date stamp) - System settings in menu mode (date and time
settings)
13
System settings in menu mode (language setting – setting TV output) 14
System settings in menu mode (setting TV output, energy control settings, formatting setting) 15
System settings in menu mode (reset of all settings) – System settings in viewing mode (protect files) 16
System settings in viewing mode (protect files, delete files)
-
Commissioning of the inspection camera
and operation with the camera cable 17
Length of the movable end of camera cable according to model - Moving the camera cable 18
Implementation of the different functions (short explanation) – Cleaning of the camera cable 19
Cleaning of camera head and main unit – Storage – Trouble shooting 20
Specifications (camera, camera cable,) – Working environment 21
Specifications (display & system) - Imprint 22

4
Scope of delivery
The following intems are included within the package. Please Die folgenden Gegenstände sind im Lieferumfang
enthalten. Please check for completeness:
A. transport case
B. main unit/monitor
C. camera cable /control unit
D. extension cable (except for models TTS-S08-8.5 W 2W + TTS-8-8.5 W 4W)
E. adapter for video cable
F. AC plug cord
G. SD card (8 GB)
. cleaning set
I. USB card reader

5
Before using the camera cable for inspection or switching on the LED illumination, please always remove the protective
cap at the camera head to avoid overheating damages.
Installation
Step 1
Connect the camera cable with the main unit. lug in the connectors of main unit and control unit (camera cable)
carefully. Please do not apply strong pressure, but you only have to pay attention to the notches inside the
connectors. Align the two connectors so that the notches fit perfectly into each other. Make sure that the plastic
tab at 12 o’clock position inside the connector of the main unit is plugged in the matching notch (9 o’clock position) inside
the connector of the camera cable (see photos below). Do not apply violence or e cessive force, but first insert the
two parts loosely into each other .
main unit
camera cable
Step 2
After you connected main unit and camera cables screw
the locknut directly under the connector of the main unit
and tighten it firmly by rotating it right and upwards (see
figure at right).
Step 3
Check if both parts are firmly connected and if the main unit no longer wobbles. Otherwise it will drop down if you use the
device. It is normal that the main unit can be rotated 160° to the left and right. But it must not wobble.

6
Use of the e tension cable between main unit and control unit
You can extend the distance between main unit/monitor and control unit/camera cable by using the supplied black
extension cable.
First connect the extension cable to the main unit. lug in the connectors of the main unit and of the extension cable
carefully and first insert the two parts loosely into each other. Then tighten the silver locking nut at the extension cable by
turning it upwards to the right. After that take the other end of the extension cable and connect it to the control unit
(camera cable) by firmly tightening it upwards. Please do not force the extension cable into the connectors, but you
should only take care of the notches inside of both connectors. Make sure that the plastic tab at 12 o’clock position
inside the connector of the main unit is plugged in the matching notch (9 o’clock position) inside the connector of
extension cable and vice versa in case of the camera cable (see photos page 5 Step 1). Do not apply violence or
e cessive force, but first insert the two parts loosely into each other and tighten it only afterwards
Charging the built-in battery
1.
Before using the device for the first time, please fully recharge it (approx.7 hours). A new battery can not reach
its optimum performance until some cycles of full charge and discharge
2.
Before using the device, please always take a look at the battery level indicator (02).
3.
If the main unit does not start after being switched on the battery will be empty. lease charge the battery by
using the AC plug cord provided or connect the device to a C.
4.
After the main unit is fully charged (battery level indicator shows ‘full’) please remove the AC plug cord. Now
you can use the device with the fully charged battery up to 8 hours (depending on type of application).
5.
The power cord is solely intended for this device and should not be used otherwise.
6.
Do not use the power cord in damp environment.
7.
If the appliance is not used for longer periods, we recommend to charge the battery every 2-3 month. After
charging always turn off the main unit.

7
Inserting the SD memory card
The monitor shows if an SD card is inserted or not inserted.
SD card is NOT inserted.
SD card IS inserserted.
You have to insert a SD card, to use the photo or video function. A 8 GB card is included in the delivery scope.
lease insert this card with the contacts facing upwards and in direction of the monitor (see image below).
As soon as the SD card is inserted it is shown on the display (see image above). To transfer the photos and videos from
SD card to your computer, you can use the included USB card reader. Insert the SD card carefully into the slot of the
card reader and then the USB connector into an USB port of your computer.

8
Parts and their functions
01
main unit
06
OK
button
11
brightness
02
battery level indicator
07
play button
12
camera cable
connector
03
MENU button
08
video recordi
ng
reco
Aufnahme
13
locking nut
04
up arrow key
09
photos
14
cable control
05
down arrow key
10
on/off button
15
control unit

9
Basic operation
Button
F
unction
Handling
W
hat happens
?
on/off ress button briefly (for 1-2 sec.) to turn
on the unit.
The device can be used now.
on/off To turn off the unit press briefly (about 2
sec.).
The device is now switched off.
LED
illumination
on/off + dim
lighting
After turning on the unit, press
the ’brightness’ button once to switch on
the full lighting.
lease always remove the protective cap
at the camera head before you use the
camera cable or switch on the LED
lighting.
The full LED lighting is on.
LED-
illumination
on/off + dim
lighting
After you have switched on the LED
illumination press the button ‘brightness’
again (2-4 times) to dim the lighting.
ress it 5 times to switch of the lighting.
The LED lighting will be dimmed or turned
off.
Connections sockets
Anschluss Bezeichnung Bedienung Was geschieht?
5V DC
To connect AC plug cord
The main united will be
charged
TV Out
Use the applied video cable or the adapter
for video cable to connect the main unit to
a TV or external monitor.
Now you can view your
photos or videos also on
an external monitor.
Reset
Reset
–
Insert a pointed object
(e
.g. an
unbent paper clip but no objects with sharp
tips as needles) into the small ‘Reset’ hole
between the both connection sockets.
The complete system will
be reset and restarted-

1
Micro USB port 2.0
lug in your Micro USB cable into the
connection port.
The main unit can be
connected to other
devices like C or
notebook.
SD card slot
Insert a SD card up to 32 GB (8 GB incl.)
as external storage.
Photos or videos are
only possible with
inserted SD card!
Use as e ternal drive
If you use the USB cable to connect the main unit to a
computer and switch it on, you will see the image at the
right: Left behind the MENU button a red LED lights up.
Now the main unit is recognized by the computer as
external drive. Open the removable disk on your
computer and you will find all your photos and videos in
the directory ‘“DCIM“ and in the folder “100MEDIA“.
Operating modes
The following 3 basic operating modes are available:
Preview mode shows the current view, which can be stored as photo or video or only be viewed
Viewing mode hotos or videos stored on SD card can be viewed.
MENU mode Here is where all settings take place. Also photo or video files can be saved or
deleted.

11
Control buttons and their functions
All control buttons of the main unit have, depending on operating mode, always different functions (see table
below):
Button Preview mode View mode MENU mode
Zoom x2, x4, x8, change screen
format
return to the previous photo
select previous function or
option
mirror image
rotate screen by 180 degrees
move to next photo or video move to the following
option
image freeze display or pause confirm selection
either ‘Camera’ (camera settings),
‘Effect’ or ‘Date Stamp’ for
photos/videos or back to preview
mode
either ‘Lock or Delete’ of
the currently displayed
photo or video or back to
the viewing mode
back to the previous option
or back to preview mode
take a photo or snapshot
start or end video recording
change to the viewing mode back to the preview mode camera settings (‘Camera’,
‘Effect’, ‘Date Stamp’) or
system settings

12
Camera settings in preview mode
Push the ‘MENU’ button in preview mode to display the following options for camera setting:
lease always confirm your selection by pressing the‘OK’ button .
After that you will automatically return to the previous selection
menu. If you press the MENU button again, you will leave the
setting menu and return to the preview mode.
Attention: For the models TTS-S08-2.0 2W + TTS-S08-2.08 4W
and TTS-S08-2.8 2W + TTS-S08-2.8 4W the first selection
‘Camera’ does not apply.
Use the arrow keys or to select the following options:
‘Camera’ gives the opportunity to do the camera settings according to your
existing camera cable.
Attention: For the models TTS-S08-2.0 2W + TTS-S08-2.08 4W
and TTS-S08-2.8 2W + TTS-S08-2.8 4W the first selection
‘Camera’ does not apply.
Choose according to the diameter of your camera head:
•VGA 5,5 – if camera head = 5,5 mm
•VGA 4.0 & 5.5N mm – if camera head = 4.0 or 5.3 mm
•HD - for 1 Mio pixel version
‚Effect’ gives you the opportunity to choose ‘Normal’ or ‘B&W’ (black & white).
If you selected ‘Effect’ you will have 2 choices:
•
Normal means coloured view.
•
B&W means black & white view.

13
‚Date Stamp‘ allows you to take pictures or videos with or without date and time
stamp. If you selected ‘Date Stamp‘ there are 3 opportunities:
•
Off – hotos and videos are taken without date stamp.
•
Date – You can see the respective date on your photos or videos.
•
Date & Time – Date and time will appear on your photo and video
•
recordings.
System settings in Menu mode
ress the MENU button to return to the previous selection window.
After that press the right key arrow to make further settings (see
photo).
Please always confirm your selection by pressing the OK button . After selecting and confirming you will
return back to the main menu. If you press the MENU button again, you will leave the setup menu (menu
mode) and return to preview mode.
ress the OK button to select ‚Date&Time‘.
Date and time settings
ress the OK button again for the ‘Date & Time’ settings. After that do the
further settings as described in the following section.

14
MM =
month
/ DD =
day
/ YYYY =
year
/
hours minutes
Use the arrow keys or to increase or reduce the displayed
values. Use the right arrow key to change between month, day, year
and time. After you made these settings, please return to back main menu by
pressing the MENU button.
Language setting
Use the down arrow to skip to ‚Language‘ and confirm with OK .
Now you can choose between 7 languages.
As soon as you selected a language the screen will automatically return to the
main menu.
Setting TV output
You have the possibility to view the live images, which are normally displayed on the monitor of the main unit , as well as
stored photos or videos also on an external monitor or projector. BEFORE YOU CONNECT THE VIDEO CABLE
LEASE DO ALL THE SETTINGS FOR THE TV OUT UT ! Because if you first connect the video cable you will see
nothing on the display of your main unit and cannot do the necessary settings for the device.
Select ‘MENU‘ in preview mode and use the down arrow to go to
`TV Out’ and confirm with OK .

15
Under
`
TV
OUT
`
you can choose between
two output formats:
•
NTSC (for America or East Asia)
•
PAL (for Europe)
After that connect the adapter for video cable or the video cable itself to the ‘TV OUT’ port. The monitor of the main unit
will show no more picture but the live images will be displayed directly on your external screen.
Energy control settings
Use the down arrow to move to ‘Power Save’ and confirm with OK
.
If you selected ‘Power Save’ 4 time intervals for the automatic shutdown will
appear:
•
3min. – automatic switch-off after 3 minutes
•
5min – automatic switch-off after 5 minutes
•
10min. – automatic switch-off after 10 minutes
•
OFF – The system does NOT switch off automatically.
Formatting setting
Use the down arrow key to skip to ‘Format’ and confirm with OK .
The function ‘Format’ enables you to delete all data of the SD card (such as
photos, videos, folders). Please note that formatting the SD memory card will
erase all stored data forever.
•
No – Nothings happens and all data will remain.
•
Yes – all stored data on SD memory card will be deleted.

16
Reset of all settings
Choose ‘Reset All‘ with the down arrow and cornfirm with the OK button
.
The function ‘Reset All‘ enables you to reset all previous settings to factory
setting.
•
No – nothing happens and all your previous settings will remain.
•
Yes – all your previous settings will be deleted and the system will be reset
to factory setting.
System settings in viewing mode – protect files
Press the ‘MENU‘ button in viewing mode to protect or delete photos or videos. You can either
delete all photos or videos or individual files.
When you switch on the main unit you will be in preview mode. ress the button right arrow to change
to viewing mode. In viewing mode you can view or manage all existing photo or video files.
Use the up/down arrows or to select a photo or video. Then use the ‘MENU‘ button again to
select the following options.
Here you can first select, if you want to lock or delete your data.
If you select ‘LOCK‘ a further selection menu appears.

17
( hoto has to be changed after correction of software)
•
Lock one – Only one photo or video will be protected.
•
Lock All – All photos or videos will be protected.
•
Unlock All – All photos and videos will NOT be protected..
If you select ‘DELETE ‘ the following menu will appear.
•
One – Only one photo or video will be deleted.
•
All – All photos or videos will be deleted.
Commissioning of the inspection camera and operation with the camera cable
Press the on/off button for 1-2 seconds, to switch on the main unit. Insert the camera cable as straight as
possible into the area which you want to inspect. You should remember that the larger the bending of the
camera cable, the smaller the possible bending angle of the camera head. That means that moving the camera
head right or left is easier with a straight camera cable. The movable end of the camera cable has different
lengths depending on the models (see table page 18). Therefore the diameter of the opening has to be not less
than 1 cm greater as the length of the movable end of the camera head). Otherwise you cannnot properly move
the camera head or it will be too close to the object to be viewed. After inserting the camera cable you should
switch on the illumination .
When pulling out the camera cable please hold the movable end with the camera head as straight as possible.
right
wrong

18
Length of the movable end of camera cable according tomodel:
TTS-S08-2.0 = 1,6 cm
TTS-S08-2.8 = 2,4 cm
TTS-S08-4.0 = 3,5 cm
TTS-S008-4.0M = 3,0 cm
TTS-S08-4.0IR = 3,5 cm
TTS-S08-5.5 = 4,0 cm
TTS-S08-6.0(D) = 5,2 cm
TTS-S08-6.0IR = 4,0 cm
TTS-S08-6.0UV = 4,0 cm
TTS-S08-6.0W = 4 ,0 cm
TTS-S08-8.5HW = 7,0 cm
TTS-S08-18.5TM = 9,0 cm
In order to turn the camera head properly right and left, the opening to be inspected should be at least 1 cm
bigger in diameter than the length of the moveable camera cable.
E ample photo for model TTS-S08-8.5HW
This photo shows the movable end of the camera cable.
Moving the camera cable
With the control levers at the control unit (according to model either one control lever and two directions or two control
levers and 4 directions) you can move the camera cable. Insert the camera cable as straight as possible into the opening
to be inspected. If you push the lever upwards or downwards the camera head will move right/left or up/down.

19
Implementation of the different fuctions (short e planation)
Intension What to do? Buttons Symbols on the
display
Remarks
take pictures
press camera
release
After taking pictures the system automatically
switches back to preview mode.
video recording
press button
‘video
recording’
In the upper left corner of the screen
Further a flickering red point appears in the lower left
of the screen.
stop video
recording
ress button
‘video
recording’
again.
The video icon at the top left and the red point in the
lower left will disappear.
change screen
format
ress the up
arrow key in
preview
mode.
bottom right:
Display will change from full screen to 4:3 format and
the symbol left beside appears at the bottom right.
zooming ress the up
arrow key in
preview
mode.
The current camera image will be enlarged 2x, 4x or
8x. .
Mirror image –
180° display
rotation
ress down
arrow key in
preview
mode.
The current picture display can be mirrored or
rotated through 180°.
.
Cleaning
•
Cleaning of the camera cable
Always clean the camera cable immediately after use. Remaining dirt can lead to corrosion. Therefore wet a cloth
with a neutral detergent and wipe off the dirt thoroughly.
Then use a cloth dampened with clear water
to wipe again.
Finally dry the camera cable with a dry cloth.

2
•
Cleaning of the camera head
Hold the rigid end above the swiveling part of the camera cable (please do NOT hold at the swiveling part !) and
wipe off the dirt or moisture at the camera lens with a soft, damp cloth or with a damp cotton bud. The best cleaning
result you will achieve with commercial pure ethanol.
•
Cleaning of the main unit
Clean the main unit with a soft, slightly moistened cloth and then finish with a dry cloth.
Storage
Store the device only in the provided transport case and at a dry well ventilated place at normal room temperature and
normal humidity. The storage temperature should not exceed 60° C and not be below -20° C. Bring the camera head in
a straight position before storage.
Troubleshooting
problem possible solution
no image on screen after switching on the main unit Battery is weak or empty. Use the supplied power
supply cable and charge the battery.
no image but only letterings on screen after switching
on the device
Make sure that the control unit (camera cable) is
correctly connected to the main unit (see Installation
page 5)
photos or videos are not possible Check if the memory card is inserted correctly and
ensure that sufficient space is left on the memory card.
the whole device or some functions fail Insert a straightened paper clip or any similar (but no
sharp objects like needles) into the small hole
‘Reset‘ between the connection sockets at the right
side of the main to reset and restart the system.
This manual suits for next models
10
Table of contents
Other Titan Diagnostic Equipment manuals
